ICS Tunnel Master Jr Manual page 77

My Epson Dot Matrix printer
is printing garbage
All of my equipment is
shutting off half way through
the tunnel.
I am getting unloaded cars
on my shift reports.
Troubleshooting
TUNNEL MASTER JR MANUAL
Printer dipswitch settings are
incorrect.
Faulty Gate Switch. Invalid /
Max car violation.
Min Car Length set too high.
Cars not being loaded properly.
Antibounce is set incorrectly.
Turn printer upside down.
Loosen the screw to get to the
dipswitches. DSW1 # 3 should
be on and everything else should
be off.
Test your Gate switch. If you
have photo eyes, put something
in front of them and see if the
gate light on the relay box to see
if it comes on. If you have a logo
loop, put something metal over
the loop and see if the gate light
on the relay box comes on. If the
gate does not function properly,
set Auto Gate to Y. See Wash
Controller Input Check on page
68.
If your Min Car Length is set too
high, and a car that is less than
the min car length comes through
the eye, the system will not
register it as a car and the
equipment will shut off.
Roller is called up manually
without a service being loaded.
Your antibounce should be
higher than your pulse length and
less then your min car length.
77
