THE COOKTOP LIGHT
To turn on the fluorescent light under the upper oven, push the button underthe
control panel marked TOP LITE. Hold it in for a second before letting it go. Push it
again to shut off the light.
To replace the light tube:
1.
Turn off the electric power 2. Remove the 3 screws and
at main power supply front metal trim that sup-
ports the light cover. The
glass is heavy. Hold it
securely.
3. With both hands, lower
the front of the cover a
little and pull it straight
toward you.
4. Turn top of fluorescent
tube toward you until It
comes out of the recep-
tacles at both ends
5. Replace with a 20-watt
cool-white fluorescent
tube
6. With both hands, care-
fully fit the glass cover
into the metal support
trim at the back.
;.
Slide the cover back far
enough for the front to
fit behind the sprrng tabs
at the ends.
8. Replace the front support
trim and the 3 screws.
9. Turn electric power back
on at main power supply.
The oven vent
Hot air and moisture escape
from the lower oven through a
vent under the right rear surface
unit You can cook on the unit,
or keep food warm on it while
the oven is on. Plastic utensils
left over the vent can melt.
Do not block the vent. Poor
baking can result
16
