Triple Plus+ and Triple Plus+ IR
How to change an option
To change an option, use the first two keys, labelled with the << and >> sym-
bols, to change the current selection, and the third key (labelled QUIT) to finish
changing the selection. If the QUIT key is pressed and the parameter has been
modified then the user is prompted with a save changes message. Two keys
are soft key function labelled, one with YES and one with NO. Press the desired
button.
For example, to configure the start-up option, from the configuration Menu
follow the steps below:
DISPY ALARM ZERO PUMP
<< >>
Scroll the menu list to the left until START is selected.
ALARM ZERO PUMP START
<< >>
Press the UNMARKED button to enter the START submenu.
START: ZERO & LOG
<< >>
Use the << and >> buttons to scroll through options (Section 3.2). Press QUIT
to select option and quit menu.
Save the changes?
YES
Press the first button to save the change and move the menu back up a level,
and the last key to leave the selection as it was (unchanged) and move back
up a level.
The menu system has timeouts on all operations. If no keys are pressed within
about 20 seconds the system steps back one level at a time. Changes that have
been accepted by pressing YES to the save changes prompt are retained. Any
change that has not been explicitly saved will be lost.
The following parameters are modifiable via the instrument front panel but-
tons, and are displayed on the screen in the following order:
ZERO FLAMM LEVEL PUMP CALIB DISPY ALARM START BUTTN TIME
OFF LIGHT
QUIT PUMP
QUIT START
QUIT
NO
Setting Up
9
