INSTAL LATI O N
Surface mount directly to the wall
Surface or panel mount of back plate – either with cables through hole (if cables can be run through the
wall) or out the side to end up on the surface of the wall or mounting point. Mark holes with template,
open up larger holes for cables if desired, run cables, attach back plate.
The wires may be run out the back of the case rear, or to the sides using the available openings.
Consult a knowledgeable person about the best type of hardware to attach to your wall surface.
Approximate hole locations
(use case back as template)
Wall screws (not included)
Controller
Installing the controller to the back plate.
After all cables have been attached, snap the controller in place.
After installation, the controller can be removed by pulling it, and it will snap away from its back,
exposing the cabling and also giving access to the mounting points.
