Summary of Contents for Hover-1 HY-H1
- Page 1 E L E C T R I C S C O O T E R OPERATION MANUAL HY-H1...
- Page 2 HELMETS SAVE LIVES! Always wear a properly tted helmet that complies with CPSC or CE safety standards when you ride your bicycle. Correct Fitting: Make sure your helmet covers your forehead. Incorrect Fitting: Forehead is exposed and vulnerable to serious injury.
- Page 3 2. The operating temperature range of the charger is 32° F-104° F (0-40° C). 3. The operating temperature range of the Hover-1 is 32-104° F (0-40° C). 4. Do not ride on icy or slippery surfaces. 5. Read the user manual and warning labels before riding.
- Page 4 LOW TEMPERATURE WARNING Low temperature will affect the lubrication of moving parts inside the H1 scooter, increasing internal resistance. At the same time, in low temperatures, the discharge capacity and the capacity itself of the battery will be significantly decreased. Use caution when riding the H1 in cold temperatures (below 40 degrees F).
- Page 5 • Do not operate, or allow others to operate, the Hover-1, until the user understands all instructions, warnings and safety features described in this manual. • Check with your doctor if you have a medical condition that could affect your ability to use the H1 •...
- Page 6 INTRODUCTION The Hover-1 H1 is a personal transporter. Our technology and production processes are developed with strict testing for each Hover-1 scooter. Riding without following the contents of this manual may lead to damage to your device, or may cause bodily injury.
- Page 7 Inspect the entire device thoroughly before every ride, and do not ride it until any problems have been corrected. SPECIFICATIONS Model: HY-H1 Net Weight: 22.04 lbs (10 kg) Load: 44-265 lbs (20-120 kg) Max Speed: Up to 9 mph (14.4 km/h) Max Distance Range: Up to 9 miles (14.4 km)
- Page 8 STATUS INDICATOR When the operator triggers the foot mats, the LED Status Indicator will light up, which indicates that the Hover-1 is now ready for use. When the system has an error during operation, the status LED light will turn red (for more details see SAFETY ALERTS).
- Page 9 SMART PHONE APP Your H1 is an App-enabled scooter that works with most mobile devices. You must download the Hover-1 app in order to change certain features of your H1 such as headlight colors and skill mode. Please download the App from either the App Store or download the App from the Google Play Store.
- Page 10 2) DASHBOARD Before allowing you to access the dashboard, a safety screen will pop-up for 3 seconds. Please review the safety notes in this screen while the dashboard loads. The dashboard will appear as shown below. Connected E L E C T R I C S C O O T E R ODO 9.3 miles TRIP 12.4 miles...
- Page 11 LOADING... Remember to always wear protective gear while riding your Hover-1 Remember to be alert at all times and be aware of your surroundings 1. Connect Your H1 - To connect to your H1 through Bluetooth on your smart phone, press “Connect”. If your H1 is already paired, this part of the screen will show “Connected”...
- Page 12 3) CONNECT Press “Connect” to have the App begin scanning for any Hover-1 devices. Your H1 must be powered on and your smart phone’s Bluetooth must be enabled. If your Bluetooth is not enabled on your smart phone, the App will remind you to enable it.
- Page 13 The mode will only change if you are not using your H1 scooter. • Beginner Mode - This mode is recommended for first time Hover-1 scooter users. In this mode, the sensitivity and top speed are very low.
- Page 14 7) HEADLIGHTS Press “Headlights” to set a custom color for your H1’s Path Illumination Lights. Simply choose your desired color from the color wheel. For your convenience, 4 basic colors have also been set as presets below the brightness bar. Headlights Power Presets...
- Page 15 The H1 has a powerful built-in wireless speakers so you can play your music while riding. PAIRING THE SPEAKER 1. Ensure your H1 is turned off. If it is not, please turn off your Hover-1 first before pairing. 2. Turn on your H1 and the speakers will announce that it’s waiting for a Bluetooth connection.
- Page 16 IPX4 WATER RESISTANCE Ideal for both indoor and outdoor use, the H1 scooter features a water-resistant, weatherized case that protects its components from splashing water. This ensures that the high-quality tech within the H1 is protected while riding around outdoors & indoors and getting caught in the rain.
- Page 17 Hover-1 is not liable for tickets or violations given to riders who do not follow these regulations. • For your safety, always wear a helmet that meets CPSC or CE safety standards.
- Page 18 • Slow down at all street intersections and look to the left and right before crossing. Your Hover-1 is not equipped with reflectors. It is not recommended that you ride your bike in conditions of low visibility. If you are riding your scooter in low-visibility conditions, ensure your LED lights are turned on, and that you are wearing bright, reflective clothing.
- Page 19 • The device can be used on paved roads that are flat and even. If you encounter uneven pavement, please lift your Hover-1 over and past the obstruction. • Do not ride in inclement weather: snow, rain, hail, sleek, on icy roads...
- Page 20 • Do not ride in or near pools or other large bodies of water. • Bend your knees when riding on bumpy or uneven pavement to absorb the shock and vibration and help you keep your balance. • If you are unsure if you can safely ride on a specific terrain, step off and carry your device.
- Page 21 • Do not step forward off of your device. • Do not attempt to jump on or off your device. • Do not attempt any stunts or tricks with your device. • Do not ride the device in dark or poorly lit areas. •...
- Page 22 RIDING YOUR H1 FAILURE TO FOLLOW ANY OF THE FOLLOWING SAFETY PRECAUTIONS CAN AND MAY LEAD TO DAMAGE TO YOUR DEVICE, VOID YOUR MANUFACTURER WARRANTY, LEAD TO PROPERTY DAMAGE, CAUSE SERIOUS BODILY INJURY, AND CAN LEAD TO DEATH. Before using your device, be sure to familiarize yourself with the operating procedures.
- Page 23 The Hover-1 is an incredibly intuitive device; it senses even the slightest bit of motion, so having any anxiety or reservation about stepping on may cause you to panic and trigger unwanted movement. When you first begin using your device, the fastest way to move in your desired direction is to focus in that direction.
- Page 24 Make sure to lift your leg completely off the foot mat to clear the device when stepping back to dismount. Failure to do so may send the Hover-1 into a tailspin. NOTES: If the H1 is not placed on a level surface, an alarm will sound and the warning indicator will light up and prevent the H1 from moving.
- Page 25 BALANCE & CALIBRATION If your Hover-1 is unbalanced, vibrating, or not turning properly, you can follow the below steps to calibrate it. • In order for the balance calibration system to work properly, please place the scooter on a flat, horizontal surface.
- Page 26 SAFETY ALERTS While riding your H1 scooter, if there is a system error or improper operation performed, the device will prompt the user in a variety of ways. You will notice the Running Indicator Light will turn RED and you will hear a beep sound alerting you to take precaution and cease operation.
- Page 27 When the H1 turns off during a Safety Alert, all operation systems will halt. Do not continue attempting to ride the H1 when the system initiates a stop. Turn your Hover-1 off and back on to unlock it from a Safety Lock.
- Page 28 CHARGING YOUR H1 CHARGING THE DEVICE • Ensure that the charging port is clean and dry. • Make sure that there is no dust, debris or dirt inside the port. • Plug the charger into a grounded wall outlet. • Connect the cable with the power supply (100V ~ 240V; 50, 60 Hz). •...
- Page 29 • The battery contains dangerous substances, do not open the battery, or insert anything into the battery. • Use only the charger supplied by Hover-1. • Do not attempt to charge the device if the battery has discharge or emits any substances. In that case, immediately distance yourself from the battery in case of fire or explosion.
- Page 30 FCC STATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 31 CARE & MAINTENANCE • Do not expose the device to liquid, moisture, or humidity to avoid damage to the product's internal circuitry. • Do not use abrasive cleaning solvents to clean the device. • Do not expose the device to extremely high or low temperatures as this will shorten the life of the electronic device, destroy the battery, and/or distort certain plastic parts.
- Page 32 WARRANTY This product comes with a 30 day limited replacement warranty for manufacturer’s defects. This includes defects to the motor, gyroscopic sensor battery, etc. This product comes with a 120 day parts and labor warranty. Shipping & handling costs are not included. The condition of this warranty and our responsibilities under this warranty are as follows: Manufacturer's warranty is non-transferable.
- Page 33 All repairs are performed at a Hover-1 facility. Parts that have been replaced or exchanged become property of Hover-1.
- Page 34 2) Hover-1 will try to diagnose and solve your problem. If it is determined that a warranty claim exists, you will be given an RMA number (Return Material Authorization) and will be asked to send the product to Hover-1.
