Four-Faith F2164 User Manual

F2x64 series
Hide thumbs Also See for F2164:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
F2X64 Series User
Manual
F2X64 Series User Manual
The user manual is suitable for the following model:
Document Version
V2.0.0
Product Name：F2X64
Model
Product Type
F2164
GPRS RTU
F2264
CDMA RTU
F2464
WCDMA RTU
F2664
EVDO RTU
F2764
TDD-LTE RTU
F2864
FDD-LTE RTU
F2A64
LTE RTU
Four-Faith Smart Power Technology Co., Ltd.
Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen
Tel：+86-17750019379 Email:Allen@four-faith.com
Web:http://www.four-faith.hk
Page
Total:99

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F2164 and is the answer not in the manual?

Questions and answers

Related Manuals for Four-Faith F2164

Summary of Contents for Four-Faith F2164

  • Page 1 F2164 GPRS RTU F2264 CDMA RTU F2464 WCDMA RTU F2664 EVDO RTU F2764 TDD-LTE RTU F2864 FDD-LTE RTU F2A64 LTE RTU Four-Faith Smart Power Technology Co., Ltd. Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen Tel：+86-17750019379 Email:Allen@four-faith.com Web:http://www.four-faith.hk...
  • Page 2 2. Add the sms command to control output 2015-5-28 V1.4 1. Add ADC sample type description 2017-10-10 V2.0.0 1.Change of company address 2 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 3 Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
  • Page 4 F2X64 User Manual Note: There may be different components and interfaces in different model,please in kind prevail. 4 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 5: Table Of Contents

    4.1.4 Configuration......................33 4.1.4.1 Digital channel settings.................33 ◆ Digital input function..................33 ◆ MODBUS logic corresponding function............34 ◆ Acquisition purpose..................34 5 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 6 ◆ ModBus work mode..................50 ◆ ModBus address..................50 ◆ RTU work mode..................51 4.1.4.6 Data Service Center Settings................ 52 ◆ Data Center Number................... 52 6 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 7 ◆ Data upload Style..................78 4.1.4.11 Functions..................... 79 ◆ Show Configure..................79 ◆ Show Baudrate.................... 79 ◆ Auto Detect....................79 7 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 8 5.2.8 Center service information..................96 5.2.9 Query data........................ 96 5.2.10 Remote configure....................97 5.2.11 Upgrade........................98 5.2.12 Reset device......................99 Appendix............................100 8 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 9: Chapter 1 Brief Introduction Of Product

     SIM/UIM port: 15KV ESD protection  Power port: reverse-voltage and overvoltage protection  Antenna port: lightning protection(optional) Standard and Convenient 9 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 10  Support RTU extended protocol. It has counter function that the initial value of the timer is set and the value of the timer is queried 10 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 11: Working Principle

    The principle chart of the RTU is as following: 8 ch analog 8ch digital 4ch relay out input input 4ch isolated out 11 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 12: Specifications

    Module SIM/UIM Interface Power Module User Interface 1.4 Specifications Cellular Specification ITEM CONTENT F2164 GPRS RTU Standard and Band EGSM 900/GSM 1800MHz, GSM 850/900/1800/1900MHz(optional) Compliant to GSM phase 2/2+ GPRS class 10, class 12(optional) Bandwidth 85.6Kbps TX power GSM850/900: <33dBm GSM1800/1900: <30dBm...
  • Page 13 TD-HSPA+: Download speed 4.2Mbps, Upload speed 2.2Mbps EVDO Rev. A: Download speed 3.1Mbps, Upload speed 1.8Mbps TX power <23dBm RX sensitivity <-97dBm 13 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 14 DC 12V/0.5A Power Range DC 5~35V Power Consumption Working States Power Consumption Communication 88-100mA@12VDC Standby 52mA@12VDC Timing Power 0.9mA@12VDC 14 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 15: Chapter 2 Installation Introduction

    2.2 Encasement List Name Quantity Remark RTU host Cellular Antenna Power adapter RS232 data cable optional RS485 data cable optional 15 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 16: Installation And Cable Connection

    Default function Function expansion Number None Power input positive Power None Power input negative RS232 G/232 RS232 GND None 16 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 17 None ADC 2 None ADC 3 None ADC 4 None ADC 5 None ADC 6 None ADC 7 None 17 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 18 Black Cathode RS232 Cable： Cable Color Corresponding DB9-M Pin Number Brown Pin 2 Blue Pin 3 Black Pin 5 18 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 19 Cable Color Signal definition RS485(A) Black RS485(B) Power adapter and communication cable connection chart as following: Digital Input cable connection 19 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 20 F2X64 User Manual Wet contact Dry contact cable connection Optocoupler output Relay output cable connection 20 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 21: Power

    RTU is powered off BLINK Data is communicating No data Online RTU has logged on network RTU hasn’t logged on network 21 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 22: Chapter 3 Rtu Function Introduction

    The following introduces MODBUS RTU protocol, All of the following MODBUS data are high byte first (big-endian mode). 22 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 23: Modbus Settings

    8 ports . If read one channel, this parameter should be 0001 Response 01 02 01 00 A1 88 Parse response: 23 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 24: Modbus Digital Io Output Introduction

    Parse response: The response command is the same as sending command, please refer to appendix the above control command. 24 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 25: Modbus Read Digital Io Output Introduction

    Function Data length status checksum Address code value Meaning Read coil Bytes count status checksum value, bit0~bit7 correspondi IO1-IO8 25 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 26: Modbus Counter Introduction

    Set counter initial value, command as following: 01 10 00 00 00 02 04 00 00 00 0A 73 A8 Parse command: 26 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 27: Modbus Analog Input Introduction

    8 channels (the value of each channel is a signed 32-bit data, this data is the actual value of the sensor). The MODBUS parameters of analog input please refer to appendix 4.1.4.3 Analog input function. 27 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 28 28 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 29: Rtu Extended Protocol

    All the RTU parameters can be configured through RS232/RS485 、 SMS and RTU extended protocol. Please refer to appendix chapter 4 configuration. 29 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 30: Remote Upgrade Firmware

    Before configuration, It’s necessary to connect the RTU with the configure PC by the shipped RS232 or RS232-485 cable as following. 4.1.1 Configuration introduction There are two ways to configure the RTU: 30 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 31: Run The Configure Tool

    If the button text is“Close”, it shows the serial port now has been opened. If the text is “Open”, you should open the port first. When the port opened, the “Output 31 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk...

  • Page 32: Re-Power Rtu

    RTU and displays on the right configure columns. It’s now ready to configure. 32 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 33: Configuration

    Parameter: y range 1~8, Corresponding to digital input channel 1 ~ 8. x range 0~1， 0 means disable，1 means enable. Example: AT+RTUINIOEN1=1 33 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 34: Modbus Logic Corresponding Function

    Parameter: y range 1~8, corresponding to digital input channel 1~8. x range 0-4294967295，0 means close acquisition function.. Example: AT+RTUINIOTIME1=6000 34 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 35: Alarm Trigger Condition

    7). Example: AT+RTUINIOSETLRMNO1=13912345678,13812345678 35 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 36: Optocoupler And Relay Settings

    It controls digital output ports(4 optocouplers ports and 4 relay outputs ). Its function includes MODBUS control and RTU extended protocol control. Command: AT+RTUOUTIOENy=x 36 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 37: Modbus Logic 1 Output

    This item configure square wave cycle when MODBUS logic 1 is configured as square wave output. The unit is 20ms(milliseconds). for expamle: 50 means 50 * 20ms = 1s(seconds). 37 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 38: Modbus Logic 0 Square-Wave Cycle

    Optocoupler output: x range 0-1，0 means low level，1 means high level. relays: x range 0-1，0 means disconnet，1 means connect. Example: AT+RTUOUTIODEFVAL1=1 38 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 39: Analog Channel Settings

    For example: There is a temperature sensor that the measuring range is -40.5 ~ 50.5 ℃ and output votage 1.3 ~ 4.5V. This sensor connect to RTU fisrt analog input channel. The decimal 39 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk...
  • Page 40 1~8, corresponding to input channel 1~8. x range -2147483648 to 2147483647，its value related to the decimal point. Example: AT+RTUADCZEROVAL1=100 40 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 41: Set Sensor Voltage Or Current Output

    Parameter: y range 1~8, corresponding to analogl input channel 1~8. x range 0-4294967295，it related to the sensor ouput type 41 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 42: Modbus Function

    Parameter: y range 1~8, corresponding to analog input channel 1~8. x range 0-4294967295，0 means close acquisition function. Example: AT+RTUADCTIME1=1 42 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 43: Alarm Trigger Condition

    1-8, it is analog input channel. xxx mean alarm phone number(can configure multiple phone numbers, the numbers are separated by comma,total numbers should not 43 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 44: Active Report Function

    1~8, corresponding to analog input channel 1~8. x range 0-1，0 means disable, 1 means enable. Example: AT+RTUADCREPORTEN1=0 44 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 45: Rtu Counter、Report、Alarm Settings

    ◆ Counter work mode The counter value will add 1 when the input waveform match the configured condition. if 45 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 46: Counter Initial Value

    Parameter: xxx mean counter alarm content(<=140 bytes). Example: AT+RTUCOUNTERLRMTXT=counter alarm ◆ Alarm phone number when RTU counter alarm, RTU will send sms to these numbers. 46 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 47: Alarm Upper Limit

    30 seconds, it will keep trying until server received successfully. If this parameter is zero, RTU will stop active report function. 47 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 48: Alarm Report Method

    This parament should be used together with he parament of “Continuous alarm interval”. It use to limit the continuous alarm number of times. 0 means not continuous alarm, 255 means not limit 48 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk...

  • Page 49: Alarm Administrator Number

    7). Example: AT+RTUDELADMINNO=13912345678,13812345678 4.1.4.5 ModBus Setting 49 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 50: Modbus Work Mode

    AT+MBMODE=1 ◆ ModBus address It sets MODBUS device address of this RTU, server identify devices based on this address. 50 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 51: Rtu Work Mode

    Explanation: set RTU work mode. Parameter: x range 0-1, 0 mean no wireless module, 1 mean has wireless module. Example: AT+RTUWRKMDE=1 51 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 52: Data Service Center Settings

    If the Data Center Number is 0,there is no DSC working. If the Data Center Number is 1, RTU work in Main and Backup DSC mode. 52 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 53: Main Center Addr+Port

    ◆ Backup Center Addr+Port: IP address and port of the Backup DSC AT command of the Backup DSC IP address or domain: 53 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 54: Multi Dsc Configuration

    2-5, corresponding to the center 2 to center 5. x range 10-11, 10 means MODBUS, 11 means RTU extended protocol. 54 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 55: Main And Backup Center Dns Server

    AT command of 2~5 DNS Server AT+DNSSVRn=aaa.bbb.ccc.ddd n is 1~4 correspond to center 2~5 DNS server. aaa.bbb.ccc.ddd is the DNS server IP address 55 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 56: Device Settings

    TCPCON: All data interaction based on the TCP link. UDPCON: All data interaction based on the UDP link. AT command: AT+MODE=xxxx xxxx: one of the above workmode 56 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 57: Trigger Type

    0-1, 0 means disable, 1 means enable ◆ Debug Level Debug information is used to debug software when there is software problem. 57 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 58: Databit, Parity, Stopbit

    --- 9600 bps 14400 --- 14400 bps 19200 --- 19200 bps 38400 --- 38400 bps 56000 --- 56000 bps 58 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 59: Auto Back To Main Server

    AT+IDNT=aabbccdd aabbccdd: the identity number of RTU ◆ SIM Card No The phone number of the SIM card . 59 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 60: Bytes Interval

    This item is only valid when the WorkMode is TCST. It’s the self defined heartbeat string, It can be empty, the maximum length is 70 bytes. AT Command: AT+LINKRGST=xxx xxx：self defined heartbeat string 60 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 61: Reconnect Setting

    <<RTU Transfer Meaning Explanation In the PROT work mode>>. If this item is set to 1, all the transmission is transparent. AT Command: AT+STRAIGHT=x x：0 or 1 61 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 62: Other Settings

    Normally, the device Model and the parameters can configured as the following,if this can not work please inquiry your local mobile operators for the corresponding settings. 62 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 63: Sms Center

    F2X64 User Manual Model Username Call center password F2164 Cmnet null *99***1# F2264 null card #777 F2364 cmnet null *99***1# F2464 3gnet null *99# F2564 cmnet null *98*1# F2664 null card #777 AT Command of APN: AT+APN=xxxx xxxx: access point name...

  • Page 64: Call Trigger Phone No

    It will return to the idle state when receives trigger off data. 64 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 65: Multi Center Reconnect Interval

    When “SMS configure function” is enabled, RTU parameters are set by SMS. The format of SMS refer to 4.2 Setting by SMS. 65 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 66 Explanation: this password is used, when parameters are set by sms. Parameter: xxx mean password, it is not more than 7 bytes. Example: AT+SMSCPW=1234 4.1.4.9 Scheduled Power ON/OFF Setting 66 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 67: Rtc(Real Time Clock) Time Setting

    Press “Set” you will see the follow window, you can do the setting. AT Command: AT+EXCALx=<options>[, <value1>[,<value2>[,<value3>]]] Options: D -- Disabled. Scheduled Power On/Off function is disabled (Default). 67 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 68 AT+EXCALx=D Note: There is no blank in this AT command, the same as followings. 2. On-time switch power on 68 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 69 RTU power on at 12:30:00, and power off at 13:30:00 on August 1st,2010 AT+EXCAL5=OT,"2010/08/01,12:30:00",3600 3. Power on per hour AT Command: AT+EXCALx=OH,<strTime>,<holdTime> <strTime>: Format "00:30:00" <holdTime>: Hold time value.(Unit:Second) For example: 69 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 70 <holdTime>: Hold on value(Unit:Second) For example: RTU power-On at 09:00:00 everyday, and power-off 1 hour later. AT+EXCAL3=OD,"09:00:00",3600 5.Power on per week 70 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 71 RTU power on at 09:00:00 on the 28th every month,and power off 1 hour later. AT+EXCAL3=OM,28,"09:00:00",3600 7.Power on with time interval 71 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 72 RTU power on interval every 10 minutes, and power off 120 seconds later. AT+EXCAL1=OP,10,120 8.RTU online/offline with time interval 72 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 73 Note: RTU not power off in this mode, it is standby. 9.Power off at one time AT Command: AT+EXCALx=ST,<strTime> 10.Power off per hour 73 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 74 AT Command: AT+EXCALx=SH,<strTime> 11.Power off per day AT Command: AT+EXCALx=SD,<strTime> 12.Power off at the same time in every week 74 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 75 F2X64 User Manual AT Command: AT+EXCALx=SW,<week>,<strTime> 13.Power off per month AT Command: AT+EXCALx=SM,<date>,<strTime> 14.Power off with countdown 75 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 76 For example: RTU power off 600 seconds later: AT+EXCAL1=SC,60 Note: If the <aftertime> is 0,the RTU will power off immediately. 76 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 77: Sms Setting

    When RTU “Data upload Style” selects “SMS Only” or “Main Network SMS backup”, The RTU will send report information by SMS. This parameter used for setting SMS destination number. 77 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 78: Sms Sending Format

    AT Command: AT+OPENSMSBCKP=x x range 0-2 0 means Network Only, 1 means SMS Only, 2 means Main network SMS backup 78 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 79: Functions

    ◆ Auto Detect Simple way to determine whether RTU work fine ◆ Version Display Show the software and hardware version 79 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 80: Signal Value

    Browse the file directory ◆ Save Configure Save the current settings to a file, you can restore it from this file later 80 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 81: Load Configure

    AT+ remaining command. This command is AT command of SMS. Multiple commands are separated by a semicolon. …: This symbol indicates that one sms can include multiple commands. 81 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 82: Setting Remote Upgrade

    Parameter: none. Example: <123456;STPUPGRADE> 4.2.3 Read digital IO input Command: RTUINIOTEST Explanation: read digital IO input Parameter: none. Example: <123456;RTUINIOTEST> 82 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 83: Control Digital Io Output

    Example: <123456;RTUADCVALTEST> 4.3 Setting for RTU extended protocol RTU extended protocol configuration, please refer to appendix 5.2.10 Remote configure. 83 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 84: Chapter 5 Software Manual

    Info.mdb,Please open Info.mdb by using Access ,and choose menu “Tools”->” Database practical tools”->” Compression and repair the database” of the Access to repair it. 84 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 85: Install The Driver

    ,then click OK to install the driver. Then the PC will install device driver,and show whether the driver has been installed successfully as following. 85 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 86: Add Virtual Serial Port

    5.1.3 Add virtual serial port Click button or click “window”-----“Tunnel Manager”as below： Click “Add Tunnel”,Set the params according to the serial port property. 86 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 87 When finishing setting transfer parameters ,click “Save” ,it will show whether the add tunnel operation is success. If add tunnel success,it will show transfer parameters on Tunnel Manger interface as following： 87 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 88: Setting The Server Parameters

    ,if the value big than 32,the software will show this RTU has disconnected) 88 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 89: Server Connection State

    When connection establish success ,the list will show the Phone Number,Source IP,Inbound flow and Outbound flow as above. Click to stop service. 89 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 90: Monitor

    RTU but transfer to serial port failed as following ， Also you can just open the database file “Info.mdb”(Access Database file),find table “NotTransData” to query the data. 90 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 91: Delete Database Data

    ， you can delete the data by device ID,also you can delete all of the data in database ,the dialog as below 91 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 92: Quit

    Click menu “Operation”->”Exit”,or press button ,it will show as below Press OK to quit TCP2COM. 5.2 RTU center service 5.2.1 Open software 92 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 93: Service Setting

    “Offline Time” is interval that center software scan equipment time. “Service Style” is the style of the network. Configuration parameters accord to the actual situation . Please click “OK” after configuration 93 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 94: Start Equipment And Connect

    Specific parameter modification please refer to appendix 4.1.4.7 Device ID SIM Card 5.2.4 View the acquisition data 94 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 95: Send Data To Rs232/Rs485

    According to the different device ID control different optocoupler and relay. Just click “Send Control” button o complete control. Please set parametes thart refer to 4.1.4.2 Digital output function. 95 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 96: Alarm Information

    Select the device ( click the check box in front of the device ID), Please click icon or operate as following picture. Please click it, then appear as follow picture. 96 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 97: Remote Configure

    Select the device ( click the check box in front of the device ID), Please click icon or operate as following picture. Please click it, then appear as following picture. 97 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 98: Upgrade

    Select the device ( click the check box in front of the device ID), Please click icon or operate as following picture. Please click it, then appear as follow picture. 98 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 99: Reset Device

    Select the device ( click the check box in front of the device ID), Please click icon or operate as following picture. If click this button, RTU will reboot. 99 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...

  • Page 100: Appendix

    The following steps describe how to make RTU enter configure state with the Windows XP Hyper Terminal. 1. Press “Start””Programs””Accessories””Communications””Hyper Terminal” 100 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 101 4. Configure the serial port parameters as following, choose “OK” Bits per second: 115200 Data bits: 8 Parity: None Stop bits: 1 Flow control: None 101 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 102 Re-power RTU, put mouse focus on the Hyper Terminal and press “s” key continuously until RTU enter configure state as following 102 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
  • Page 103 F2X64 User Manual 7. RTU has entered configure state, you can configure the parameters by AT command. 103 / 103 Email: allen@four-faith.com Tel: +86-17750019379 Web: www.four-faith.hk Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China...
