GS-7605 | 5-Port PoE Gigabit Ethernet Smart-Lite Switch
I
I.
Product Information
I-1. Package Contents
1
4
1.
GS-7605 PoE Switch
2.
QIG
3.
Manual CD
2
5
4.
Power Adapter
5.
4 x Foot Pads
3
Advertisement
Related Manuals for Comtrend Corporation GS-7605
Summary of Contents for Comtrend Corporation GS-7605
- Page 1 Quick Installation Guide GS-7605 | 5-Port PoE Gigabit Ethernet Smart-Lite Switch Product Information I-1. Package Contents GS-7605 PoE Switch Power Adapter 4 x Foot Pads Manual CD...
- Page 2 I-2. Hardware Overview Front Panel The front panel of the switch consists of: • 5 x 10/100/1000Mbps RJ-45 Ports o Ports 1-4 are PoE Capable • A Series of LED Indicators Rear Panel The rear panel of the switch features the AC power connector...
- Page 3 I-3. LED Indicator Power/SYS: Mode LED Status Description Power on Green Blinking System boot-up Power off or fail Link/ACT: LED Status Mode Description 1000Mbps Green On/Blinking connected/data transmitting 10/100Mbps Amber On/Blinking connected/data transmitting Disconnected or fail PoE Max: LED Status Mode Description PoE power output is over...
- Page 4 I-4. Desktop Installation Install the switch on a desktop by attaching the cushioning rubber feet to the bottom corners of the switch to protect against external vibration. Allow adequate space for ventilation between the device and any objects around.
-
Page 5: Quick Setup
Quick Setup II-1. Switch to End Device 1. Connect the switch to local power with the included power cable. 2. Use a standard Cat 5/5e Ethernet cable to connect the switch to end devices as shown below. Switch ports will automatically adjust to the link rate of the device to which it’s connected. - Page 6 II-2. Login 1. Open a web browser and go to the switch’s IP address. 2. Enter the access point’s default IP address 192.168.169.1 into the URL bar of a web browser. 3. You will be prompted for a password. Enter the default password “admin”.
- Page 7 4. You will arrive at the switch configuration window as shown below:...
- Page 8 Your Device is Now Connected! FOR MORE HELP: For instructions on advanced features, FAQ, etc., please visit our online Product Webpage. For more information: YouTube: https://www.youtube.com/user/ComtrendConnection Facebook: https://facebook.com/Comtrend Website: http://us.comtrend.com/ Support: Visit our website or call 1-877-COMTREND (1-877-266-8736)
