Features of your vehicle
Applying the shackle on the guide
rail
OJFW046460L
• Put the shackle (A) in the position
where the shackle is put in the rail.
• To move the shackle, press the but‐
ton (1) and move the shackle along
the rail.
• Make sure the shackle is clicked into
place.
• To fix the luggage, pull up the hook
(2) in the middle cargo bay.
• Now you can mount e.g. belt to fix
the luggage in the hook.
4-188
• The shackle cannot be used in the po‐
sition where the shackle is put in and
out of the rail (3).
CAUTION
Tensile force: max. 30 kgf for 1
shackle
