Connect Cables and Power on
Data Domain DD9500 and DD9800 Systems 6.1 Hardware Overview and Installation Guide
78
Table 26 Standby node cabling instructions (continued)
String I/O - Port
(Loop)
6 I/O 9 - Port 3
6 I/O 6 - Port 2
a.
Cable lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be
used.
Shelf Port
A controller EXPANSION
or DD Cloud Tier metadata shelf
B controller EXPANSION
or DD Cloud Tier metadata shelf
Length
2M
port of the SSD shelf
2M
port of the SSD shelf
a
