Intex ZX50 Owner's Manual
  1. Manuals
  2. Brands
  3. Intex Manuals
  4. Swimming Pool Vacuum
  5. ZX50
  6. Owner's manual

Intex ZX50 Owner's Manual

Automatic pool cleaner
Hide thumbs

Advertisement

Quick Links

(78IO) ZX50 MINI AUTOMATIC POOL CLEANER ENGLISH SIZE: 4.875" X 7.25" PANTONE 295U 08/21/2021
ZX50 Automatic
Pool Cleaner
For illustrative purposes only.
Don't forget to try these other fine Intex products:
pools, pool accessories, inflatable pools and in-home
toys, airbeds and boats available at fine retailers or
visit our website.
Due to a policy of continuous product improvement,
Intex reserves the right to change specifications and
appearance, which may result in updates to the
instruction manual without notice.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous
licence de/Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in
einigen Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Development Co. Ltd., Hong Kong &
Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué dans
l'Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V.,
Venneveld 9, 4705 RR Roosendaal – The Netherlands
www.intexcorp.com
IMPORTANT
SAFETY RULES
Read, understand, and follow
all instructions carefully before
installing and using this product.
©2021 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Recreation
Corp. All rights reserved/Tous droits réservés/Todos los derechos reservados/
Alle Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/
Gedruckt in China.
English
78A
078-*A*-R0-2208

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZX50 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intex ZX50

Summary of Contents for Intex ZX50

  • Page 1 Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Development Co. Ltd., Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., Venneveld 9, 4705 RR Roosendaal –...

  • Page 2: Table Of Contents

    (78IO) ZX50 MINI AUTOMATIC POOL CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 08/21/2021 TABLE OF CONTENTS Warnings................. 3 Parts Reference..............4 Set Up Instructions..............5-8 Debris Net Cleaning............... 9-10 Troubleshooting Guide............11-12 Long Term Storage..............13 General Aquatic Safety............

  • Page 3: Warnings

    (78IO) ZX50 MINI AUTOMATIC POOL CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 08/21/2021 IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. WARNING • To rEDUcE ThE risk of injUry, Do noT pErmiT chilDrEn To UsE This proDUcT.

  • Page 4: Parts Reference

    (78IO) ZX50 MINI AUTOMATIC POOL CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 08/21/2021 PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only. Actual product may vary.

  • Page 5: Setup Instructions

    (78IO) ZX50 MINI AUTOMATIC POOL CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 08/21/2021 SETUP INSTRUCTIONS IMPORTANT PREPARATION INFORMATION please read, understand, and follow all instructions carefully before installing and using this product. General • The Auto cleaner operates from the suction side of the pool water outlet connector (water flowing from the pool to the filter pump).
  • Page 6 (78IO) ZX50 MINI AUTOMATIC POOL CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 08/21/2021 SETUP INSTRUCTIONS (continued) Before setup, make sure that: • The filter pump is turned off, and disconnect the power cord from the electrical outlet. • The pool is free from objects that will hinder the auto cleaner free movements by removing the ladder, surface skimmer, water sprayer (if applicable), floats or any other objects from the pool.
  • Page 7 (78IO) ZX50 MINI AUTOMATIC POOL CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 08/21/2021 SETUP INSTRUCTIONS (continued) screw the hose collar nuts (6) and foam float (10) to the hose (7). see fig. 3. √ × √ Brush assembly. see fig. 4.
  • Page 8 (78IO) ZX50 MINI AUTOMATIC POOL CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 08/21/2021 SETUP INSTRUCTIONS (continued) Venting the system is necessary for air to escape as the auto cleaner fills with water. hold the auto cleaner handle and slowly lower it into the pool water.

  • Page 9: Debris Net Cleaning

    (78IO) ZX50 MINI AUTOMATIC POOL CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 08/21/2021 DEBRIS NET CLEANING Make sure the filter pump is turned off, and disconnect the power cord from the electrical outlet. Lift the auto cleaner’s hose slowly then hold the auto cleaner up with one hand.
  • Page 10 (78IO) ZX50 MINI AUTOMATIC POOL CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 08/21/2021 DEBRIS NET CLEANING (continued) Push the left and right levers to the unlock position. see fig. 12. Lever Remove the debris net (2) from the cleaner base (3). if debris is on the debris net and cleaner base, use a garden hose to flush the debris off.

  • Page 11: Troubleshooting Guide

    (78IO) ZX50 MINI AUTOMATIC POOL CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 08/21/2021 TROUBLESHOOTING GUIDE TROUBLE SOLUTION • Ensure the filter pump is operating and within the specified pump AUTo clEAnEr flow rate [900 - 1500 gallons/hour (3407 - 5678 liters/hour)].
  • Page 12 (78IO) ZX50 MINI AUTOMATIC POOL CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 08/21/2021 TROUBLESHOOTING GUIDE (continued) TROUBLE SOLUTION TAkEs lonGEr • This is normal, as the auto cleaner reversing time is TimE To rEVErsE dictated by the size of the filter pump flow rate.

  • Page 13: Long Term Storage

    (78IO) ZX50 MINI AUTOMATIC POOL CLEANER ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 08/21/2021 LONG TERM STORAGE make sure the filter pump is turned off, and disconnect the power cord from the electrical outlet. Using the set Up instructions in reverse, disassemble the auto cleaner.
