SYST E M SE T- UP AND CALIBR ATIO N
System Configuration via the Front Panel
After the Qt CRE is mounted and the emitters have been tested, it is time to configure the Qt CRE for
general operation. The front panel display shows system information and allows for
adjustment of the masking and the auxiliary audio input levels.
The Qt CRE controller has two operating Modes:
User Mode – Simple controls, no adjustment or set-up access.
▪
Set-up Mode – Installer set-up adjustments. Accessible only by special key press (holding down
▪
the OFF and ON buttons for 5 seconds).
System Information
Initial display of the front panel, shown below, shows the software version and system status.
Followed by...
The system always boots up into User Mode, and will always return to the last used setting on power up
(on/off/low/high)
Qt Conference Room Edition Installation and Operations Guide page 25
