INSTAL LATI O N
Mounting options for the privacy signs
There are several options for mounting the privacy signs. These options allow for mounting on a variety
of wall surfaces, including glass.
1-gang box (North American NEMA or UK/EU types)
If using a 1-gang box, retrofit or pre-installed, first run cable to the box. Then mount the plate. Then
attach the cable. Then slide the sign down on the plate to secure it.
To remove, slide the light panel up and off the metal bracket.
Wall hole
1 gang NEMA wall
box or low voltage clip
(not included)
2x privacy
sign screws
Wall plate
Privacy sign
Wall hole
1 gang EU/UK wall box
(not included)
2x privacy
sign screws
Wall plate
Privacy sign
