Baxi Megaflo 2 System 24 Compact User's Operating Instructions & Important Warranty Information page 6

THESE BUTTONS
INACTIVE
Temperature Adjustment
On/Off Selector Button
The button can be pressed so that the display shows
the following information:-
'00' alternates with Sub-Code (only when fault on boiler) or '000'
'01' alternates with CH Flow Temperature
'02' alternates with Outside Temperature (where Sensor fitted)
'03' alternates with DHW Temperature
'04' alternates with DHW Temperature
'05' alternates with System Water Pressure
'06' alternates with CH Return Temperature
'07' alternates with Flue Temperature
'08' - not used
'10' alternates with Zone 1 CH Flow Temperature
'11' alternates with Zone 2 CH Flow Temperature
'12' alternates with Ion current
'13' alternates with Burner working hours
'14' alternates with Zone 1 CH mode
'15' alternates with Zone 2 CH mode
'16' alternates with DHW circuit operating mode
'17' alternates with Boiler operating mode
'18' alternates with Solar plant operating mode
'19' alternates with Manufacturer information
'20' alternates with Manufacturer information
6
© Baxi Heating UK Ltd 2013
Display Screen
Central Heating
3.0 Temperature Adjustment &
3.1 To adjust the central heating temperature
1. Press
2. Press
NOTE: An overheat thermostat (NTC) is positioned in the
heat exchanger which shuts down the appliance if the
boiler temperature exceeds 100°C. Press
R
re-establish normal operating conditions.
3.2 Boiler On Selector
1. Press the
appears:-
3.2 Cleaning the Outer Case
1. The painted panels should be wiped with a damp cloth and
R
then dried completely. DO NOT USE ABRASIVE CLEANING
AGENTS.
3.5 Boiler Frost Protection
1. The boiler incorporates an integral frost protection feature
that will operate in both Central Heating & Domestic Hot
Water modes, and also when in standby (
2. If the boiler temperature falls below 5° C, then the boiler
will operate until the water temperature has been raised.
3. Further protection may be required for the system. Consult
your installer for details.
3.6 Information Display
1. The table opposite shows information that can be displayed
by pressing the
2. Depending upon boiler model and any system controls
connected to the appliance, not all information codes will be
displayed and some that are will not have a value.
3. Press
Care of the Boiler
to increase the boiler temperature.
to decrease the boiler temperature.
button until the Boiler On mode
button.
R
to return to the normal display.
R
button to
displayed).
