Code CR900FD Configuration Manual page 97

Reg Setting Name
2F2 Leave Targeting On
During Read
2FE Allow Host
Communication If
Locked
2FF Reject PDF417 in AV
Mode
300 Ignore DL Expiration
Date in AV Mode
D014465 CR1400 CR1000 CR2300 CR2600 CR3600 CR44X5 CR8000 CR900FD CR6000 CR5000 T500 Client Version ICD
© 2013-2016 The Code Corporation
Default (Hex) Comment
0 0: The targeting LED will be turned off during the brief period
during which the reader is capturing an image
1: The targeting LED will not be affected by the reader
capturing an image
1 0: Disabled
1: Enabled
When this register is enabled, a locked reader will process
commands sent directly from the host, including CortexTools,
CortexMobile, or custom applications based on the CodeUtil
library. This includes applications written for PC, Apple,
Android and Windows Mobile.
Keywords: #SettingsLock
1 0: Disabled
1: Enabled
When this register is enabled, a reader in SimpleAV mode will
reject all PDF417 barcodes which the decoder determines are
not valid Driver License data.
Note: Applies to CR5000RTC readers in SimpleAV mode only.
Keywords: #SimpleAV
0 0: Disabled
1: Enabled
When this register is enabled, a reader in SimpleAV mode will
ignore the expiration date in a Driver License. This includes DL
data that does not include expiration data. The current
Minnesota DL is one example that does not include expiration.
Note: Applies to CR5000RTC readers in SimpleAV mode only.
Keywords: #SimpleAV

12393 South Gateway Park Place Suite 600, Draper, UT 84020
4/14/2016
Page 97 of 106
 
(801) 495-2200 FAX (801) 495-0280
