SETUP INSTRUCTIONS (continued)
4. Brush assembly. See Fig. 4.
NOTE: Remove the brushes from underneath the device when
vacuuming large debris or leaves on the pool floor.
13
12
5. With hose clamp (6), fasten
the end of hose D (11) to the
top connection of cleaner.
A small coin can be used to
tighten the hose clamp.
See Fig. 5.
6. Place auto cleaner into the
water. Fill up the hose assembly
with water by submerging the
hose into the water to remove
all of the entrapped air from the
hose.
7. Hold the auto cleaner upside
down below the water surface to
jet out the water. See Fig. 6.
This will evacuate all the air in
the hose and auto cleaner, so
the cleaner will sink to the
bottom and keep the pool clean.
S AVE THESE INSTRUCTIONS
