WELCOME HOME TO WARMTH
P/N 900556-00 Rev. NC 12/2015
P900556-00
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home, where not
prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate. This
appliance is not convertible for use with other gases.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. Refer to Air for Combustion and Ventilation
section on page 5 of this manual.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Installation and Operation Instructions
TM
Biltmore
Models
PFS
®
C
US
Report No. F09-126
Unvented (Vent-Free) Gas Log Heaters
TM
Biltmore24LMN
Biltmore24LMP
24" AND 30" REMOTE CONTROL READY
BILTMORE™ SPLIT OAK
LOG AND BURNER SETS:
BILTMORE24LMN/LMP AND BILTMORE30LMN/LMP
Also Design-Certified As Vented Decorative Appliances
When Not Used With Hand-Held Thermostat Remote
Biltmore30LMN
Biltmore30LMP
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Comfort Flame Biltmore24LMN
Summary of Contents for Comfort Flame Biltmore24LMN
- Page 1 Report No. F09-126 24" AND 30" REMOTE CONTROL READY BILTMORE™ SPLIT OAK LOG AND BURNER SETS: BILTMORE24LMN/LMP AND BILTMORE30LMN/LMP Also Design-Certified As Vented Decorative Appliances When Not Used With Hand-Held Thermostat Remote INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Thank you for your purchase. We appreciate your business! Safety ..................... 2 Local Codes ................... 4 Please carefully read and follow all instructions in this manual. Pay Product Identification ..............4 special attention to all warnings and safety information. Unpacking .................. - Page 3 SAFETY Continued Keep the appliance area clear and free from com- WARNING: Any change to this heater or its con- bustible materials, gasoline and other flammable trols can be dangerous. vapors and liquids. DANGER: Carbon monoxide poisoning may lead 1. This appliance is only for use with the type of gas indicated on the to death! rating plate.
-
Page 4: Local Codes
SAFETY Continued 14. Do not use this heater to cook food or burn paper or other objects. a qualified service person should install, service or repair heater. 15. Do not use heater if any part has been exposed to or under water. 18. -
Page 5: Product Features
PRODUCT FEATURES OPERATION SAFETY PILOT This heater is clean burning. It requires no outside venting. There is This heater has a pilot with an Oxygen Depletion Sensing (ODS) no heat loss out a vent or up a chimney. Heat is generated by realistic safety shutoff system. - Page 6 AIR FOR COMBUSTION AND VENTILATION Continued The space in the above example is a confined space because the actual DETERMINING FRESH-AIR FLOW FOR HEATER LOCATION Btu/Hr used is more than the maximum Btu/Hr the space can support. Determining if You Have a Confined or Unconfined Space Using You must provide additional fresh air.
-
Page 7: Installation
AIR FOR COMBUSTION AND VENTILATION Continued wall connecting the two spaces (see options 1 and 2, Figure 2). You can also remove door into adjoining room (see option 3, Figure 2). Follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Air for Com- Ventilated Outlet Attic... - Page 8 INSTALLATION Continued CHECK GAS TYPE NOTICE: Manual control heaters may be used as a Use the correct gas type (natural or propane/LP) for your unit. If your vented product. If so, you must always run heater gas supply is not correct, do not install heater. Call dealer where you with chimney flue damper open.
- Page 9 INSTALLATION Continued Mantel Shelf 12" Underside of 10" Heat Resistant Mantel Shelf 8" Material 6" " All minimum distances are in inches Minimum Non- Combustible Log Set Material 8" 12" 15" 18" 20" 18" and 24" Models Min. Top of Fireplace Opening Hood Distances to...
- Page 10 INSTALLATION Continued FLOOR CLEARANCES Area of Various Standard Round Flues A. If installing appliance on the floor level, you must maintain the Diameter Area minimum distance of 14" to combustibles (see Figure 8). 5" 20 sq. in. 6" 29 sq. in. B.
- Page 11 INSTALLATION Continued Installation Items Needed • hardware package (provided with heater) • approved flexible gas hose (not provided) (if allowed by local codes) • sealant resistant to propane/LP gas, not provided • electric drill with 3/16" masonry drill bit Masonry NOTE: Install optional remote receiver and hand-held remote kit (see Screw Accessories, page 24) before installing gas log heater.
- Page 12 INSTALLATION Continued Installation Items Needed IMPORTANT: Install equipment shutoff valve in an ac- Before installing heater, make sure you have the items listed below. cessible location. The equipment shutoff valve is for • piping (check local codes) turning on or shutting off the gas to the appliance. •...
- Page 13 INSTALLATION Continued CHECKING GAS CONNECTIONS Equipment WARNING: Test all gas piping and connections, Open Shutoff Valve internal and external to unit, for leaks after installing or servicing. Correct all leaks at once. Closed WARNING: Never use an open flame to check for a leak.
- Page 14 INSTALLATION Continued PRESSURE TESTING HEATER GAS CONNECTIONS Front Log (#1) 1. Open equipment shutoff valve (see Figure 15). 2. Open propane/LP supply tank valve or main gas valve located on or near gas meter for natural gas. 3. Make sure control knob of heater is in the OFF position. 4.
- Page 15 INSTALLATION Continued 4. Locate pegs on bottom of crossover log (#4). Slide pegs into holes located in middle log (#2) and back log (#3). See Figure 21, for placement. Pegs 5. Locate pegs on bottom of crossover log (#5). Slide pegs into holes located in crossover log (#4) and front log (#1).
-
Page 16: Operation
OPERATION NOTE: Homeowners generally prefer to operate their heater with FOR YOUR SAFETY the chimney damper closed. This will put all the heat into the room. READ BEFORE LIGHTING However, there may be times you will desire the full flames of the HI heat setting but will find the heat output excessive. - Page 17 OPERATION Continued After lighting, let pilot flame burn for about one minute. Turn control Flame Adjustment Knob knob to ON position. Adjust flame adjustment knob anywhere be- Control Knob tween HI and LO. Slide the selector switch to the REMOTE position (see Figure 27).
-
Page 18: Cleaning And Maintenance
CLEANING AND MAINTENANCE INSPECTING BURNERS WARNING: Turn off heater and let cool before Check pilot flame pattern and burner flame patterns often. cleaning. PILOT FLAME PATTERN Figure 28 shows a correct pilot flame pattern. Figure 29, shows an WARNING: Failure to keep the primary air incorrect pilot flame pattern. -
Page 19: Replacement Parts
WIRING DIAGRAM White Receiver Remote TPTH Gas Control TPTH TP Thermopile White SPECIFICATIONS Biltmore24LMN Biltmore24LMP Biltmore30LMN Biltmore30LMP • Rating (Variable): 20,000/39,000 Btu/Hr • Rating (Variable): 20,000/39,000 Btu/Hr • Type Gas: Natural • Type Gas: Propane/LP • Ignition: Piezo • Ignition: Piezo •... -
Page 20: Troubleshooting
TROUBLESHOOTING WARNING: Turn off heater and let cool before servicing. Only a qualified service person should service and repair heater. CAUTION: Never use a wire, needle, or similar object to clean ODS/pilot. This can damage ODS/pilot unit. WHAT TO DO IF YOU SMELL GAS •... - Page 21 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Burner does light after ODS/pilot is lit 1. Burner orifice clogged 1. Clean burner (see Cleaning and Mainte- nance, page 18) or replace burner orifice 2. Inlet gas pressure is too low 2. Contact local natural or propane/LP gas company 3.
-
Page 22: Parts
PARTS MODELS BILTMORE24LMN, BILTMORE24LMP BILTMORE30LMN AND BILTMORE30LMP Cat. No. Model F2579 Biltmore24LMN F2580 Biltmore24LMP F2581 Biltmore30LMN F2582 Biltmore30LMP NOTE: Items 28 and 29 are Natural Gas only. ComfortFlame.US.com 900556-00 NC... - Page 23 Left Back Crossover Log J4569 J4571 Left Top Crossover Log J4573 J4572 Right Btm Crossover Log — J4575 Right Top Crossover Log PART NUMBER Biltmore24LMP Biltmore24LMN Biltmore30LMP Biltmore30LMN DESCRIPTION J3830 — J3830 — ODS Pilot Assembly LP — J3831 — J3831...
-
Page 24: Accessories
ACCESSORIES RECEIVER AND THERMOSTAT REMOTE CONTROL KIT NOTICE: All accessories may not be available for Cat. No. J0385, Model CTRC all fireplace models. For all Remote-Ready Models. Allows the appliance to be operated in a manually or thermostatically controlled mode. You can turn the fire- Purchase these appliance accessories from your local dealer. -
Page 25: Warranty
THE WARRANTY Innovative Hearth Products Limited One Year Warranty ("IHP") warrants your Comfort Flame brand Gas Log Set ("Product") to be free from defects in materials and work- manship at the time of manufacture. The logs and grate carry the Limited One Year Warranty. After installation, if covered components manufactured by IHP are found to be defective in materials or workmanship during the Limited One Year Warranty period and while the Product remains at the site of the original installation, IHP will, at its option, repair or replace the covered components. - Page 26 ComfortFlame.US.com Record the following important information about your appliance: Appliance model number Appliance serial number Date appliance was Installed Type of gas appliance uses Dealer name IHP reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
