Installation - RX Receiver unit
1. Mount the RX wallplate onto the wall - cable access
must be from behind or below the wallplate.
Typical wiring diagrams, showing the interconnection
between time controls and zone valves, are shown on
pages 11-14.
NOTE: Earth connections are for customer use only.
2. The RX receiver may now be mounted onto the wallplate
and secured using the two screws on the bottom of the
wallplate.
Important note: Please ensure that when positioning
!
the thermostat setting unit that there are no large metal
obstructions, ie cylinder or boiler case, sitting in between the
thermostat and the RX receiver unit as these will block radio
communication and prevent the thermostat from operating
correctly.
