Aruba 7005 Series Installation Manual

Aruba 7005 Series Controller
Installation Guide
The Aruba 7005 Controller is a wireless LAN controller that connects, controls, and intelligently integrates
wireless Access Points (APs) and Air Monitors (AMs) into a wired LAN system. The 7005 controller includes
four ethernet ports, one Console port, one mini-USB console port, and USB port. This device supports up to
eight APs and 512 users.
The 7005 controller requires ArubaOS 6.4.0.0 or later.

Package Contents

Aruba 7005 Controller

Console cable

DC adapter and cable

Installation Guide (this document)

Quick Start Guide (Printed)

End User License Agreement (Printed)

Aruba Document Pointer (Printed)

Optional accessories are available for use with the Aruba 7005 controllerand are sold separately. Contact your
Aruba sales representative for details and assistance.

7005 Components

This section introduces the component and its location in the Aruba 7005 controller.
Figure 1 shows the front panel of the Aruba 7005 controller and
7005 controller.
Figure 1 Front Panel of the Aruba 7005 Controller
0511563-01 | January 2014
Figure 2 shows the back panel of the Aruba
1
