Operating Instructions

Automatic Wedge Welder
Wedge It LE
MUNSCH Kunststoff-Schweißtechnik GmbH
Im Staudchen • D-56235 Ransbach-Baumbach
Phone: +49 (0) 2623 898-80
Fax: +49 (0) 2623 898-85
mailto: munsch@munsch.de
http://www.munsch.de
Firmensitz/Registered Office: Im Staudchen, D-56235 Ransbach-Baumbach
Registergericht/Registration Court: Amtsgericht Montabaur, HRB 3959
Geschäftsführer/Managing Director: Stefan Munsch
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wedge it LE and is the answer not in the manual?

Questions and answers

Related Manuals for Munsch Wedge it LE

Summary of Contents for Munsch Wedge it LE

  • Page 1: Operating Instructions

    Operating Instructions Automatic Wedge Welder Wedge It LE MUNSCH Kunststoff-Schweißtechnik GmbH Im Staudchen • D-56235 Ransbach-Baumbach Phone: +49 (0) 2623 898-80 Fax: +49 (0) 2623 898-85 mailto: munsch@munsch.de http://www.munsch.de Firmensitz/Registered Office: Im Staudchen, D-56235 Ransbach-Baumbach Registergericht/Registration Court: Amtsgericht Montabaur, HRB 3959...

  • Page 2: Table Of Contents

    Welding Procedure ......................8 conforms to the standards, codes and regulations listed below. Any modifications Service and Repair made to the unit(s) without prior consultation with MUNSCH Kunststoff – Warranty and Conformity Schweißtechnik GmbH will void this declaration. Note:...
  • Page 3 Service and Repair Repairs shall be carried out exclusively by MUNSCH Kunststoff-Schweißtechnik GmbH. Any warranties for units which are no longer in the original condition shall be expressly excluded. The units may not be modified and/or changed in any way whatsoever.

  • Page 4: Safety

    Safety Important Note Danger to life when opening the unit due to exposure to live components. Disconnect the power supply (all poles) before opening the unit. A damaged connecting cable may cause fatal electrical shock. The rated voltage indicated on the unit type tag must match the mains voltage.

  • Page 5: Product Description

    Now, the welding process has been started. Product Description Once the unit reaches the last few centimetres of the weld seam, disengage the nip pressure lever (1) and move the heating wedge (4) to its starting position. Press the “Motor Stop“ button to turn off the motor (page 4) When restarting the machine, it will continue with the same travel speed unless the potentiometer has been readjusted.

  • Page 6: Control

    Control Operation of the nip pressure lever (1) as shown in the illustration on the left will cause the nip pressure cam (7) to turn and the upper nip roller to pinch down on the sheet. The nip pressure cam is labelled with the respective sheet thicknesses (2.5, 2.0.

  • Page 7: Function

    This will cause unnecessary heat development and ultimately damage to the machine components. Overlap weld with air channel The Wedge It LE produces an Position the unit in the overlap area between the two sheets to be welded. overlap seam with a width of 50 mm Press the “Motor Start“...

  • Page 8: Preparation Of Unit

    The lower contour rollers (G) can be Preparation of Unit adjusted for optimum contact of the sheet with the wedge. For this purpose, loosen the hex screws (SW10) on the rear and turn The dimension “E“ (wedge position between nip rollers) can be adjusted. contour roller (I), which is mounted on eccentric cams, using an Allan key (SW3).
