Dynojet Power commander V Installation Instructions page 4

FIG.D
FIG.E
FIG.F
I23-007 www.powercommander.com
8
Unplug
9
10 Attach the ground wire of the PCV to the negative side of the battery (Fig. E).
11 Using the supplied velcro attach the PCV to the inside of the left radiator
12 Reinstall seat.
Unplug the stock wiring harness from the ignition coil (Fig. D).
Plug the PCV harness in-line of the stock ignition coil and wiring harness.
shroud (Fig. F).
Make sure to clean the surface with the alcohol swab before attaching.
2011-2013 Husqvarna 511 Models PCV - 4
