Writing Desk
ITM. / ART. 1041240
Model # CSC48WD-1
ASSEMBLY INSTRUCTIONS
RETAIN
FOR
READ CAREFULLY
Date 2016-09-09 Rev. 0001-A Factory: ZHIFUR
LOT NUMBER:
DATE PURCHASED:
FUTURE REFERENCE:
/
/
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bayside CSC48WD-1
Summary of Contents for Bayside CSC48WD-1
- Page 1 LOT NUMBER: DATE PURCHASED: Writing Desk ITM. / ART. 1041240 Model # CSC48WD-1 ASSEMBLY INSTRUCTIONS IMPORTANT, RETAIN FUTURE REFERENCE: READ CAREFULLY If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased.
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S ® MANUFACTURER: Bayside Furnishings CATALOG: Writing Desk (CSC48WD-1) MADE IN CHINA MAXIMUM LOAD 90.7 kg / 200 lb MAXIMUM LOAD 13.6 kg / 30 lb...
- Page 3 Parts and Hardware List PART # PART DESCRIPTION PART FIGURE QUANTITY Desk Top Support Bolt 12+1 extra Lock Washer 12+1 extra Flat Washer 8+1 extra Camber Washer 4+1 extra Hex-key Wrench Tools required: Hex-key wrench (included).
- Page 4 Assembly Instructions 1. Place the desk top (A) upside down on a level and protective surface. Pull the drawer all the way forward for the following steps (remove the drawer completely, if necessary). 2. Align and attach the legs (B) to the desk top (A) with eight bolts (AA) and eight washers (BB and CC). 3.
- Page 5 Assembly Instructions 4. Ask for assistance to lift the unit upright and position it at the desired location. 5. If necessary, adjust the pre-attached floor levelers at the bottom of legs (B) to level the unit. 6. If you need to remove the drawer, please pull the drawer all the way out, then simultaneously push the plastic release lever of the ball bearing slide up on one side and down on the other side, and then pull the drawer completely out.
-
