- Page 1 AIM Infotech Ducati Hypermotard Release 1.00...
- Page 2 Bike years This tutorial describes how to connect AIM SoloDL, EVO4 and ECU Bridge to Ducati Hypermotard from 2009 onward. CAN bus connection Ducati Hypermotard communicates through the CAN Bus that can be reached on an FCI connector placed under the bike seat and shown here below.
- Page 3 Connection with AIM devices Here follow instructions on how to connect this Ducati bike to AIM SoloDL, EVO4 and ECU Bridge: Connection with SoloDL To connect SoloDL to this Ducati bike use the seven pins right Binder female connector placed under the logger.
- Page 4 EVO4 has the CAN Bus on the ECU connector (highlighted in red here below). This connection requires a dedicated cable properly designed and developed by AIM whose part number is V02563150. Please note: EVO4 needs external power. Refer to EVO4 user manual to know how to power the logger.
- Page 5 Connection with ECU Bridge ECU Bridge is available in different versions. The one that fits this installation has part number X90BGDDDA. Through the FCI connector you can also power your ECU Bridge. Here below you see ECU Bridge with the FCI connector.
-
Page 6: Available Channels
• select the configuration or press “New” to create a new one; • select ECU manufacturer “Ducati” and ECU Model “Hypermotard”; • transmit the configuration to the device pressing “Transmit”. Available channels Channels received by AIM devices connected to Ducati Hypermotard are: CHANNEL NAME FUNCTION ECU_1...
