Page 1: Instruction Manual
Microwave Instruction Manual L25MW10 DSG Retail Limited is responsible for after sales service. If you have a query about the product please contact our product support line 0844 561 6263 (Currys) and 08700 118 117 (Pixmania). -
Page 2: Important Safety Instructions
Important Safety Instructions Safety Please Read Carefully and Care should be taken so metal objects are Containers not left in the microwave Pressure will build up in sealed containers Keep for Future Reference These include : and can cause them to explode. Therefore First aid ¨... - Page 3 Electrical Information Electrical Information Before using this appliance ensure that the voltage of your electricity supply is suitable for that indicated on the rating plate of the appliance. The ultimate disconnection from the power source is the mains plug. Always make sure it is easily accessible to be unplugged in the event of an emergency.
-
Page 4: Table Of Contents
Contents Contents Unpacking and getting ready page 5 Getting to know your microwave page 6 Introducing microwave cooking page 7 Setting the child lock page 12 Using the microwave page 13 Quick Start Cooking page 15 Auto Cook page 16 Defrosting page 18 Cleaning your microwave... -
Page 5: Unpacking And Getting Ready
Unpacking and getting ready Unpacking This microwave oven is After unpacking your oven, check that it hasn't been damaged whilst in designed for home use. It the box. Make sure there are no dents, that the door closes properly, should not be used for and that the door seal is not damaged. -
Page 6: Getting To Know Your Microwave
Getting to know your Display microwave Shows the clock and cooking time/setting Control panel The oven beeps when you choose a setting on the control panel Turntable spindle Accessories: (included) LED display Shows the clock or Clock/pre-set button cooking time/setting Use this button for setting the clock and preset Defrost by weight... -
Page 7: Introducing Microwave Cooking
Introducing microwave cooking Introducing microwave cooking Always remember the basic safeguards you would follow when using any cooking equipment or handling hot food. This page gives some of the basic guidelines for microwave cooking. Cooking with a microwave Cooking with a microwave is much faster than Microwave energy can heat unevenly so stirring to conventional cooking and, whilst you should make distribute heat is very important. -
Page 8: Checking Your Cooking Utensils
Introducing microwave cooking Microwave ovens cook food using microwave energy that is Safety similar to naturally occurring radio waves. Normally, these "waves" would fade as they disappeared into the atmosphere Never use equipment but in a microwave oven they are concentrated onto food made of metal, except causing it to heat up. -
Page 9: Microwave Heating Categories
More about getting the most from microwave cooking Introducing microwave cooking Microwave heating categories Your oven has been tested and labelled to meet the government's voluntary agreement on the reheating of pre-cooked food. 900W Remember W is the output power of Always check that the food is the oven. - Page 10 Steam Introducing microwave cooking When you microwave food, steam is created as water in the food heats up and evaporates. The steam formed during microwave cooking is entirely safe. It has to escape from the microwave to prevent pressure from building up inside the oven.
-
Page 11: Checking Your Microwave
Checking your microwave Introducing microwave Check your microwave after unpacking and whenever cooking you think it might not be working properly. Pull handle to open door Safety Put the turntable ring inside the oven and place the glass turntable on For your safety, the top of the ring. -
Page 12: Setting The Child Lock
Setting the Child Lock Setting the child lock The child lock is a safety feature which will lock all of the buttons on your microwave. This prevents your microwave being used accidentally. Your microwave door can still be opened. If the oven is turned off from the mains supply, the child-lock setting will be cancelled. -
Page 13: Using The Microwave
Using the microwave Using the microwave Basic microwave cooking Hint: Make sure the glass turntable and the turntable ring Starting and stopping are inside the oven. cooking It is possible to check cooking progress at any time, by opening the door to check the food, turn the food over, stir it or leave the food to stand. - Page 14 Example: choose 50% power for a cooking time of 10 minutes Using the microwave (1) Press " POWER LEVEL " 3 times; (2) Press the numeral pads of "1", "0", "0", "0" in sequence; (3) Press " START/SPEED COOK " to start cooking, timing counts down.
-
Page 15: Quick Start Cooking
Quick start cooking Microwave cooking This function is useful when heating small amounts of food or drink, Or adding extra time during cooking in the speed cook mode. Hint The quick start feature allows you to set 30 seconds intervals Put the turntable ring inside the oven and place the glass turntable on of HIGH power cooking with top of the ring. -
Page 16: Auto Cook
Auto cook Microwave cooking Auto cook allows you to cook most of your favourite food easily by selecting the food type and weight of the food. The numeral pads 1–9 matches nine different types respectively; Display Cook Display Cook Display Cook Auto Fish... - Page 17 Refer to the chart for the automatic menu procedure: Microwave cooking After selecting the menu, continue to press to select the desired weight before pressing START/SPEED COOK Menu Times Press Display Comments Weight(g) 1m 20s 1m 50s Make sure food is thoroughly heated through. Auto Reheat 2m 20s 2m 20s...
-
Page 18: Defrosting
Defrosting Defrosting Be sure to remove any metalic ties or wraps. Make sure the glass turntable and turntable ring are inside the oven. After putting your frozen food in the oven, close the door Defrost by Weight Example: defrosting 500g of beef (1) Press "... -
Page 19: Cleaning Your Microwave
Cleaning your microwave Cleaning Cleaning your oven each time you use it will help to prevent stubborn marks that can be difficult to clean. Keep the front of the Be careful not to spill Unplug the oven before oven clean so that the water into the vents. -
Page 20: Using Aluminium Foil In Your Microwave
Using aluminium foil in your Using aluminium foil microwave It's safe to use aluminium foil in your microwave oven as long as you follow these safety guidelines. As with all metal, microwave energy Follow these guidelines when using can't pass through foil, but provided foil in your microwave: that you keep the foil away from the side of the oven it won't cause sparks... -
Page 21: Questions And Answers
Questions and answers Questions and answers Why is it so important that I allow Why doesn't food seem to cook? standing time after cooking? Check that: With microwave cooking, many foods build up enough heat inside them to continue cooking even •... - Page 22 Questions and answers Does the microwave energy get through Why won't the oven light come on? the window on the door? No. The door has a special metal screen with holes Open the door. If the light doesn't come on, the in that lets you see inside but stops microwave bulb has probably blown.
-
Page 23: Specification
Specification Specification Input 230V - 240V~, 50Hz Output 850 - 900 Watts Microwave frequency 2450MHz Outside dimensions 511mm wide x 283mm high x 440mm deep Power consumption Microwave 1450 - 1550 Watts Complies with EEC directives 89/336/EEC and 92/31/EEC. Dimensions shown are approximate. Because we continually strive to improve our products, we may change specifications without prior notice.
