SYST E M SE T- UP AND CALIBR ATIO N
Error Codes
If one or more errors exist in the sound masking system, an eight digit error code is displayed on the
LCD display (scroll forward to the "Error" screen). The error state is indicated by an eight digit code of
the form:
Error: 0_000000
Where a number other than "0" indicates an error. Examples
Error: 0_000001 Short sensed in the wiring of the zone
Error: 0_000004 Emitter not working
Error: 2_000000 Over temperature
Error: 4_000000 Intermittent fault
Error: 8_000000 Contact the manufacturer
Clearing Error Codes
To clear an error that is currently shown on the display:
Press the right arrow button on the front panel to see the error code
1.
Press the up arrow to clear the error code
2.
If the error still persists, the problem has not been resolved
3.
If you are not sure how to resolve the problem, contact support@csmqt.com
4.
Post Installation Handoff
Privacy signs do not illuminate
Perform a final walkthrough to satisfy all aspects of the
system performance:
Fill out the settings record.
1.
Store guide with completed settings record near the control module. If there is a hard module
2.
failure, the recorded values can be used to reconfigure the system. System settings are retained after
a power outage.
If you need assistance installing or commissioning this Qt CRE sound masking system, please contact
CSM support at:
1.800.219.8199
(Toll free within US & Canada)
+1.617.349.3779
(Outside US & Canada)
Qt Conference Room Edition Installation and Operations Guide
Error Code for Zone 1
Reserved
Error Code for Control Module
support@csmqt.com
www.csmqt.com/support
