Model #
1361GACf
1361CAFf
McKenzie Twin
Bookcase
Headboard
GAC = Glazed Antique Cherry finish
CAF = Caffè finish
Thank you for allowing us to help you furnish your
home. We are certain you will be delighted with
your new furniture for many years to come.
If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a
replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you
cannot order replacement parts through your dealer, please contact our customer service department.
Customer Service: 800-653-3336 • Outside the U.S.: 541-687-0213
CUSTOMER SERVICE
Hours: Our friendly customer service staff can be reached:
Monday-Friday 8:00 a.m. to 5:00 p.m. (Pacific Time).
You may leave a message 24 hours a day, seven days a week.
Fax: 541-687-2060• Email: info@whittierwood.com
P.O. Box 2827
Eugene, OR 97402 USA
IMPORTANT NOTES:
• For normal household use only. Not recommended for commercial use.
• Unload items before you move this unit.
• Do not overload the concealed storage areas.
• Do not overload the cubbies.
• This assembly requires two people.
Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the state of California to cause cancer.
Avoid inhaling wood dust or use a dust mask or other safeguards for
personal protection.
For more information go to: www.p65warnings.ca.gov/wood
This product can expose you to chemicals, including formaldehyde,
which are known to the State of California to cause cancer.
For more information go to: www.p65warnings.ca.gov/furniture
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
Production Code:
VN
WARNING
08/17
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Whittier Wood 1361GACf
Summary of Contents for Whittier Wood 1361GACf
- Page 1 If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you cannot order replacement parts through your dealer, please contact our customer service department.
- Page 2 1361GACf 1361CAFf McKenzie Twin Bookcase Headboard Parts List Please identify the parts and check that quantities received match those on this list. If you need to replace a part, refer to the following letter and part name. Part Description Quantity...
- Page 3 1361GACf 1361CAFf McKenzie Twin Bookcase Headboard Parts List Tack Glide (attached) #14 x 1-1/4" Pan Head Screw Washer #8 x 1-3/8" Lo-Profile Screw (inserted) 1361GACf_1361CAFf — Page 3 — 08/17...
- Page 4 NOTE: Use this instruction and hardware kit included with this 1361 McKenzie Twin Bookcase Headboard ONLY if you are using a Hollywood frame. IF you are using this product with Whittier Wood Furniture Footboard and Pedestal kits, disregard this instruction and hardware and use what is included with your Footboard kit.
- Page 5 1361GACf 1361CAFf McKenzie Twin Bookcase Headboard Assembly Instructions To adjust the brake tension on the Door Stay (K) turn the screw on the Door Stay clockwise to loosen or counterclockwise to tighten. See Figures 6 and 6a. Fig. 6a Fig. 6 Unwrap the False Bottoms (G) and place them on top of the rails in the Headboard Assembly (Ed).
