8. Find the Left Pedal (13), which has a ridge on the
right side. Attach the Left Pedal to the Left Pedal Arm
(11) with three M4 x 19mm Flange Screws (36) as
shown.
Attach the Right Pedal to the Right Pedal Arm (not
shown) in the same way.
9. The Console (23) requires two "AA" batteries (not
included); alkaline batteries are recommended. Slide
off the Battery Cover (29) as shown. Press two batter-
ies into the battery clip; make sure that the negative
("–") ends of the batteries are touching the
springs in the battery clip. Reattach the Battery
Cover.
10. Make sure that all parts of the elliptical trainer are properly tightened. Place a mat under the elliptical
trainer to protect the floor or carpet from damage.
8
11
9
Batteries
8
13
36
29
Battery Clip
23
