USER'S GUIDE
®
G4 ThermoPro
Series
1.5 Gallon Coffee Brewing System
READ AND SAVE THESE INSTRUCTIONS
NOTICE TO INSTALLER: Please leave this booklet with the machine.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G4TP2S10A3500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Curtis G4TP2S10A3500

Summary of Contents for Curtis G4TP2S10A3500

  • Page 1 USER’S GUIDE ® G4 ThermoPro Series 1.5 Gallon Coffee Brewing System READ AND SAVE THESE INSTRUCTIONS NOTICE TO INSTALLER: Please leave this booklet with the machine.

  • Page 2: Table Of Contents

    .......................ES52 ....................................................................................................................EC1 ..............................Contact Information Wilbur Curtis Co., Inc. 6913 Acco Street | Montebello, CA 90640 US Phone: 323-837-2300 | Toll Free: 800-421-6150 Email: csrassistance@wilburcurtis.com | Web: www.wilburcurtis.com . - 4:00 . PT Email: techsupport@wilburcurtis.com G4TP2 CONTENTS LIST...

  • Page 3: Fs24

    KEY FEATURES/SPECIFICATIONS/SYSTEM REQUIREMENTS FS24 Key Features ® • Gold Cup Series – digital control module provides precise control over all aspects of brewing: time, temperature, volume plus specialty coffee needs from pre-infusion to pulse-brewing to water bypass. • Generation Four (G4) Digital Control Module – Large, 4.3” touch screen. Icon-driven interface streamlines operation.

  • Page 4: Is2

    INSTRUCTIONS could result in personal injury or void the warranty. • This appliance is designed for commercial use. Any service other than cleaning and preventive maintenance should be performed by an authorized Wilbur Curtis service technician. • serviceable parts inside.
  • Page 5 IMPORTANT SAFEGUARDS CE Requirements • This appliance must be installed in locations where it can be overseen by trained personnel. • • • • This appliance must not be cleaned by water jet. • instruction concerning use of the appliance in a safe way and if they understand the hazards involved. •...

  • Page 6: Ii2

    INSTALLATION INSTRUCTIONS WARNING: WARNING: properly grounded. NOTICE: SPECIFICATIONS section. IMPORTANT: Installation Instructions Installation Requirements • A secure surface capable of supporting the weight of the appliance. • For units without an attached cord set: Appropriately sized, UL listed, grounding type power cable to meet enough •...

  • Page 7: Ii9

    INSTALLATION INSTRUCTIONS Installation Leveling WARNING: Use the leveling legs to level the brewer only. Do not use them to adjust brewer height. Do not extend them higher than necessary. Position the brewer on the counter top. Level it left to right and front to back by turning the bottom of the legs.
  • Page 8 INSTALLATION INSTRUCTIONS Connect the Brewer Wiring (cont.) Brewers With A Cord Set Attached WARNING: Connect the power cord to the appropriate type and size electrical outlet. If the electrical outlet is not compatible with the power cord, have it upgraded by a licensed electrician. Do not modify the power plug.

  • Page 9: Oi11

    OPERATING INSTRUCTIONS OI11 Brewing Instructions WARNING - TO AVOID SCALDING, AVOID SPLASHING. Keep body parts clear of the brewer during The G4 ThermoPro Brewer is factory preset for optimal performance. Back of brewer The brewer should be ON. Center an empty dispenser under the brew basket.

  • Page 10: Ci1

    CLEANING INSTRUCTIONS WARNING: HOT SURFACES - To avoid injury, allow the brewer and dispenser(s) to cool before cleaning. NOTICE - Do not use cleaning liquids, compounds or powders containing chlorine (bleach) or corrosives. USE OF THESE PRODUCTS WILL VOID THE WARRANTY. Cleaning The Brewer - Daily WARNING: DO NOT immerse the brewer in water or any other liquid.

  • Page 11: Ci5

    CLEANING INSTRUCTIONS Cleaning the 1.0 Gallon or 1.5 Gallon Thermal Dispensers (Daily) WARNING: DO NOT immerse the thermal server or its lid assembly in water or any other liquid. Do not place the thermal server or lid in a dishwasher. Placing a thermal server in a dishwasher will void the warranty. To avoid damage, DO NOT use a brush to clean the faucet or the inside of the faucet shank (outlet).
  • Page 12 CLEANING INSTRUCTIONS Cleaning the Faucet Parts and Gauge Glass (cont.) Sanitize - After rinsing, place all faucet and gauge parts in a sink to be sanitized. Immerse them in a commercial sanitizer suitable for food grade applications. Sanitize according to the W ASH directions on the package.

  • Page 13: Ci9

    CLEANING INSTRUCTIONS Cleaning the Airpot/Pour Pot (Daily) WARNING: DO NOT immerse the airpot/pour pot or lid assembly in water or any other liquid. Do not place the airpot/pour pot or lid in a dishwasher. Placing a airpot or pour pot in a dishwasher will void the warranty. Start by preparing a mild solution of detergent and warm water.
  • Page 14 Control symbols - all symbols may not be present at the same time Return to Home Undo Curtis logo Scroll left/right previous Entering Programming Mode The ACCESS CODE screen will appear. The menu icons. The icons vary based on the model appear.
  • Page 15 PROGRAMMING GUIDE Programming SELECTIONS FOR COFFEE BREWER MODELS Model Select Recipes Control Settings Brew Settings Settings Summary Exit Coffee Gemini Gemini IF One Batch Single Gourmet Std ThermoPro Two Batch Twin Light Roast Milano By Volume/Time Three Batch Dark Roast Pre/Pulse Omega High Yield...
  • Page 16 PROGRAMMING GUIDE USB - Easy Programming program each step individually using the touchscreen. This process also makes it easy to quickly standardize the IMPORTANT: completely Uploading the Software to the Flash Drive as desired. Downloading the Software to the Brewer from the Flash Drive Select the (identical) brewer you wish to make program changes to.
  • Page 17 ROUGH-IN DRAWINGS RD30 G4TP2S - Single Coffee Brewer 20.75 in [52.7 cm] 35.14 in [89.2 cm] 24.00 in [60.0 cm] 8.38 in 11.07 in [21.0 cm] [28.1 cm] 4.00 in [10.2 cm] G4TP2T - Twin Coffee Brewer 20.75 in 35.42 in [52.7 cm] [90.0 cm] 24.00 in...

  • Page 18: Ip42

    ILLUSTRATED PARTS LIST IP42 Supplies and Accessories - All Models WC-29050 - Spray Head CAB-1 - Cleaning Brush G4TP2S - Main Chassis - Exploded View Water tanks assemblies - See section IP43 for single voltage models - See section IP44 for dual voltage models G4TP2, ILLUSTRATED PARTS/RECOMMENDED PARTS 053117A...
  • Page 19 TRANSFORMER,120VAC-24V 4.8A W/ LEADS & WC-589-101 1 MOLEX CONNECTOR TRANSFORMER,240VAC- 24V 4.8VA W/LEADS & WC-589-102 2 MOLEX CONNECTOR 1 G4TP2S10A3500, G4TP2S63A3100, G4TP2S63A3500, 2 G4TP2S30A3100 older units. b Units built before 05/15/17. G4TP2S - Recommended Parts to Stock ITEM # PART #...
  • Page 20 ILLUSTRATED PARTS/RECOMMENDED PARTS IP42 G4TP2T - Main Chassis - Exploded View Water tank assembly, see section IP45 G4TP2, ILLUSTRATED PARTS/RECOMMENDED PARTS 053117A...
  • Page 21 ILLUSTRATED PARTS LIST IP42 G4TP2T - Main Chassis - Parts List ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION WC-37122 1 KIT, DUMP VALVE RIGHT WC-29044 SLEEVE, OVERFLOW ASSY GEN USE VALVE, BREW DUMP RIGHT 240V 12W GEM12D/ KIT, INLET VALVE REPAIR USE ON WC-826/WC- WC-854 2 WC-3765L...
  • Page 22 ILLUSTRATED PARTS LIST IP43 WC-62032 - Tank Assembly WC-62032 - Tank Assembly - Parts List ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION WC-62032 TANK, COMPLETE TP2S ULTEM FITTNGS THERMOSTAT, HI LIMIT HEATER CONTROL WC-522 DPST 277V 40A WC-5853-102 COVER, TOP HEATING TANK GEN USE WC-43055...

  • Page 23: Ip44

    ILLUSTRATED PARTS LIST IP44 WC-62031 - Tank Assembly WC-62031 - Tank Assembly - Parts List ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION WC-62032 TANK, COMPLETE TP2S ULTEM FITTNGS THERMOSTAT, HI LIMIT HEATER CONTROL WC-522 DPST 277V 40A WC-5853-102 COVER, TOP HEATING TANK GEN USE WC-43055...

  • Page 24: Ip45

    ILLUSTRATED PARTS/RECOMMENDED PARTS IP45 WC-62030 - Tank Assembly WC-62030 - Tank Assembly - Parts List ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION WC-62030 TANK, COMPLETE TP2T ULTEM FITTNGS WC-4382 GUARD, SHOCK HTNG ELMNT DOUBLE WC-37008 KIT, TANK LID ROUND (INCLUDES GASKET) THERMOSTAT, HI LIMIT HEATER CONTROL DPST WC-522 277V 40A...

  • Page 25: Es49

    ELECTRICAL SCHEMATICS ES49 G4TP2S10A3500 GTPSG4-10, ELECTRICAL SCHEMATIC 041917A...

  • Page 26: Es41

    ELECTRICAL SCHEMATICS ES41 G4GEMS63A1000, G4TP1S63A3100, G4TP2S63A3100, G4TP2S63A3500 GTPSG4-63, ELECTRICAL SCHEMATIC 041817A...
  • Page 27 ELECTRICAL SCHEMATICS ES50 G4TP1S30A3100, G4TP2S30A3100 GTPSG4-30, ELECTRICAL SCHEMATIC 041917A...

  • Page 28: Es42

    ELECTRICAL SCHEMATICS ES42 G4GEMT10A1000, G4TP1T10A3100, G4TP2T10A3100, G4TP2T10A3500 GTPTG4-10, ELECTRICAL SCHEMATIC 053117A...

  • Page 29: Es52

    ELECTRICAL SCHEMATICS ES52 G4TP1T30A3100, G4TP2T30A3100 GTPTG4-30, ELECTRICAL SCHEMATIC 053117A...
  • Page 30 TROUBLESHOOTING GUIDE WARNING: Electric Shock Hazard - Scald and Burn Hazard - IMPORTANT: always check all Valve Test Procedure Troubleshooting Guidelines • • • • Valve Test Procedure in either direction Water Not Hot Enough replace the temperature sensor Water Heats More Slowly Than Usual During Brewing...
  • Page 31 TROUBLESHOOTING GUIDE No Power - Display Not Lit Water Tank Does Not Fill Brewer Does Not Start When Brew Button is Pressed Brewing Brewing Water Too Hot (Boiling or Excessive Steaming) IMPORTANT: Over Temp Over Temp Sensor or Ready to Brew Sensor Error Message Heating Heating...
  • Page 32 TROUBLESHOOTING GUIDE Water Tank Does Not Fill IMPORTANT: Coffee/Tea Too Strong Dispenser Not Filled To Normal Level During Brewing Dispenser Not Filled To Normal Level During Brewing sure that the spray head is correctly aligned and that the tubing is routed properly to allow for maximum water...
  • Page 33 TROUBLESHOOTING GUIDE All Of The Time No Water/Tea Flows From Brewer During Brewing Water Tank Does Not Fill Low Water Flow Warning Water Level Error Message Water Level Error Message “Internal Error 1” Message on Display “Internal Error 2” Message on Display PROGRAMMING GUIDE...
  • Page 34 TROUBLESHOOTING GUIDE Water Does Not Heat At All Check to see if the water level in the tank is in contact with the water level probe. If not, see Tank Does Not Fill. • The water will not heat unless it is in contact with the probe. If the water heats, but is not hot enough, see Water Not Hot Enough.
  • Page 35 The G4 control module diagnostics can be used to detect electrical circuit failures in the brewer. When a circuit Using the Diagnostics The MAIN MENU Control Settings. Diagnostics Curtis logo Auto Test to test all circuits. If a button is highlighted green the DIAGNOSTICS Left Auto Test...

  • Page 36: Ec1

    ERROR CODES Warning Messages - Allows Brewer to Continue Brewing MESSAGE DISPLAY WARNING DESCRIPTION CAUSE Brew count “Gallons Since Reset” exceeds programmed Maintenance Required Maintenance Required preventative maintenance period. If the Inlet valve remains on longer than XX seconds (during the brew cycle only) and repeats TWICE during that brew cycle.
  • Page 37 Return Merchandise Authorization (RMA): All returned equipment must be properly re-packaged in the original carton and received by Curtis within 45 days following the issuance of a RMA. NO UNITS OR PARTS WILL BE ACCEPTED WITHOUT A RETURN MERCHANDISE AUTHORIZATION (RMA).
