- Page 1 I N S TA L L AT I O N A N D S E T U P G U I D E i D E V I C E S S M A R T H O M E S O L U T I O N S...
- Page 2 R E Q U I R E S T O O L S N E E D E D • A compatible iDevices product When installing into a gang box, you • iDevices Connected app will need the following tools: •...
- Page 3 • Ambient operating conditions: 32º F to 104º F (0º C to 40º C), 0-90% humidity, non-condensing. • The iDevices Instant Switch uses 1 CR2032 coin cell battery ONLY. Do not use a rechargeable battery. Using an improper battery may damage the iDevices Instant Switch. Please dispose of this battery at a recycling facility. Contact your local waste disposal provider to find a recycle center location nearest you.
-
Page 4: Before You Start
Connected app before attempting to setup your Instant Switch. To find information on compatible products and how to update firmware, visit iDevicesinc.com/Compatibility/ Instant-Switch • Wherever possible, install the iDevices Instant Switch in a non- metal gang box and use a non-metal or metallic faceplate, as metal gang boxes and faceplates can decrease the Bluetooth ®... - Page 5 • It is YOUR responsibility to be sure that products are installed in accordance with applicable building codes. Check with your local building office if you have questions. • If you need further help on your Instant Switch installation, please visit our support page at iDevicesinc.com/Support/Instant-Switch • Download the free iDevices Connected app.
- Page 6 D E V I C E S I N S TA N T S W I T C H Turn On/Increase Brightness. (Note: Dimmable feature only available when paired to a dimmable iDevices product). Single tap to turn on. Press and hold to increase brightness level. Double tap to quickly increase light to maximum brightness.
- Page 7 3M Command™ Strip Access Door. Remove to access 3M Command™ Strip when removing Instant Switch from wall. Level. Built-in level ensures precise installation. Instant Switch Unit Removal. Press sides to remove Instant Switch from mounting plate to access battery. Pairing Reset. Press and hold for 10 seconds, until LED blinks red.
- Page 8 G E T T I N G T O K N O W T H E i D E V I C E S I N S TA N T S W I T C H ( C O N T. ) Ground Wire Assembly.
-
Page 10: Using For The First Time
USING FOR THE FIRST TIME REMOVE BATTERY PULL TAB Before using the iDevices Instant Switch for the first time, you will need to remove the battery tab. Pull the plastic tab out from the back of the product and discard. Once the battery tab is removed, the Instant Switch will automatically enter pairing mode for 30 minutes. - Page 11 Next, launch the iDevices Connected app. The app will guide you through setup and placement of the Instant Switch in your home. Once the in-app setup is complete, follow the steps on page 12 to complete the installation.
-
Page 12: Installation Methods
There are 3 methods in which you may install your Instant Switch: By itself on the wall, using the provided 3M Command™ Strip and iDevices custom faceplate or a standard rocker faceplate of your choice. Next to an existing gang box, using the provided 3M... - Page 14 • Peel off the other side of the plastic backing and ensure that the product is level before pressing firmly to the wall. Hold for 30 seconds. • Install the magnetic iDevices faceplate, or a rocker style faceplate of your choice. If the faceplate you choose requires screws, use the shorter, 6mm screws provided to anchor the faceplate to the...
- Page 16 INSTALL NEXT TO GANG BOX • Install the 3M Command™ Strip onto the back of the Instant Switch. • Mount the faceplate onto the Instant Switch using the provided 6mm screws. • Peel off the plastic backing of the 3M Command™ Strip. •...
- Page 18 INSTALL INTO GANG BOX • Turn OFF the power to the circuit you are working on at your home’s breaker or fuse panel. • Install the ground wire assembly onto the access door of the Instant Switch.
- Page 20 INSTALL INTO GANG BOX (CONT.) • Connect the ground wire on the Instant Switch to the ground wire in the gang box, which is usually bare copper or green.
- Page 21 GROUND (Usually Bare Copper or Green)
- Page 22 • Turn the power back ON at your circuit breaker. NOTE: It is not intended to use the iDevices faceplate when mounting the iDevices Instant Switch in a gang box. Instead, use a standard rocker faceplate of your choice (not included).
-
Page 24: Replacing Battery
B AT T E RY REPLACING BATTERY • The iDevices Instant Switch uses a standard CR2032 battery ONLY, and lasts up to 2 years. • Access the battery by pressing the module assembly in where noted and tilting the top toward you to remove from the mounting plate. - Page 26 REPLACING THE MODULE ASSEMBLY • Line up the tabs on the bottom of the module assembly with the arrows on the bottom of the mounting plate. • Tilt the top of the module assembly up and press it firmly until it clicks into place. CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.
- Page 28 R E M O V I N G Y O U R WA L L M O U N T E D I N S TA N T S W I T C H • Remove the access door to expose the end of the 3M Command Strip.
-
Page 30: Reference Information
R E F E R E N C E I N F O R M AT I O N LED COLOR CODES LED State Instant Description Instant Switch is in pairing mode. The LED flashes blue. Blue Flash Pairing mode has been completed. The LED will turn solid blue. Solid Blue When the product setup or software update is complete, the LED flashes green 5 times. - Page 31 On button press, if battery needs replacement, the LED will rapidly flash red 5 times. Red Flash On button press, if Instant Switch has lost the link with its paired iDevices product, the LED will turn solid red for 5 seconds. Solid Red When Instant Switch powers on, it will flash white.
- Page 32 S U P P O RT If at any time you require assistance, please contact our Customer Experience Team. 888.313.7019 Support@iDevicesinc.com iDevicesinc.com/Support...
-
Page 33: Troubleshooting And Support
T R O U B L E S H O O T I N G A N D S U P P O RT A DEVICE RESET CAN RESOLVE MOST ISSUES. Device Reset. Press and hold 7+1 simultaneously for 10 seconds, then release to cycle power to the device. -
Page 34: Regulatory Information
R E G U L AT O RY I N F O R M AT I O N Product Information: Manufacturer: iDevices LLC Model: IDEV0020 FCC: 2ABDJ-IDEV0020 IC: 11569A-IDEV0020 The iDevices Instant Switch IDEV0020 is certified to comply with applicable FCC and IC rules and regulations governing RF and EMI emissions. -
Page 35: Fcc Notice
FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 36 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician to help. • Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. IC Notice This Class B digital apparatus complies with Canadian ICES-003.
- Page 37 brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. This device complies with the Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 38 Google Play logo are trademarks of Google Inc. The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by iDevices is under license. Other trademarks and trade names are those of their respective owners.
