Virtual Switches, Page One (Alpha-Link LIVE)

Settings in bold indicate defaults. Please also refer to the notes opposite for details of each setting.
LED
1 Number of MADI channels
2 MADI 2Fs data format
3 AES/EBU 2Fs data format
4 Analogue/Digital connection mode
5 AES/EBU channel status
Sample rate when an Fs rate signal
6
is applied to the wordclock input
7 Wordclock output at 2Fs
8 Phase angle of Wordclock output
Option Setting
64 (32 at 2Fs)
56 (28 at 2Fs)
High Speed
Legacy (SMUX)
High Speed
Legacy (SMUX)
Analogue first (lowest)
Digital first (lowest)
Use
Ignore
Fs
2Fs
Fs Clock
2Fs Clock
0°
90°
LED State See Note
1.
2.
2.
3.
4.
5.
6.
7.
15
