Summary of Contents for ANTAIRA LNX-500A-T

  • Page 1: User Manual

    Antaira Industrial Ethernet Switches LNX-0501G-SFP Series User Manual V1.0 LNX-500A 5-Port Industrial Unmanaged Ethernet Switches w/5*10/100Tx User Manual Version 2.0...
  • Page 2: Trademark Information

    Trademark Information Antaira is a registered trademark of Antaira Technologies, LLC, Microsoft Windows and the Windows logo are the trademarks of Microsoft Corp. NetWare is the registered trademark of Novell Inc. WMM and WPA are the registered trademarks of Wi-Fi Alliance.
  • Page 3: Fcc Warning

    Industrial Grade Gigabit Unmanaged Ethernet Switches User Manual Version 2.0 (Aug 2014) This manual supports the following models:  LNX-500A  LNX-500A-T This document is the current official release manual. Please check our website (www.antaira.com) for any updated manual or contact us by e-mail (support@antaira.com).
  • Page 4: Table Of Contents

    Antaira Industrial Ethernet Switches LNX-500A Series User Manual V2.0 Table of Contents 1. Overview………………… ..........1 1.1 Key Features…..........1 1.2 Package Contents ..........2 1.3 Safety Precaution……… ........2 2. Hardware Description ..........3 2.1 Physical Dimensions ........3 2.2 Front Panel…….
  • Page 5: Overview

    LNX-0501G-SFP Series User Manual V1.0 Overview Antaira’s LNX-500Aindustrial unmanaged Ethernet switch series are IP30 rated and DIN-Rail mountable. Each unit is designed with five 10/100Tx Fast Ethernet ports, which the RJ-45 interface provides auto detection of MDI or MDI-X, and each port builds with data memory buffers that support the store-and-forward mechanism.
  • Page 6: Package Contents

    Antaira Industrial Ethernet Switches LNX-500A Series User Manual V2.0 1.2 Package Contents  LNX-500A(T): 5-port industrial unmanaged Ethernet switch, w/5*10/100Tx  User manual  1-Product CD  2-Wall mounting brackets and screws  1-DC cable –18 AWG &DC jack 5.5x2.1mm 1.3 Safety Precaution...
  • Page 7: Hardware Description

    LNX-500A Series User Manual V2.0 2. Hardware Description 2.1 Physical Dimensions Figure 2.1, below, shows the physical dimensions of Antaira’s LNX-500A series: 5-port industrial unmanaged Ethernet switch with 5*10/100Tx. (W x D x H) is 30mm x 99mm x 142mm Figure2.1...
  • Page 8: Front Panel

    Antaira Industrial Ethernet Switches LNX-500A Series User Manual V2.0 2.2 Front Panel The front panel of the LNX-500A series industrial unmanaged Ethernet s witch is shown below in Figure 2.2. Figure2.2 The Front Panel of LNX-500A Series 2.3 Top View Figure 2.3, below, shows the top panel of theLNX-500A series switch that is equipped with...
  • Page 9: Led Indicators

    Antaira Industrial Ethernet Switches LNX-500A Series User Manual V2.0 2.4 LED Indicators There are LED light indicators located on the front panel of the industrial Ethernet switch that display the power status and network status. Each LED indicator has a different color and has its own specific meaning, see below in Table 2.1.
  • Page 10 Antaira Industrial Ethernet Switches LNX-500A Series User Manual V2.0  RJ-45 Pin Assignments(Table 2.2) Pin Number Assignment Table 2.2 RJ45 Pin Assignments “+” and “-” signs represent the polarity of the wires that make up each wire pair. Note All ports on this industrial Ethernet switch support automatic MDI/MDI-X operation. Users can use straight-through cables (see figure below) for all network connections to PCs, servers, other switches or hubs.
  • Page 11: Cabling

    Antaira Industrial Ethernet Switches LNX-500A Series User Manual V2.0 2.6 Cabling Use the four twisted-pair Category 5e or above cabling for RJ-45 port connection. The cable between the switch and the link partner (switch, hub, workstation, etc.) must be less than100meters (328ft.) long.
  • Page 12: Wiring The Fault Alarm Contact

    Antaira Industrial Ethernet Switches LNX-500A Series User Manual V2.0 2.8 Wiring the Fault Alarm Contact The fault alarm contact is in the middle of the terminal block connector as the picture shows below in Figure 2.8. By inserting the wires, it will detect the fault status including power failure or port link failure (managed industrial switch only) and forma normally open circuit.
  • Page 13: Mounting Installation

    Antaira Industrial Ethernet Switches LNX-500A Series User Manual V2.0 3. Mounting Installation 3.1 DIN-Rail Mounting The DIN-Rail is pre-installed on the industrial Ethernet switch from the factory. If the DIN-Rail is not on the industrial Ethernet switch, please see Figure 3.1 to learn how to install the DIN-Rail on the switch.
  • Page 14 Antaira Industrial Ethernet Switches LNX-500A Series User Manual V2.0 Follow the steps below to learn how to hang the industrial Ethernet switch. 1. Use the screws to install the DIN-Rail bracket on the rear side of the industrial Ethernet switch.
  • Page 15: Wall Mounting

    Antaira Industrial Ethernet Switches LNX-500A Series User Manual V2.0 3.2 Wall Mounting Follow the steps below to mount the industrial Ethernet switch using the wall mounting bracket as shown below in Figure 3.4. 1. Remove the DIN-Rail bracket from the industrial Ethernet switch by loosening the screws.
  • Page 16: Hardware Installation

    LNX-500A Series User Manual V2.0 4. Hardware Installation 4.1 Installation Steps This section will explain how to install Antaira’sLNX-500A series: 5-port industrial unmanaged Ethernet switch with 5*10/100Tx. Installation Steps 1. Unpack the industrial Ethernet switch from the original packing box.
  • Page 17: Network Application

    Antaira Industrial Ethernet Switches LNX-500A Series User Manual V2.0 5. Network Application This segment provides an example of an industrial Ethernet switch application (Figure 5.1). Figure5.1 Industrial Ethernet Switch Application Reference...
  • Page 18: Trouble Shooting

    Check for loose power connections, power losses or surges at the power outlet. Please contact Antaira for technical support service, if the problem still cannot be resolved.  If the industrial switch LED indicators are normal and the connected cables are correct but the packets still cannot transmit, please check the system’s Ethernet devices’...
  • Page 19: Technical Specification

    Antaira Industrial Ethernet Switches LNX-500A Series User Manual V2.0 7. Technical Specification Table 7.1has the technical specifications for Antaira’s LNX-500A series: 5-port industrial unmanaged Ethernet switch with 5*10/100Tx. IEEE 802.3 10BaseT Ethernet Standard IEEE 802.3u 100BaseTX Fast Ethernet Protocol CSMA/CD...
  • Page 20 Antaira Industrial Ethernet Switches LNX-500A Series User Manual V2.0 Safety UL EN-60950 Table 7.1 LNX-500A Series Technical Specification Any changes to this material will be announced on the Antaira website...
