Firmware Version

Whilst in diagnostic mode, the Alpha-Link unit can also be set to display the
current firmware version by simultaneously pressing both the SAMPLE RATE and
CLOCK buttons. The firmware version will be displayed across the top row of
meter LEDs (1 through 8) whilst the buttons are pressed; releasing the buttons
will return the unit to normal operation.
The number will be displayed as a two digit binary number where LEDs 1 to 4
indicate the 'major' part and LEDs 5 to 8 the 'minor' part; the table here can be
used to convert the numbers displayed on the unit into decimal – for example
a version number of '1.2' would display as '
' ' indicates an illuminated LED).
LEDs
' (where
Number
0
1
2
3
4
5
6
7
8
9
