WELCOME HOME TO WARMTH
P/N 900557-00 Rev. NC 12/2015
P900557-00
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home, where not
prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate. This
appliance is not convertible for use with other gases.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. Refer to Air for Combustion and Ventilation
section on page 5 of this manual.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Installation and Operation Instructions
TM
River Canyon
Models
PFS
®
C
US
Report No. F09-126
Unvented (Vent-Free) Gas Log Appliances
TM
RiverCyn24FMN
MODELS WITH REMOTE CONTROL
LOG AND BURNER SETS:
RIVERCYN24FMN AND RIVERCYN24FMP
Also Design-Certified As Vented Decorative Appliances
RiverCyn24FMP
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Comfort Flame River Canyon 24FMN
Summary of Contents for Comfort Flame River Canyon 24FMN
- Page 1 Installation and Operation Instructions River Canyon Unvented (Vent-Free) Gas Log Appliances WELCOME HOME TO WARMTH P/N 900557-00 Rev. NC 12/2015 Models RiverCyn24FMN RiverCyn24FMP ® P900557-00 Report No. F09-126 MODELS WITH REMOTE CONTROL LOG AND BURNER SETS: RIVERCYN24FMN AND RIVERCYN24FMP Also Design-Certified As Vented Decorative Appliances INSTALLER: Leave this manual with the appliance.
-
Page 2: Table Of Contents
Thank you for your purchase. We appreciate your TABLE OF CONTENTS business! Safety ..................... 2 Please carefully read and follow all instructions in this manual. Pay Local Codes ................... 4 special attention to all warnings and safety information. Product Identification ..............4 Following these safety, care, and operation instructions will help Unpacking .................. - Page 3 SAFETY Continued Keep the appliance area clear and free from com- WARNING: Any change to this heater or its con- bustible materials, gasoline and other flammable trols can be dangerous. vapors and liquids. DANGER: Carbon monoxide poisoning may lead 1. This appliance is only for use with the type of gas indicated on the to death! rating plate.
-
Page 4: Local Codes
SAFETY Continued 14. Do not operate heater if any log is broken. Do not operate heater 17. These appliances must not be connected to any external electrical if a log is chipped (dime-sized or larger). source. 15. Turn heater off and let cool before servicing, installing or repair- 18. -
Page 5: Product Features
PRODUCT FEATURES OPERATION SAFETY DEVICE This heater is clean burning. It requires no outside venting. There is no This heater has a pilot with an Oxygen Depletion Sensing (ODS) heat loss out a vent or up a chimney. Heat is generated by both realistic safety shutoff system. - Page 6 AIR FOR COMBUSTION AND VENTILATION Continued The space in the above example is a confined space because the actual DETERMINING FRESH-AIR FLOW FOR HEATER LOCATION Btu/Hr used is more than the maximum Btu/Hr the space can support. Determining if You Have a Confined or Unconfined Space Using You must provide additional fresh air.
-
Page 7: Installation
AIR FOR COMBUSTION AND VENTILATION Continued Ventilation Air From Outdoors Provide extra fresh air by using ventilation grills or ducts. You must provide two permanent openings: one within 12" of the ceiling and Ventilated Outlet Attic one within 12" of the floor. Connect these items directly to the out- doors or spaces open to the outdoors. - Page 8 INSTALLATION Continued CHECK GAS TYPE NOTICE: Manual control heaters may be used as a Use the correct type of gas (natural or propane/LP). If your gas supply vented product. If so, you must always run heater is not the correct gas type, do not install heater. Call dealer where you with chimney flue damper open.
- Page 9 INSTALLATION Continued Mantel Shelf 12" 10" Underside of Mantel Shelf 8" Heat Resistant Heat Resistant 6" Material Material 1 /2 " All minimum distances are in inches Minimum Noncombustible Material Log Sets 8" 12" 15" 18" 20" 24" Models Min. Top of Fireplace Opening...
- Page 10 INSTALLATION Continued FLOOR CLEARANCES Area of Various Standard Round Flues A. If installing appliance on the floor level, you must maintain the Diameter Area minimum distance of 14" to combustibles (see Figure 8). 5" 20 sq. in. 6" 29 sq. in. B.
- Page 11 INSTALLATION Continued Installation Items Needed Masonry • hardware package (provided with appliance) Screw • approved flexible gas hose and fittings (not provided) (if allowed by local codes) • sealant (resistant to propane/LP gas, not provided) • electric drill with 3/16” masonry drill bit NOTE: Install Receiver and Hand-Held Remote Control before install- ing the gas log appliance.
- Page 12 INSTALLATION Continued Installation Items Needed IMPORTANT: Install equipment shutoff valve in an accessible loca- Before installing appliance, make sure you have the items listed below. tion. The equipment shutoff valve is for turning on or shutting off • external regulator (supplied by installer) the gas to the appliance.
- Page 13 INSTALLATION Continued CHECKING GAS CONNECTIONS Equipment Open Shutoff Valve WARNING: Test all gas piping and connections, internal and external to unit, for leaks after installing Closed or servicing. Correct all leaks at once. WARNING: Never use an open flame to check for a leak.
- Page 14 INSTALLATION Continued INSTALLING LOGS Middle Right Log WARNING: Failure to position the parts in ac- Middle cordance with these diagrams or failure to use only Left Log parts specifically approved with this heater may result in property damage or personal injury. Each log is marked with a number.
-
Page 15: Operation
OPERATION NOTE: Homeowners generally prefer to operate their heater with the FOR YOUR SAFETY chimney damper closed. This will put all the heat into the room. However, READ BEFORE LIGHTING there may be times you will desire the full flames of the HI heat setting but will find the heat output excessive. - Page 16 OPERATION Continued 8. Keep control knob pressed in for 30 seconds after lighting pilot. TO TURN OFF GAS After 30 seconds, release control knob. TO APPLIANCE • If control knob does not pop out when released, contact a quali- fied service person or gas supplier for repairs. 1.
-
Page 17: Cleaning And Maintenance
CLEANING AND MAINTENANCE INSPECTING BURNERS WARNING: If yellow tipping occurs, your heater Check pilot flame pattern and burner flame patterns often. could produce increased levels of carbon monoxide. PILOT FLAME PATTERN If front burner flame pattern shows yellow tipping, Figure 25 shows a correct pilot flame pattern. Figure 26 shows an follow instructions at bottom of this page. - Page 18 CLEANING AND MAINTENANCE Continued 4. Check orifice holder located at the end of the burner tube again. WARNING: Turn off heater and let cool before Remove any large particles of dust, dirt, lint or pet hair with a soft cleaning. cloth or vacuum cleaner nozzle.
-
Page 19: Replacement Parts
REPLACEMENT PARTS 4. The description of the part. See pages 23-24 for a complete replacement parts list. Use only 5. The quantity required. parts supplied from the manufacturer. 6. The installation date of the appliance. Normally, all parts should be ordered through your IHP distributor If you encounter any problems or have any questions concerning the or dealer. -
Page 20: Troubleshooting
TROUBLESHOOTING WARNING: Turn off appliance and let cool before servicing. Only a qualified service person should service and repair heater. CAUTION: Never use a wire, needle, or similar object to clean ODS/pilot. This can damage ODS/pilot unit. WHAT TO DO IF YOU SMELL GAS •... - Page 21 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY One or both burners do not light after ODS/pilot is lit 1. Inlet gas pressure is too low 1. Contact local natural or propane/LP gas com- 2. Burner orifice(s) clogged pany 2. Clean burner(s) (see Cleaning and Maintenance, page 17) or replace burner orifice(s) 3.
- Page 22 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Gas odor even when control knob is in OFF position 1. Gas leak. See Warning statement on page 20 1. Locate and correct all leaks (see Checking Gas Connections, page 13) 2. Control valve or gas control defective 2.
-
Page 23: Parts
PARTS REMOTE-READY VARIABLE CONTROL MODELS RIVERCYN24FMN AND RIVERCYN24FMP Cat. No. Model F2583 RiverCyn24FMN F2584 RiverCyn24FMP 900557-00 NC ComfortFlame.US.com... - Page 24 PARTS REMOTE-READY VARIABLE CONTROL MODELS This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replacement Parts on page 19 of this manual. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP.
- Page 25 PARTS LOG MODELS RIVERCYN24FMN AND RIVERCYN24FMP This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed under Replacement Parts on page 19 of this manual. PART NUMBER RiverCyn24FMN RiverCyn24FMP DESCRIPTION J5714 Front Right Log J5713 Front Left Log J6554...
-
Page 26: Accessories
ACCESSORIES Purchase these appliance accessories from your local dealer. If they can DAMPER CLAMP not supply these accessories, contact IHP at ComfortFlame.US.com Cat. No. F1760, Model GA6080 for referral information. You can also write to the address listed Permanently opens chimney flue damper for vented operation. on the back page of this manual. -
Page 27: Warranty
THE WARRANTY Innovative Hearth Products Limited One Year Warranty ("IHP") warrants your Comfort Flame brand Gas Log Set ("Product") to be free from defects in materials and work- manship at the time of manufacture. The logs and grate carry the Limited One Year Warranty. After installation, if covered components manufactured by IHP are found to be defective in materials or workmanship during the Limited One Year Warranty period and while the Product remains at the site of the original installation, IHP will, at its option, repair or replace the covered components. - Page 28 ComfortFlame.US.com Record the following important information about your appliance: Appliance model number Appliance serial number Date appliance was Installed Type of gas appliance uses Dealer name IHP reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
