ILLUSTRATED PARTS LIST
G4TP2T - Main Chassis - Parts List
ITEM # PART # DESCRIPTION
WC-37122 1
1A KIT, DUMP VALVE RIGHT
VALVE, BREW DUMP RIGHT 240V 12W GEM12D/
WC-854 2
1B
TP/TPC
WC-37121 1
2A KIT, DUMP VALVE LEFT
VALVE, BREW DUMP LEFT 240V 12W GEM12D/
WC-853 2
2B
TP/TPC
SOLENOID, LOCK BREW CONE RIGHT/LEFT
WC-442 1
3A
120V TP2T/TP2S/GEMSS/GEM
SOLENOID, LOCK BREW CONE RIGHT 220V
WC-446 2
3B
THERMOPRO/GEMTS
WC-2977K a
4A KIT, SPRAYHEAD FITTING METAL
WC-2977-101K b
4B KIT, SPRAYHEAD FITTING PLASTIC
VALVE, BY-PASS, NON-ADJUSTABLE WITH
WC-844-101 1
5A
RESTRICTOR (WC-2945)
VALVE, BY-PASS, 240V NON-ADJUSTABLE W/
WC-844-102 2
5B
RESTRICTOR (WC-2945)
KIT, VALVE REPAIR FOR INVENSYS WC-
6 WC-37132
820WDR,WC-821WDR, WC-844WDR
7 WC-10000 CONTROL MODULE, TOUCH SCREEN G4
8 WC-10001 CONTROL MODULE, UPM 120/220V G4
9 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
RELAY, SOLID STATE 280V/40A W/ HEATSINK
10 WC-8559
AND QUICK DISCONNECTS
BREW CONE,ASSY W/SPLASH POCKET BRWN
11 WC-3417
STYLIZED GEMIN HOT COFFEE
12 WC-58037-101 COVER, CENTER WRAP TP 90 DEG
13 WC-2402P ELBOW, 3/8"FL x 3/8" NPT PLATED
14 WC-1412 CORD GRIP, 3/4" FOR METAL CORD TO .81"OD
15 WC-14045-101 CURRENT SENSOR ASSY G4
HARNESS ASSY, COMPLETE G4TP2T
WC-13450 1
16A
(INCLUDES TERMINAL BLOCK)
HARNESS ASSY COMPLETE G4TP2T G4TPC2T/
WC-13450-101 2
16B G4GEMT/G4TP1T-30'S (INCLUDES TERMINAL
BLOCK)
1 G4TP2T10A3100, G4TP2T10A3500, 2 G4TP2T30A3100
a
older units.
b Units built before 05/15/17.
G4TP2T - Recommended Parts to Stock
ITEM # PART # DESCRIPTION
1A WC-37122 KIT, DUMP VALVE RIGHT
2A WC-37121 KIT, DUMP VALVE LEFT
SOLENOID, LOCK BREW CONE RIGHT/LEFT
3A WC-442
120V TP2T/TP2S/GEMSS/GEM
VALVE, BY-PASS, NON-ADJUSTABLE WITH
5A WC-844-101
RESTRICTOR (WC-2945)
8 WC-10001 CONTROL MODULE, UPM 120/220V G4
G4TP2, ILLUSTRATED PARTS/RECOMMENDED PARTS
ITEM # PART # DESCRIPTION
17 WC-29044 SLEEVE, OVERFLOW ASSY GEN USE
KIT, INLET VALVE REPAIR USE ON WC-826/WC-
18 WC-3765L
826L/WC-847 (OLDER UNITS)
VALVE, INLET 2 GPM 120V 10W GEN USE
WC-847 1
19A
BROWN BODY
WC-883 2
19B VALVE, INLET 2 GPM 240V 6W
WC-596 2
20 FILTER, NOISE EMI 250VAC/30A 1PH
21 WC-1501 FUSE, HOLDER ASSY W/5A FUSE
SWITCH, TOGGLE NON-LIT SPST 15A 125/6A
WC-102 1
22A
250VAC RESISTIVE
SWITCH, TOGGLE NON-LIT DPST 25A
WC-103 2
22B
125/250VAC RESISTIVE
23 WC-5459 COVER, TOP SS THERMOPRO
LEG, 4" ADJUSTABLE 3/8-16 THRD ITALIAN
WC-3528 1
24A
STYLE
LEG, 4" ADJUSTABLE W/TIE DOWNS 3/8-16
WC-3500T 2
24B
THRD
25 WC-1825 FAUCET, ASSY HOT WATER TP2S
26 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
27 WC-5231 COMPOUND, SILICONE 5 OZ
28 WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
TRANSFORMER,120VAC-24V 4.8A W/ LEADS &
29A 1
WC-589-101
MOLEX CONNECTOR
TRANSFORMER,240VAC- 24V 4.8VA W/LEADS &
29B 2
WC-589-102
MOLEX CONNECTOR
30 WC-10008 UNIVERSAL HOST ADAPTER USB
O'RING, 0.487I.D.x 0.693OD x0.103CS BUNA-N
WC-4320 a
31A
#112
GASKET, 1.00OD X .625 I.D. X .030 THK WHITE
WC-43089 b
31B
EPDM 70 SHORE
WC-4213 a
32A NUT, 5/8 LOCK PLATED
WC-4212-02 b
32B NUT, 5/8-18 JAM PLASTIC
ITEM # PART # DESCRIPTION
9 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
15 WC-14045-101 CURRENT SENSOR ASSY G4
VALVE, INLET 2 GPM 120V 10W GEN USE
19A WC-847
BROWN BODY
26 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
28 WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
IP42
053117A
