Outputs - ICS Tunnel Master Jr Manual

Anti Collision
Auto Stop Period Enter the number of seconds after the last car you want
Wet Down
Period
Flash On
Flash Off
Shift
Auto Shift
Tax Rate 1 %
Tax Rate 2 %
Stacking
Input Device
Push Button
Rows
Push Button
Cols
Console Debug
Wash Configuration
TUNNEL MASTER JR MANUAL
This is going to be the distance from first gate input to
where you want the anti collision feature to trigger.
See the page 14 for the anti-collision diagram and for
a detailed explanation. (Must have Panic Enable
Circuit wired in.)
the system to automatically shut the conveyor off. You
must have an Auto Stop output wired and setup in
order for this feature to work.
Enter the number of seconds you would like to have
the wash equipment turned on for the wet down
process. A wet down will fire all of the outputs that
have Y for the wet down option.
In 100 mili-seconds increments how long the relay will
flash on. This is what the system looks at when you set
the output flash to Y.
In 100 mili-seconds increments how long the relay will
flash off. This is what the system looks at when you set
the output flash to Y.
This displays the shift number that the system is
currently on. You cannot change this setting.
Enter Y for yes, N for no. If you set this option to Y,
the system will automatically close the shift at
midnight. This option should be set to Y if you are
using the TMJ Interface.
The percentage rate for the first tax rate charge.
The percentage rate for the second tax rate charge.
Enter Y for yes or N for no. If you set this option to Y,
the system will start stacking. This option should be
set to N if using the TMJ Interface.
This is set K for keypad, P for push button or C for
Computer / Controller. This is used to interface with
Tunnel Master Sr.
If a push button entry station is being used, enter the
number of rows, going across, of buttons on the
station. This will tell the system what inputs to accept.
If you do not have a push button station, this option is
disregarded.
If a push button entry station is being used, enter the
number of columns, going down, of buttons on the
station. If you do not have a push button station, this
option is disregarded.
This is a debug utility that ICS may use to track system
activity. This should be set to N if you are using the
TMJ Interface.
41
