String I/O - Port
(Loop)
2 I/O 2 - Port 0 B controller port 0 of the highest number shelf in V2
3 I/O 6 - Port 1 A controller port 0 of shelf V3.1
3 I/O 3 - Port 1 B controller port 0 of the highest number shelf in V3
4 I/O 2 - Port 2 A controller port 0 of shelf V4.1
4 I/O 3 - Port 2 B controller port 0 of the highest number shelf in V4
5 I/O 6 - Port 3 A controller HOST
5 I/O 3 - Port 3 B controller HOST
a.
Cable lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be
used.
Shelf Port
port of the SSD shelf
port of the SSD shelf
Connect Cables and Power on
Length
2M
2M
2M
2M
5M
2M
2M
DD9500 /DD9800
a
71
