Kisai Blade Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Blade and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kisai Blade

Summary of Contents for Kisai Blade

  • Page 2 INSTRUCTION MANUAL USB Port Button Button...

  • Page 3: How To Read The Time

    • Press button A to show the time. I. Turning Mode The display will light up an blade which rotates around the face 3 times. Each time it rotates it leaves 1 line lit, indicating in turn: [hour] [group of 10 mins] [single mins] This is known as the 12-5-9 method of time telling.
  • Page 4 20 minutes Blade rotates Third Spin On the third rotation the blade leaves the 7 o’clock line lit, indicating 7 minutes. It is 4:27 exactly 7 minutes Note: If the blade rotates without leaving any line lit, it indicates ZERO...

  • Page 5: Flashing Mode

    The display will light up Hours & Minutes at the same time similar to a regular clock. One blade will light up to show the hour, one blade will flash to show the minutes. Additional dots may appear to indicate the exact minute.
  • Page 6 • The date or alarm will be displayed in your chosen display mode [TURNING] or [FLASHING] Date example [Turning Mode] June 24th Blade rotates Blade rotates Blade rotates 6 (June) Date icon *You may choose to show [Month > Day] or [Day > Month] See section 5 “How to set the date“...
  • Page 7 4. How to set the time & display modes • From the time display, press & HOLD button B to begin setting the time. • You will be asked to set the following options in sequence. Hours Minutes Mode Animation *Setting mode will exit after 7 seconds of inactivity I.
  • Page 8 II. Minutes (group of 10) In the 12-5-9 time telling method, the “group of 10 mins” are [00, 10, 20, 30, 40, 50]. So in this stage, if the exact minute is 34, you would set 30. • The display will flash the current group of 10 minutes. •...

  • Page 9: Display Mode

    IV. Display Mode Blade has 2 display modes [TURNING] & [FLASHING] See section 1 “How to read the time” for an explaination of each mode. • The display will flash the current display mode. • Press button A to change the mode •...
  • Page 10 Change the way you think about time...
  • Page 11 V. Animation Blade has an animation mode which causes the watch to animate the display every 15 mins between 6pm & midnight. You may set the animation mode ON or OFF. • The display will flash the current animation setting.

  • Page 12: How To Set The Date

    5. How to set the date • Press button A twice to show the date. • Press & HOLD button B to begin setting the date. • icon will be lit. (date) *Setting mode will exit after 7 seconds of inactivity I.

  • Page 13: Date Format

    III. Day (single days) In the 12-5-9 date telling method, the single days are [0-9]. So in this stage, if the exact day is 24, you would set 4. • The display will flash the current single days (0-9). • Press button A to change the “group of 10”...

  • Page 14: How To Set The Alarm

    6. How to set the alarm • Press button A three times to show the alarm. • Press & HOLD button B to begin setting the alarm. • icon will be lit. (alarm) *Setting mode will exit after 7 seconds of inactivity I.
  • Page 15 III. Alarm minutes (groups of 10) In the 12-5-9 time telling method, the “group of 10 mins” are [00, 10, 20, 30, 40, 50]. So in this stage, if the exact minute is 09, you would set 0. • The display will flash the current group of 10 minutes. •...

  • Page 16: Charging The Watch

    7. Charging the watch • The watch battery can be recharged by connecting the USB charging cable provided to the watch USB port and the other end to your computer’s USB port. • To open the watch USB port, use the screw driver included. USB charging port screw Charging light •...

  • Page 17: User Information

    8. User information I. Battery Blade uses a PL301517 rechargable watch battery. • • The battery should last about 1 month between charges. • The battery lifetime is expected to be 300 charges. • Only use the cable provided with the watch for recharging, as it is designed specifically for this watch.

  • Page 18: Specifications

    SPECIFICATIONS Case Materials Wood Strap Materials Wood Case Dimensions 45mm x 53mm x 12mm Finish Clear Coatng Maximum Fit 210mm (approx.) Wrist Size Weight Display LED Digital Tube Battery PL301517 Rechargable...
