User Manual
AiM user guide
EVO4 and SoloDL kit
for Yamaha YZF-R1/R1M
from 2015 and YZF-R6
from 2017
Release 1.05
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Aim EVO4
Summary of Contents for Aim EVO4
- Page 1 AiM user guide EVO4 and SoloDL kit for Yamaha YZF-R1/R1M from 2015 and YZF-R6 from 2017 Release 1.05...
- Page 2 Supported models and years This user guide explains how to connect AiM EVO4 and SoloDL to the Yamaha YZF ECU. Supported models and years are: • Yamaha YZF-R1 (YEC included) from 2015 • Yamaha YZF-R1M (YEC included) from 2015 • Yamaha...
- Page 3 • 2 M4x10 screws (5) • 1 AiM interface cable for Yamaha YZF-R1 and YZF-R1M (6) AiM interface cable (6) and bracket kit (1-5) can be also bough separately as spare parts: • SoloDL cable for Yamaha YZF-R1/R1M from 2015and YZF-R6 from 2017: V02569340...
- Page 4 AiM cable for SoloDL SoloDL cable for Yamaha YZF-R1/R1M from 2015 and YZF-R6 from 2017–below – is: V02569340 The image below shows the cable construction scheme.
- Page 5 AiM cable for EVO4 EVO4 cable for Yamaha YZF-R1/R1M from 2015 and YZF-R6 from 2017 – shown below – is: V02563310 The image below shows the cable construction scheme.
- Page 6 Installation and connection Here you find the instructions to install Solo and SoloDL and to connect EVO4 and SoloDL to your Yamaha bike ECU. EVO4 cable is long enough to allow installation of the logger under the bike seat. Installing Solo and SoloDL...
- Page 7 Insert the rawl nut in the handle bar hinge. Screw the central screw on the hinge so that this last grips. Hook Solo/SoloDL to its bracket. Fix Solo screwing the kit bracket screws.
- Page 8 Connecting SoloDL and EVO4 to the bike ECU Yamaha bikes are equipped with a bus communication protocol based on CAN on the Sumitomo connector placed under the bike seat and shown here below. The table below shows colours of the cables of Sumitomo connector and their function.
- Page 9 For EVO4 connect 5 pins Binder 712 female connector of EVO4, labelled "ECU"– the third from the left of the top row – to 5 pins Binder 712 male connector of V02563310 connection kit as shown here below. Race Studio 2 configuration Before connecting EVO4/SoloDL to the bike ECU set it up using AiM Race Studio 2 software.
- Page 10 Available channels Channels received by SoloDL and EVO4 connected to "Yamaha" "CAN_2015" protocol are: CHANNEL NAME FUNCTION ECU_1 ECU_RPM ECU_2 ECU_GEAR Gear ECU_3 ECU_W_SPD_F Wheel Speed Front ECU_4 ECU_W_SPD_R Wheel Speed Rear ECU_5 ECU_THROTTLE Throttle position sensor ECU_6 ECU_TPS_HAND Throttle Handgrip...
- Page 11 ECU_25 ECU_FR_REB Front dumper rebound ECU_26 ECU_RR_COMP Rear dumper compression ECU_27 ECU_RR_REB Rear dumper rebound ECU_28 ECU_R_ABS_IN Rear ABS intervention ECU_29 ECU_F_ABS_IN Front ABS intervention ECU_30 ECU_LAUNCH_IN Launch control intervention ECU_31 ECU_LIFT_IN Lift control intervention ECU_32 ECU_SCS_IN Slide control system intervention ECU_33 ECU_TCS_IN Traction control system intervention...
