User's Manual
FOR YOUR SAFETY: This product must be installed and serviced by a professional service technician,
qualified in hot water boiler installation and maintenance. Improper installation and/or operation could
create carbon monoxide gas in flue gases which could cause serious injury, property damage, or death.
Improper installation and/or operation will void the warranty. For indoor installations, as an additional
measure of safety, Laars strongly recommends installation of suitable Carbon Monoxide detectors in the
vicinity of this appliance and in any adjacent occupied spaces.
WARNING
If the information in this manual is not
followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life.
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
nearby phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
Installation and service must be performed
by a qualified installer, service agency, or gas
supplier.
User's Manual for
Copper Brute II
includes
Hydronic Boiler
Model BWCH
Water Heater
Model BWCV
Sizes 500-2000
U.S. Reg. 2,765,423
Assurez-vous de bien suivres les instructions
données dans cette notice pour réduire au
minimum le risque d'incendie ou d'explosion
ou pour éviter tout dommage matériel, toute
blessure ou la mort.
Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables dans
le voisinage de cet appareil ou de tout autre
appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d'allumer d'appareils.
• Ne touchez à aucun interrupteur. Ne pas vous
servir des téléphones dansle bâtiment où vous
vous trouvez.
• Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de
gaz, appelez le sservice des incendies.
L'installation et l'entretien doivent être assurés par
un installateur ou un service d'entretien qualifié ou
par le fournisseur de gaz.
Document 1393
™
LOW TEMP Copper Brute ll
AVERTISSEMENT
Advertisement
Table of Contents
Related Manuals for Bradford White Copper Brute ll BWCH
Summary of Contents for Bradford White Copper Brute ll BWCH
- Page 1 User's Manual Document 1393 User's Manual for Copper Brute II ™ includes LOW TEMP Copper Brute ll Hydronic Boiler Model BWCH Water Heater Model BWCV Sizes 500-2000 U.S. Reg. 2,765,423 FOR YOUR SAFETY: This product must be installed and serviced by a professional service technician, qualified in hot water boiler installation and maintenance.
- Page 2 Page 2 RADFORD HITE ORP. TABLE OF CONTENTS SECTION 3 Electrical Connections ......11 SECTION 1 Caring For Your Copper Brute ll .... 3 Installation Warnings .......11 General Care ..........3 Line Voltage Connections ......11 Annual Inspection of Flue and Vents ..3 3.B.1 Main Power..........11 In the Event of a Power Failure ....
- Page 3 Keep grille openings on the boiler free for proper Contact your installing contractor, gas utility, ventilation of interior components. Bradford White dealer, or call Bradford White Do not obstruct or block a free flow of air to the for the nearest authorized representative in boiler to ensure proper ventilation.
- Page 4 Page 4 RADFORD HITE ORP. SECTION 2 Touchscreen and System Operations 2.A The Home Screen Figure 1. The Home Screen Model Stages Section 6.9 Status Window Low Temp On/Off 500 - 750 1000 2.A.1 Home Screen Status Window 1250 - 2000 Icon Description Setpoint...
- Page 5 Page 5 COPPER BRUTE II (500 - 2000) USER'S MANUAL 2.A.2 Home Screen Active Icons Name Icon Description Security Displays the current lock status. Touch the lock icon to lock or unlock the Touchscreen Display. Quick Start Provides quick touch access to the most commonly used parameters for easy installation.
- Page 6 Page 6 RADFORD HITE ORP. 2.B Lock / Unlock Display Screen Password Protection: To change parameters, a password is required. The control system includes three levels of password protection. Touch the 'Current Lock Status' Icon. Current Lock Status To Logout Walk Away Result Screen 1.
- Page 7 Page 7 COPPER BRUTE II (500 - 2000) USER'S MANUAL 2.C Keypad Operations As you navigate in, you will find that all screens have either a numeric keypad to enter in your customizable parameters OR selection buttons to choose the device of your configuration. NOTE: You can always tell exactly where you have navigated to by Navigation Bar.
- Page 8 Page 8 RADFORD HITE ORP. 2.D Quick Start To navigate to the Quick Start Screen, touch the Touching CH1/DHW1 navigates to the CH1/ Quick Start Icon in the lower left-hand portion of the DHW1 Quick Start Screen Home Screen. 2.D.1.a CH1 /DHW1 Screen 4.
- Page 9 Page 9 COPPER BRUTE II (500 - 2000) USER'S MANUAL 2.D.2 DHW/DHW3 will maximize the boiler outlet temperature to the To navigate to the DHW/DHW3 Quick Start Maximum Water Temperature. Screen, touch the DHW faucet icon on the Quick Start Screen.
- Page 10 Page 10 RADFORD HITE ORP. 2.D.6 Time & Date 2.D.5 Anti-Short Cycle To navigate to the Time & Date Quick Start To navigate to the Anti-Short Cycle Quick Start Screen, touch the Time & Date Icon on the Quick Start Screen, touch the Anti-Short Cycle Icon on the Quick Screen.
-
Page 11: Installation Warnings
Page 11 COPPER BRUTE II (500 - 2000) USER'S MANUAL SECTION 3 Electrical Connections 3.B.2 Pump Power The pump circuit is identified by three 12 AWG wires: black with a white stripe (L2), white (N2), and 3.A Installation Warnings green (Ground). WARNING If desired, an installer can change the pump This appliance must be electrically grounded... -
Page 12: Auxiliary Power Output
Page 12 RADFORD HITE ORP. DHW/DHW3: Connect the aquastat or end switch (isolated contact only) wires to terminals 5 and 6 of the input terminal strip. If preferred, a DHW tank sensor can be used in lieu of an aquastat to generate a heat demand, refer the Installation Manual (Doc 1392) NOTE: The heat demand contacts must be dry contacts. -
Page 13: Field Wiring - Outputs
Page 13 COPPER BRUTE II (500 - 2000) USER'S MANUAL Detail Figure 4. Input and Output Terminal Strips terminals 1 (common), 2 (normally closed), and 3 function. The controller automatically detects the (normally open) of the output terminal strip. The presence of this sensor and initiates a call for heat when the DHW temperature drops below the DHW controller closes the normally open set of contacts... -
Page 14: Cascade Rs485
Page 14 RADFORD HITE ORP. JUMPER 4 - 20mA ANALOG INPUTS NO JUMPER 0 - 10VDC JUMPERS JUMPERS 0 - 10VDC 4-20 mA ANALOG OUTPUTS Figure 5. Analog Input and Output Jumper Placement 3.C.2.b Cascade RS485 A system supply sensor must be installed and Prior to wiring Copper Brute ll units for cascade connected to the lead boiler, see System Supply in operations, select one Copper Brute ll as the lead... -
Page 15: Section 4 Burner Set Up
Page 15 COPPER BRUTE II (500 - 2000) USER'S MANUAL 3.D Cascade Wiring Connections For the complete list of wiring diagrams and logic diagrams, please reference the Installation and Operating Manual. Document 1392 Figure 6. Cascade Wiring Connections Figure 7. Cascade BAS Wiring Connections SECTION 4 Burner Set Up 4. - Page 16 Ambler, PA 19002 Tech. Service (800) 334-3393 200 Lafayette St. www.BradfordWhite.com Service Parts (800) 538-2020 Middleville, MI 49333 Warranty Service (800) 531-2111 Warranty: (800) 531-2111 Litho in U.S.A. © Bradford White 1711 Document 1393...
