Page 1: User Guide
United Kingdom User Guide Gas Fired Wall Mounted Condensing Combination Boiler D D uo-tec Combi 24 - 28 - 33 - 40 28 LPG Please keep these instructions in a safe place. If you move house, please hand them over to the next occupier. -
Page 2: Table Of Contents
Benchmark is managed and promoted by the Heating and Hotwater Industry Council. For more information visit www.centralheating.co.uk © Baxi Heating UK Ltd 2015 All rights reserved. No part of this publication may be reproduced or transmitted in any form or by any means, or stored in any... -
Page 3: Quick Reference Guide
Central Heating System Pressure - The normal operating water pressure is between 1 and 2.0 bar. If the pressure exceeds 3 bar the safety pressure valve will operate and a fault is indicated. Contact your Installer. © Baxi Heating UK Ltd 2015... -
Page 4: Troubleshooting
? If the reading falls below 1 bar repressurise the system as Turn the ON/OFF/Reset described in section 3.1. Selector Switch to Reset. If boiler does not Reset Error Code E119 showing low pressure. © Baxi Heating UK Ltd 2015... - Page 5 INSTALLER OR SERVICE ENGINEER. If you don’t know what you need to do to get the boiler to light, or need help with the system and controls, contact your installer as soon as possible. © Baxi Heating UK Ltd 2015...
-
Page 6: Repressurising System
Requires 8. Disconnect the copper pipe from the taps (a small Repressurising amount of water may be present) and remove it. Keep the pipe in a safe place for future use. © Baxi Heating UK Ltd 2015... -
Page 7: Clearances
11. It is important that the condensate drain system is not blocked, modified or damaged in any way as this would affect the operation of your boiler. Your installer should have insulated any exposed pipework. 5mm Min Fig. 4 In Operation © Baxi Heating UK Ltd 2015... -
Page 8: Care Of The Boiler
5 E133 Interruption Of Gas Supply or Flame Failure seconds. If the boiler does not relight, or the code is displayed E160 Fan or Fan Wiring Fault regularly contact your installer or service engineer. © Baxi Heating UK Ltd 2015... -
Page 9: Legislation
The service engineer should complete the relevant Service Record on the Benchmark Checklist after each service. 4. The Benchmark Checklist may be required in the event of any warranty work. © Baxi Heating UK Ltd 2015... -
Page 10: Warranty & Service
Standard Warranty Terms and Conditions Warranty Registration, Service & Repair For full terms and conditions, visit www.baxi.co.uk/terms. Benchmark Checklist The Benchmark Checklist will be completed by your installer and records that the boiler has been installed and commissioned correctly. - Page 11 If you experience a problem with your boiler For any in or out of warranty repair, Baxi Customer Support is on hand to help you. Call our award-winning team to arrange for one of our nationwide team of Gas Safe registered engineers to visit.
-
Page 12: Erp Information
Water heating - Annual energy consumption Seasonal space heating energy efficiency Water heating energy efficiency Sound power level L indoors For specific precautions about assembling, installing and maintaining consult the relevant section as detailed on the Contents page. © Baxi Heating UK Ltd 2015... - Page 13 The value of the seasonal space heating energy efficiency of the preferential space heater, expressed in %. The factor for weighting the heat output of preferential and supple mentary heaters of a package as set out in the following table. © Baxi Heating UK Ltd 2015...
- Page 14 (1) The intermediate values are calculated by linear interpolation between the two adjacent values. (2) Prated is related to the preferential space heater or combination heater. Package efficiency Baxi Duo-tec Combi ErP 28 LPG Temperature control X Temperature control Y © Baxi Heating UK Ltd 2015...
- Page 15 %, where Q is taken from the product fiche of the solar device and Q from Regulation EU 811/2013, Annex VII Ta ble 15 for the declared load profile M, L, XL or XXL. © Baxi Heating UK Ltd 2015...
-
Page 16: Notes
9.0 Notes © Baxi Heating UK Ltd 2015... - Page 17 9.0 Notes © Baxi Heating UK Ltd 2015...
- Page 18 9.0 Notes © Baxi Heating UK Ltd 2015...
-
Page 19: Emergency
