Tynetec ZXT427 Manual

__________________________________________________________________________________________________________
Where should Gas & Carbon Monoxide Detectors be fitted?
Combined Gas & Carbon Monoxide (CO) detectors should be fitted in all rooms with a fuel burning appliance such as a boiler or
gas cooker and where a lot of time is spent e.g. the kitchen or living room.
They should not be fitted in the bathroom or areas subject to steam, damp or humidity.
Choosing a Location
The combined gas & CO detector should be wall mounted in the highest part of the room, approx 300mm from the ceiling and
between 1 and 5 metres from the appliance.
The combined gas & CO detector should not be located inside a cupboard, behind a curtain, directly above the cooker or sink, next
to a door or window or near an extractor fan.
The combined gas & CO detector should be within 5 metres of a mains socket otherwise the cable provided will need extending.
Typical Tools Required
Be careful when using step ladders – always face the direction you are working.
Always make sure the correct drill bits and screwdrivers are used.
Installation
1. Fix the mounting plate complete with detector to the wall using
the screws and plugs provided through FIXING HOLES "A".
2. Run the mains lead to the nearest socket and secure using
the self adhesive cable clips provided.
3. Plug‐in and switch on the mains supply – the GREEN ON light
will FLASH for about 2 minutes during the sensor warm‐up period.
4. When the GREEN ON light goes steady the unit is operating normally.
Doc No. FM0471 issue F Page 1
169MHz Telecare Devices
Gas & Carbon Monoxide Detector











4 FIXING HOLES "A"
Compatible with Reach at‐home alarms, Advent xt warden call,
Altec Response and Touchsafe Pro Nursecall systems
Gas alarm activates at 10% of Lower Explosive Limit
CO alarm activates on Time Weighted Average;
30ppm 2hrs, 50ppm 1hr, 100ppm 10mins or 300ppm 0‐3mins
85dB @ 3m sounder
Indicator lights: green power, yellow fault & red alarm
Requires 240V AC mains supply (5m lead & plug supplied)
Transmitter low battery warning
Complies with EN50194 (Gas) & EN50291 (CO)
Backplate dimensions: 175 x 140mm (depth = 55mm)
Weight: 640 grams
Product Code: ZXT427
A
TRANSMIT
GAS
Tynetec and Aidcall are business units of Legrand Electric Ltd
Unit 10 Cowley Road, Blyth Riverside Business Park, Blyth
Northumberland, NE24 5TF. Tel: 01670 352 371 Fax: 01670 362 807
Email: sales@tynetec.co.uk Web: www.tynetec.co.uk
A
TRANSMIT
CO

A
