TV Console
ITM. / ART. 1049340
Model # CSC75LC-3
IMPORTANT,
RETAIN
FOR
FUTURE REFERENCE:
READ CAREFULLY
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
1-877-494-2536 (English, French and Spanish)
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to Friday
(In U.S ., Canada, and Mexico only)
Or visit our website www.baysidefurnishings.com
Or e-mail your request to parts@baysidefurnishings.com
Date 2017-09-26 Rev. 0001-A Factory: CHYEWO
Advertisement
Table of Contents
Related Manuals for Bayside 1049340
Summary of Contents for Bayside 1049340
- Page 1 TV Console ITM. / ART. 1049340 Model # CSC75LC-3 ASSEMBLY INSTRUCTIONS IMPORTANT, RETAIN FUTURE REFERENCE: READ CAREFULLY If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S ® MANUFACTURER: Bayside Furnishings CATALOGUE: TV Console (CSC75LC-3) MADE IN VIETNAM FITS UP TO MOST 203.2 cm / 80 in...
- Page 3 Parts and Hardware List PART # PART DESCRIPTION PART FIGURE QUANTITY TV Console Adjustable Shelf (Pre-attached) Cable Wheel Small Bolt 8+1 extra Acrylic Stopper Touch-up Pen Tipping Restraint 2 sets Hardware Kit Additional tools required (not included): Phillips screwdriver, stud finder, power drill, and 3 mm / 0.1 in drill bit.
- Page 4 Assembly Instructions 1. The adjustable shelf (B) is pre-installed for shipping. If the shelf position is not to your liking, adjust it to your desired location. 2. Attach four cable wheels (C) to the backside of console with two bolts (AA) per cable wheel.
- Page 5 Assembly Instructions 3. The vented rear panel is removable. Be sure to route the cables through the side cutout, instead of through the ventilation holes. NOTE: You must install the acrylic TV stopper to prevent the TV from tipping when placing your flat panel television directly on the top panel.
- Page 6 Assembly Instructions 6. Position the console at the desired location against a wall and adjust the pre-attached floor levelers to correct tilting and/or level the doors. 7. Follow the instructions printed on the plastic bag containing the tipping restraint hardware to attach the tip-over restraints to the unit and the wall.
-
Page 7: Care And Maintenance
Should this product be defective in workmanship or materials or fail under normal use, we will repair or ® replace it for up to one (1) year from date of purchase. Every Bayside Furnishings product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
