Page 1 MC770 / MC770+ / MC780 / MC780+ MPS3537mc / MPS3537mc+ MPS4242mc / MPS4242mc+ Maintenance Manual (2 of 2) Controller Unit 051515B...
Page 2 Nothing contained herein shall be construed as conferring by estoppel, implication or otherwise any license or right under any patent or trademark of Oki Data, Oki Electric Industry Co., Ltd. ("Oki Electric"), or any third party. Except as provided above nothing contained herein shall be construed as conferring any license or right under any Oki Data copyright.
Page 3 Oki Data CONFIDENTIAL Document Revision History Corrected items Person in Rev.No. Date charge Page Description of change 2013-04-10 ISSUE P2E1 T. Asaba ii / 45584901TH Rev.1...
Page 4 • FLOIL is a registered trademark of Kanto Kasei Ltd. CORPORATION. • Molykote is a registered trademark of Dow Corning Corporation. • Web Page is a trademark of OKI DATA Corporation. • Other company names and product names in this manual are the trademarks of their respective companies.
Page 5 Oki Data CONFIDENTIAL GeNeRaL PReCaUTIONs ReGaRDING THe seRVICe FOR THIs eQUIPmeNT The installation and service shall be done by a qualified service technician. 1. Transportation/Installation - When transporting/installing the equipment, employ two or more persons and be sure to hold the positions as shown in the figure. The equipment is quite heavy and weighs approximately 60 kg (132.27 lb.) (including the finisher), therefore pay full attention when...
Page 6 Be sure to handle/install them properly. If these parts are short-circuited and their functions become ineffective, they may result in fatal accidents such as a burnout. Avoid short-circuiting and do not use parts not recommended by OKI DATA Corporation. 45584901TH Rev.1...
Page 7 Oki Data CONFIDENTIAL 4. Cautionary Labels - During servicing, be sure to check the rating plate and cautionary labels to see if there is any dirt on their surface and if they are properly stuck to the equipment. [1] Identification label 5.
Page 8 Oki Data CONFIDENTIAL aLLeGemeINe sICHeRHeITsmassNaHmeN IN BeZUG aUF DIe WaRTUNG Die Installation und die Wartung sind von einem qualifizierten service- Techniker durchzuführen. 1. Transport/Installation - Das Tragen oder Installieren des Gerätes braucht wenigstens zwei Menschen. Die angezeigten Stellen sind wie in der Abbildung festzuhalten. Das Gerät ist ziemlich schwer und wiegt ungefähr 60 kg (mit dem Finisher);...
Page 9 Wenn diese Teile kurzgeschlossen und funktionsunfähig werden, kann dies zu schwerwiegenden Schäden, wie einem Abbrand, führen. Kurzschlüsse sind zu vermeiden, und es sind ausschließlich Teile zu verwenden, die von der OKI DATA Corporation empfohlen sind. viii / 45584901TH Rev.1...
Page 10 Oki Data CONFIDENTIAL 4. Warnetiketten - Im Rahmen der War tung unbedingt das Leistungsschild und die Etiketten mit Warnhinweisen überprüfen [z. B. „Unplug the power cable during service“ („Netzkabel vor Beginn der Wartungsarbeiten abziehen“), „CAUTION. HOT“ („VORSICHT, HEISS“), „CAUTION. HIGH VOLTAGE“ („VORSICHT, HOCHSPANNUNG“), „CAUTION. LASER BEAM“...
Page 11 Oki Data CONFIDENTIAL CONTeNTs sPeCIFICaTIONs/sYsTem LIsT ..............1-1 Specifications ..................1-1 1.1.1 General ......................1-1 1.1.2 HDD Memory Map ..................1-2 System List ................... 1-3 DIsassemBLY aND RePLaCemeNT ............2-1 Removal and Installation of Options ............. 2-1 2.1.1 Inner Finisher (MJ-1038) ................2-1 2.1.2...
Page 12 Oki Data CONFIDENTIAL 3.13 List print mode (9S) ................3-32 3.13.1 Operation procedure ..................3-32 3.13.2 List Printing ....................3-33 seTTING / aDJUsTmeNT ................4-1 Image Related Adjustment ..............4-1 4.1.1 Adjustment Order .................... 4-1 4.1.2 Performing density correction ................. 4-2 4.1.3...
Page 13 Oki Data CONFIDENTIAL 4.4.14 JPEG compression level adjustment ............4-30 4.4.15 Color conversion table selection ..............4-30 eRROR CODe aND TROUBLesHOOTING ..........5-1 General Descriptions ................5-1 5.1.1 If a problem continues even after performing all troubleshooting....5-1 5.1.2 Collection of debug logs with a USB device ...........
Page 14 Oki Data CONFIDENTIAL 6.2.3 Precautions and procedures when replacing the HDD ......... 6-11 6.2.4 Precautions and Procedures when replacing the CU board ......6-16 6.2.5 Precautions and procedure when replacing the SRAM board (for the CU board) ..................6-20 6.2.6 Precautions and Procedures when replacing the PU board ......
Page 15 Oki Data CONFIDENTIAL 9.1.3 Backup files..................... 9-2 9.1.4 Cloning procedure ..................9-2 AES Data Encryption Function Setting ..........9-5 9.2.1 General description ..................9-5 9.2.2 Precautions ....................9-5 9.2.3 Setting procedure ................... 9-6 9.2.4 Procedure for disabling data encryption function .......... 9-10 9.2.5...
Page 16: Specifications/System List
Oki Data CONFIDENTIAL sPeCIFICaTIONs/sYsTem LIsT Specifications 1.1.1 General Memory Main memory 2 GB (including page memory) (RAM) Page Memory Included in main memory 160 GB Account Codes 10000 codes Department Codes 1000 codes Machine version ODA: US, Canada, LA OEL: Europe...
Page 17: Hdd Memory Map
Oki Data CONFIDENTIAL 1.1.2 HDD Memory Map Category Item Unit Copy Memory copy e-Filing 80 (Shared with e-filing/Strage file) Public box User box Folders per box Folder Documents per box Document 400 Pages per document Page Number of maximum jobs Job...
Page 18: System List
Oki Data CONFIDENTIAL System List IC Card Reader(F) 45535901 (KP-2006) Antenna IC Card Reader(H) 45518001 (GN-3010) 45518501 (KP-2004) IC Card Reader(M) Wireless LAN module 45518601 45517901 (KP-2005) (GN-1060) Meta Scan Enabler 45518201 Inner Finisher (GS-1010) 45372301 (MJ-1038) External Interface Enabler...
Page 19: Disassembly And Replacement
Oki Data CONFIDENTIAL DIsassemBLY aND RePLaCemeNT Removal and Installation of Options Important: • Before installing or removing options, turn the main power switch off and disconnect the power cable from the outlet. 2.1.1 Inner Finisher (MJ-1038) (1) Press the [Power] button on the control panel to shut it down.
Page 20 Oki Data CONFIDENTIAL (6) Take off the connector cover. Fig. 2-3 (7) Disconnect the connector. Fig. 2-4 (8) Remove 2 screws and take off the finisher. Fig. 2-5 2-2 / 45584901TH Rev.1...
Page 21: Fax Unit (Gd-1340)
Oki Data CONFIDENTIAL 2.1.2 Fax Unit (GD-1340) Refer to  P. 6-7 “6.1.6 FAX unit”. 2.1.3 Option-Tray (1) Press the [Power] button on the control panel to shut it down. (2) Turn the main power switch of the equipment off.
Page 22: Caster Stand
Oki Data CONFIDENTIAL 2.1.4 Caster Stand (1) Press the [Power] button on the control panel to shut it down. (2) Turn the main power switch of the equipment off. (3) Disconnect the power cable. (4) Release the lock. Fig. 2-8 (5) Remove 2 screws and take off 2 fixing brackets.
Page 23: Spacer
Oki Data CONFIDENTIAL 2.1.5 Spacer (1) Press the [Power] button on the control panel to shut it down. (2) Turn the main power switch of the equipment off. (3) Disconnect the power cable. (4) Remove 2 screws and take off 2 fixing brackets.
Page 24: Offline Stapler
Oki Data CONFIDENTIAL 2.1.6 Offline Stapler (1) Press the [Power] button on the control panel to shut it down. (2) Turn the main power switch of the equipment off. (3) Disconnect the power cable. (4) Take off the right side cover.
Page 25: Self-Diagnostic Mode
Oki Data CONFIDENTIAL seLF-DIaGNOsTIC mODe Overview [a] starting each mode To enter the desired mode, turn the power ON while pressing two digital keys designated to each mode (e.g. [0] and [5]) simultaneously. Hold the two keys until the [DATA] lamp is lit.
Page 26 Oki Data CONFIDENTIAL Note: Do not enter any of the modes shown below since they are provided only for production. If you do so, the equipment may not be restarted. [2]+[CLEAR]+[POWER] [7]+[CLEAR]+[POWER] [8]+[CLEAR]+[POWER] [9]+[CLEAR]+[POWER] [D] state transition diagram of self-diagnosis modes...
Page 27 Oki Data CONFIDENTIAL • Test mode (03) Refer to  P. 3-7 “3.3 Input check (Test mode 03)” and  P. 3-8 “3.4 Output check (test mode 03)”. • Test print mode (04) Refer to  P. 3-9 “3.5 Test print mode (test mode 04)”.
Page 28 Oki Data CONFIDENTIAL • Password reset mode (489) This mode resets the administrator password and service password. The user data is erased when resetting the passwords. Operation procedure [4][8][9] (Operation started) [POWER] OFF/ON [POWER] (Exit) • SRAM data cloning mode (59) Refer to ...
Page 29: Service Ui
Oki Data CONFIDENTIAL Service UI 3.2.1 Overview The following self-diagnostic modes can be used with Service UI on the touch panel of the control panel. • 05 ADJUSTMENT MODE • 08 SETTING MODE • FAX LIST PRINT MODE • CHART PRINT MODE 3.2.2...
Page 30: Service Mode] Screen
Oki Data CONFIDENTIAL [2] In the security mode If the security mode (the value of 08-8911 is “3”) is set, log into Service UI following the steps below. (1) Turn the power ON. (2) Enter the user name and password on the USER AUTHENTICATION screen. The password needs to be changed to log in for the first time.
Page 31: Input Check (Test Mode 03)
Oki Data CONFIDENTIAL Input check (Test mode 03) The status of each input signal can be checked by pressing the [FAX] button, [COPY] button, [SCAN] button and the digital keys in the test mode (03). <Operation procedure> [FAX] [0][3] [COPY]...
Page 32: Output Check (Test Mode 03)
Oki Data CONFIDENTIAL Output check (test mode 03) Status of the output signals can be checked in the test mode 03. <Operation procedure> Procedure 1 [0][3] Operation Stop Operation [POWER] OFF/ON [START] (Code) [START] code [POWER] (Exit) Procedure 2 [0][3]...
Page 33: Test Print Mode (Test Mode 04)
Oki Data CONFIDENTIAL Test print mode (test mode 04) The embedded test pattern can be printed out in the test print mode (04). <Procedure 1> [POWER] [0][4] (Code) (Media selection) [START] Operation [CLEAR] OFF/ON [POWER] Continuous (Exit) Test Printing <Procedure 2>...
Page 34: Operation Procedure In Adjustment Mode (05)
Oki Data CONFIDENTIAL Operation Procedure in Adjustment Mode (05) Procedure 1 [Digital key] [FAX] [OK] [POWER] [Digital key] [0][5] * [RESET] [START] OFF/ON (Code) [POWER] (Key in a value) [INTERRUPT] [START] (Exit) [CANCEL] (Stores value in RAM) (Test copy) [CLEAR] *Press [RESET] to enter minus (-).
Page 35 Oki Data CONFIDENTIAL Procedure 7 [CANCEL] [FAX] [OK] [POWER] [0][5] [Digital key] [Digital key] Automatic [START] [START] Stores value (Code) (Sub code) adjustment OFF/ON [POWER] [START] in RAM (Exit) (Test copy) [CLEAR] (Corrects value) *[CANCEL] or [CLEAR] * When the automatic adjustment ends abnormally, an error message is displayed.
Page 36: Test Print Pattern In Adjustment Mode (05)
Oki Data CONFIDENTIAL Test print pattern in Adjustment Mode (05) Operation: One test print is printed out when the [FAX] button is pressed after the code is keyed in at Standby Screen. Code Types of test pattern Remarks Copier gamma adjustment pattern Refer to 4.2.1Automatic gamma adjustment...
Page 37 Oki Data CONFIDENTIAL Code Types of test pattern Remarks Printer gamma correction table confirmation pattern Refer to 4.3.1Automatic gamma adjustment (Thin paper/PS/600dpi) Copier gamma adjustment pattern Refer to 4.2.1Automatic gamma adjustment (Color & black integrated / Plain paper) Copier gamma confirmation pattern Refer to 4.2.1Automatic gamma adjustment...
Page 38 Oki Data CONFIDENTIAL Code Types of test pattern Remarks Copier gamma adjustment pattern Refer to 4.3.1Automatic gamma adjustment (Thick paper 2 / PS / 1200dpi) Copier gamma confirmation pattern Refer to 4.3.1Automatic gamma adjustment (Thick paper 2 / PS / 1200dpi) Copier gamma adjustment pattern Refer to 4.3.1Automatic gamma adjustment...
Page 39 Oki Data CONFIDENTIAL Code Types of test pattern Remarks Printer gamma correction table confirmation pattern Refer to 4.3.1Automatic gamma adjustment (Special paper 5 / PS / 600dpi) Printer gamma correction table creation pattern Refer to 4.3.1Automatic gamma adjustment (Special paper 6 / PS / 600dpi) Printer gamma correction table confirmation pattern Refer to 4.3.1Automatic gamma adjustment...
Page 40: Operation Procedure In Setting Mode (08)
Oki Data CONFIDENTIAL Operation Procedure in Setting Mode (08) Procedure 1 [CANCEL] [OK] [0][8] [Digital key] [POWER] OFF/ON [Digital key] [START] [POWER] (Code) (Exit) *[RESET] [INTERRUPT] Sets or (Stores value in RAM) changes value [CLEAR] (Corrects value) * Press [RESET] to enter minus (-).
Page 41 Oki Data CONFIDENTIAL Procedure 9 [CANCEL] [OK] [0][8] [Digital key] [POWER] OFF/ON [Select button] [START] [POWER] (Code) (Exit) [INTERRUPT] (Stores value in RAM) [CLEAR] (Corrects value) Procedure 10 [CANCEL] [OK] [POWER] [0][8] [Digital key] [Digital key] [Digital key] [START] [START]...
Page 42: Assist Mode (3C)
Oki Data CONFIDENTIAL Assist Mode (3C) 3.9.1 General description This is a mode to operate the partitions of HDD, initialize the SRAM data, erase the HDD/SRAM data, back up/restore the encryption key and licences. Functions: • Clearing update error flag (Clear Error Flag in Software Installation) •...
Page 43 Oki Data CONFIDENTIAL [C] Creating HDD partition (Format HDD) When the HDD is replaced or UI data, etc. are downloaded using the USB storage, it is necessary to format a partition in the HDD before downloading. In this case, the partition is created in the HDD with this function.
Page 44 Oki Data CONFIDENTIAL [F] erasing HDD securely (erase HDD securely) This function is used when installing Data Overwrite Enabler (GP-1070) or before discarding the HDD. It overwrites all the used areas on the HDD with the selected data, and makes it unusable.
Page 45: Hdd Assist Mode (4C)
Oki Data CONFIDENTIAL 3.10 HDD Assist Mode (4C) 3.10.1 General description This mode is available only when the security HDD (ADI-HDD) is mounted in the equipment. It enables you to check the type of the mounted HDD, revert the ADI-HDD to the factory default or remove keys.
Page 46 Oki Data CONFIDENTIAL • When a normal HDD is mounted HDD Assist Mode System Firmware Version : xxxx(x.x.x.x) Current HDD type: SATA HDD Update Mode : 4c Mode Select number (1-2) and press START key 1. Revert factory initial status HDD 2.
Page 47: Functions
Oki Data CONFIDENTIAL 3.10.3 Functions [a] 1. Revert factory initial status HDD Select this to dispose of the ADI-HDD as well as the equipment. When this item is selected, all data in the HDD are deleted and the HDD is reverted to its initial status at the factory shipment.
Page 48 Oki Data CONFIDENTIAL [B] 2. Remove key Select this to reuse the ADI-HDD as well as the equipment. When this item is selected, all image data in the HDD are deleted. This operation requires approx. 20 minutes since the partition must be rebuilt.
Page 49: File System Recovery Mode (5C)
Oki Data CONFIDENTIAL 3.11 File System Recovery Mode (5C) 3.11.1 Overview This is a mode to check if there is any damage to the file system (HDD) and recover it if necessary. Use this mode only in the following cases:.
Page 50: Functions
Oki Data CONFIDENTIAL 3.11.3 Functions [a] Check of the File system (Check F/s) In case that particular service calls occur or there is a possibility of damage to the file system, the status of each partition in the HDD can be checked.
Page 51 Oki Data CONFIDENTIAL [C] Initialize the File system (Initialize HDD) In case that an error occurs during the file system check and the partition cannot be recovered with the recovery, each partition can be initialized. It is recommended to export the user information such as address book before performing this function.
Page 52 Oki Data CONFIDENTIAL [D] Initialize the DB (Initialize DB) In case that particular service calls occur or there is a possibility of damage to the databases, each one can be initialized. File System(F/S) Recovery Mode -> Initialize DB Please Select Partition 0: Main menu 1.
Page 53 Oki Data CONFIDENTIAL [F] Displaying usage rate of each partition (DIsk Info) The usage rate of each partition can be checked. When this item is selected, the usage rate of each partition is displayed. File System(F/S) Recovery Mode -> DISK Info...
Page 54: Sram Clear Mode (6C)
Oki Data CONFIDENTIAL 3.12 SRAM Clear Mode (6C) 3.12.1 General description This is a mode in which you can clear particular errors such as F800 or F900 without entering a Service Technician password. For example, when SYS-SRAM is in an abnormal status or needs replacement but service technicians cannot log into the 3C mode, SRAM can be initialized by entering the SRAM clear mode (6C) and selecting item 1 below.
Page 55: Functions
Oki Data CONFIDENTIAL 3.12.3 Functions [a] 0. set serial Number When replacing SYS-SRAM, select this to set the serial number of the equipment since it must be done in advance of recovery from SRAM backup data. • Clear SRAM first and then set the serial number in this mode.
Page 56: Operation Procedure
Oki Data CONFIDENTIAL 3.13 List print mode (9S) 3.13.1 Operation procedure [1] Print out [9][START] (Code) [Digital keys] [Digital keys] [START] [POWER] [START] [START] [POWER] 101: Adjustment mode (05) Key in the first Key in the last List starts to...
Page 57: List Printing
Oki Data CONFIDENTIAL 3.13.2 List Printing Lists below are output in the list print mode. List data are printed out or output in a CSV format by storing them in a USB device. Paper sizes available for this printing are A4 or LT or larger. This section introduces a sample of each list.
Page 58 Oki Data CONFIDENTIAL • Setting mode (08) 08 SETTING MODE DATA LIST TOTAL: 9999999 S/N: xxxxxxxxx MC7xx DF TOTAL: 9999999 20xx-xx-xx xx:xx CODE DATA CODE DATA CODE DATA CODE DATA 2010 2880 3040 3070 Fig. 3-23 The selected setting codes and the current setting value for each code are output in a list. See the following page for the setting code (08): Refer to “Appendix”...
Page 59: Error History
Oki Data CONFIDENTIAL • Error history ERROR HISTORY LIST S/N: xxxxxxxxx TOTAL: 9999999 DF TOTAL: 9999999 MC7xx 20xx-xx-xx xx:xx CODE COUNTER DATE TIME ZOOM_XY ABCD EFHI JLOP Q R F110 00000000 xxxx-xx-xx xx:xx:xx 000 000 0000_0000_0000_0_0000000000 F110 00000000 xxxx-xx-xx xx:xx:xx...
Page 60 Oki Data CONFIDENTIAL • Firmware update log FW UPGRADE LOG S/N: xxxxxxxxx TOTAL: 9999999 MC7xx DF TOTAL: 9999999 20xx-xx-xx xx:xx MANUFACTURE DATE 20xx-xx-xx UNPACKING DATE 20xx-xx-xx USER ROM/VERSION DATE TOTAL COPY(B) COPY(2) COPY(C) PRINT(B) PRINT(2) PRINT(C) LIST STATUS Service Txxxxxxx-xxxx 20xx-xx-xx 99999999 99999999 99999999 99999999 99999999 99999999 99999999 99999999 99999999 OK...
Page 61 Oki Data CONFIDENTIAL • Power-ON/OFF log POWER ON_OFF LOG S/N: xxxxxxxxx TOTAL: 9999999 MC7xx DF TOTAL: 9999999 20xx-xx-xx xx:xx DATE TIME FUNCTION TOTAL DATE TIME FUNCTION TOTAL xxxx-xx-xx xx:xx:xx ON 99999999 xxxx-xx-xx xx:xx:xx ON 99999999 xxxx-xx-xx xx:xx:xx OFF 99999999 xxxx-xx-xx xx:xx:xx OFF...
Page 62 Oki Data CONFIDENTIAL • Version list VERSION LIST TOTAL: 9999999 S/N: xxxxxxxxx MC7xx DF TOTAL: 9999999 20xx-xx-xx xx:xx SYSTEM FIRMWARE ROM VERSION : Oxxxxxxxxxxx SYSTEM FIRMWARE INTERNAL ROM VERSION: Vx.x.x.xx.xx PRINTER ROM VERSION : xxxM-xxx SCANNER ROM VERSION : xxxS-xxx...
Page 63 Oki Data CONFIDENTIAL • Total counter list TOTAL COUNTER LIST TOTAL: 9999999 S/N: xxxxxxxxx 20xx-xx-xx xx:xx MC7xx DF TOTAL: 9999999 PRINT COUNTER TOTAL FULL COLOR TWIN/MONO COLOR BLACK TOTAL COPY PRINTER LIST TOTAL COPY FULL COLOR TWIN/MONO COLOR BLACK TOTAL...
Page 64: Image Related Adjustment
Oki Data CONFIDENTIAL seTTING / aDJUsTmeNT Image Related Adjustment 4.1.1 Adjustment Order This chapter mainly explains the procedures for image related adjustment. In the following diagram, the solid lines with arrow lead to essential adjustments, while the dotted lines lead to adjustments to be performed if necessary.
Page 65: Performing Density Correction
Oki Data CONFIDENTIAL 4.1.2 Performing density correction (1) When any of the following parts is replaced, be sure to perform the “Performing of density correction (05-4905)” procedure. • Drum unit • Transfer belt unit Notes: When performing “Automatic gamma adjustment” in addition, “Performing of density correction (05-4905)”...
Page 66: Image Dimensional Adjustment
Oki Data CONFIDENTIAL 4.1.3 Image Dimensional Adjustment There are several adjustment items in the image dimensional adjustment, as listed below. Item to be adjusted Code in mode 05 Image dimensional Reproduction ratio adjustment of primary 7000 adjustment in the copy/...
Page 67: Image Dimensional Adjustment In The Copy/Printer/Fax Function
Oki Data CONFIDENTIAL 4.1.4 Image dimensional adjustment in the copy/printer/fax function [1] Reproduction ratio adjustment of primary scanning direction The reproduction ratio in the primary scanning direction of the printed image can be adjusted as follows: <Adjustment Mode (05)> Code...
Page 68: Image Quality Adjustment (Copying Function)
Oki Data CONFIDENTIAL Image Quality Adjustment (Copying Function) 4.2.1 Automatic gamma adjustment When the reproduction of gradation is not appropriate, the gradation reproducibility of all colors Y, M, C and K can be corrected by performing this automatic gamma adjustment. In case the gradation reproduction of the image checked is not satisfactory, make this adjustment as described below at parts replacement.
Page 69 Oki Data CONFIDENTIAL (5) When the adjustment has finished normally, press the [OK] button to have the adjustment results reflected. (To cancel the reflection of adjustment results, press the [CANCEL] button.) In the case of an abnormal ending, “ADJUSTMENT ERROR” is shown.
Page 70: Image Quality Adjustment (Printing Function)
Oki Data CONFIDENTIAL Image Quality Adjustment (Printing Function) 4.3.1 Automatic gamma adjustment When the reproduction of gradation is not appropriate, the gradation reproducibility of all colors Y, M, C and K can be corrected by performing this automatic gamma adjustment. In case the gradation reproduction of the image checked is not satisfactory, make this adjustment as described below at parts replacement.
Page 71 Oki Data CONFIDENTIAL (3) Place the patch chart for adjustment printed in step (2) face down on the original glass, with its side, on which two black squares are present, aligned against the original scale. (4) Key in a code and press the [START] button. → The scanner reads the chart automatically and performs automatic gamma adjustment calculation (approx.
Page 72: Gamma Balance Adjustment (Black Mode)
Oki Data CONFIDENTIAL 4.3.2 Gamma balance adjustment (Black Mode) The gamma balance is adjusted by adjusting the density at the Black Mode. The adjustment is performed by selecting its density area from the following: low density, medium density, and high density.
Page 73 Oki Data CONFIDENTIAL <Procedure> (1) While pressing [0] and [5] simultaneously, turn the power ON. (2) Key in the codes to be adjusted (language and screen) and press the [START] button. (3) Key in the value corresponding to the density area to be adjusted (0, 1 or 2) and press the [START] button.
Page 74: Color Balance Adjustment
Oki Data CONFIDENTIAL 4.3.3 Color balance adjustment The color balance is adjusted by adjusting the density of each color. The adjustment is performed by selecting its density area from the following: low density, medium density, and high density. <Adjustment Mode (05)>...
Page 75 Oki Data CONFIDENTIAL Twin color print Item to be adjusted Color specified for Remarks twin color print Black Yellow Magenta Cyan Black 8023-0 The larger the value is, the darker the color to be adjusted becomes. 8023-1 Acceptable values: 0 to 255...
Page 76: Adjustment Of Faint Text
Oki Data CONFIDENTIAL 4.3.4 Adjustment of faint text The faint text can be improved in the following codes. <Adjustment Mode (05)> Black mode Color mode Remarks 7340 7341 7342 8130 8131 8132 When the small characters or fine lines in a halftone image are faint, they can be improved by increasing the value to raise the density level.
Page 77: Maximum Toner Density Adjustment (Special Paper 3)
Oki Data CONFIDENTIAL 4.3.6 Maximum toner density adjustment (Special Paper 3) The maximum toner amount adhering to the paper can be controlled. <Adjustment Mode (05)> Color Code Paper type Remarks Color (600dpi) 8145 Special Paper 3 The smaller the value is, the toner amount adhered decreases of the high density area (ex.
Page 78: Pureblack/Puregray" Threshold Adjustment (Twin Color Mode)
Oki Data CONFIDENTIAL 4.3.9 “PureBlack/PureGray” threshold adjustment (Twin color mode) <Adjustment Mode (05)> Code Item to be adjusted Remarks 8213 Text The larger the value is, the wider the color range to be printed only with the black toner becomes. The smaller...
Page 79: Toner Limit Threshold Adjustment
Oki Data CONFIDENTIAL 4.3.12 Toner limit threshold adjustment <Adjustment Mode (05)> Smooth/ Smooth/ Detail (PS/ Detail Auto (PS/ Auto Paper type Remarks PCL/ XPS) (1200dpi) PCL/ XPS) (1200dpi) 8071-0 8070-0 8090-0 8089-0 Plain paper When you set a larger value, the...
Page 80: Sharpness Adjustment
Oki Data CONFIDENTIAL 4.3.13 Sharpness adjustment This adjustment is applied when images need to be softer or sharper. The adjustment for each original mode is available. The performance of this adjustment differs depending on the setting value of 05-7322 or 05- 8102 with “...
Page 81: Thin Line Width Lower Limit Adjustment
Oki Data CONFIDENTIAL 4.3.14 Thin line width lower limit adjustment <Adjustment Mode (05)> Code Remarks 8240 Sets the lower limit value of the thin line width when “Distinguish Thin Lines” is (600dpi) selected in the screen selecting menu of the printer driver.
Page 82: Led Emission Level Adjustment
Oki Data CONFIDENTIAL 4.3.17 LED emission level adjustment The LED emission level in the BOX printing (black/binary), network FAX and e-mail FAX can be set. The size of the dots can be adjusted. <Adjustment Mode (05)> Code Item to be adjusted...
Page 83: Density Adjustment Of Graphic Lines (1200 Dpi)
Oki Data CONFIDENTIAL 4.3.18 Density adjustment of graphic lines (1200 dpi) This adjustment is available regardless of whether “Distinguish Thin Lines” of the printer driver is selected or not. <Adjustment Mode (05)> Color mode Code Remarks Color/Black 8242-0 The density of the line in Black in the line density range specified by "05-8243-0"...
Page 84: Auto Trapping Width/Density Adjustment (Ps)
Oki Data CONFIDENTIAL 4.3.19 Auto Trapping width/density adjustment (PS) <Adjustment Mode (05)> Code Item to be adjusted Remarks 8244-0 Trapping width (dot) Sets the value of width for auto trapping. When the value increases, the bigger gap is suppressed, but the overlap part becomes more visible.
Page 85: Image Quality Adjustment (Scanning Function)
Oki Data CONFIDENTIAL Image Quality Adjustment (Scanning Function) 4.4.1 Gamma balance adjustment The gamma balance at the Black Mode is adjusted by adjusting the density. The adjustment is performed by selecting its density area from the following: low density, medium density and high density.
Page 86: Density Adjustment
Oki Data CONFIDENTIAL 4.4.2 Density adjustment Adjusts the center density. <Adjustment Mode (05)> Original mode Color Item to be Remarks Text/ Custom Mode adjusted Text Photo Photo mode Color 8339 8340 8341 8380 Manual The larger the value is, the density center darker the image becomes.
Page 87: Background Adjustment (Color Mode)
Oki Data CONFIDENTIAL 4.4.3 Background adjustment (Color Mode) The adjustment level of background center value is adjusted. The control value of background adjustment button is automatically adjusted to the same level as the adjusted center value. For example, when the control value of background adjustment key ranges from 0 to 6, the background center value (-2 to +2) is used to be the range from 6 to 14 accordingly.
Page 88: Background Adjustment (Black/Grayscale)
Oki Data CONFIDENTIAL 4.4.4 Background adjustment (Black/Grayscale) The density of background can be adjusted as follows. <Adjustment Mode (05)> Code Color mode Original mode Remarks 7436 Black Text/Photo The smaller the value is, the background becomes lighter. 7437 Text Acceptable values: 0 to 255 (Default: 128)
Page 89: Sharpness Adjustment
Oki Data CONFIDENTIAL 4.4.6 Sharpness adjustment If you want to make scan images look softer or sharper, perform the following adjustment. The adjustment can be made for each of the color modes and original modes independently. <Adjustment Mode (05)> Code...
Page 90: Rgb Conversion Method Selection
Oki Data CONFIDENTIAL 4.4.8 RGB conversion method selection The color space conversion method of image is decided at color-scanning. <Adjustment Mode (05)> Code Original mode Remarks 8319 Text/Photo 0: sRGB, 1: AppleRGB, 2: ROMMRGB, 3: AdobeRGB (Default: 0) 8320 Text...
Page 91: Adjustment Of The Capacity And Image Quality Of Slimpdf
Oki Data CONFIDENTIAL 4.4.10 Background offsetting adjustment for RADF (common for copy, scan and fax) The background level for scanning originals with the RADF is adjusted when the background fogging at the scanning of a manually-set original and an original used with the RADF is different.
Page 92: Surrounding Void Amount Adjustment
Oki Data CONFIDENTIAL 4.4.12 Surrounding void amount adjustment The void amount around the network scanned image is adjusted. In network scanning, since the void amount is very small in stored images, a shadow may appear around the scanned image due to the subtle difference in the original sizes. This shadow can be eliminated by adjusting the setting value.
Page 93: Jpeg Compression Level Adjustment
Oki Data CONFIDENTIAL 4.4.14 JPEG compression level adjustment The compression level for saving the scanned data in the JPEG format can be adjusted as follows. <Adjustment Mode (05)> Code Item to be adjusted Remarks 8304-0 High quality The larger the value is, the better the quality becomes, and the larger the size of file becomes.
Page 94: General Descriptions
Oki Data CONFIDENTIAL eRROR CODe aND TROUBLesHOOTING General Descriptions This chapter explains the procedures for solving troubles occurring in the equipment. When a trouble occurs, check if an error code is displayed on the LCD screen of the control panel first. If displayed, refer to“ P. 5-4 “5.2 Error Code List”” to figure out the classification and contents of the error, and then refer to “...
Page 95: Collection Of Debug Logs With A Usb Device
Oki Data CONFIDENTIAL 5.1.2 Collection of debug logs with a USB device [1] General description The purpose of collecting the debug logs is to acquire the information for analyzing problems which occurred during the MFP’s operation. In such a case, you can collect the debug logs by inserting a USB device into the MFP.
Page 96 Oki Data CONFIDENTIAL Notes: • Do not remove the USB device while the LED in the MFP is blinking. • If the LED does not start blinking after the USB device is inserted and a few minutes have passed, try the procedure from step 1 again.
Page 97: Error Code List
Oki Data CONFIDENTIAL Error Code List The following error codes is displayed at the upper right of the screen when the “CLEAR PAPER” or “CALL SERVICE” symbol is blinking. Notes: For the error codes not described in this guide, refer to the Hardware Guide.
Page 98: Service Call
Oki Data CONFIDENTIAL 5.2.2 Service call Error code Classification Contents Troubleshooting CB30 Finisher related Stacker motor abnormality P. 5-32 service call CB40 Rear alignment HP abnormality P. 5-32 CB50 Stapler motor HP abnormality P. 5-33 CC03 Download abnormality P. 5-33...
Page 99 Oki Data CONFIDENTIAL Error code Classification Contents Troubleshooting F101_5 Other service Partition mount error: The HDD cannot be connected P. 5-47 call (mounted) caused by damage to the "/registration" partition. F101_6 Partition mount error: The HDD cannot be connected P. 5-47 (mounted) caused by damage to the "/backup"...
Page 100 Oki Data CONFIDENTIAL Error code Classification Contents Troubleshooting F120 Other service Database abnormality: Database is not operating P. 5-57 call normally. F121 Database abnormality (user information P. 5-58 management database) F122 Database abnormality (Message/Job log P. 5-58 management database) F124 Database abnormality: Database is not operating P.
Page 101: Error In Internet Fax / Scanning Function
Oki Data CONFIDENTIAL 5.2.3 Error in Internet FAX / Scanning Function 1. Internet FAX related error Error code Classification Troubleshooting 1C10 System access abnormality P. 5-63 1C11 Insufficient memory P. 5-63 1C12 Message reception error P. 5-63 1C13 Message transmission error P.
Page 102 Oki Data CONFIDENTIAL 2. RFC related error Message displayed in the Error code Contents Troubleshooting Web Page screen 2500 Syntax error, command HOST NAME error (RFC: 500) P. 5-65 unrecognized Destination mail address error (RFC: 500) Terminal mail address error...
Page 103 Oki Data CONFIDENTIAL 3. Electronic Filing related error Message displayed in the Error code Contents Troubleshooting Web Page screen 2B11 Job status failed. JOB status abnormality P. 5-65 2B20 Failed to access file. File library function error P. 5-65 2B30 Insufficient disk space.
Page 104 Oki Data CONFIDENTIAL 4. Remote scanning related error Message displayed in the Error code Contents Troubleshooting Web Page screen 2A20 Failed to acquire resource System management module resource P. 5-66 acquiring failure 2A31 WS Scan function is not Disabled WS Scan P.
Page 105 Oki Data CONFIDENTIAL 5. E-mail related error Message displayed in the Error code Contents Troubleshooting Web Page screen 2C10 Illegal Job status System access abnormality P . 5-67 2C11 Not enough memory Insufficient memory P . 5-67 2C12 Illegal Job status Message reception error P .
Page 106 Oki Data CONFIDENTIAL 6. File sharing related error Message displayed in the Error code Contents Troubleshooting Web Page screen 2D10 Illegal Job status System access abnormality P. 5-69 2D11 Not enough memory Insufficient memory P. 5-69 2D12 Illegal Job status Message reception error P.
Page 107 Oki Data CONFIDENTIAL Message displayed in the Error code Contents Troubleshooting Web Page screen 2DA3 Scanned documents in Manual deletion of scanned documents shared folder deleted upon completed properly. user’s request. 2DA4 Sent Fax Documents in Manual deletion of transmitted FAX shared folder deleted upon documents completed properly.
Page 108 Oki Data CONFIDENTIAL 7. E-mail reception related error Message displayed in the Error code Contents Troubleshooting Web Page screen 3A10 MIME Error has been E-mail MIME error P. 5-72 deteched in the received mail 3A20 Analyze Error has been E-mail analysis error P.
Page 109 Oki Data CONFIDENTIAL Message displayed in the Error code Contents Troubleshooting Web Page screen 3C70 Power Failure has been Power failure error P. 5-74 occurred in Email receiving. 3C90 OffRamp Fax transmission OffRamp Fax transmission disable error P. 5-74 disable error has been detected in the received mail.
Page 110: Printer Function Error
Oki Data CONFIDENTIAL 5.2.4 Printer function error Following codes are displayed at the end of the user name on the print job log screen. Error code Contents Troubleshooting 4011 Print job cancellation - Print job (copy, list print, network print) is deleted P.
Page 111 Oki Data CONFIDENTIAL Error code Contents Troubleshooting 4412 Double-sign encoding error: A double-sign encoding error occurred P. 5-76 because the PDF file is encrypted in a forbidden language or in a language not supported. 4611 Font download failure (exceeding maximum number of registrations): P.
Page 112: Web Page Related Error/Communication Error With External Application
Oki Data CONFIDENTIAL 5.2.5 Web Page related error/Communication error with external application Message displayed in the Error code Contents Troubleshooting Web Page screen 5010 Internal setting error: There is a print job, P. 5-77 a proof print job, a private print job, a...
Page 113: Mfp Access Error
Oki Data CONFIDENTIAL 5.2.6 MFP access error Message displayed in the Error code Contents Troubleshooting Web Page screen 6007 Failed user login Unsuccessful User Login to MFP: P. 5-81 User authentication cannot be done because connection to the authentication server has failed.
Page 114: Maintenance Error
Oki Data CONFIDENTIAL 5.2.7 Maintenance error Message displayed in the Error code Contents Troubleshooting Web Page screen 7101 Failed to update Copier System firmware installation failure P. 5-83 Firmware 7103 Failed to update Copier Engine firmware installation failure P. 5-83...
Page 115: Network Error
Oki Data CONFIDENTIAL 5.2.8 Network error Message displayed in the Error code Contents Troubleshooting Web Page screen 8000 Static IPv4 duplicated IPv4 address overlaps. P. 5-88 address detected 8011 Link Local address of IPv6 Linklocal Address Conflict P. 5-88 was duplicated.
Page 116 Oki Data CONFIDENTIAL Message displayed in the Error code Contents Troubleshooting Web Page screen 8043 IKE Version mismatch Ipsec error if ike version is not matching P. 5-93 8044 Encapsulation mode Ipsec error for encaptulation is not P. 5-93 mismatch...
Page 117 Oki Data CONFIDENTIAL Message displayed in the Error code Contents Troubleshooting Web Page screen 8127 Domain - Invalid logon hours Domain - Invalid logon hours for the P. 5-97 for the User User 8128 Active Directory Domain Active Directory Domain - Clock Skew P.
Page 118: Error History
Oki Data CONFIDENTIAL 5.2.9 Error history In the setting mode (08-9703), the latest twenty groups of error data will be displayed. Display example EA10 99999999 0 6 0 4 1 4 1 7 5 7 2362_1000_0000_0 _XXXXXXXXXX Error code Total counter...
Page 119 Oki Data CONFIDENTIAL Color mode 0: Auto color 1: Full color 2: Black 3: Unused 4: Twin color copy 5: Gray scale 6: Unused 7: Image smoothing Media type 0: Plain 1: Thick1 2: Thick2 3: Thick3 4: Thick4 5: Thick5...
Page 120: Diagnosis And Prescription For Each Error Code
Oki Data CONFIDENTIAL Diagnosis and Prescription for Each Error Code 5.3.1 Check item Check item Contents Sensor check • Check the sensor in the test mode. • Check that there is no dust on the sensor. • Check that the actuator is correctly operated.
Page 121: Paper Jam In Finisher Section
Oki Data CONFIDENTIAL 5.3.2 Paper jam in finisher section [ea10] Paper not detected Classification Error content Paper jam in finisher section Paper was not detected at the finisher within the set period after the paper was fed by the main unit.
Page 122 Oki Data CONFIDENTIAL [ea26] Paper transport jam (stop command request) Classification Error content Paper jam in finisher section Main unit requested finisher to stop operating while finisher was feeding paper. Check item Measures Transport path If there is paper in the paper transport path, remove the paper.
Page 123 Oki Data CONFIDENTIAL [ea2B] Paper transport jam (exit transport sensor) Classification Error content Paper jam in finisher section Paper stayed for longer than set period at exit transport sensor while being transported in finisher transport path. Check item Measures Transport path If there is paper in the paper transport path, remove the paper.
Page 124 Oki Data CONFIDENTIAL [ea40] side cover open jam Classification Error content Paper jam in finisher section Jam occurred because finisher's side cover was opened while finisher was transporting paper. Check item Measures Transport path If there is paper in the paper transport path, remove the paper.
Page 125: Finisher Related Service Call
Oki Data CONFIDENTIAL 5.3.3 Finisher related service call [CB30] stacker motor abnormality * If [EAF8] occurs two times consecutively, it becomes a [CB30] error. Classification Error content Finisher related service call Stacker motor position detection error Check item Measures Stack home position sensor •...
Page 126 Oki Data CONFIDENTIAL [CB50] stapler motor HP abnormality * If [EAF2] occurs two times consecutively, it becomes a [CB50] error. Classification Error content Finisher related service call Stapler motor HP abnormality Check item Measures Stapler • Connector check (P9-1) • Harness check Stapler motor •...
Page 127 Oki Data CONFIDENTIAL [CC91] ejector abnormality * If [EAF3] occurs two times consecutively, it becomes a [CC91] error. Classification Error content Finisher related service call Ejector abnormality Check item Measures Ejector home position sensor • Sensor check (S7) • Connector check (P7-16) •...
Page 128 Oki Data CONFIDENTIAL [CC96] Lever path HP abnormality * If [EAF5] occurs two times consecutively, it becomes a [CC96] error. Classification Error content Finisher related service call Lever path HP abnormality Check item Measures Lever path home position • Sensor check (S15) sensor •...
Page 129 Oki Data CONFIDENTIAL [eaF2] stapler motor HP abnormality Classification Error content Finisher related service call Stapler motor HP abnormality Check item Measures Stapler • Connector check (P9-1) • Harness check Stapler motor • Motor check (M9) • Connector check (P9-1) •...
Page 130 Oki Data CONFIDENTIAL [eaF4] Paper support HP abnormality Classification Error content Finisher related service Paper support HP abnormality call Check item Measures Paper support home position • Sensor check (S6) sensor • Connector check (P7-13) • Harness check Paper support motor •...
Page 131 Oki Data CONFIDENTIAL [eaF6] Front alignment HP abnormality Classification Error content Finisher related service call Front alignment HP abnormality Check item Measures Front alignment plate home • Sensor check (S4) position sensor • Connector check (P8-3) • Harness check Front alignment motor •...
Page 132 Oki Data CONFIDENTIAL [eaF8] stacker motor position detection error Classification Error content Finisher related service call Stacker motor position detection error Check item Measures Stack home position sensor • Sensor check (S9) • Connector check (P7-11) • Harness check Stacker motor •...
Page 133: Communication Related Service Call
Oki Data CONFIDENTIAL 5.3.4 Communication related service call [F070] Communication error between CU board and PU board Classification Error content Communication related Communication error between CU board and PU board service call Check item Measures Error code • Turn the power OFF and then back ON using the main power switch, and then check if the error code changes to another one.
Page 134 Oki Data CONFIDENTIAL [F071] Communication initialization error between CU board and PU board Classification Error content Communication related Communication initialization error between CU board and PU board service call Proce- Check item Measures dure LED head, harness 1-1. Disconnect all the harnesses of the LED heads, and then turn the power ON.
Page 135 Oki Data CONFIDENTIAL [F110] Communication error between system-CPU and scanner-CPU [F111] scanner response abnormality Classification Error content Communication related [F110] Communication error between System-CPU and Scanner-CPU service call [F111] Scanner response abnormality Check item Measures SU board • Check if the harness connecting the SU board and CU board is disconnected or open circuited.
Page 136: Circuit Related Service Call
Oki Data CONFIDENTIAL 5.3.5 Circuit related service call [F090] sRam abnormality on the CU board Classification Contents Circuit related service call SRAM abnormality on the CU board Check item Measure SRAM Check the connection of SRAM 1. Turn the power OFF, and start up the Setting Mode (08).
Page 137 Oki Data CONFIDENTIAL [F400] CU board abnormality Classification Contents Circuit related service call CU board abnormality Check item Measures CU board Board check Replacement part Measure CU board 5-44 / 45584901TH Rev.1...
Page 138: Other Service Call
Oki Data CONFIDENTIAL 5.3.6 Other service call [F100_0] HDD format error (Operation failure of key data) Classification Contents Other service call HDD format error: Operation of HDD key data fails. Check item Measures Setting Reboot the equipment. If it cannot be recovered, reinstall the software in the following procedure.
Page 139 Oki Data CONFIDENTIAL [F100_2] HDD format error (HDD encryption key data damaged - both boards) Classification Contents Other service call HDD format error: Encryption key data of both the CU board and the SRAM board for the CU board are damaged.
Page 140 Oki Data CONFIDENTIAL [F101_0] HDD connection error (HDD connection cannot be detected.) [F101_1] Root partition mount error (HDD formatting fails.) [F101_2][F101_3] Partition mount error (The HDD cannot be connected (mounted) caused by damage to areas other than those described in the F101_1 and F101_4 to F101_9 errors.) [F101_5] Partition mount error (The HDD cannot be connected (mounted) caused by damage to the “/registration”...
Page 141 Oki Data CONFIDENTIAL [F101_4] Partition mount error (The HDD cannot be connected (mounted) caused by damage to the “/work” partition.) Classification Contents Other service call HDD unmounted: Connection of HDD cannot be detected. Sub-code 4: Partition mount error (The "/work" partition is damaged.)
Page 142 Oki Data CONFIDENTIAL [F102] HDD start error [F103] HDD transfer time-out [F104] HDD data error [F105] HDD other error Classification Contents Other service call HDD start error: HDD cannot become “Ready” state. HDD transfer time-out: Reading/writing cannot be performed in the specified period of time.
Page 143 Oki Data CONFIDENTIAL [F106_1] aDI-HDD error: HDD type detection error Classification Error item Other service call ADI-HDD error: HDD type detection fails. Check item Measures Setting If the error is not recovered after rebooting the equipment or no abnormality is found on any check items for the HDD, reinstall the system software.
Page 144 Oki Data CONFIDENTIAL [F106_3] aDI-HDD error: aDI authentication admin Password generation error Classification Error item Other service call ADI-HDD error: The generation of ADI authentication Admin Password fails. Check item Measures Setting Reinstall the system firmware. Reinstall the system software.
Page 145 Oki Data CONFIDENTIAL [F109_0] key consistency error (Consistency check operation error) Classification Contents Other service call Key consistency error - Key consistency check on each key data fails. Check item Measures Setting Reboot the equipment. If it cannot be recovered, reinstall the software in the following procedure.
Page 146 Oki Data CONFIDENTIAL [F109_3] key consistency error (HDD encryption parameter damage) Classification Contents Other service call Key consistency error - Parameter used for HDD partition encryption are damaged. Check item Measures Check the message displayed by [3] + [C] + [POWER] → 5. Key Backup...
Page 147 Oki Data CONFIDENTIAL [F109_4] key consistency error (license data damage) Classification Contents Other service call Key consistency error - The license data are damaged. Check item Measures Check the message displayed by [3] + [C] + [POWER] → 5. Key Backup...
Page 148 Oki Data CONFIDENTIAL [F109_5] key consistency error (encryption key for aDI-HDD is damaged) Classification Contents Other service call Key consistency error - Encryption key for ADI-HDD is damaged. Check item Measures Check the message displayed by [3] + [C] + [POWER] → 5. Key Backup...
Page 149 Oki Data CONFIDENTIAL SRAM Key FROM Key Measure Status Status KeyMismatch KeyMismatch <The error occurs when the CU board is replaced> Recover the encryption key on the CU board. (Transfer the license from SYS-SRAM to SYS-FROM.)  P. 6-16 "6.2.4 Precautions and Procedures when replacing the CU board"([D]Restore ADI key)
Page 150 Oki Data CONFIDENTIAL SRAM Key FROM Key Measure Status Status KeyNull/ KeyNull/ <No USB backup data> KeyBroken KeyBroken 1. Create the partition in the HDD, and reinstall the system software.  P. 6-11 "6.2.3 Precautions and procedures when replacing the HDD"(Perform step 3 or later in “[E]Replace / Format HDD”)
Page 151 Oki Data CONFIDENTIAL [F121] Database abnormality (user information management database) Classification Error item Other service call Login after the startup fails in any starting mode because user management database is corrupted. Check item Measures Setting 1. Delete the log in the following procedure:[5] + [C] + [POWER] →...
Page 152 Oki Data CONFIDENTIAL [F130] Invalid maC address Classification Contents Other service call Invalid MAC address Check item Measures Setting Compare the serial number of the equipment with a number displayed with 08-9601. If they are different, enter the correct serial number at 08- 9601, 08-9083.
Page 153 Oki Data CONFIDENTIAL [F200] Data Overwrite option (GP-1070) disabled Classification Contents Other service call Data Overwrite option (GP-1070) disabled Check item Measures Setting Perform firmware installation (all firmware: OS, HDD, SYS, Engine Main Firmware, and Scanner Firmware) with the USB device.
Page 154 Oki Data CONFIDENTIAL [F520] Operating system start error Classification Error item Other service call The operating system fails to start. Check item Measures Setting 1. Reboot. 2. If it has still not recovered, reinstall the system software. 3. If it still persists after step 2, perform [3] + [C] + [POWER] → 3, and then reinstall the system software.
Page 155 Oki Data CONFIDENTIAL [F700] Overwrite error Classification Error item Other service call Overwriting fails. Check item Measures Setting • If a service call occurs again after the reboot, replace the HDD. [F800] Date error Classification Error item Other service call...
Page 156: Error In Internet Fax / Scanning Function
Oki Data CONFIDENTIAL 5.3.7 Error in Internet FAX / Scanning Function Notes: • When formatting the HDD ([5] + [C] + [POWER] ON → [3] → [1]), all data in the shared folder, Electronic Filing, Address Book, template, etc. are erased. Back up these data before the initialization.
Page 157 Oki Data CONFIDENTIAL [1C63] Terminal IP address unset Reset the Terminal IP address. Turn the power OFF and then back ON. Perform the job in error again. [1C64] Terminal mail address unset Reset the Terminal mail address. Turn the power OFF and then back ON. Perform the job in error again.
Page 158 Oki Data CONFIDENTIAL RFC related error [2500] HOsT Name error (RFC: 500) / Destination mail address error (RFC: 500) / Terminal mail address error (RFC: 500) [2501] HOsT Name error (RFC: 501) / Destination mail address error (RFC: 501) / Terminal mail address error (RFC: 501) Check if the Terminal mail address and Destination mail address are correct.
Page 159 Oki Data CONFIDENTIAL [2B50] Image library error [2B90] Insufficient memory capacity Turn the power OFF and then back ON. Perform the job in error again. If the error still occurs, replace the main memory. Delete the job in progress or being set or in the HOLD/PRIVATE/PROOF/INVALID, and retry the job in error.
Page 160 Oki Data CONFIDENTIAL [2a51] Power failure Check if the power cable is properly connected. Check if the power supply voltage is inconstant. [2a60] Ws scan user authentication failure • When “1” (WIA driver) is set for 08-9749 and also Windows Fax&Scan is used Check if the user name that you used to log in Windows is a name registered as a user.
Page 161 Oki Data CONFIDENTIAL [2C30] Directory creation failure [2C31] File creation failure [2C33] File access failure Check if the access privilege to the storage directory is writable. Check if the server or local disk has a sufficient space in disk capacity.
Page 162 Oki Data CONFIDENTIAL [2C6a] HOsT Name error (No RFC error) Check if there is an illegal character in the device name. Delete the illegal character and reset the appropriate device name. [2C6B] Terminal mail address error Check the SMTP Authentication method.
Page 163 Oki Data CONFIDENTIAL [2D14] Invalid parameter When a template is used, form the template again. If the error still occurs, turn the power OFF and then back ON, and perform the job again. [2D15] exceeding the maximum size for file sharing Divide the file in error into several files and retry.
Page 164 Oki Data CONFIDENTIAL [2D68] File sharing service not available Check if the setting of SMB is valid. [2D69] NetWare service not available Check if the Netware setting is enabled. [2DC1] Power failure Check if the power cable is connected properly and it is inserted securely.
Page 165 Oki Data CONFIDENTIAL [2e43] encryption failure in UsB storage Turn the power OFF and then back ON. Perform the job in error again. [2e44] encryption PDF enforced mode error in UsB storage Reset the encryption and perform the job in error again. To create an image file not encrypted, consult your administrator.
Page 166 Oki Data CONFIDENTIAL [3a50] Insufficient HDD capacity error These errors occur when the HDD capacity is not sufficient for a temporary concentration of the jobs, etc. Request the sender to retransmit after a certain period of time, or divide the mail into more than one.
Page 167 Oki Data CONFIDENTIAL [3C70] Power failure error Check if the mail is recovered after turning ON the power again. Request the sender to retransmit the mail if it is not recovered. [3C90] OffRamp Fax transmission disable error 5 OffRamp Fax transmission disable error has been detected in the received mail.
Page 168: Printer Function Error
Oki Data CONFIDENTIAL 5.3.8 Printer function error [4011] Print job cancellation This message appears when deleting the job on the screen. [4021] Print job power failure When there are running jobs, perform the job in error again after the completion of the running jobs.
Page 169 Oki Data CONFIDENTIAL [4214] Fax/Internet Fax transmission limitation error Check the settings of this equipment. [4221] Private-print-only error Select “Private print”, and then perform the printing again. [4231] Hardcopy security printing error Hardcopy security printing cannot be performed because the function is restricted in the self- diagnosis mode.
Page 170: Web Page Related Error/Communication Error With External Application
Oki Data CONFIDENTIAL 5.3.9 Web Page related error/Communication error with external application [5010] Internal setting error Classification Error item Communication error with There is a print job, a proof print job, a private print job, a print job external application without a set department code, a scan job or a fax job remaining in this equipment.
Page 171 Oki Data CONFIDENTIAL [5016] expired ssL certificate Classification Error item Communication error with SSL certificate is expired. external application Check item Measures Setting Set the correct time. [5017] Other ssL certificate related error Classification Error item Communication error with SSL certificate is invalid.
Page 172 Oki Data CONFIDENTIAL [501B] No URL (host/port) or invalid path Classification Error item Communication error with Initial URL is invalid. external application Check item Measures Setting Set the correct initial URL. [5030] HTTP communication error Classification Error item Communication error with...
Page 173 Oki Data CONFIDENTIAL [5BD0] Power failure during restoration Classification Error item Web Page related error Check item Measures Setting • Check if the power cable is connected properly and is inserted securely. • Check if the power voltage is unstable.
Page 174: Mfp Access Error
Oki Data CONFIDENTIAL 5.3.10 MFP access error [6007] Unsuccessful User Login to mFP Classification Error item MFP access error User authentication cannot be done because connection to the authentication server has failed. Check item Measures Setting Check if the operating status of the server and connection from an MFP have been confirmed.
Page 175 Oki Data CONFIDENTIAL [6041] Card authentication: Card related error Classification Error item MFP access error Card data cannot be obtained correctly. Check item Measures Setting Reattempt scanning. If the error still occurs after reattempting scanning for several times, card data may be corrupted or the card reader may be out of order.
Page 176: Maintenance Error
Oki Data CONFIDENTIAL 5.3.11 Maintenance error [7101] system firmware installation failure [7103] engine firmware installation failure [7105] scanner firmware installation failure [7111] Patch installation failure [7113] Plug-in installation failure [7115] HDD data installation failure Classification Error item Maintenance error System firmware installation failed. ([7101]) Engine firmware installation failed.
Page 177 Oki Data CONFIDENTIAL [711D] License key returning failure Classification Error item Maintenance error The one-time dongle license fails to be returned to USB device. Check item Measures Setting Return the license to the USB device used for installing the license.
Page 178 Oki Data CONFIDENTIAL [71aC] File save error during certificate acquisition from sCeP server Classification Error item Maintenance error File save error occurred during certificate acquisition from SCEP server. Check item Measures Setting File saving failed for some reason. If the error still occurs after rebooting the equipment, start up using the following procedure:[3] + [C] + [POWER] →...
Page 179 Oki Data CONFIDENTIAL [7263] sU Loader installation failure Classification Error item Maintenance error SU Loader installation failure Check item Measures Setting SU Loader installation failed. Reinstall the firmware. [7265] sU Recovery installation failure Classification Error item Maintenance error SU Recovery installation failure...
Page 180 Oki Data CONFIDENTIAL [726F] Finisher installation failure Classification Error item Maintenance error Finisher installation failure Check item Measures Setting Finisher installation failed. Reinstall the firmware. [7271] Duplex installation failure Classification Error item Maintenance error Duplex installation failure Check item Measures Setting Duplex installation failed.
Page 181: Network Error
Oki Data CONFIDENTIAL 5.3.12 Network error [8000] static IPv4 address conflict Classification Error item Network error IPv4 address overlaps. Check item Measures Setting Check if the same IP address is not used by other machine. [8011] Linklocal address Conflict Classification...
Page 182 Oki Data CONFIDENTIAL [8023] Can not contact authentication server/switch Classification Error item Network error Failed in connection to authentication server and switch. Check item Measures Setting Check connectivity to switch or server. [8024] Certificate verification Failure Classification Error item Network error Failed in verification of certificate.
Page 183 Oki Data CONFIDENTIAL [8034] Ikev1 invalid certificate Classification Error item Network error Ipsec error if invalid certificate uploaded Check item Measures Setting Check the CA and User certificate in MFP and peer machine. [8035] Ikev1 certificate not supported Classification Error item...
Page 184 Oki Data CONFIDENTIAL [8039] Ikev1 invalid signature Classification Error item Network error Ipsec error for invalid signaturer for certificate Check item Measures Setting Mismatch in Signature payload (MAC or IV). Check the CA and user certificate in MFP and peer machine.
Page 185 Oki Data CONFIDENTIAL [803e] Ikev2 IsakmP sa unavialable Classification Error item Network error Ipsec error if ISAKMP SA is not created of destroyed due to some uncertain condition Check item Measures Setting Restart IPsec service on Peer and retry. [803F] Ikev2 cryptographic operation failed...
Page 186 Oki Data CONFIDENTIAL [8043] IPsec Ike version mismatch Classification Error item Network error Ipsec error if ike version is not matching Check item Measures Setting Mismatch in IKE version. Check the IKE version in MFP and peer. [8044] IPsec encaptulation mismatch...
Page 187 Oki Data CONFIDENTIAL [8049] IPsec Remote IP mismatch Classification Error item Network error Ipsec error for remote ip mismatch Check item Measures Setting Remote traffic selector mismatch. Check the source address/port in IPsec filter. [804a] IPsec Ike timeout Classification Error item...
Page 188 Oki Data CONFIDENTIAL [8069] Invalid TsIG/sIG(0) key file Classification Error item Network error This message is displayed when the key file for SIG(0) or TSIG is invalid. Check item Measures Setting Verify the TSIG/SIG(0) key files used. [8101] Wireless association with access point failure...
Page 189 Oki Data CONFIDENTIAL [8122] Domain - Invalid Username or Password Classification Error item Network error The user name or password of the domain authentication is not valid and the user cannot log on. Check item Measures Setting Check if the user name or password is correctly entered. Enter them by specifying the upper and lower case letters correctly.
Page 190 Oki Data CONFIDENTIAL [8127] Domain - Invalid logon hours for the User Classification Error item Network error The user log-on time is invalid at domain authentication and the user cannot log-on. Check item Measures Setting Check the log-on time setting of the user account in "Active Directory User and Computer".
Page 191: Other Errors
Oki Data CONFIDENTIAL Other errors 5.4.1 Equipment operation disabled after the installation of option(s) Check if the optional board is installed properly. 5.4.2 Wireless LAN connection disabled The connection state and settings of the Wireless LAN can be checked with [USER FUNCTIONS] →...
Page 192: Removal And Installation Of Pc Boards/Hdd
Oki Data CONFIDENTIAL RePLaCemeNT OF PC BOaRDs/HDD Removal and Installation of PC Boards/HDD Refer to the Hardware Guide for the removal and installation procedures of the PC boards other than the CU board, HDD, and SRAM board <for CU board>.
Page 193 Oki Data CONFIDENTIAL (3) Release 2 latches. Fig.6-6 (4) Release the latch. Fig.6-7 (5) Close the scanner and top cover, then open the feeder unit. Remove the right side cover [1]. Fig.6-8 6-2 / 45584901TH Rev.1...
Page 194: Cu Board Cover
Oki Data CONFIDENTIAL 6.1.2 CU board cover (1) Take off the right side cover.  P. 6-1 “6.1.1 Right side cover” (2) Remove 15 screws, and take off the CU board cover. Fig.6-9 6.1.3 CU board (1) Take off the right side cover.
Page 195 Oki Data CONFIDENTIAL (5) Take out the connectors and cable from the CU board case. Fig.6-11 (6) Remove 2 screws. Fig.6-12 (7) Remove 8 screws, and then take off the CU board. Notes: When removing the CU board, do not apply pressure to the heat sink, memory or SRAM board by holding them too firmly.
Page 196: Hard Disk (Hdd)
Oki Data CONFIDENTIAL 6.1.4 Hard disk (HDD) (1) Take off the right side cover.  P. 6-1 “6.1.1 Right side cover” (2) Take off the CU board cover.  P. 6-3 “6.1.2 CU board cover” (3) Take off the fax unit if it’s installed.
Page 197: Sram Board
Oki Data CONFIDENTIAL 6.1.5 SRAM board <for CU board> (1) Take off the right side cover.  P. 6-1 “6.1.1 Right side cover” (2) Take off the CU board cover.  P. 6-3 “6.1.2 CU board cover” (3) Take off the fax unit if it’s installed.
Page 198: Fax Unit
Oki Data CONFIDENTIAL 6.1.6 FAX unit (1) Take off the right side cover.  P. 6-1 “6.1.1 Right side cover” (2) Take off the CU board cover.  P. 6-3 “6.1.2 CU board cover” (3) Remove 2 screws. Fig.6-19 (4) Unplug the connectors and cable connected to the CU board.
Page 199: Precautions, Procedures And Settings For Replacing Pc Boards And Hdd
Oki Data CONFIDENTIAL Precautions, Procedures and Settings for Replacing PC Boards and HDD 6.2.1 Precautions when replacing PC boards • The ID for each equipment is registered on the PU board, the CU board and SU board. So, if their replacement is required, be sure to replace only one board at a time. Do not replace the CU board and the SRAM board (for the CU board) together.
Page 200: Hdd Fault Diagnosis
Oki Data CONFIDENTIAL 6.2.2 HDD fault diagnosis This code displays the HDD operation history, which is recorded in the HDD, on the control panel. HDD failure can be diagnosed or predicted with the information displayed. 1. Display The following screen is displayed with setting code 08-9065. You can also refer to the same information by pressing the [POWER] button while pressing [5] and [C] simultaneously and then selecting “5.
Page 201 Oki Data CONFIDENTIAL 3. ID=05 and c5 Name Description Remarkd Re-allocated Sector The number of sectors reassigned This value tends to Count increase at HDD failure. Current Pending The number of candidate sectors to be reassigned This value tends to...
Page 202: Precautions And Procedures When Replacing The Hdd
Oki Data CONFIDENTIAL 6.2.3 Precautions and procedures when replacing the HDD Notes: • When the HDD is replaced, it is necessary to back up the data in the HDD before replacing and to recover them after replacing. • To maintain the security, ask users to perform the backup/restore for users’ data/information in the HDD.
Page 203 Oki Data CONFIDENTIAL [a] Back up in HDD Ask the user (machine administrator) to back up the data in the HDD. Refer to the table below for the type of data, availability and method of backup. Type of data in HDD...
Page 204 Oki Data CONFIDENTIAL [D] erase HDD In case of the ADI-HDD: (1) Turn the power ON while pressing [4] and the [CLEAR] button simultaneously. (2) Key in [1] to select “1: Revert factory install status HDD.” and then press the [START] button.
Page 205 Oki Data CONFIDENTIAL [F] Reset user’s setting items and restore data/information Ask the user (machine administrator) to reset the user’s setting items and to restore data or information. Refer to the following for the reset and restore: Items to reset/restore...
Page 206 Oki Data CONFIDENTIAL [I] adjust image quality (1) Start up with the Adjustment mode (05). (2) Enter the password, and then press the [OK] button. (If the password is not set for Service, press the [ENTER] button without entering anything.) (3) Perform “Automatic gamma adjustment”...
Page 207: Precautions And Procedures When Replacing The Cu Board
Oki Data CONFIDENTIAL 6.2.4 Precautions and Procedures when replacing the CU board A procedure for CU board replacement is shown below. Start [A] Return License [B] Replace the CU board [C] Restore ADI key [D] Restore encryption key [E] Restore license...
Page 208 Oki Data CONFIDENTIAL (7) After 10 to 40 seconds passes, the screen for notifying the success of performance is displayed. Then press the [OK] button. If this screen is not displayed or the screen for notifying the failure of performance is displayed, quit this operation by pressing the [NO]/[CLOSE] button.
Page 209 Oki Data CONFIDENTIAL [D] Restore encryption key Notes: If turning the power ON while pressing [3] and the [CLEAR] button simultaneously or restoring the key is not possible, update the system firmware using the download jig, and then perform this procedure again.
Page 210 Oki Data CONFIDENTIAL [G] Reinstall license If the license was returned in "[A]Return License", reinstall it with the following procedure. (1) Turn the power ON while pressing [0] and [8] simultaneously. (2) Enter the password, and then press the [OK] button.
Page 211 Oki Data CONFIDENTIAL 6.2.5 Precautions and procedure when replacing the SRAM board (for the CU board) Notes: Do not replace the HDD and the SRAM board (for the CU board) together. Be careful not to damage the board when replacing the SRAM board.
Page 212 Oki Data CONFIDENTIAL [a] Backup sRam Notes: If “[A] Backup SRAM” fails, proceed to “[B]Return License”. If “[A] Backup SRAM” succeeds, proceed to “[C]Replace SRAM board”. (1) Turn the power ON while pressing [6] and the [CLEAR] button simultaneously. (2) When “SRAM Clear Mode” appears on the LCD, key in [0] to select “0. Set Serial Number”...
Page 213 Oki Data CONFIDENTIAL [C] Replace sRam board (1) Confirm that the power is turned OFF. (2) Take off the Fax Unit (GD-1340) if it is installed. (3) Replace the SRAM board (for the CU board).  P. 6-6 “6.1.5 SRAM board <for CU board>”...
Page 214 Oki Data CONFIDENTIAL [G] Backup aDI key If the ADI-HDD is installed, follow the steps below. To confirm the type of device, start up the equipment in the 4C mode. (1) Turn the power ON while pressing [3] and the [CLEAR] button simultaneously.
Page 215 Oki Data CONFIDENTIAL [J] Initialize sRam board (1) Start up with the Setting Mode (08). (2) Initialize the SRAM error. 1. When “SRAM REQUIRES INITIALIZATION” is displayed on the LCD, check the destination and then press the [START] button. If the destination is not correct, key in the correct one and then press the [START] button.
Page 216 Oki Data CONFIDENTIAL [L] enable HDD encryption If the HDD encryption function is used, follow the procedure below. (1) Start up with the Setting mode (08). (2) Enter the password, and then press the [OK] button. (If the password is not set for Service, press the [ENTER] button without entering anything.)
Page 217: Precautions And Procedures When Replacing The Pu Board
Oki Data CONFIDENTIAL 6.2.6 Precautions and Procedures when replacing the PU board Refer to the Hardware Guide for the replacement procedure of the PU board. 6.2.7 Precautions and Procedures when replacing the SU board Refer to the Hardware Guide for the replacement procedure of the SU board.
Page 218: License Re-Registration Using The One-Time Dongle
Oki Data CONFIDENTIAL 6.2.9 License re-registration using the one-time dongle Re-registration when the board is replaced The license registered using the one-time dongle can be re-registered only in the same equipment. When the CU board and SRAM board (for CU board) are replaced, follow the procedures for re- registration given below.
Page 219 Oki Data CONFIDENTIAL (6) The Remove screen is displayed. Then press the [YES] button. If this screen is not displayed, check that the one-time dongle is installed in the equipment properly. (7) After 10 to 40 seconds have passed, the screen for notifying the success of the performance is displayed.
Page 220: Precautions For Installation Of Gp-1070 And Disposal Of Hdd/ Board
Oki Data CONFIDENTIAL Precautions for Installation of GP-1070 and Disposal of HDD/ Board 6.3.1 Precautions for Installation of GP-1070 When installing the Data Overwrite Enabler (GP-1070), perform the following setting: 3C → 6. Erase HDD Securely : HDD securely erasing This setting is the overwriting method complying with DoD 5220.22-M.
Page 221: Remote Service
Oki Data CONFIDENTIAL RemOTe seRVICe There are following functions as Remote Service. 1. Auto Supply Order Automatically orders the toner by FAX or E-mail. 2. Service Notification Notifies the status of the equipment to the service technician by E-mail or FAX.
Page 222 Oki Data CONFIDENTIAL (2) Touch Panel Setting Each item is set from the Auto Supply Order screen on the touch panel. Entering the password and customer information is required because the setting is made from the ADMIN screen. Setting it with the administrator is a must.
Page 223 Oki Data CONFIDENTIAL • E-mail information of this equipment (common information) [ADMIN] > [E-MAIL] FROM ADDRESS E-mail address of this equipment (*) FROM NAME E-mail username of this equipment * When sending an E-mail, validity of the address is checked. If the address is invalid, it is not sent.
Page 224: Setting Procedure
Oki Data CONFIDENTIAL 7.1.3 Setting procedure (1) Start up the self-diagnosis setting mode 08-9783, and then change the setting value to “0”. (2) Turn the power OFF, and then ON. (3) Press the [SETTING] button to enter the user function screen.
Page 225 Oki Data CONFIDENTIAL (7) The SERVICE screen is displayed. Fig. 7-3 (8) Press the [SUPPLY ORDER SETUP] button. Fig. 7-4 (9) Press the [ORDER INFORMATION] button. (10) The ORDER INFORMATION screen is displayed. Fig. 7-5 7-5 / 45584901TH Rev.1...
Page 226 Oki Data CONFIDENTIAL (11) Press the buttons on the screen of ORDER INFORMATION to set the required item. [FAX]/[MAIL]/ [OFF] Select the [FAX] or the [MAIL] button for the transmitting way of order. (HTTP has not been supported yet.) [OFF]: Turn off the AUTO SUPPLY ORDER function.
Page 227 Oki Data CONFIDENTIAL (16) The SERVICE screen is displayed. Fig. 7-7 (17) Press the [SERVICE INFORMATION] button. (18) The CUSTOMER/SERVICE TECHNICIAN screen is displayed. Fig. 7-8 (19) Press the buttons of the screen of CUSTOMER/SERVICE TECHNICIAN to set the required item.
Page 228 Oki Data CONFIDENTIAL (20) Press the [OK] button to register and complete the order information setting. (21) The SERVICE screen is returned. Fig. 7-9 (22) Press the [SUPPLY ORDER SETUP] button. Fig. 7-10 (23) Press the [TONER ORDERING] button. (24) The TONER ORDERING screen is displayed.
Page 229 Oki Data CONFIDENTIAL (25) Select the part to be ordered. (Press the [YELLOW(Y)] button.) Fig. 7-12 (26) Input the order information of TONER. [PART NUMBER] Toner number [CONDITION] The order is placed when the number of toner empty reaches the number specified for the CONDITION.
Page 230 Oki Data CONFIDENTIAL (29) Press the [MAGENTA(M)] / [CYAN(C)] / [BLACK(K)] / [USED TONER CONTAINER] button, and then input the order information in the same way. Fig. 7-14 (30) Press the [OK] button to register the order information. Notes: Auto Supply Order setting is also available from the following setting mode (08).
Page 231 Oki Data CONFIDENTIAL Items 08 code Contents RESULT PRINTING 9782 0: OFF [OFF] / [ALWAYS] / [ON ERROR] 1: Always 2: ON Error YELLOW(Y) TONER 9773 Maximum 20 digits [PART NUMBER] YELLOW(Y) TONER 9775 1-99 [CONDITION] YELLOW(Y) TONER 9774 1-99...
Page 232 Oki Data CONFIDENTIAL (33) Press the [ON] or [OFF] button in “Service Notification (Device Info). When the [OFF] button is pressed, all functions related Service Notification (Device Info) become ineffective. Fig. 7-15 (34) When Service Notification (Device Info) is set to ON, the screen to set the notification date is displayed.
Page 233 Oki Data CONFIDENTIAL • Notify Date 1 and Notify Date 2 ([DATE] button) Pressing the [DATE] button sets up to 2 dates on which you wand to send data. * This is not affected by the specified day of the week.
Page 234: Order Sheet Format
Oki Data CONFIDENTIAL 7.1.4 Order Sheet Format The sample of order sheet is as follows. (1) FAX (This format is the same as that of TIFF image attached E-mail.) *1 Part not to be ordered is not output. (Less space between the lines) DATE &...
Page 235 Oki Data CONFIDENTIAL (2) E-MAIL (TIFF image attached with the E-mail is the same format with that of the FAX order sheet.) SUBJECT: SUPPLY ORDER REQUEST *1 Part not to be ordered is not output. (Less space between the lines) Date&Time: '12-04-14 00:17...
Page 236 Oki Data CONFIDENTIAL (3) Result list *1 Part not to be ordered is not output. (Less space between the lines) ORDER XXXXXXXXX DATE & TIME :99-99-'99 99:99 CUSTOMER NUMBER :XXX CUSTOMER NAME :XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX CUSTOMER ADDRESS :XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX CUSTOMER TEL NUMBER :XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX...
Page 237 Oki Data CONFIDENTIAL TONER CARTRIDGE: Toner cartridge CYAN: Cyan MAGENTA: Magenta YELLOW: Yellow BLACK: Black DESCRIPTION AREA: Remarks DEVICE DESCRIPTION: Model name (MFP model name) SERIAL NUMBER: Serial number DEVICE FAX NUMBER: Fax number DEVICE E-MAIL ADDRESS: E-mail address PRINT COUNTER:...
Page 238: Service Notification
Oki Data CONFIDENTIAL Service Notification 7.2.1 Outline This function automatically notifies the status of the equipment to the service technician by E-mail or FAX. The following three are the items to be notified. • Total counter notification When this function is effective, it notifies each counter information periodically (on the set date and time every month).
Page 239 Oki Data CONFIDENTIAL (2) Press the [SERVICE] button. Fig. 7-23 (3) Press the [SERVICE NOTIFICATION] button. Fig. 7-24 (4) Press the [E-MAIL] or [FAX] button in “SERVICE NOTIFICATION”. When the [OFF] button is pressed, all functions related Service Notification become ineffective.
Page 240 Oki Data CONFIDENTIAL (5) Enter the E-mail address or FAX number of the destination. When pressing the [E-MAIL] button, the screen is switched to a full keyboard. Then enter the E- mail addresses and press the [OK] button. (Maximum 3 addresses can be set.)
Page 241 Oki Data CONFIDENTIAL (6) Press the [ON] button to notify or the [OFF] button not to notify each item for E-mail and FAX. When Total Count Transmit is set to ON, the screen to set the notification date is displayed. Then set the notification date with the following procedure.
Page 242 Oki Data CONFIDENTIAL • Notify Date 1 and Notify Date 2 ([DATE] button) Pressing the [DATE] button sets up to 2 dates on which you wand to send data. * This is not affected by the specified day of the week.
Page 243 Oki Data CONFIDENTIAL (7) Press the [OK] button. The setting completes. Notes: Service Notification setting is also available from the following setting mode (08). Items 08 code Contents Service Notification setting 9793 0: OFF (Invalid) 1:E-mail 2:FAX E-mail address 1...
Page 244: Items To Be Notified
Oki Data CONFIDENTIAL 7.2.3 Items to be notified The items to be notified are shown below. Total Counter Transmit by E-mail Subject: Counter Notification Date : 04/26/2012 12:34 Machine Model : MC7xx SerialNumber : 1234567890 Total Counter : 00004787 Supplier:...
Page 245 Oki Data CONFIDENTIAL ① Date ② Machine model name ③ Serial number ④ Total counter value ⑤ Supplier information ⑥ Customer information ⑦ Service technician information ⑧ Count setting of large-sized paper (Fee charging system counter) ⑨ Definition setting of large-sized paper (Fee charging system counter) ⑫...
Page 246 Oki Data CONFIDENTIAL Total Counter Transmit by FAX Sheet 1 COUNTER NOTIFICATION (*1) DATE : 12/04/14 13:47 MACHINE MODEL : MC7xx SERIAL NUMBER : 1234567890 TOTAL COUNTER : 00004787 CUSTOMER NAME : CUSTOMER_NAME CUSTOMER ADDRESS : CUSTOMER_ADDRESS CUSTOMER TEL NUMBER : 1234567890 : customer _ emailaddress @ dddd.xxx...
Page 247 Oki Data CONFIDENTIAL Sheet 3 COUNTER NOTIFICATION (*1) PRINTER ERROR HISTORY DATE TIME ERROR CODE COUNTER DATE TIME ERROR CODE COUNTER 08/04/13 16:44 F110 00000000 08/04/13 16:44 F110 00000000 08/04/12 22:28 F110 00000000 08/04/13 16:44 F110 00000000 08/04/12 22:23 F110...
Page 248 Oki Data CONFIDENTIAL Number of scanning pages in the FAX Function (BLACK) Number of scanning pages in the Network Scanning Function (BLACK) Number of transmitted pages in the FAX Function (BLACK) Number of received pages in the FAX Function (BLACK) History of error *2 The latest 20 errors are displayed.
Page 249 Oki Data CONFIDENTIAL Toner near-empty notification by e-mail Subject: Toner Near-Empty Notification Date : 04/26/2012 12:34 Machine Model : MC7xx SerialNumber : 1234567890 Total Counter : 00004787 Supplier: Name : SUPPLIER_NAME Fax Number : 1122334455 E-Mail : Supplier_emailaddress@cccc.xxx Address : SUPPLIER_ADDRESS...
Page 250 Oki Data CONFIDENTIAL Date Machine model name Serial number Total counter value Supplier information Customer information Service technician information Count setting of large-sized paper (Fee charging system counter) Definition setting of large-sized paper (Fee charging system counter) Number of output pages in the Copier Function (BLACK)
Page 251 Oki Data CONFIDENTIAL Toner near-empty notification by FAX Sheet 1 TONER NEAR-EMPTY NOTIFICATION (*1) DATE : 12/04/14 13:47 MACHINE MODEL : MC7xx SERIAL NUMBER : 1234567890 TOTAL COUNTER : 00004787 CUSTOMER NAME : CUSTOMER_NAME CUSTOMER ADDRESS : CUSTOMER_ADDRESS CUSTOMER TEL NUMBER : 1234567890 : customer _ emailaddress @ dddd.xxx...
Page 252 Oki Data CONFIDENTIAL Sheet 3 COUNTER NOTIFICATION (*1) Toner Cartridge Information: Toner Near-Empty Counter Setting 00000000 Current 00000000 Color code Point Of Destination Used History Developer Counter 00000056 Developer Driving Time 00000057 Drum Driving Time 00000058 Toner Information Yellow Remaining Quantity (%)
Page 253 Oki Data CONFIDENTIAL Color of toner cartridge 1: Black 2: Yellow 3: Magenta 4: Cyan Destination setting of toner cartridge *2 The latest 20 errors are displayed. Toner remaining quantity (Yellow) Toner remaining quantity (Magenta) Toner remaining quantity (Cyan) Toner remaining quantity (Black) 7-33 / 45584901TH Rev.1...
Page 254 Oki Data CONFIDENTIAL Service Call Transmit Subject: Service Call Notification Date: 04/14/2012 13:47 Machine Name: MC7xx SerialNumber:1234567890 Function: Printer Severity: Error ErrorCode: XXXX Message: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX Supplier: Name : SUPPLIER_NAME Tel Number : 1122334455 E-Mail : supplier_emailaddress@cccc.xxx Address : SUPPLIER_ADDRESS Customer:...
Page 255 Oki Data CONFIDENTIAL ① Date (When an error occurs) ② Machine model name ③ Serial number ④ Function: Fixed at “Printer” ⑤ Severity: Fixed at “Error” ⑥ Error code ⑦ Error message: The content of error is displayed. ⑧ Supplier information ⑨...
Page 256: Firmware Updating
Oki Data CONFIDENTIAL FIRmWaRe UPDaTING Overview When you want to update the firmware to the latest one or the equipment becomes inoperable due to some defect in the firmware, updating can be performed as follows. Note! ODC does not support use of the download jig.
Page 257 Oki Data CONFIDENTIAL Fig.8-2 System firmware P. 8-23 Fig.8-3 FAX firmware (GD-1340) P. 8-26 Notes: • Written firmware varies depending on the kinds of the boards provided as service parts. For updating, only the minimum firmware is installed on the system control PC board, logic PC board, and scanning section control PC board.
Page 258: Firmware Updating With Usb Device
Oki Data CONFIDENTIAL Firmware Updating with USB Device To update firmware, store update program and firmware data files in the USB device. The update program is “signatures.sig”, and it needs to be stored in the USB device. It is necessary for updating firmware except that of the System firmware.
Page 259 Oki Data CONFIDENTIAL Important: • Only the USB devices which meet the following conditions should be used for updating. Be careful since updating with any device other than the above is never guaranteed. - A combination USB device with a flash memory (to be connected directly to the USB port) and its capacity is 2GB or more.
Page 260: Update Procedure
Oki Data CONFIDENTIAL 8.2.2 Update procedure Important: • The file system of USB device should be formatted in the FAT or FAT32 format. Be careful since the devices formatted in NTFS or other format will not be able to be operated. The file system can be confirmed on the device properties in applications such as Explorer of Windows.
Page 261 Oki Data CONFIDENTIAL (5) Enter the password, and then press the [OK] button. (If the password is not set for Service, press the [OK] button without entering anything.) Enter Password “ & ‘ < > Caps Space Backspace Reset Fig.11-1 The screen for selecting items to be updated is displayed after approx.
Page 262 Oki Data CONFIDENTIAL Notes: • The display of items on this screen varies depending on the types of data written on the USB device. Each item is displayed only when each data file is written on the USB device in the following conditions.
Page 263 Oki Data CONFIDENTIAL (7) Press the [START] button. Updating starts and the processing status is displayed on the LCD screen. Status display during update Status display when update is completed SYSTEM FIRMWARE(OS Data) SYSTEM FIRMWARE(OS Data) update in progress Completed...
Page 264 Oki Data CONFIDENTIAL Notes: • “Update Failed.” is displayed at the bottom of the LCD screen when the updating is not completed properly. “Failed” appears next to the failed item on the status display. Even though an update fails, do not turn the power OFF until other updates are finished.
Page 265 Oki Data CONFIDENTIAL • When a PU firmware update error or SU firmware update error occurs, “Update Failed” or “Failed” appears on the screen and the error number and error message appear next to the message. For details of each error, refer to the following tables.
Page 266 Oki Data CONFIDENTIAL (9) Press the [POWER] button to shut down the equipment, and then remove the USB device. (10) Perform the initialization of the updating data. • Press the [POWER] button while simultaneously holding down the [0] and [8] buttons.
Page 267 Oki Data CONFIDENTIAL During the update, “Update in progress” is displayed on the right of each item. After it is completed, “Completed” is displayed there. Example screens of the system firmware update are as follows, and these are the same for other firmware.
Page 268: Patch Updating With Usb Device
Oki Data CONFIDENTIAL Patch Updating with USB Device System firmware and System software can be updated in a shorter time than normal update using the data file for the patch update. Notes: When performing the update, use the latest program.
Page 269 Oki Data CONFIDENTIAL Important: • Only the USB devices which meet the following conditions should be used for updating. Be careful since updating with any device other than the above is never guaranteed. - A combination USB device with a flash memory (to be connected directly to the USB port) and its capacity is 1GB or more.
Page 270: Update Procedure
Oki Data CONFIDENTIAL 8.3.2 Update procedure Important: • The file system of USB device should be formatted in the FAT or FAT32 format. Be careful since the devices formatted in NTFS or other format will not be able to be operated. The file system can be confirmed on the device properties in applications such as Explorer of Windows.
Page 271 Oki Data CONFIDENTIAL (5) Enter the password, and then press the [OK] button. (If the password is not set for Service, press the [OK] button without entering anything.) Enter Password “ & ‘ < > Caps Space Backspace Reset Fig.11-2 The screen for selecting items to be updated is displayed after approx.
Page 272 Oki Data CONFIDENTIAL Notes: • The display of items on this screen varies depending on the types of data written on the USB device. Each item is displayed only when each data file is written on the USB device in the following conditions.
Page 273 Oki Data CONFIDENTIAL (7) Press the [START] button. Updating starts and the processing status is displayed on the LCD screen. The follow screen shows the display when selecting “1. SYSTEM FIRMWARE (OS Data)” in the update selection menu. “Update in progress” is displayed on the right side of the selected item, and then “Verifying Signature...”...
Page 274 Oki Data CONFIDENTIAL Notes: • “Update Failed.” is displayed at the bottom of the LCD screen when the updating is not completed properly. “Failed” appears next to the failed item on the status display. Even though an update fails, do not turn the power OFF until other updates are finished.
Page 275: Firmware Updating With Pwa-Dwnld-Jig2
Oki Data CONFIDENTIAL Firmware Updating with PWA-DWNLD-JIG2 The data to be overwritten by this update are as follows. When the CU board is replaced, update the ROM data written on CU board as necessary. equipment Firmware Updating method System firmware...
Page 276: Writing The Data To The Download Jig (Pwa-Dwnld-Jig2)
Oki Data CONFIDENTIAL 8.4.1 Writing the data to the download jig (PWA-DWNLD-JIG2) The download jig (PWA-DWNLD-JIG2) is that in which the Flash ROM is mounted on the board directly. The ROM writer adapter (PWA-DL-ADP-350) is required to write data to these Flash ROMs.
Page 277 Oki Data CONFIDENTIAL [a] Precautions when writing the system firmware data • Set the writing voltage (VID) to 3.3 V. When an error appears while the data are being written to the download jig, set the writing voltage (VID) to 12 V and then write them.
Page 278: System Firmware
Oki Data CONFIDENTIAL 8.4.2 System firmware The system firmware can be updated individually by using PWA-DWNLD-JIG2. Important: • Be sure to shut down the equipment before installing and removing the download jig. • Do not shut down the equipment during the update. The data could be damaged and not be able to be operated properly.
Page 279 Oki Data CONFIDENTIAL (14) Restore the key and license data by following the steps below. • Restore the key data by pressing the [1] key to select “1. Key SRAM to FROM”, then press the [START] button. • If the state of “FROM Licence Status” is “KeyMismatch”, restore the license data by pressing the [3] key to select “3.
Page 280: Firmware Updating With K-Pwa-Dlm-320
Oki Data CONFIDENTIAL Firmware Updating with K-PWA-DLM-320 The firmware of the option (FAX ROM) can be updated individually by using K-PWA-DLM- 320F. Update the ROM data written on each board according to the need such as the case of replacing the board.
Page 281: Fax Unit Firmware (Gd-1340)
Oki Data CONFIDENTIAL 8.5.1 FAX unit firmware (GD-1340) Important: • Before updating the FAX firmware, make sure to print out the current Function list for maintenance, Function list (ADMIN), Address book list and Group number information. In case the updating is failed and the registered information of the users is lost for some reason, re-register the user information referring to the lists and recover it.
Page 282 Oki Data CONFIDENTIAL (7) Turn the power OFF using the main power switch of the equipment, remove the download jig, and then install the right side cover. (8) In the FAX Clearing Mode, perform the “FAX Set Up”. • Confirm the destination setting is correct in the Setting Mode (08).
Page 283: Confirmation Of The Updated Data
Oki Data CONFIDENTIAL Confirmation of the updated data After the updating is completed, check each data version in Setting Mode (08) to confirm that the data were overwritten properly. Firmware Code Remarks Updating System firmware 08-9930 System firmware version Updating PU firmware...
Page 284: When Firmware Updating Fails
Oki Data CONFIDENTIAL When Firmware Updating Fails When the equipment was shut down during firmware updating or it could not be started after updating for some reason, perform firmware updating again following the procedure below. 8.7.1 Procedure (1) Update “System firmware“ of the system control PC board (CU board) using the download jig (PWA-DWNLD-JIG2).
Page 285: Flow Chart For Correcting Usb Update Failure
Oki Data CONFIDENTIAL 8.7.2 Flow chart for correcting USB update failure [a] When the update of the system firmware failed USB update failed Update USB. Failed twice or more? " 11.1 Firmware Updating with USB device " Update download jig.
Page 286 Oki Data CONFIDENTIAL [B] When the update of system software failed USB update failed Update USB. Failed twice or more? " 11.1 Firmware Updating with USB device " Check HDD harness connection. Update USB. Update succeeded? Replace HDD. Update USB.
Page 287: Backup Function
Oki Data CONFIDENTIAL BaCkUP FUNCTION Data Cloning 9.1.1 General description Data cloning is a function that backs up user data, setting data and SRAM data into a USB device and also restores these data into the equipment. This function backs up or restores the data of the same equipment (same serial number), and is performed in the following cases.
Page 288: Backup Files
Oki Data CONFIDENTIAL 9.1.3 Backup files The following files are saved in the root directory of the USB device by backing up. Filename Remark Modelname_MFPSerialNo_yyyy-MM-dd_ E.g.: When backup was performed at 13:59 on hh-mm October 1st, 2010. T280_CUK911379_2010-10-01_13-59 9.1.4 Cloning procedure [a] Backup procedure (1) Press the [POWER] button to shut down the equipment.
Page 289 Oki Data CONFIDENTIAL [B] Restore procedure (1) Press the [POWER] button to shut down the equipment. (2) Connect the USB device [1] to the USB port [2] on the right upper cover. Fig. 9-4 Notes: Backing up cannot be performed with multiple USB device [1] connected at the same time.
Page 290 Oki Data CONFIDENTIAL [C] Confirmation of the error “Backup Failed” or “Restore Failed” is displayed on the lower left part of the LCD screen when the data have not been properly backed up or restored. Moreover, details of an error are displayed under the above message.
Page 291: Aes Data Encryption Function Setting
Oki Data CONFIDENTIAL AES Data Encryption Function Setting 9.2.1 General description Data encryption is a function that encrypts data in the HDD to enhance the security. Note that this function may affect the equipment performance. 9.2.2 Precautions When the data encryption function is set enabled, data currently stored in the HDD will not be retrieved.
Page 292: Setting Procedure
Oki Data CONFIDENTIAL 9.2.3 Setting procedure A procedure for setting the data encryption function is shown below. Start [A] Back up data in HDD [B] Print out "FUNCTION FOR MAINTENANCE" [C] Print out "FUNCTION" list [D] Erase HDD [E] Reset user's setting item and restore data/information [F] Reset "FUNCTION LIST FOR MAINTENANCE"...
Page 293 Oki Data CONFIDENTIAL [a] Back up in HDD Ask the user (machine administrator) to back up the data in the HDD. Refer to the table below for the type of data, availability and method of backup. Type of data in HDD...
Page 294 Oki Data CONFIDENTIAL [C] Print out “FUNCTION” list (1) Press the [SETTING] button. (2) Press the [ADMIN] button, enter the password, and then press the [ENTER] button. (3) Press the [LIST/REPORT] button and then the [LIST] button. (4) Press the [FUNCTION] button. The “FUNCTION” list is printed out.
Page 295 Oki Data CONFIDENTIAL [F] Reset “FUNCTION LIsT FOR maINTeNaNCe” (1) Print out the “FUNCTION LIST FOR MAINTENANCE” list after the formatting. (2) While pressing [1] and [3] simultaneously, turn the power ON. (Function Mode) (3) Compare the lists which were printed before and after the formatting to check the setting items having the different setting values.
Page 296: Procedure For Disabling Data Encryption Function
Oki Data CONFIDENTIAL 9.2.4 Procedure for disabling data encryption function The basic procedure is the same as the one for enabling this function. To disable it, set “0 (Invalid)” in the code 08-9379 at step  P. 9-8 “[D] Enable data encryption function”.
Page 297: High Security Mode
Oki Data CONFIDENTIAL High Security Mode 9.3.1 General description The High Security Mode is a security mode complying with the IEEE2600.1 Security Standards Requirement. To have the equipment enter this mode, follow the procedure and the precautions below. 9.3.2 Prior confirmation •...
Page 298: Precautions
Oki Data CONFIDENTIAL 9.3.4 Precautions • In the High Security Mode, an integrity check system is operated at every restart. If F521 (integrity check error) is displayed, take the necessary measures following the troubleshooting procedure. • When a self-diagnostic mode is started in the High Security Mode, an authentication screen appears.
Page 299: External Counters
Oki Data CONFIDENTIAL eXTeRNaL COUNTeRs 10.1 Outline This chapter describes the interface between the equipment and coin controller. This equipment does not support card controller and mechanical counter. 10.2 Signal Notes: • Use 24V supplied from the main equipment as power for the output signals (CTRON) from the transistor.
Page 300 Oki Data CONFIDENTIAL 2. Connector on the CU board: CN110 (JST-made B7B-PH-SM4) (Coin Controller) Signal name Function Voltage level Remarks 1260 LARGE / Paper size Signal Open Collector L: Large size In use SMALL FULL Full color mode Open Collector...
Page 301: Details Of The Signals
Oki Data CONFIDENTIAL 10.2.2 Details of the signals 1. CTRON signal (output signals) These signals are synchronized with electronic counter of the equipment and they become “Low” when one sheet of paper is counted up. They are the signals for coin controller, and output from the LGC board.
Page 302 Oki Data CONFIDENTIAL 5. BKCTR signal, MNCTR signal, FLCTR signal (output signals) These signals become “Low” (ON) synchronizing with the CTRON signal according to the copying mode used. The pulse width corresponds to the fixed time. Though the CTRON signal is set to “Double count”, they are not outputted synchronizing with the second count signal.
Page 303: Notices
Oki Data CONFIDENTIAL 10.3 Notices 10.3.1 Setting code Each signal will be enabled by configuring the setting code “08-9016” (Counter installed externally). 08-9016 0: No external counter (Default) 1: Coin controller 5: Coin controller supporting ACS 10.3.2 Setting value change and restrictions when using the coin controller 1.
Page 304: Self-Diagnosis Code (03/04/05/08 Code)
Oki Data CONFIDENTIAL seLF-DIaGNOsIs CODe (03/04/05/08 CODe) Test mode (03)/Test Print mode (04) Input check (Test mode 03) Items to be checked and the condition of the equipment when the buttons [A] to [H] are highlighted are listed on the following pages.
Page 305 Oki Data CONFIDENTIAL Output check (test mode 03) Code Function Procedure Modem test 2100Hz Modem test 14.4KBPS(V17) Modem test 9.6KBPS(V29) Modem test 4.8KBPS(V27) Modem test 300BPS Modem test 1850Hz Modem test 1650Hz Modem test 1100Hz Modem test 462Hz Modem test 1300Hz Modem test 33.6KBPS(V.34)
Page 306 Oki Data CONFIDENTIAL Test print mode (test mode 04) Code Types of test pattern Remarks Remarks Output from Overall halftone for printer (Image) Size A4/LT Printer secondary scanning direction 32 Size A4/LT gradation steps (Image) 11-3 / 45584901TH Rev.1...
Page 307: Adjustment Mode (05) Codes
Oki Data CONFIDENTIAL Adjustment Mode (05) Codes Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Printer Feeding Setting method of 4800 1st Tray SYS 0: Manual mode system/ Tray size...
Page 308 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Printer Image Density correction Fine adjustment of 4903 Cyan 13~19 13: -3 mode control density correction 14: -2...
Page 309 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Printer Image Fine adjustment for 4908 Color 0: -2 mode control printing plain paper 1: -1 2: 0...
Page 310 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Sharpness PPC(black) 7056 Text/Photo 0-255 SYS The larger the value, the sharper the image becomes. mode Proce-...
Page 311 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Density PPC(black) Automatic density 7123 Text/Photo 0-255 SYS The larger the value, the darker the image becomes.
Page 312 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Gamma PPC(black) Photo 7192 Medium density 0-255 SYS The larger the value, the darker the image of the area...
Page 313 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Gamma PPC(black) User custom 7276 High density 0-255 SYS The larger the value, the darker the image of the area...
Page 314 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Gamma PRT(black) PS/Detail/1200dpi 7310 Medium density 0-255 SYS When the value increases, the density in the target...
Page 315 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Gamma PRT(black) XPS/Smooth/ 7319 Low density 0-255 SYS When the value increases, the density in the target...
Page 316 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure Emission level 3/4 SYS The smaller the value, the lower the emission level 05 Adjustment Image PRT(black) 7330 0-255 mode...
Page 317 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Gamma Monochrome/ PS/Image 7362 High density 0-255 SYS When the value increases, the density in the target...
Page 318 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Gamma Monochrome/ XPS/Graphics 7367 Medium density 0-255 SYS When the value increases, the density in the target...
Page 319 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Density SCN(black) Manual 7444 Text/Photo 0-255 SYS The larger the value, the darker the image at the center...
Page 320 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Gamma SCN(black) Text/Photo 7485 Low density 0-255 SYS The larger the value, the darker the image of the area...
Page 321 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Density FAX(black) Automatic density 7543 Photo 0-255 SYS The larger the value, the darker the image becomes.
Page 322 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Black area PPC(color) Black and red 7642 High density 0-255 SYS The larger the value, the larger the area recognized as...
Page 323 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Copy color Mono color Yellow green 7646 0-255 SYS Performs the density adjustment for the specified color...
Page 324 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Copy color Mono color Pink 7648 0-255 SYS Performs the density adjustment for the specified color mode...
Page 325 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Copy color Mono color / twin Green 7651 0-255 SYS Performs the density adjustment for the specified color...
Page 326 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Back- PPC(color) 7657 Text 0-255 SYS The larger the value, the darker the background mode Proce- ground becomes.
Page 327 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Fine PPC(color) Text 7666 Cyan 0-255 SYS The larger the value, the darker the blue becomes. mode...
Page 328 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Fine PPC(color) Photo (developing 7668 Magenta 0-255 SYS The larger the value, the darker the red becomes. The...
Page 329 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Fine PPC(color) Text/Photo 7675 Yellow 0-255 SYS Input the larger value to increase the saturation, and mode...
Page 330 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Fine PPC(color) Photo 7677 0-255 SYS Input the larger value to increase the saturation, and mode Proce- adjustment input the smaller value to decrease the saturation.
Page 331 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Fine PPC(color) Photo (developing 7678 Magenta 0-255 SYS Input the larger value to increase the saturation, and...
Page 332 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Fine PPC(color) User custom 7680 Blue 0-255 SYS Input the larger value to increase the saturation, and...
Page 333 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Density PPC(color) Manual 7717 0-255 SYS The larger the value, the darker the image becomes. mode Proce-...
Page 334 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Density Twin color Manual 7733 Text/Photo 0-255 SYS The larger the value, the darker the image becomes.
Page 335 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Sharpness PPC(color) Mono color 7803 Printed image 0-255 SYS The larger the value, the sharper the image becomes.
Page 336 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Marker 7850 PPC(color) "C" SYS The color of the one-touch adjustment "Marker" can be mode Proce- color adjusted.
Page 337 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Automatic PPC(color) Color/Black 7871 Thick paper4 SYS When color deviation is found in gradation reproduction, mode Proce-...
Page 338 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Maximum PPC(color) 7902 Plain paper 0-255 SYS The smaller the value, the less toner is adhered to the...
Page 339 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Maximum PPC(color) 7913 Thick paper 5 0-255 SYS The larger the value, the larger the maximum amount...
Page 340 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Maximum PPC(color) 7913 Envelope 0-255 SYS The larger the value, the larger the maximum amount mode Proce- toner of toner to be adhered becomes.
Page 341 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color PPC(color) "Y" Printed image 7962 High density 0-255 SYS The target color, mode and density area become...
Page 342 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color PPC(color) "M" Printed image 7967 Medium density 0-255 SYS The target color, mode and density area become...
Page 343 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color PPC(color) "C" Printed image 7972 Low density 0-255 SYS The target color, mode and density area become...
Page 344 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color PPC(color) "K" Text 7976 High density 0-255 SYS The target color, mode and density area become...
Page 345 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color PPC(color) "M" User custom 7981 Medium density 0-255 SYS The target color, mode and density area become...
Page 346 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Automatic PRT(color) 600dpi 8004 Thick paper3 SYS When color deviation is found in gradation reproduction, mode Proce-...
Page 347 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Automatic PRT(color) 1200dpi 8005 Thick paper3 SYS When color deviation is found in gradation reproduction, mode Proce-...
Page 348 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Back- PRT(color) Smooth/Color/ 8010 0-255 SYS The larger the value, the darker the background mode Proce- ground 600dpi becomes.
Page 349 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Back- PRT(color) Detail/Twin Color/ 8014 0-255 SYS The larger the value, the darker the background mode Proce-...
Page 350 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color 2 color printing/ 8023 High density 0-255 SYS The larger the value, the darker only the target color...
Page 351 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color 2 color printing/ 8028 Medium density 0-255 SYS The larger the value, the darker only the target color...
Page 352 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color 2 color printing/ 8033 Low density 0-255 SYS The larger the value, the darker only the target color...
Page 353 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color 2 color printing/ 8037 High density 0-255 SYS The larger the value, the darker only the target color...
Page 354 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color PRT(color) "Y" XPS/Smooth/ 8042 Medium density 0-255 SYS The larger the value, the darker only the target color...
Page 355 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color PRT(color) "M" XPS/Detail/600dpi 8047 Low density 0-255 SYS The larger the value, the darker only the target color...
Page 356 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color PRT(color) "M" PS/Smooth/600dpi 8051 High density 0-255 SYS The larger the value, the darker only the target color...
Page 357 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color PRT(color) "C" PS/Detail/600dpi 8056 Medium density 0-255 SYS The larger the value, the darker only the target color...
Page 358 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color PRT(color) "K" PCL/Smooth/ 8061 Low density 0-255 SYS The larger the value, the darker only the target color...
Page 359 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color PRT(color) "K" PCL/Detail/600dpi 8065 High density 0-255 SYS The larger the value, the darker only the target color...
Page 360 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Maximum PRT(color/600 dpi) Detail 8070 Special paper 4-6 0-255 SYS The larger the value, the larger the maximum amount...
Page 361 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Maximum PRT(color/600 dpi) Smooth 8071 Thick paper3 0-255 SYS The larger the value, the larger the maximum amount...
Page 362 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Maximum PRT(color/1200 Detail 8089 Thick paper 5 0-255 SYS The larger the value, the larger the maximum amount...
Page 363 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Maximum PRT(color/1200 Detail 8089 Envelope 0-255 SYS The larger the value, the larger the maximum amount mode...
Page 364 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Maximum PRT(color/1200 Smooth 8090 Special paper 4-6 0-255 SYS The larger the value, the larger the maximum amount...
Page 365 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Sharpness PRT(color) e-BRIDGE/PS/ 8108 Photo 0-255 SYS The larger the value, the sharper the image becomes. mode...
Page 366 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Sharpness PRT(black) e-BRIDGE/PS 8118 Text 0-255 SYS The larger the value, the sharper the image becomes. mode...
Page 367 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Upper PRT color/Two- 600 dpi 8160 0-255 SYS The smaller the value, the lighter the printed image...
Page 368 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Pure PRT(color) PCL/Image 8212 General 1-255 SYS The larger the value, the wider the range of colors to...
Page 369 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Stroke PS/PDF automatic 600dpi 8239 Minimum stroke SYS This code is used to change the width of fine lines in...
Page 370 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Line width PRT(color) 8241 1200dpi SYS The larger the value, the darker the fine lines become. mode...
Page 371 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Pure PRT(color) XPS/Text 8249 Presentation 1-255 SYS The larger the value, the wider the range of colors to...
Page 372 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Pure PRT(color) XPS/Image 8251 Line art 1-255 SYS The larger the value, the wider the range of colors to...
Page 373 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Pure PRT(color) PS/Graphic 8253 Advanced 1-255 SYS The larger the value, the wider the range of colors to...
Page 374 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color PRT(color) PS/Smooth/ 8270 Low density 0-255 SYS When the value increases, the density in the target...
Page 375 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Color PRT(color) PS/Detail/1200dpi/ 8274 High density 0-255 SYS When the value increases, the density in the target...
Page 376 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Fine SCN(color) 8315 Text SYS The larger the value, the darker the black side of the mode...
Page 377 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment Image Density SCN(color) Manual 8341 Photo 0-255 SYS The larger the value, the darker the image becomes. mode...
Page 378 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 05 Adjustment System Mainte- 9960 Display of Refer SYS Displays the equipment information in SRAM. mode nance equipment 0: Not set...
Page 379: Setting Mode (08) Codes
Oki Data CONFIDENTIAL Setting Mode (08) Codes Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User Card reading device 3500 Device setting 0006 SYS To enable the e-Bridge ID Gate, a card reading device...
Page 380 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User Card reading device 3502 Card reader format SYS The data of the block number in the noncontact IC is set.
Page 381 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Available profile 3600 SH_IS34_08.icc SYS Displays PG Device Pure Gray TRC attribute for the mode display current RGB Ink Sim profile and the same sub-code.
Page 382 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Available profile 3600 SH_IS34_28.icc SYS Displays PG Device Pure Gray TRC attribute for the mode display current RGB Ink Sim profile and the same sub-code.
Page 383 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Available profile 3600 SH_IS34_48.icc SYS Displays PG Device Pure Gray TRC attribute for the mode display current RGB Ink Sim profile and the same sub-code.
Page 384 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Displaying the 3604 SH_IS34_05.000 SYS Displays the default RGB Ink Sim profile and PG Device mode attribute of the profile PureGray TRC attribute in the same sub-code.
Page 385 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Displaying the 3604 SH_IS34_19.000 SYS Displays the default RGB Ink Sim profile and PG Device mode attribute of the profile PureGray TRC attribute in the same sub-code.
Page 386 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Displaying the 3604 SH_IS34_33.000 SYS Displays the default RGB Ink Sim profile and PG Device mode attribute of the profile PureGray TRC attribute in the same sub-code.
Page 387 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Displaying the 3604 SH_IS34_47.000 SYS Displays the default RGB Ink Sim profile and PG Device mode attribute of the profile PureGray TRC attribute in the same sub-code.
Page 388 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Displaying the 3608 SH_IS34_02.001 SYS Displays the adjusted Output Profile and PG CIE Based mode attribute of the profile Pure Gray TRC attribute in the same sub-code.
Page 389 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Displaying the 3608 SH_IS34_16.001 SYS Displays the adjusted Output Profile and PG CIE Based mode attribute of the profile Pure Gray TRC attribute in the same sub-code.
Page 390 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Displaying the 3608 SH_IS34_30.001 SYS Displays the adjusted Output Profile and PG CIE Based mode attribute of the profile Pure Gray TRC attribute in the same sub-code.
Page 391 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Displaying the 3608 SH_IS34_44.001 SYS Displays the adjusted Output Profile and PG CIE Based mode attribute of the profile Pure Gray TRC attribute in the same sub-code.
Page 392 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Real time log 3626 Department SYS Sets whether the department information (number, Mode notification function information...
Page 393 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network 3720 Windows domain UTY Maximum 128 letters mode No.3 of user authentication 08 Setting System Network...
Page 394 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network 3743 LDAP client 1-180 NIC Use when a timeout occurred at LDAP client connection mode TimeOut...
Page 395 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network 3778 Acquiring DHCPv6 NIC When Stateless Address is selected, an option is mode Option acquired from DHCPv6 server.
Page 396 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Scanner 3805 Department SYS Sets the department management with remote scanning mode Management setting as follows: by Remote Scan...
Page 397 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Scanner PDF file 3817 Version setting SYS The version of PDF file produced by the Scan function is mode set.
Page 398 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Summer time Start 3856 Day of the week SYS 0: Sun 1: Mon 2: Tue 3: Wed 4: Thu 5: Fri 6: Sat...
Page 399 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting Printer Paper Automatic change of When a Tray is 4016 SYS Sets whether the automatic change of paper source is...
Page 400 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting Printer Paper Paper size setting 4104 Refer 0-255 SYS Press the button on the LCD to select the size. This code...
Page 401 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting Counter Printer Full color 6061 Large 8 digits SYS Counts the number of output pages at the Full Color...
Page 402 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting Counter Copy Print Black 6063 Small 8 digits SYS Counts the number of output pages at the Black Mode in mode the Copier Function according to its size (large/small).
Page 403 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting Counter FAX Print Black 6066 Large 8 digits SYS Counts the number of output pages in the FAX Function mode according to its size (large/small).
Page 404 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting Counter NW Full color 6068 Small 8 digits SYS Counts the number of scanning pages at the Full Color...
Page 405 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting Counter FAX Scanning Black 6071 Large 8 digits SYS Counts the number of scanning pages in the FAX mode Function according to its size (large/small).
Page 406 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting Counter FAX Transmission Black 6073 Small 8 digits SYS Counts the number of transmitted pages in the FAX mode Function according to its size (large/small).
Page 407 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting Counter Double For charging Paper type 6083 Special1(Label1) / SYS Sets the weight of fee charging count for printing per...
Page 408 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting Counter Counter Color/Black quota 6087 Twin/Mono color SYS When the pages are counted for twin/mono color Mode Settings...
Page 409 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting Image Automatic Last updated date Color PPC 7052 Thick paper3 SYS Last updated date and time of automatic tone correction...
Page 410 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting Image Automatic Last updated date NW printer/600dpi 7352 Thick paper2 SYS Last updated date and time of automatic tone correction...
Page 411 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting Image Automatic Last updated date NW printer/ 7354 Thick paper4 SYS Last updated date and time of automatic tone correction...
Page 412 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting Image User User custom mode 8303 Color SYS 0: Unused mode Proce- interface setting 1: Text/Photo base ssing...
Page 413 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General 8518 Overwriting mode SYS 0: Always OFF mode for scanned files 1: Meta Scan function ON / Normal scan function OFF...
Page 414 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General ACS release factor 8530 Short size 1-99 SYS Sets a percentage of each paper size in the total number...
Page 415 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User 8538 Toner near empty SYS 0: Disabled mode interface notification setting 1: Enabled 08 Setting System User...
Page 416 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User 8603 Special usage of SYS 0: None Mode interface external options I/F 1: Usage 1 2: Usage 2...
Page 417 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User 8704 Email/FAX address SYS 0: No restriction Mode interface restriction 1: Search for external LDAP only Use this code to restrict address of emal/fax to specified LDAP server.
Page 418 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User Service notification 8715 Password for zip file #10481 SYS Password for zip file with password of service notification...
Page 419 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User 8724 Display setting of SYS 0: Not displayed (From Address cannot be edited) Mode interface Edit From Address...
Page 420 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General 8750 Time to wait for print SYS Sets whether the drum idling is executed or not when the...
Page 421 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Scanning 8767 Default value of Refer SYS Sets the default value of original size for the network...
Page 422 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network IPsec 8802 Enable/Disable NIC 1: Enabled 2: Disabled mode setting 08 Setting System Network SNMPv3 8803...
Page 423 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Preview 8902 Default display SYS Sets the default display method on the preview screen Mode method when using the Fax function.
Page 424 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System MFP 8914 Save as Local HDD SYS Sets whether the function that saves data to HDD in the...
Page 425 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System MFP 8914 Network SYS Sets whether the Network InternetFAX function is mode function InternetFAX enabled or disabled.
Page 426 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Depart- 8926 Clearing of all SYS In cases when the administrator has prohibited the mode ment department...
Page 427 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User General Language package 8970 Service UI Displays the language package information of the Mode interface information installed Service UI.
Page 428 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Scheduled automatic 8981 Day of the week 0-255 SYS Sets the condition and day of the week for scheduled...
Page 429 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Mainte- Notification Notification setting 8991 Notification setting SYS 0: Disabled Mode nance of equipment 1: Enabled information...
Page 430 24: South Africa 25: Taiwan 26: Russia 27: Brazil <Default value> ODA: 4 Others: 5 08 Setting System General 9003 OEM identification SYS 0: Reserve, 1: OKI mode code destination 08 Setting System General 9010 Line adjustment SYS 0: For factory shipment...
Page 431 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General 9012 Language selection English SYS en_US: English de_DE: German fr_FR: French mode to be displayed at...
Page 432 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Mainte- General 9059 Operation switching Refer SYS Switches whether a menu for selecting paper in user Mode...
Page 433 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General 9103 Time differences Refer 0-47 SYS 0: +12.0h 1: +11.5h 2: +11.0h 3: +10.5h 4: +10.0h mode 5: +9.5h 6: +9.0h 7: +8.5h 8: +8.0h 9: +7.5h...
Page 434 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User Power save 9114 Energy saving mode SYS 0: Off mode Mode interface 1: Sleep mode 2: Auto mode...
Page 435 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User Default mode setting Default setting 9132 Default setting of 0-99 SYS Sets the screen to be displayed after the auto-clear time...
Page 436 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User Automatic Sorting 9150 Automatic Sorting SYS 0: Invalid mode interface Mode setting (RADF) Mode setting 1: STAPLE...
Page 437 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User 9163 Default setting of SYS 0: Short edge mode interface printing direction 1: Long edge for Time Stamp and...
Page 438 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network Retention period 9193 Web data retention 3 digits SYS When a certain period of time has passed without...
Page 439 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Option 9211 Default setting of SYS Sets the default value for the page by page of Internet...
Page 440 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User Default mode setting Default setting of 9218 Black SYS 0: 150 dpi Mode interface resolution (SCN)
Page 441 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User Default mode setting 9226 Default setting SYS 1: Step -4 mode interface of background 2: Step -3...
Page 442 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Image Binarizing level 9230 Step 0 (center) 0-255 SYS Sets the binarizing level of each step. mode setting When the value increases, the image becomes darker.
Page 443 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Data 9240 HDD data SYS Select the type of the overwriting level for deleting mode overwrite overwriting type HDD data.
Page 444 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network 9274 "From" address SYS 0: User name + @ + Domain name mode assignment method 1: LDAP searching at the time of 2: Use the address registered at "From"...
Page 445 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network 9299 Restriction on "To" SYS 0: No restriction mode ("cc") address 1: Can be set from both of the Address book and LDAP...
Page 446 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Paper Paper information 9302 Tray 3 Refer to SYS 0: Plain paper mode feeding contents 1: Thick paper 1...
Page 447 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Paper Paper information 9304 Refer to SYS 0: Plain paper mode feeding contents 1: Thick paper 1...
Page 448 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network Print Raw printing job 9309 Paper size Refer Refer to SYS 1: LG mode contents 2: LT...
Page 449 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Paper Paper size (MPT/non- 9318 Memory 1 127/64 127-356/ SYS Registers the paper size of MPT (non-standard type) into...
Page 450 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network Print 9334 PCL line feed code SYS Sets the PCL line feed code. mode setting 0: Automatic setting...
Page 451 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User Copy Binding margin 9341 Top binding front 0-100 SYS Sets the binding margin displayed as default on the...
Page 452 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Available profile 9361 SH_OP_07.icc SYS Displaying the current Output Profile and PG CIE Based...
Page 453 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Available profile 9361 SH_OP_18.icc SYS Displaying the current Output Profile and PG CIE Based...
Page 454 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Available profile 9361 SH_OP_29.icc SYS Displaying the current Output Profile and PG CIE Based...
Page 455 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Available profile 9361 SH_OP_40.icc SYS Displaying the current Output Profile and PG CIE Based...
Page 456 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Available profile 9361 SH_OP_51.icc SYS Displaying the current Output Profile and PG CIE Based...
Page 457 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Displaying the 9365 SH_OP_04.000 SYS Displays the default Output Profile and PG CIE Based...
Page 458 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Displaying the 9365 SH_OP_15.000 SYS Displays the default Output Profile and PG CIE Based...
Page 459 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Displaying the 9365 SH_OP_26.000 SYS Displays the default Output Profile and PG CIE Based...
Page 460 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Displaying the 9365 SH_OP_37.000 SYS Displays the default Output Profile and PG CIE Based...
Page 461 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Displaying the 9365 SH_OP_48.000 SYS Displays the default Output Profile and PG CIE Based...
Page 462 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Displaying the 9369 SH_OP_01.001 SYS Displays the adjusted Output Profile and PG CIE Based...
Page 463 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Displaying the 9369 SH_OP_12.001 SYS Displays the adjusted Output Profile and PG CIE Based...
Page 464 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Displaying the 9369 SH_OP_23.001 SYS Displays the adjusted Output Profile and PG CIE Based...
Page 465 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Displaying the 9369 SH_OP_34.001 SYS Displays the adjusted Output Profile and PG CIE Based...
Page 466 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General Color profile Displaying the 9369 SH_OP_45.001 SYS Displays the adjusted Output Profile and PG CIE Based...
Page 467 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User Email 9380 Converting 1-byte SYS 0: Non-conversion mode interface katakana into 2 1: With conversion byte- katakana at...
Page 468 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network Scanning 9388 Date display format SYS Sets the data display format of the file for "Save as file"...
Page 469 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network TCP/IP 9406 Method of acquiring NIC 1: Fixed IP address Mode IP address 2: Dynamic IP address...
Page 470 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network NetWare 9426 Availability of NIC 1: Available mode Bindery 2: Not available 08 Setting System Network...
Page 471 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network 9505 Bonjour setting NIC 1: Valid mode 2: Invalid 08 Setting System Network 9514 Host name...
Page 472 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network DHCP 9580 Enabling server's IP Domain Name Server option (6) mode address acquired by 1: Enabled...
Page 473 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Mainte- Remote-controlled 9608 Destination E-mail SYS Maximum 192 letters mode nance service address 3 08 Setting System Mainte-...
Page 474 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Wireless 9649 Wireless LAN NIC Sets whether the wireless LAN connection is enabled or mode setting disabled.
Page 475 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Mainte- RDMS General 9724 Writing data of self- SYS 0: Prohibited Mode nance diagnostic code 1: Accepted...
Page 476 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network Scanning 9749 WIA Scan Driver NIC Selects WIA Scan Driver. mode 1: OKI 2: Microsoft 08 Setting...
Page 477 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Mainte- Remote-controlled Automatic ordering 9766 Notes SYS Maximum 128 letters mode nance service function of supplies 08 Setting...
Page 478 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Mainte- 9788 Service call 0-12 SYS 0: No checking period specified (= Calls service mode nance checking period...
Page 479 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Version Printer ROM version of 9807 Tray2 00.00.00- Mode printer optional FF.FF.FF tray 08 Setting System Version...
Page 480 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General 9816 Addition of the page SYS Only when job is executed with TimeStamp enabled for mode...
Page 481 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Mainte- General 9843 Serial number SYS Displays the serial number of PU board. mode nance display 08 Setting...
Page 482 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Image Default value setting Background peak 9897 Black SYS 1: -4 2: -3 3: -2 4: -1 5: 0 6: +1 7: +2 8: +3 9: +4...
Page 483 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General S-ACS operation 9934 Copy SYS 1: The number of contact control: 1 mode setting Continuous color control: 1 sheet...
Page 484 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System General S-ACS operation 9934 Box, Others SYS 1: The number of contact control: 1 mode setting Continuous color control: 1 sheet...
Page 485 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Network E-mail 9958 Bcc address display SYS Sets whether the Bcc address is displayed or not on...
Page 486 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System User Default setting ACS original mode 9977 SYS 0: Text/Photo mode interface 1: Text 2: Printed image...
Page 487 Oki Data CONFIDENTIAL Sub- Default Acceptable Proce- 05/08 Mode Element Item Subitem Code Details Contents element code value value dure 08 Setting System Fax 9987 Retention of fax SYS Sets whether the fax sending settings are retained or Mode sending settings not.
