1 0 / / A C V u s e r m a n u a l
6 8
7 9
C O N N E C T I N G R E A R T R I A N G L E C O N N E C T I N G R E A R T R I A N G L E
T O B O X L I N K // T O T O P L I N K //
A A
Follow previous step to connect rear Hold spacers (#130765) with squared
triangle to box link (IMAGES #6 & 7). edges against the bearing and the rounded
edges facing outward (IMAGE #8), Swing
B Use 8mm HEX to install, then torque the seat stays up and align with the lower
pivot bolt (#130791) to 7 NM or 60 in/lbs. spacers. From the non drive side of top
link, install greased pivot bolt (#130791)
(IMAGE #9).
B Use an 8mm HEX to install. Torque
main pivot bolt (#130791) to 7 NM or
60 in/lbs.
10 12
11 13
I N S TA L L I N G R E A R S H O C K //
A
Holding the rear shock in one hand, match the forward end to the foward shock
mount on the frame and install greased M6x40mm bolt (#410053) through drive side
of frame (IMAGE #10). Do not tighten.
B
Match rear end of shock to desired travel setting (see below) on upper link and
install greased M6x45mm bolt (#410054) through non-drive side of link (IMAGE #11).
C
Torque shock bolts (#410053 & #410054) to 7 NM or 60 in/lbs (IMAGES #12 & 13).
adjustable travel NOTE
the top link of the Acv features dual mounting positions. The Upper shock mounting
hole on top link is for LONG travel, the lower hole is for SHORT travel. for more
information see the set up guide on page 14.
15
14 16
T I G H T E N I N G S E AT S TAY S T O T O P L I N K //
A B
Grease and install adjuster cone Using hand pressure, squeeze the top
(#130807) into head of main pivot bolt of seat stay together at the lower top
(#130791) and greased M6x22mm bolt link location to eliminate side to side
(#410009) through the adjuster cone play (IMAGE #15) then use a 5mm HEX
into the main pivot bolt (IMAGE #14). to make snug.
C
Torque M6x22mm (#410009) to 14 NM
or 125 in/lbs (IMAGE #16).
I N T E N S E C Y C L E S / / 1 1
