Safety Vision OBSERVER 4116 Hardware User's Manual

Hide thumbs Also See for OBSERVER 4116:

Advertisement

Quick Links

OBSERVER™ 4116 NVR
HARDWARE USER GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the OBSERVER 4116 and is the answer not in the manual?

Questions and answers

Related Manuals for Safety Vision OBSERVER 4116

Summary of Contents for Safety Vision OBSERVER 4116

  • Page 1 OBSERVER™ 4116 NVR HARDWARE USER GUIDE...

  • Page 2: Important Notices

    Safety Vision. Safety Vision® is a registered trademark of Safety Vision, LLC. All other products or name brands mentioned in this document are trademarks of their respective owners. For more information about Safety Vision and its products, go to www.

  • Page 3: Table Of Contents

    OBSERVER 4116 NVR HARDWARE GUIDE Table of Contents Main Wiring Diagram Installation Hard Drive Removal SD Card Insertion/Removal Components Appendix A: Specifications Appendix B: Dimensions...

  • Page 4: Main Wiring Diagram

    OBSERVER 4116 NVR HARDWARE USER GUIDE Main Wiring Diagram CAN BOX connections COLOR BLACK 485B-1 GREEN 485B-1 WHITE...

  • Page 5: Installation

    OBSERVER 4116 NVR HARDWARE GUIDE Installation Flat Mount Secure the NVR to the surface with self-tapping screws or rivets. Ensure that the front panel of the NVR remains accessible and there is a minimum 2.5 inches of clearance for cables.. Do not...

  • Page 6: Hard Drive Removal

    OBSERVER 4116 NVR HARDWARE USER GUIDE Hard Drive Removal To remove the hard drive from the NVR: Ensure the NVR is powered off. Release the two faceplate security tabs on the side of the enclosure. Insert the key into the faceplate lock and turn it clockwise.

  • Page 7: Sd Card Insertion/Removal

    OBSERVER 4116 NVR HARDWARE GUIDE SD Card Insertion/Removal Do not force the SD card into the slot upside down or backwards. Ensure the SD card’s write protection slider is in the “unlocked” position. Do not remove the SD card until the NVR is turned off.

  • Page 8: Components

    OBSERVER 4116 NVR HARDWARE USER GUIDE Components STATUS LEDS 1 - Removable Hard Drive - The hard disk drive (HDD) Indicates network activity provides the main storage for recorded data. Power NVR is receiving power NVR is recording video 2 - USB Port...
  • Page 9 OBSERVER 4116 NVR HARDWARE GUIDE 1 - Power Port - Connection for the main power harness. 2 - Panel Port - Connection for optional CP4-series monitors. 3 - Serial Port - Connection for the sensor block wiring harness. 4 - WAN/LAN Ports (RJ45) - Connections for optional network accessories.

  • Page 10: Appendix A: Specifications

    OBSERVER 4116 NVR HARDWARE USER GUIDE Appendix A: Specifications SPECIFICATIONS Part No. 4116-NVR OS Support Linux 3.0.8 Access Control CP4, web interface (Wi-Fi or interface), mouse (wireless) Cameras Supported Up to 16 IP cameras Audio/Video Output Port 1 video output channel and 1 audio output channel (SV-VID-MON-OUT required)

  • Page 11: Appendix B: Dimensions

    OBSERVER 4116 NVR HARDWARE GUIDE Appendix B: Dimensions...
  • Page 12 OBSERVER 4116 NVR HARDWARE USER GUIDE FCC Compliance Statement NOTE This device has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 13 OBSERVER 4116 NVR HARDWARE USER GUIDE...
  • Page 14 CORPORATE HEADQUARTERS 6100 W. Sam Houston Pkwy. N. Houston, TX 77041-5113 Main: 713.896.6600 Toll Free: 800.880.8855 Fax: 713.896.6640 www.safetyvision.com...
