HOBO® U-Shuttle (U-DT-x) Manual
HOBO U-Shuttle
Models: U-DT-1
U-DT-2
Included Items:
• 30 cm (12 inch) serial
logger cable
• USB cable
Required Items:
• HOBOware 2.2 or later for
U-DT-1
• HOBOware 2.6 or later for
U-DT-2
• Compatible logger with
appropriate cable and/or
base station
13401-F MAN-UDTx
Shop for Data Logging products online at:
The U-DT-1 is compatible with all U-Series loggers (except the HOBO U30 Station), all UX-Series
loggers, HOBO Weather Stations and Micro Stations (H21), and the HOBO Energy Logger (H22).
The U-DT-2 is compatible with the HOBO U30 Station, HOBO Weather Stations and Micro
Stations (H21), and HOBO Energy Logger (H22).
The HOBO U-Shuttle performs the following major functions:
•
Reads out data from loggers in the field for transfer to a host computer
• Optionally relaunches the logger—synchronizes the logger's clock with the shuttle's
clock and (in most cases) sets logging to begin at the next interval
• Preserves data in nonvolatile memory, even if batteries are depleted
• Displays logger status, including memory, battery level, and sensor readings for some
sensors (on some models)
• Displays its own status, including clock, memory, and battery level
• Lets you change the batteries in the field without resetting the clock
• Allows you to test individual smart sensors (does not support the TRMSA-D)

Specifications

Compatibility U-DT-1: All U-Series loggers, all UX-Series loggers, HOBO Weather Stations
and Micro Stations (H21), and HOBO Energy Logger (H22)
U-DT-2: HOBO U30 Station, HOBO Weather Stations and Micro Stations
(H21), and HOBO Energy Logger (H22)
Firmware Upgrades Available on the Onset website as needed to provide compatibility with
future supported logger models
Operating Temperature 0° to 50°C (32° to 122°F)
Storage Temperature -10° to 50°C (14° to 122°F)
Time Accuracy ±1 minute per month at 25°C (77°F); see Plot A
Logger-to-Shuttle Transfer USB/optic: 64K in approximately 30 seconds
Speed Serial: 512K in approximately 60 seconds
Shuttle-to-Host-Transfer Full shuttle offload (4 MB) to host computer in 3 to 5 minutes, depending
Speed on computer
Data Capacity (Full 4 MB (minus 64 KB for shuttle information): enough for 504 readouts of 8K
Loggers) loggers, 63 readouts of 64K loggers, or 7 readouts of 512K loggers
Idle Timeout Shuttle powers down after two minutes of idle time, except when actively
communicating with HOBOware (see HOBOware User's Guide for details)
or changing logger batteries (10 minutes)
Ports RJ-12 jack for communicating with smart sensors; mini-B full speed USB
port for communicating with host computer; full speed USB port for
communicating with U-Series loggers and base stations; high speed serial
port for communicating with serial loggers. Shuttle communicates with
only one device at a time.
Batteries Main: 2 AA alkaline batteries / Clock backup: 1 CR1225 lithium battery (3 V)
Battery Life Main: 2 AA alkaline batteries / Clock backup: 1 CR1225 lithium battery (3 V)
Weight 153 g (5.4 oz)
Dimensions 11.0 x 6.9 x 2.7 cm (4.35 x 2.70 x 1.05 inches)
Case Materials ABS case with urethane rubber grips, polycarbonate label
The CE Marking identifies this product as complying with all relevant
directives in the European Union (EU). To maintain CE compliance, this
product must be used with the supplied USB cable or equivalent (less than
3 m long).
