Bayside CSC6634AC-1 Assembly Instructions Manual

Accent cabinet

Advertisement

Quick Links

IMPORTANT,
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Accent Cabinet
ITM. / ART. 1041180
Model # CSC6634AC-1
RETAIN
READ CAREFULLY
1-877-494-2536 (English, French and Spanish)
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to Friday
(In US, Canada, and Mexico only)
Or visit our website www.baysidefurnishings.com
Or e-mail your request to parts@baysidefurnishings.com
Date 2016-04-19 Rev. 0001-A Factory: LONWEA
FOR
FUTURE REFERENCE:
LOT NUMBER:
DATE PURCHASED:
/
/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSC6634AC-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bayside CSC6634AC-1

  • Page 1 LOT NUMBER: DATE PURCHASED: Accent Cabinet ITM. / ART. 1041180 Model # CSC6634AC-1 ASSEMBLY INSTRUCTIONS IMPORTANT, RETAIN FUTURE REFERENCE: READ CAREFULLY If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased.
  • Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S ® MANUFACTURER: Bayside Furnishings CATALOG: Accent Cabinet (CSC6634AC-1) MADE IN CHINA FITS UP TO MOST 190.5 cm / 75 in FLAT PANEL TVs MAXIMUM LOAD 61.2 kg / 135 lb...
  • Page 3 Parts and Hardware List PART # PART DESCRIPTION PART FIGURE QUANTITY Cabinet Side Foot Middle Foot Side Adjustable Shelf (Pre-attached) Middle Adjustable Shelf (Pre-attached)
  • Page 4 Parts and Hardware List PART # PART DESCRIPTION PART FIGURE QUANTITY Bolt 12 + 1 extra Lock Washer 12 + 1 extra Flat Washer 12 + 1 extra Acrylic Stopper Hex-key Wrench Touch-up Pen Tipping Restraint 2 sets Hardware Kit Additional tools required (not included): Phillips screwdriver, rubber mallet, power drill, and 9.5 mm / 0.3 in drill bit.
  • Page 5 Assembly Instructions 1. Lay the cabinet (A) at its back edge carefully. Align and attach the feet (B and C) to the bottom of cabinet with two bolts (AA), two lock washers (BB) and two flat washers (CC) per foot. Tighten the bolts with the enclosed hex wrench.
  • Page 6 Assembly Instructions NOTE: You must install the Acrylic TV Stopper to prevent the TV from tipping when placing your flat panel television directly on the top panel. 4. Remove the paper backing of acrylic stopper (DD), align the acrylic stopper into the cut-out on the acrylic stopper template.
  • Page 7 Assembly Instructions 8. Position the cabinet (A) at the desired location against a wall and adjust the pre-attached floor levelers to correct tilting and/or level the doors. 9. Follow the instructions printed on the plastic bag containing the tipping restraint hardware to attach the tip-over restraints to the unit and the wall.
  • Page 8: Care And Maintenance

    Should this product be defective in workmanship or materials or fail under normal use, we will repair or ® replace it for up to one (1) year from date of purchase. Every Bayside Furnishings product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
