ProForm PFEL03900 User Manual page 8

6. Attach the T-Handle (10) to the Upright (3) with two
M6 x 16mm Screws (54) and two M6 Black Nylon
Locknuts (55).
7. The Console (6) requires four ÒAAÓ batteries (not
included). Alkaline batteries are recommended.
To install batteries, look under the Console (6) and
locate the two Battery Covers (66)Ñthere is one
Battery Cover on each side. Remove the Battery
Covers by sliding them in the direction shown by the
arrows on the Battery Covers. Insert two batteries into
each battery compartment; make sure that all four
batteries are turned so the negative ends (marked
ÒÐÓ) are touching the springs in the battery com-
partments. Then, reattach the Battery Covers by slid-
ing them in the opposite direction.
8. Make sure that all parts of the elliptical trainer are properly tightened. Place a mat under the elliptical
trainer to protect the floor or carpet from damage.
6
3
7
8
54
10
55
6
Batteries
66
