SYST E M SE T- UP AND CALIBR ATIO N

Troubleshooting

Privacy signs do not illuminate
Check wiring polarity
1.
Note that the small switch on the side of the controller must be set to the "up" position (closer to
2.
the top of the case) for the lights to work. The "down" setting enables the external USB jack, used
for firmware updates or for the optional Bluetooth dongle supplied the Qt100 iPad app.
USB connection
(special purpose
see page 14)
System commissioning with slow ramping is not possible
With traditional sound masking systems, a commission process is use that ramps up the sound masking
over several weeks' time. In the case of the Qt CRE system, because sound masking is user-initiated at
the time of using the conference room, no commissioning ramp is used. Note that commission ramp is
not possible from the Qt CRE calibration app, even though the option is resented as possible in the app
user interface.
Error Codes and Clear Error
System errors are shown on the control module front panel display. If an error occurs, the message
"Status: Error" will be displayed. To determine the cause of the error, press NEXT (right arrow button), to
display the error code.
Qt Conference Room Edition Installation and Operations Guide
Sign is
active
USB connection
in use
page 31
