7-Piece Dining Set
ITM. / ART. 730413
Model # CSC7PD-1
IMPORTANT,
RETAIN
FOR
FUTURE REFERENCE:
READ CAREFULLY
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
1-877-494-2536 (English, French and Spanish)
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to Friday
(In US, Canada, and Mexico only)
Or visit our website www.baysidefurnishings.com
Or e-mail your request to parts@baysidefurnishings.com
Date 2017-07-17 Rev. 0001-B Factory: UNVILT
Advertisement
Table of Contents
Related Manuals for Bayside 730413
Summary of Contents for Bayside 730413
- Page 1 7-Piece Dining Set ITM. / ART. 730413 Model # CSC7PD-1 ASSEMBLY INSTRUCTIONS IMPORTANT, RETAIN FUTURE REFERENCE: READ CAREFULLY If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
- Page 2 G E N E R A L I N F O R M A T I O N A N D T I P S 1. This product is for indoor domestic use only. 2. Please read the Assembly Instructions prior to assembling this product. 3.
- Page 3 Parts and Hardware List PART # PART DESCRIPTION PART FIGURE QUANTITY Table Top Mounting Board Outer Leg Inner Leg Stretcher...
- Page 4 Parts and Hardware List PART # PART DESCRIPTION PART FIGURE QUANTITY Bolt 16+1 extra Bolt 4+1 extra Lock Washer 20+1 extra Flat Washer 20+1 extra Wood Plug 4+1 extra Wood Dowel 6+1 extra Hex Wrench Touch-up Pen Tools required: Hex wrench (included) and rubber mallet (not included).
- Page 5 Assembly Instructions 1. Insert two wood dowels (FF) into the middle holes of the stretcher (E) at both ends. 2. Combine one outer leg (C) and one inner leg (D) together by fitting the cutouts properly. 3. Attach the leg assembly to the stretcher (E) by threading two bolts (BB) with lock washers (CC) and flat washers (DD) through the countersunk holes on the outer leg (C) and then screw into the threaded inserts on the stretcher (E).
- Page 6 Assembly Instructions 7. Place the table top (A) upside down on a level and protective surface as shown. 8. Flip the assembled base upside down and align the drilled holes on mounting boards (B) with the threaded inserts on the slide supports on the table top (A). Insert eight bolts (AA) with lock washers (CC) and flat washers (DD) through the drilled holes on the mounting boards (B) and then securely screw into the slide supports, using the enclosed hex wrench.
- Page 7 Assembly Instructions 11. Unlock the sash locks underneath the table top (A), then pull the table top wide open equally from both ends. 12. Lift the butterfly leaf from the compartment of the table top (A). Flip up the leaf and rest it on one slide support.
- Page 8 To Store the Butterfly Leaf When Not In Use 15. Unlock the sash locks underneath the table top (A), then pull the table top wide open equally from both ends. 16. Fold two centre leaves together and flip down the leaf aprons. 17.
-
Page 9: Care And Maintenance
Should this product be defective in workmanship or materials or fail under normal use, we will repair or ® replace it for up to one (1) year from date of purchase. Every Bayside Furnishings product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
