Download this manual See also: Owner's Manual
Kia, THE COMPANY
Thank you for becoming the owner of a new Kia vehicle.
As a global car manufacturer focused on building high-quality vehi-
cles with exceptional value, Kia Motors is dedicated to providing you
with a customer service experience that exceeds your expectations.
All information contained in this Owner's Manual is accurate at the
time of publication. However, Kia reserves the right to make changes
at any time so that our policy of continual product improvement can
be carried out.
This manual applies to all models of this vehicle and includes descrip-
tions and explanations of optional as well as standard equipment. As a
result, you may encounter material in this manual that is not applica-
ble to your specific Kia vehicle.
Drive safely and enjoy your Kia!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Optima and is the answer not in the manual?

Questions and answers

Related Manuals for Kia Optima

Summary of Contents for Kia Optima

  • Page 1 Kia, THE COMPANY Thank you for becoming the owner of a new Kia vehicle. As a global car manufacturer focused on building high-quality vehi- cles with exceptional value, Kia Motors is dedicated to providing you with a customer service experience that exceeds your expectations.
  • Page 2 Thank you for choosing a Kia vehicle. The information and specifications provided in this manual were accurate at the time of printing. Kia reserves the right to When you require service, remember that your Kia dealer discontinue or change specifications or design at any time knows your vehicle best.

  • Page 3: Table Of Contents

    Introduction How to use this manual / Fuel requirements / Vehicle break-in process Your vehicle at a glance Exterior overview / Interior overview / Instrument panel overview / Engine compartment Safety features of your vehicle Seats / Seat belts / Child restraint system / Air bag Features of your vehicle Keys / Door locks / Trunk / Windows / Hood / Fuel filler lid / Sunroof / Steering wheel / Mirrors / Instrument cluster / Lighting / Wipers &...

  • Page 4: Introduction

    Introduction How to use this manual ..... . 1-2 Fuel requirements ......1-3 •...

  • Page 5: How To Use This Manual

    Introduction HOW TO USE THIS MANUAL We want to help you get the greatest The general layout of the manual is You will find various types of safety possible driving pleasure from your provided in the Table of Contents. instructions in this manual. These vehicle.

  • Page 6: Fuel Requirements

    Introduction FUEL REQUIREMENTS Your new Kia vehicle is designed to Gasoline containing alcohol and 1. Gasoline or gasohol containing use only unleaded fuel having a methanol methanol. pump octane number ((R+M)/2) of 2. Leaded fuel or leaded gasohol. Gasohol, a mixture of gasoline and...

  • Page 7: Gasoline Containing Mmt

    Manganese Tricarbonyl). Detergent Gasoline, which helps formance problems that are prevent deposit formation in the Kia does not recommend the use of caused by the use of fuels con- engine. These gasolines will help the gasoline containing MMT. taining methanol or fuels con-...

  • Page 8: Operation In Foreign Countries

    Introduction VEHICLE BREAK-IN PROCESS Operation in foreign countries No special break-in period is need- ed. By following a few simple precau- If you are going to drive your vehicle tions for the first 1,000 km (600 in another country, be sure to: miles) you may add to the perform- •...

  • Page 9: Vehicle Data Collection And Event Data Recorders

    Introduction VEHICLE DATA COLLECTION AND EVENT DATA RECORDERS This vehicle is equipped with an These data can help provide a bet- To read data recorded by an EDR, event data recorder (EDR). The ter understanding of the circum- special equipment is required, and main purpose of an EDR is to stances in which crashes and access to the vehicle or the EDR is...

  • Page 10: Your Vehicle At A Glance

    Your vehicle at a glance Exterior overview ......2-2 Interior overview ......2-4 Instrument panel overview .

  • Page 11: Exterior Overview

    Your vehicle at a glance EXTERIOR OVERVIEW ■ Front view 1. Hood .............4-30 2. Head lamp .........4-100, 7-79 3. Fog lamp ........4-104, 7-84 4. Wheel and tire ........7-47 5. Outside rearview mirror ......4-55 6. Front windshield wiper blades ...4-105, 7-42 7.
  • Page 12 Your vehicle at a glance ■ Rear view 8. Door locks..........4-18 9. Fuel filler lid ..........4-32 10. Rear combination lamp.......7-85 11. High mounted stop lamp ....7-88 12. Trunk ...........4-22 13. Antenna ..........4-148 14. Back-Up Warning System....4-94 15. Rear Camera Display ......4-97 ❈...

  • Page 13: Interior Overview

    Your vehicle at a glance INTERIOR OVERVIEW 1. Driver position memory system ..4-40 2. Door lock/unlock button ....4-18 3. Outside rearview mirror control switch ..........4-55 4. Power window lock button ....4-29 5. Power window switches ....4-25 6. Central door lock switch....4-19 7.

  • Page 14: Instrument Panel Overview

    Your vehicle at a glance INSTRUMENT PANEL OVERVIEW 1. Instrument cluster ......4-58 2. Light control / Turn signals...4-100, 4-103 3. Wiper/Washer .........4-105 4. Horn ..........4-43 5. Steering wheel audio control ..4-149 6. Auto cruise control ......5-34 7. Driver’s air bag........3-47 8.

  • Page 15: Engine Compartment

    Your vehicle at a glance ENGINE COMPARTMENT ■ ■ 2.4L Engine 1. Engine coolant reservoir ....7-31 2. Engine oil filler cap ......7-29 3. Brake fluid reservoir......7-34 4. Air cleaner.........7-37 5. Fuse box ...........7-61 ■ ■ 2.0L Engine 6. Positive battery terminal ....7-44 7.

  • Page 16: Safety Features Of Your Vehicle

    Safety features of your vehicle Seat........3-2 •...

  • Page 17: Features Of Your Vehicle

    Safety features of your vehicle SEAT Driver’s seat (1) Seat adjustment, forward / back- ward (2) Seatback recliner (3) Seat adjustment, height (4) Lumbar support (5) Driver position memory system (6) Seat warmer switch (7) Headrest Front passenger’s seat (8) Seat adjustment, forward / back- ward (9) Seatback recliner (10) Seat warmer switch...
  • Page 18 Safety features of your vehicle WARNING WARNING WARNING Loose - Driver Seat cushion objects responsibility for passen- Occupants should never sit on gers Do not place anything in the dri- seat cushions. The passenger's ver's foot well or under the front hips may slide under the lap seats.

  • Page 19: Front Seat Adjustment - Manual

    Safety features of your vehicle Front seat adjustment - manual WARNING WARNING - Driver’s seat - Seat Forward and backward • Never attempt to adjust the adjustment seat while the vehicle is mov- • Do not adjust the seat while ing.
  • Page 20 Safety features of your vehicle Seatback angle Seat Cushion height WARNING - Unexpected (for driver's seat) seat movement After adjusting a manual seat, always check that it is locked by shifting your weight to the front and back. Sudden or unexpect- ed movement of the driver's seat could cause you to lose control of the vehicle.

  • Page 21: Front Seat Adjustment - Power

    Safety features of your vehicle Lumbar support (for driver’s seat) Front seat adjustment - power CAUTION (if equipped) • The power seat is driven by an The front seat can be adjusted by electric motor. Stop operating using the control switch located on once the adjustment is com- the outside of the seat cushion.
  • Page 22 Safety features of your vehicle Forward and backward Seatback angle Seat cushion height (for driver's side) OTF030006 OTF030007 OTF030008 Push the control switch forward or Push the control switch forward or backward to move the seat to the backward to move the seatback to Pull the front portion of the control desired position.
  • Page 23 Safety features of your vehicle Lumbar support Headrest Also, adjust the headrest as close to (for driver’s seat, if equipped) your head as possible. For this reason, the use of a cushion that holds the body away from the seatback is not recommended. WARNING - Headrest removal/adjustment...
  • Page 24 Safety features of your vehicle ■ Type A OTF034086 ■ Type B OTF030012 OTF030010 Forward and backward adjustment Adjusting the height up and down The headrest may be adjusted for- To raise the headrest, pull it up to the ward to 4 different positions by desired position (1).
  • Page 25 Safety features of your vehicle ■ Type A 3. Press the headrest release button 3. Adjust the headrest to the appro- (3) while pulling the headrest up (4). priate height. WARNING WARNING - Headrest Reinstallation NEVER allow anyone to ride in a seat with the headrest removed.

  • Page 26: Seat Warmer (Front)

    Safety features of your vehicle Seat warmer (if equipped) During mild weather or under condi- CAUTION - Seat damage tions where the operation of the seat warmer is not needed, keep the • When cleaning the seats, do switches in the OFF position. not use an organic solvent such as paint thinner, ben- With the seat warmer switch in the...

  • Page 27: Air Ventilation Seat

    Safety features of your vehicle Air ventilation seat (if equipped) When the operation of the air ventila- WARNING - Seat warmer tion is not needed, keep the switches burns in the OFF position. The seat warmer may cause • Each time you press the switch, burns, even at low tempera- the airflow will change as follows: tures, if used over a long period...

  • Page 28: Seatback Pocket

    If there is no could cause the air ventilation change, have your vehicle inspected seat performance to impair. by an authorized Kia dealer. • When cleaning the seats, do OTF030016 not use an organic solvent such as paint thinner, ben- The seatback pocket is provided on zene, alcohol and gasoline.

  • Page 29: Rear Seat Adjustment

    Safety features of your vehicle Rear seat adjustment For maximum effectiveness in case WARNING Seatback of an accident, the headrest should Headrest pocket be adjusted so the middle of the headrest is at the same height of the Do not put heavy or sharp center of gravity of an occupant's objects in the seatback pocket.

  • Page 30: Seat Warmer (Rear)

    Safety features of your vehicle Seat warmer (if equipped) OTF030017 OTF030018 Adjusting the height up and down Removal and installation OTF034025 (if equipped) To remove the headrest, raise it as The seat warmer is provided to warm To raise the headrest, pull it up to the far as it can go then press the the rear seats during cold weather.

  • Page 31: Armrest

    Safety features of your vehicle • Each time you press the button, Armrest Folding the rear seat the temperature setting of the seat The rear seatbacks may be folded to will change as follows : facilitate carrying long items or to increase the luggage capacity of the OFF →...
  • Page 32 Safety features of your vehicle To fold the rear seatback WARNING - Objects 1. Set the front seatback to the Objects carried on the folded upright position and if necessary down seatback should not slide the front seat forward. extend higher than the top of 2.
  • Page 33 Safety features of your vehicle To unfold the rear seat WARNING - Rear seatback 1. To use the rear seat, lift and pull the seatback rearward. Pull the When returning the rear seat- seatback firmly until it clicks into back from a folded to an upright place.

  • Page 34: Seat Belts

    Safety features of your vehicle SEAT BELTS Seat belt restraint system • Never allow children to ride in the WARNING - Twisted seat front passenger seat. See child Seat belts are designed to bear upon belt restraint system section for further the bony structure of the body, and discussion.
  • Page 35 Safety features of your vehicle Seat belt warning Seat belt warning Conditions Warning Pattern (for driver’s seat) (for front passenger’s seat) Vehicle Chime- Seat Belt Light-Blink Speed Sound Unbuckled 6 seconds Buckled 6 seconds None Below 5 km/h 6 seconds None (3 mph) Buckled →...
  • Page 36 Safety features of your vehicle Riding in an improper position Seat belt - Driver's 3-point system Conditions Warning Pattern adversely affects the front passen- with emergency locking retractor Vehicle Seat Belt Light-Blink ger's seat belt warning system. It is Speed important for the driver to instruct the Unbuckled 6 seconds...
  • Page 37 Safety features of your vehicle It will also lock if you try to lean for- To raise the height adjuster, pull it up ward too quickly. (1). To lower it, push it down (3) while pressing the height adjuster button (2). If you are unable to pull out the seat belt from the retractor, firmly pull the Release the button to lock the anchor...
  • Page 38 Safety features of your vehicle Seat belts - Front passenger and It automatically adjusts to the proper rear seat 3-point system with length only after the lap belt portion of the seat belt is adjusted manually convertible locking retractor so that it fits snugly around your hips. To fasten your seat belt When the seat belt is fully extended Combination retractor type seat belts...

  • Page 39: Pre-Tensioner Seat Belt

    Safety features of your vehicle Pre-tensioner seat belt OBH038023N B210A01NF-1 When using the rear center seat belt, To release the seat belt OXMA033101 the buckle with the “CENTER” mark The seat belt is released by pressing Your vehicle is equipped with driver's must be used.
  • Page 40 Safety features of your vehicle 2. Emergency Fastening Device Both the driver's and front passen- (EFD) ger's pre-tensioner seat belts may be activated in certain frontal collisions. The Emergency Fastening Device (EFD) is a supplemental system of The pre-tensioners will not be acti- the seat belts.

  • Page 41: Seat Belt Precautions

    This must be placed and installed in the rear seat. ignition switch has been turned to the done by an authorized Kia dealer. For more information about the use ON position, and then it should turn of these restraints, refer to “Child off.
  • Page 42 Safety features of your vehicle Larger children Restraint of pregnant women WARNING - Small Children who are too large for child Pregnant women should wear children restraint systems should always occu- lap/shoulder belt assemblies when- py the rear seat and use the available Do not allow small children to ever possible according to specific lap/shoulder belts.

  • Page 43: Care Of Seat Belts

    One person per belt authorized Kia dealer. Periodic inspection Two people (including children) should never attempt to use a single All seat belts should be inspected WARNING seat belt.

  • Page 44: Child Restraint System

    Safety features of your vehicle CHILD RESTRAINT SYSTEM Children riding in the car should sit in Children could be injured or killed in WARNING - Hot child the rear seat and must always be a crash if their restraints are not properly restrained to minimize the properly secured.

  • Page 45: Using A Child Restraint System

    CRS09 described in this section, have the your child's height and weight. Forward-facing child restraint system system checked immediately by your authorized Kia dealer. WARNING - Seat belt use Do not use one seat belt for two WARNING - Unattended occupants at the same time.
  • Page 46 Safety features of your vehicle Placing a passenger seat belt WARNING Child seat into the auto lock mode installation • Always follow the instructions provided by the child restraint system manufacturer. Child restraint system manufactur- ers know their products best. •...
  • Page 47 Safety features of your vehicle OEN036102 OEN036103 OEN036104 3. Pull the shoulder portion of the 4. Slowly allow the shoulder portion 5. Remove as much slack from the seat belt all the way out. When the of the seat belt to retract and listen belt as possible by pushing down shoulder portion of the seat belt is for an audible “clicking”...

  • Page 48: Tether Anchorage System

    Safety features of your vehicle The lap/shoulder belt automatically Securing a child restraint seat returns to the “emergency lock with tether anchorage system mode” whenever the belt is allowed to retract fully. Therefore, the preceding seven steps must be followed each time a child restraint is installed.

  • Page 49: Lower Anchor System

    Safety features of your vehicle Securing a child restraint seat with WARNING Tether strap child seat lower anchor system Never mount more than one child restraint to a single tether Lower Anchor or to a single lower anchorage Position Indicator point.
  • Page 50 Safety features of your vehicle Follow the child seat manufacturer’s WARNING - Weight for instructions to properly install child restraint seats with LATCH or LATCH sys- LATCH-compatible attachments. Once you have installed the LATCH The recommended weight for child restraint, assure that the seat is the LATCH system is under properly attached to the LATCH and 29.48 kg (65 lb).

  • Page 51: Air Bag - Advanced Supplemental Restraint System

    Safety features of your vehicle AIR BAG - ADVANCED SUPPLEMENTAL RESTRAINT SYSTEM (1) Driver’s front air bag (2) Passenger’s front air bag (3) Side air bag (4) Curtain air bag Even in vehicles with air bags, you and your passengers must always wear the safety belts provided in order to minimize the risk and sever- ity of injury in the event of a collision...

  • Page 52: How Does The Air Bag System Operate

    Safety features of your vehicle How does the air bag system • The front air bags will completely • There are even circumstances inflate and deflate in an instant. operate under which contact with the steering wheel air bag can cause It is virtually impossible for you to •...
  • Page 53 Safety features of your vehicle Noise and smoke Installing a child restraint on a WARNING - Hot compo- front passenger’s seat is forbidden When the air bags inflate, they make nents a loud noise and they leave smoke and powder in the air inside of the Do not touch the air bag storage vehicle.

  • Page 54: Air Bag Warning Light

    ON, the indicator light should illumi- nate for approximately 6 seconds, then go off. Have the system checked by an authorized Kia dealer if: • The light does not turn on briefly when you turn the ignition ON. 3 39...

  • Page 55: Srs Components And Functions

    If any of the following conditions OTF032049N/Q occurs, this indicates a malfunction The SRS consists of the following of the SRS. Have an authorized Kia components: dealer inspect the air bag system as soon as possible. 1. Driver's front air bag module •...
  • Page 56 Safety features of your vehicle Driver’s front air bag (1) Driver’s front air bag (2) Driver’s front air bag (3) B240B01L B240B02L B240B03L The air bag modules are located Upon deployment, tear seams mold- A fully inflated air bag, in combina- both in the center of the steering ed directly into the pad covers will tion with a properly worn seat belt,...

  • Page 57: Occupant Detection System

    Safety features of your vehicle ✽ ✽ NOTICE Occupant detection system Passenger’s front air bag Before you replace a fuse or discon- nect a battery terminal, turn the ignition switch to the LOCK posi- tion and remove the ignition key. Never remove or replace the air bag related fuse(s) when the ignition switch is in the ON position.
  • Page 58 Safety features of your vehicle Main components of occupant If the front passenger seat is occu- • The ODS (Occupant Detection detection system pied by a person that the system System) may not function properly if determines to be of adult size, and the passenger takes actions which •...
  • Page 59 Safety features of your vehicle Condition and operation in the front passenger occupant detection WARNING - ODS system system Riding in an improper position Indicator/Warning light Devices adversely affects the occupant detection system (ODS) and Condition detected by the occu- PASSENGER AIR Front passenger may result in the deactivation of...
  • Page 60 Safety features of your vehicle (Continued) B990A08O 1KMN3663 1KMN3665 - Never sit with the hips shifted - Never place the feet on the - Never put a heavy load in the towards the front of the seat. dashboard. front passenger seat. OVQ036014N 1KMN3662 1KMN3664...
  • Page 61 Safety features of your vehicle ✽ ✽ NOTICE If the PASSENGER AIR BAG “OFF” indicator is still on, ask the passen- The PASSENGER AIR BAG “OFF” ger to move to the rear seat. indicator illuminates for about 4 sec- onds after the ignition switch is WARNING turned to the ON position or after - “AIR BAG...

  • Page 62: Driver's And Passenger's Front Air Bag

    Safety features of your vehicle Any child age 12 and under should If the occupant detection system is Driver's and passenger's front ride in the rear seat. Children too not working properly, the SRS air air bag large for child restraints should use bag warning light on the instru- Driver’s front air bag...
  • Page 63 Safety features of your vehicle The indications of the system's pres- The advanced SRS offers the ability Additionally, your vehicle is equipped ence are the letters "AIR BAG" to control the air bag inflation with with an occupant detection system in embossed on the air bag pad cover two levels.
  • Page 64 1JBA3514 ized Kia dealer using original Rollover Front air bags are not intended to Kia parts designed for this vehi- deploy in side-impact, rear-impact or cle and model. Any other such rollover crashes. In addition, front air replacement or modification...

  • Page 65: Side Air Bag

    Safety features of your vehicle Side air bag The purpose of the air bag is to pro- The side air bag is supplemental to vide the vehicle's driver and/or the the driver's and the passenger's seat Front front passenger with additional pro- belt systems and is not a substitute tection than that offered by the seat for them.

  • Page 66: Curtain Air Bag

    They are designed to help protect have the vehicle checked and the heads of the front seat occupants repaired by an authorized Kia dealer. and the rear outboard seat occu- Inform that your vehicle is equipped pants in certain side impact colli- with side air bags and an occupant sions.

  • Page 67: Inflation And Non-Inflation Conditions Of The Air Bag

    Safety features of your vehicle Why didn’t my air bag go off in Air bag collision sensors a collision? (Inflation and non- inflation conditions of the air bag) There are many types of accidents in which the air bag would not be expected to provide additional protection.
  • Page 68 Therefore, do not try to per- the intensity, speed or angles of form maintenance impact of the front collision. around the air bag sensors. Have the vehicle checked and repaired by an authorized Kia dealer. 3 53...
  • Page 69 Safety features of your vehicle Although the front air bags (driver’s Air bag non-inflation conditions and front passenger’s air bags) are designed to inflate in frontal colli- sions, they also may inflate in other types of collisions if the front impact sensors detect a sufficient frontal force in another type of impact.
  • Page 70 Safety features of your vehicle OED036100 1JBA3516 1JBA3521 • Air bags are not designed to inflate • Front air bags may not inflate in • In a slant or angled collision, the in rear collisions, because occu- side impact collisions, because force of impact may direct the pants are moved backward by the occupants move to the direction of...
  • Page 71 Safety features of your vehicle 1JBA3517 1JBA3522 1JBA3518 • Just before impact, drivers often • Air bags may not inflate in rollover • Air bags may not inflate if the vehi- brake heavily. Such heavy braking accidents because the vehicle can cle collides with objects such as lowers the front portion of the vehi- not detect rollover accident.

  • Page 72: Srs Care

    Kia precautions must be observed. An dealer. Improper handling of the SRS authorized Kia dealer knows these...

  • Page 73: Air Bag Warning Label

    Safety features of your vehicle Air bag warning label OTF030043-1 OTF030044-1 Air bag warning labels, some required by the Canada Motor Vehicle Safety Standards (CMVSS), are attached to the sunvisor to alert the driver and passengers of poten- tial risks of the air bag system.
  • Page 74 Features of your vehicle Keys ........4-4 •...
  • Page 75 Mirrors ........4-45 • Non-operational conditions of Back-Up Warning System.
  • Page 76 • Trunk room lamp ......4-110 • Power outlet ....... . 4-143 •...

  • Page 77: Keys

    This may damage the key. set. Should lose your keys, this number will enable an authorized Kia dealer to duplicate the keys easily. Remove WARNING - Aftermarket the key code tag and store it in a safe keys place.
  • Page 78 Features of your vehicle Type B WARNING - Ignition key (Smart key) Never leave the keys in your vehicle with unsupervised chil- dren. Leaving children unat- tended in a vehicle with a man- ual ignition key or a smart key is dangerous.

  • Page 79: Smart Key

    Features of your vehicle SMART KEY (IF EQUIPPED) Smart key functions Locking Carrying the smart key, you may lock and unlock the vehicle doors. Also, you may start the engine. Refer to the following, for more details. OYDDCO2007 With a smart key, you can lock or OTF040008 unlock a door and even start the Pressing the button of the front out-...

  • Page 80: Smart Key Precautions

    Pressing the button in the front pas- immediately take the vehicle and opened. senger's outside door handle with all key to your authorized Kia dealer doors closed and locked, unlocks all to protect it from potential theft. the doors. The hazard warning lights •...
  • Page 81 Features of your vehicle • If the smart key is in close proximity This device complies with Industry to your cell phone or smart phone, Canada Standard RSS-210. the signal from the smart key could Operation is subject to the following be blocked by normal operation of two conditions: your cell phone or smart phone.

  • Page 82: Remote Keyless Entry

    Features of your vehicle REMOTE KEYLESS ENTRY (IF EQUIPPED) Remote keyless entry system Lock (1) Unlock (2) operations All doors are locked if the lock button The driver's door is unlocked if the is pressed. If all doors (and trunk) are unlock button is pressed once.

  • Page 83: Transmitter Precautions

    When the transmitter (or smart key) does not work properly, open and close the door with the ignition key. If you have a problem with the trans- mitter (or smart key), contact an authorized Kia dealer.

  • Page 84: Battery Replacement

    A battery should last for several years, but if the transmitter or smart key is not working properly, try replacing the battery with a new one. If you are unsure how to use or replace the battery, contact an authorized Kia dealer. 4 11...

  • Page 85: Immobilizer System

    Operation is subject to the fol- Your immobilizer system is com- contact an authorized Kia dealer. lowing two conditions: (1) this prised of a small transponder in the • Using the wrong battery can cause...
  • Page 86 1. This device may not cause harm- If you need additional keys or lose ful interference, and To activate the immobilizer your keys, consult an authorized Kia system: 2. This device must accept any inter- dealer. ference received, including inter-...
  • Page 87 30 switch. Your password is only avail- seconds, the engine will not start able from an authorized Kia dealer- and you will have to input your ship. Contact an authorized dealer password again.

  • Page 88: Theft-Alarm System

    Features of your vehicle THEFT-ALARM SYSTEM (IF EQUIPPED) Armed stage • Lock the doors by pressing the button of the front outside door Park the vehicle and stop the engine. handles with the smart key in Arm the system as described below. Armed your possession.

  • Page 89: Theft-Alarm Stage

    Transmitter If you want this feature, consult an is armed. authorized Kia dealer. - The door unlock button is pressed. • A front or rear door is opened with- - The engine is started. (within 3...
  • Page 90 30 seconds. Then the system will be disarmed. • If you lose your keys, consult your authorized Kia dealer. • If the system is not disarmed with the transmitter, insert the key into the ignition switch and start the engine.

  • Page 91: Door Locks

    Features of your vehicle DOOR LOCKS Operating door locks from • Doors can also be locked and Operating door locks from unlocked with the transmitter key outside the vehicle inside the vehicle (or smart key). (if equipped) With the door lock button •...

  • Page 92: Central Door Lock Switch

    Features of your vehicle • If the inner door handle of the front If a power door lock ever fails to func- With central door lock switch door is pulled when the door lock tion while you are in the vehicle, try (if equipped) button is in the lock position, the one or more of the following tech-...

  • Page 93: Impact Sensing Door Unlock System

    Features of your vehicle • Press the switch to the "Unlock" Impact sensing door unlock An authorized Kia dealer can acti- position (2), all vehicle doors will vate or deactivate some auto door system unlock. lock/ unlock features as follows;...

  • Page 94: Child-Protector Rear Door Lock

    Features of your vehicle Child-protector rear door lock 3. Close the rear door. To open the rear door, pull the out- side door handle (2). Even though the doors may be unlocked, the rear door will not open by pulling the inner door handle until the rear door child safety lock is unlocked.

  • Page 95: Trunk

    Features of your vehicle TRUNK Opening the trunk WARNING The trunk swings upward. Make sure no objects or people are near the rear of the vehicle when opening the trunk. CAUTION Make certain that you close the trunk before driving your vehi- OTF040016 cle.

  • Page 96: Emergency Trunk Lid Release Cable

    WARNING Exhaust authorized Kia dealer. Fumes The trunk lid should always be kept completely closed while the vehicle is in motion. If it is left open or ajar, poisonous OTF040017...

  • Page 97: Emergency Trunk Safety Release

    Features of your vehicle Emergency trunk safety WARNING release • No one should be allowed to occupy the trunk at any time. The trunk is a very dangerous location in the event of a crash. • Use the release lever for emergencies only.

  • Page 98: Windows

    Features of your vehicle WINDOWS (1) Driver’s door power window switch (2) Front passenger’s door power window switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing (6) Automatic power window down (7) Power window lock button OTF040019N 4 25...

  • Page 99: Power Windows

    Features of your vehicle ✽ ✽ NOTICE In cold and wet climates, power win- Window opening and closing dows may not work properly due to (if equipped) While driving with the rear windows freezing conditions. down or with the sunroof (if equipped) in an open (or partially open) position, your vehicle may Power windows...
  • Page 100 Features of your vehicle Auto down window (if equipped) Auto up/down window If the power window is not operated (Driver’s window) (if equipped) correctly, the automatic power win- dow system must be reset as follows: 1. Turn the ignition switch to the ON position.
  • Page 101 Features of your vehicle And if the power window switch is WARNING pulled up continuously again within 5 seconds after the window is lowered Always check for obstructions by the automatic window reversal before raising any window to feature, the automatic window rever- avoid injuries or vehicle damage.

  • Page 102: Power Window Lock Button

    Features of your vehicle Power window lock button When the power window lock WARNING - Power switch is pressed: (if equipped) windows • The driver's master control can operate all the power windows. Do not allow children to play with the power windows. Keep •...

  • Page 103: Hood

    Features of your vehicle HOOD Opening the hood Closing the hood 1. Before closing the hood, check the following: • All filler caps in engine compart- ment must be correctly installed. • Gloves, rags or any other com- bustible material must be removed from the engine compartment.
  • Page 104 Features of your vehicle WARNING WARNING - Unsecured engine hood Before closing the hood, ensure that obstructions Always double check to be sure removed from the hood open- that the hood is firmly latched ing. Closing the hood with an before driving away.

  • Page 105: Fuel Filler Lid

    Features of your vehicle FUEL FILLER LID Opening the fuel filler lid Closing the fuel filler lid 1. To install the cap, turn it clockwise until it "clicks" once. This indicates that the cap is securely tightened. 2. Close the fuel filler lid and push it lightly and make sure that it is securely closed.
  • Page 106 Features of your vehicle Always check that the fuel cap is WARNING WARNING - Static - Portable fuel installed securely to prevent fuel spillage in the event of an accident. electricity container • Before touching the fuel noz- When using an approved portable zle, you should eliminate fuel container, be sure to place WARNING...

  • Page 107: Emergency Fuel Filler Lid Release

    When refueling, always shut the If the fuel filler cap requires replace- engine off. Sparks produced by ment, use only a genuine Kia cap or electrical components related the equivalent specified for your vehi- to the engine can ignite fuel cle.

  • Page 108: Sunroof

    Features of your vehicle SUNROOF (IF EQUIPPED) In cold and wet climates, the sunroof WARNING - Sunroof may not work properly due to freez- operation ing conditions. After the vehicle is washed or in a When closing the sunroof, make rainstorm, be sure to wipe off any sure there are no body parts in water that is on the sunroof before...

  • Page 109: Sliding The Sunroof

    Features of your vehicle Sliding the sunroof When the sunshade is opened Closing the sunroof If you pull the sunroof control lever To close the sunroof glass only backward, the sunroof glass will slide Push the sunroof control lever for- all the way open.

  • Page 110: Tilting The Sunroof

    Features of your vehicle Automatic reversal Tilting the sunroof WARNING - Sunroof Do not extend the face, neck, arms or body outside through the sunroof opening while driv- ing or operating the sunroof. CAUTION To prevent damage to the sun- roof, periodically remove any dirt that may accumulate on the guide rail.

  • Page 111: Sunshade

    Features of your vehicle ✽ ✽ NOTICE When the sunshade is opened Sunshade If you push the sunroof control lever It is normal for wrinkles to form on upward, the sunroof glass will tilt. the blind because of its material characteristic.

  • Page 112: Resetting The Sunroof

    Features of your vehicle ❈ For more detailed information, Resetting the sunroof contact an authorized Kia dealer. Whenever the vehicle battery is dis- connected or discharged, or related fuse is blown, you must reset your ✽ ✽ NOTICE sunroof system as follows:...

  • Page 113: Driver Position Memory System

    Features of your vehicle DRIVER POSITION MEMORY SYSTEM (IF EQUIPPED) Storing positions into memory WARNING using the buttons on the door Never attempt to operate the Storing driver’s seat positions driver position memory system 1. Move the shift lever into P (for while the vehicle is moving.

  • Page 114: Easy Access Function

    Features of your vehicle Recalling positions from memory Easy access function (if equipped) 1. The shift lever is in P or N (for Automatic transaxle) with one of With the shift lever in the P position, the condition below: the system will move the driver's seat automatically as follows: - The ignition switch in the ON position or engine running.

  • Page 115: Steering Wheel

    Take your vehicle to an vehicle may still be steered, but it will tion switch on. This happens as the authorized Kia dealer and have the require increased steering effort. system performs the EPS system vehicle checked as soon as possible.

  • Page 116: Tilt And Telescoping Steering

    Features of your vehicle Tilt and telescoping steering Horn Tilt steering allows you to adjust the steering wheel before you drive. You can also raise it to give your legs more room when you exit and enter the vehicle. The steering wheel should be posi- tioned so that it is comfortable for you to drive, while permitting you to see the instrument panel warning...

  • Page 117: Heated Steering Wheel

    Features of your vehicle Heated steering wheel If you turn on the ignition again after turning off your engine in half an (if equipped) hour (after operating heater button), the heating system will be main- tained in its 'on' condition. CAUTION •...
  • Page 118 Features of your vehicle MIRRORS Inside rearview mirror Day/night rearview mirror Electric chromic mirror (ECM) (if equipped) (if equipped) Adjust the rearview mirror so that the The electric rearview mirror automat- center view through the rear window ically controls the glare from the is seen.
  • Page 119 Features of your vehicle • Press the ON/OFF button (1) to ■ Type A CAUTION - Cleaning turn the automatic dimming func- mirror tion off. The mirror indicator light will turn off. When cleaning the mirror, use a paper towel or similar material Press the ON/OFF button (1) to dampened with glass cleaner.
  • Page 120 Features of your vehicle Electric chromic mirror (ECM) Automatic-Dimming Night Vision ® ® with HomeLink system and Safety (NVS ) Mirror compass (if equipped) ® The NVS Mirror in your vehicle is the most advanced way to reduce Your vehicle may be equipped with a annoying glare in the rearview mirror Gentex Automatic-Dimming Mirror ®...
  • Page 121 Features of your vehicle ✽ ✽ NOTICE Automatic-dimming function CAUTION Your mirror will automatically dim The mirror defaults to the ON posi- The NVS ® Mirror automatically upon detecting glare from the vehi- tion each time the vehicle is started. reduces glare during driving cles traveling behind you.
  • Page 122 Features of your vehicle Compass function The Compass can be turned ON and OFF and will remember the last state when the ignition is cycled. To turn the display feature ON/OFF: 1. Press and release the button to turn the display feature OFF. 2.
  • Page 123 Features of your vehicle To adjust the Zone setting: 1. Press and hold the button for WARNING 1. Determine desired Zone more than 6 seconds. When the Number based upon your current compass memory is cleared a "C" Before programming ®...
  • Page 124 Features of your vehicle Retain the original transmitter of the ® Standard programming Programming HomeLink RF device you are programming for ✽ ✽ NOTICE To train most devices, follow these use in other vehicles as well as for instructions: • When programming a garage ®...
  • Page 125 Features of your vehicle 5. Press and hold the just-trained Rolling code programming To train rolling code devices, follow ® HomeLink button and observe these instructions: Rolling code devices which are the red Status Indicator LED. If the "code-protected" and manufactured 1.
  • Page 126 Features of your vehicle 3. Return to the vehicle, firmly press Gate operator & Canadian pro- Reprogramming single ® and hold for two seconds the gramming HomeLink button ® desired HomeLink button then During programming, your handheld To program a new device to a previ- release.
  • Page 127 Features of your vehicle Erasing HomeLink ® buttons FCC ID: NZLZTVHL3 ® and ZNav are registered trademarks. Nav are of Gentex Individual buttons cannot be erased. IC: 4112A-ZTVHL3 Corporation, Zeeland, Michigan. However, to erase all three pro- grammed buttons: ® HomeLink is a registered trade- This device complies with Industry...
  • Page 128 Features of your vehicle Outside rearview mirror Remote control CAUTION - Rearview Be sure to adjust mirror angles mirror before driving. Do not scrape ice off the mirror Your vehicle is equipped with both face; this may damage the sur- left-hand and right-hand outside face of the glass.
  • Page 129 Features of your vehicle After the adjustment, put the lever Folding the outside rearview mirror CAUTION - Electric type into neutral (center) position to pre- outside rearview mirror vent inadvertent adjustment. electric type outside rearview mirror operates even CAUTION - Outside mirror though the ignition switch is in •...
  • Page 130 Features of your vehicle OTF040045 Manual type To fold outside rearview mirror, grasp the housing of mirror and then fold it toward the rear of the vehicle. 4 57...

  • Page 131: Instrument Cluster

    Features of your vehicle INSTRUMENT CLUSTER ■ ■ Type A 1. Tachometer 2. Speedometer 3. Engine coolant temperature gauge 4. Fuel gauge 5. Turn signal indicators 6. Warning and indicator lights ■ ■ Type B 7. LCD display ❈ The actual cluster in the vehicle may differ from the illustration.

  • Page 132: Instrument Cluster Control

    Features of your vehicle Instrument Cluster Control LCD Display Control ■ Type A Adjusting Instrument Cluster Illumination OTF044111L ■ Type B OTFH044363L The LCD display modes can be changed by using the control buttons OTF044052 on the steering wheel. The instrument panel illumination intensity can be adjusted by pressing the control switch with the headlight : MODE button for changing...
  • Page 133 Features of your vehicle Gauges Tachometer The tachometer pointer may move slightly when the ignition switch is in Speedometer ■ Type A ACC or ON position with the engine ■ Type A OFF. This movement is normal and will not affect the accuracy of the tachometer once the engine is run- ning.
  • Page 134 Features of your vehicle Engine coolant temperature gauge Fuel gauge WARNING - Fuel gauge ■ ■ Type A ■ Type B Type A ■ Type B Stop and obtain additional fuel as soon as possible after the warning light comes on or when the gauge indicator comes close to the E level.
  • Page 135 Features of your vehicle Odometer Outside Temperature Display The outside temperature on the dis- play may not change immediately ■ ■ Type A Type A like a Hg thermometer to prevent the driver from being inattentive. The temperature unit (from °C to °F or from °F to °C) can be changed by using the “User Settings”...

  • Page 136: Transaxle Shift Indicator

    Features of your vehicle Transaxle Shift Indicator • Park : P • Reverse : R Automatic Transaxle Shift • Neutral : N Indicator (if equipped) • Drive : D ■ Type A • Sports Mode : 1, 2, 3, 4, 5, 6 OTF044364 ■...
  • Page 137 Features of your vehicle LCD DISPLAY (IF EQUIPPED) LCD Modes (for Type B cluster) Modes Symbol Explanation This mode displays driving information like the tripmeter, fuel economy, and so on. Trip Computer For more details, refer to “Trip Computer” in this chapter. Turn By Turn This mode displays the state of the navigation.

  • Page 138: Service Mode

    Features of your vehicle Service Mode If the remaining mileage or time ■ Type A reaches 1,500 km (900 mi.) or 30 Service Interval days, "Service in" message is dis- ■ Type A played for several seconds each time you set the ignition switch or Engine Start/Stop Button to the ON position.
  • Page 139 Features of your vehicle ✽ ✽ NOTICE To reset the service interval to the ■ Type A mileage and days you inputted If any of the following conditions before: occurs, the mileage and days may be - Press the SELECT/RESET button incorrect.

  • Page 140: User Settings Mode

    Features of your vehicle Master Warning Mode User Settings Mode Door (if equipped) Auto Door Lock (if equipped) Description • Off: ■ Type A • This warning light informs the driv- The auto door lock operation will er the following situations be deactivated.
  • Page 141 Features of your vehicle Auto Door Unlock (if equipped) Two Press Unlock (if equipped) Lamp • Off: • Off: One Touch Turn Lamp (if equipped) The auto door unlock operation will The two press unlock function will If this item is checked, the lane be canceled.
  • Page 142 Features of your vehicle Convenience Seat Easy Access (if equipped) Driving Assist (if equipped) If this item is checked, the driver’s Language RCTA seat will automatically move forward Choose the language you prefer If this item is checked RCTA (Rear or rearward for the driver to enter or within the LCD.
  • Page 143 Features of your vehicle Service Interval A/V Mode (if equipped) Turn By Turn Mode (if equipped) ■ Type A OTF044135L ■ Type B OTF044129 OTF044128 This mode displays the state of the This mode displays the state of the A/V system. navigation.

  • Page 144: Warning Messages

    Features of your vehicle Low Key Battery Warning Messages • At this time, the Engine Start/Stop (for smart key system) Button turns to the ACC position (If Shift to "P" position (for smart key you press the Engine Start/Stop system and automatic transaxle) ■...
  • Page 145 Features of your vehicle Press START button while turning • It means that you should press the Steering wheel unlocked wheel (for smart key system) Engine Start/Stop Button while (for smart key system) turning the steering wheel right ■ ■ Type A Type A and left.
  • Page 146 Features of your vehicle Check steering wheel lock Press brake pedal to start engine • This warning message illuminates system (for smart key system) (for smart key system and auto- if the Engine Start/Stop Button changes to the ACC position twice matic transaxle) ■...
  • Page 147 Features of your vehicle Key not in vehicle Key not detected Press START button again (for smart key system) (for smart key system) (for smart key system) ■ ■ ■ Type A Type A Type A OTF044137L OTF044139L OTF044143L ■ ■...
  • Page 148 ■ Type A • If the warning illuminates each ■ Type A time press Engine Start/Stop Button, have your vehi- cle inspected by an authorized Kia dealer. OTF044145L ■ Type B OTF044156L ■ Type B OTF044146L OTF044157L • This warning message illuminates if you press the Engine Start/Stop •...
  • Page 149 Features of your vehicle ✽ ✽ NOTICE • It means that you should replace Shift to "P" or "N" to start engine the fuse with a new one. If that is (for smart key system and auto- You can start the engine with the not possible, you can start the matic transaxle) shift lever in the N (Neutral) posi-...
  • Page 150 Features of your vehicle Door Open Trunk Open Low Washer Fluid ■ ■ ■ Type A Type A Type A OTF044160 OTF044162 OTF044158L ■ ■ ■ Type B Type B Type B OTF044161 OTF044163 OTF044159L • It means that any door is open. •...
  • Page 151 Features of your vehicle Turn on "FUSE SWITCH" • It means that you should turn the Align steering wheel (if equipped) (if equipped) fuse switch on. ■ Type B For more details, refer to "Fuses" in ■ Type A chapter 7. OTF044153L OTF044166L ■...

  • Page 152: Trip Computer

    Features of your vehicle TRIP COMPUTER Overview Trip Modes (Type A) Trip Modes (Type B) Description Tripmeter A FUEL ECONOMY The trip computer is a microcomput- ↕ ↕ • Distance To Empty er-controlled driver information sys- • Average Fuel Economy Tripmeter B tem that displays information related •...
  • Page 153 Features of your vehicle ✽ ✽ NOTICE Fuel Economy • The Distance to empty (range) is the estimated distance the vehicle Distance to empty (Range) (1) • If the vehicle is not on level ground can be driven with the remaining or the battery power has been ■...
  • Page 154 Features of your vehicle Average Fuel Economy (2) Manual reset Instant Fuel Economy (3) • The average fuel economy is calcu- To clear the average fuel economy • This mode displays the instant fuel lated by the total driving distance manually, press the SELECT/RESET economy during the last few sec- and fuel consumption since the last...
  • Page 155 Features of your vehicle Trip A/B • The tripmeter is the total driving Average Vehicle Speed (2) distance since the last tripmeter • The average vehicle speed is cal- Tripmeter (1) reset. culated by the total driving dis- ■ Type A - Distance range: 0.0 ~ 9999.9 km tance and driving time since the or mi.
  • Page 156 Features of your vehicle Elapsed Time (3) One time driving information mode (for Type B cluster) • The elapsed time is the total driv- ing time since the last elapsed time reset. - Time range (hh:mm): 00:00 ~ 99:59 • To reset the elapsed time, press the SELECT/RESET button OK on the steering wheel for more than 1 second when the elapsed time is...
  • Page 157 Belts" in chapter 3. situation that needs attention. - It illuminates for approximately 6 seconds and then goes off. • When there is a malfunction with the SRS. In this case, have your vehicle inspected by an authorized Kia dealer.
  • Page 158 Warning Light In this case, have your vehicle - If the warning light illuminates Driving the vehicle with a warn- towed to an authorized Kia dealer with the parking brake released, it ing light ON is dangerous. If the and inspected.
  • Page 159 ABS (The normal braking sys- decrease. dealer. tem will still be operational without In this case, have your vehicle inspect- the assistance of the anti-lock ed by an authorized Kia dealer as WARNING - Electronic brake system). soon as possible. Brake force Distribution...
  • Page 160 In this case, have your vehicle - It remains on until the engine is - It remains on until the engine is inspected by an authorized Kia started. started. dealer as soon as possible. • When there is a malfunction with •...
  • Page 161 If the belt is adjusted properly, able, have your vehicle inspected there may be a problem in the by an authorized Kia dealer as electrical charging system. soon as possible. In this case, have your vehicle inspected by an authorized Kia dealer as soon as possible.
  • Page 162 3. Start the engine again. If the equipped). warning light stays on after the engine is started, turn the engine off immediately. In this case, have your vehi- cle inspected by an author- ized Kia dealer. 4 89...
  • Page 163 If the warning situation is solved, the In this case, have your vehicle master warning light will be turned off inspected by an authorized Kia and the LCD Modes Icon will be dealer. For more details, refer to "Electronic changed back to its previous icon ( Stability Control (ESC)"...
  • Page 164 SPORT the immobilizer system. seconds: In this case, have your vehicle • When the smart key is not in the inspected by an authorized Kia This indicator light illuminates: vehicle. dealer. • When you select “SPORT” mode - At this time, you can not start the as drive mode.
  • Page 165 Button is ON. the high beam position. In this case, have your vehicle • When the turn signal lever is pulled inspected by an authorized Kia into the Flash-to-Pass position. If any of the following occurs, there dealer. may be a malfunction with the turn signal system.
  • Page 166 Features of your vehicle Front Fog Indicator Cruise Indicator Light KEY OUT Indicator Light CRUISE Light (if equipped) (if equipped) (if equipped) This indicator light illuminates: This indicator light illuminates: When the ENGINE START/STOP button is in the ACC or ON position, •...

  • Page 167: Back-Up Warning System

    Features of your vehicle BACK-UP WARNING SYSTEM (IF EQUIPPED) Operation of the Back-Up WARNING Warning System • The Back-Up Warning System Operating condition is a supplementary function • This system will activate when only. The operation of the backing up with the ignition switch Back-Up Warning System can be affected by several factors •...
  • Page 168 Features of your vehicle Non-operational conditions of The detecting range may decrease Back-Up Warning System pre- when: Back-Up Warning System cautions 1. The sensor is stained with foreign The Back-Up Warning System may • The Back-Up Warning System may matter such as snow or water. not operate properly when: not sound sequentially depending (The sensing range will return to...
  • Page 169 Kia dealer as soon as possible. tion. Stop immediately if you are Always visually check behind the aware of a child anywhere near vehicle when backing up.

  • Page 170: Rear Camera Display

    Features of your vehicle REAR CAMERA DISPLAY (IF EQUIPPED) Note- during initial start up, system WARNING - Rear Camera may not display instantly due to the audio system booting up. Display 2 ~ 4 seconds may be required before The Rear-Camera Display is not displaying during initial reverse selec- a substitute for proper and safe tion.
  • Page 171 Features of your vehicle WELCOME SYSTEM (IF EQUIPPED) Welcome light (if equipped) Escort welcome (if equipped) Interior light When the headlight (light switch in When the interior light switch is in the the headlight or AUTO position) is on DOOR position and all doors (and and all doors (and trunk) are locked trunk) are locked and closed, the and closed, the position light and...
  • Page 172 (or smart key) twice or turning If necessary, to keep the lights on by an authorized Kia dealer. off the light switch from the headlight when the ignition key is removed, Don't attempt to inspect or replace or Auto light position.

  • Page 173: Daytime Running Light

    Features of your vehicle Daytime running light Lighting control Parking light position ( Daytime Running Lights (DRL) can make it easier for others to see the front of your vehicle during the day. DRL can be helpful in many different driving conditions, and it is especially helpful after dawn and before sunset.
  • Page 174 Features of your vehicle Auto light position (if equipped) If your vehicle has window tint or Headlight position ( other types of metallic coating on the front windshield, the Auto light sys- tem may not work properly. OAM049042 OVG049181 When the light switch is in the AUTO When the light switch is in the head- light position, the taillights and head- light position (2nd position) the head,...
  • Page 175 Features of your vehicle High beam operation WARNING - High beams Do not use high beam when there are other vehicles. Using high beam could obstruct the other driver's vision. OAM049043 To flash the headlights, pull the lever OAM049044 towards you. It will return to the normal To turn on the high beam headlights, (low-beam) position when released.
  • Page 176 Features of your vehicle Turn signals and lane change If an indicator stays on and does not One-touch lane change function flash or if it flashes abnormally, one of signals To activate an one-touch lane the turn signal bulbs may be burned change function, move the turn sig- out and will require replacement.
  • Page 177 Features of your vehicle Front fog light (if equipped) OAM049046N Fog lights are used to provide improved visibility when visibility is poor due to fog, rain or snow, etc. The fog lights will turn on when the fog light switch (1) is turned to the on position after the headlights are turned on.

  • Page 178: Wipers And Washers

    Features of your vehicle WIPERS AND WASHERS Windshield wipers AUTO (Automatic) control (if equipped) Operates as follows when the igni- tion switch is turned ON. MIST : For a single wiping cycle, push the lever upward and release it. The wipers will operate continuously if the lever is held in this position.
  • Page 179 Features of your vehicle To vary the speed setting, turn the Windshield washers CAUTION - Wiper speed control knob (1). position If the wiper switch is set in AUTO When washing the vehicle, set mode when the ignition switch is ON, the wiper switch in the OFF the wiper will operate once to per- position to stop the auto wiper...
  • Page 180 Features of your vehicle The reservoir filler neck is located in CAUTION - Wipers & the front of the engine compartment windshields on the passenger side. • To prevent possible damage to the wipers or windshield, CAUTION - Washer do not operate the wipers pump when the windshield is dry.

  • Page 181: Interior Light

    Features of your vehicle INTERIOR LIGHT Do not use the interior lights for Automatic turn off function Map lamp extended periods when the engine is (if equipped) not running. The interior lights automatically turn It may cause battery discharge. off approximately 20 minutes after the ignition switch is turned off.

  • Page 182: Room Lamp

    Features of your vehicle • DOOR (2) : • OFF (2) : The lights turn off even if Room lamp a door is opened. In the DOOR position, the map lamp ■ Type A and the room lamp come on when any When lamp door is opened regardless of the igni-...

  • Page 183: Trunk Room Lamp

    Features of your vehicle ■ ■ Type B • OFF : The lights turn off even if a Trunk room lamp (if equipped) door is opened. • DOOR : • ON : The room lamp stays on at all In the DOOR position, the map lamp times.

  • Page 184: Glove Box Lamp

    Features of your vehicle Glove box lamp (if equipped) Vanity mirror lamp (if equipped) OTF040112 OLM049105 The glove box lamp comes on when Push the switch to turn the light on or the glove box is opened. off. To prevent unnecessary charging •...

  • Page 185: Defroster

    Features of your vehicle DEFROSTER Rear window defroster The rear window defroster automati- CAUTION - Conductors cally turns off after approximately 20 minutes or when the ignition switch is To prevent damage to the con- turned off. To turn off the defroster ductors bonded to the inside manually, press the rear window surface of the rear window,...

  • Page 186: Manual Climate Control System

    Features of your vehicle MANUAL CLIMATE CONTROL SYSTEM 1. Fan speed control knob 5. Air intake control button 2. Front windshield defroster button 6. Mode selection button 3. Rear window defroster button 7. Air conditioning button 4. Temperature control knob OTF044311 4 113...

  • Page 187: Heating And Air Conditioning

    Features of your vehicle Heating and air conditioning 1. Start the engine. 2. Set the mode to the desired posi- tion. To improve the effectiveness of heating and cooling : - Heating: - Cooling: 3. Set the temperature control to the desired position.
  • Page 188 Features of your vehicle Mode selection Face-Level (B, C, D, E, F) Floor/Defrost-Level (A, C, D, E) Air flow is directed toward the upper Most of the air flow is directed to the body and face. Additionally, each floor and the windshield with a small outlet can be controlled to direct the amount directed to the side window air discharged from the outlet.
  • Page 189 Features of your vehicle Temperature control OTF044315 OTF044316 MAX A/C-Level (B, D) (if equipped) Instrument panel vents OTF044317 The MAX A/C mode is used to cool The outlet vents can be opened or The temperature control knob allows the inside of the vehicle faster. closed separately using the thumb- you to control the temperature of the wheel.
  • Page 190 Features of your vehicle Air intake control Recirculated air position Prolonged operation of the heater in the recirculated air position (without air The indicator light on the conditioning selected) may cause fog- button illuminates when ging of the windshield and side win- the recirculated air posi- dows and the air within the passenger tion is selected.
  • Page 191 Features of your vehicle Fan speed control To turn off the blowers Air conditioning (if equipped) OTF044319L OTF044403 OTF044320L The ignition switch must be in the ON To turn off the blowers, turn the fan Press the A/C button to turn the air position for fan operation.

  • Page 192: System Operation

    Features of your vehicle System operation Operation Tips Air conditioning (if equipped) • To prevent dust or unpleasant Kia Air Conditioning Systems are Ventilation fumes from entering the vehicle filled with R-134a refrigerant. 1. Set the mode to the position.
  • Page 193 Kia pressor cycles. This is a normal dealer. system operation characteristic. • Use the air conditioning system...

  • Page 194: Climate Control Air Filter

    The air conditioning system should accumulation on the inside of the be serviced by an authorized Kia windshield even when the outside dealer. (fresh) air position is selected. If this...

  • Page 195: Automatic Climate Control System

    Features of your vehicle AUTOMATIC CLIMATE CONTROL SYSTEM (IF EQUIPPED) ■ ■ Type A 1. Driver’s temperature control knob 2. AUTO (automatic control) button 3. Front windshield defroster button 4. Rear window defroster button 5. Fan speed control button 6. OFF button 7.

  • Page 196: Automatic Heating And Air Conditioning

    Features of your vehicle ✽ ✽ NOTICE Automatic heating and air con- ditioning • To turn the automatic operation off, select any button or switch of the following: - Mode selection button - Air conditioning button - Front windshield defroster button - Air intake control button - Fan speed control button The selected function will be con-...

  • Page 197: Manual Heating And Air Conditioning

    Features of your vehicle Manual heating and air condi- Mode selection tioning The heating and cooling system can be controlled manually by pushing buttons other than the AUTO button. In this case, the system works sequentially according to the order of buttons selected.
  • Page 198 Features of your vehicle Face-Level (B, C, D, E, F) Floor-Level (C, A, D, E) Air flow is directed toward the upper Most of the air flow is directed to the body and face. Additionally, each floor, with a small amount of the air outlet can be controlled to direct the being directed to the windshield and air discharged from the outlet.
  • Page 199 Features of your vehicle Temperature control OTF044316 OTF044329L Instrument panel vents Adjusting the driver and passenger OTF044328 side temperature individually The outlet vents can be opened or The temperature control knob allows closed separately using the thumb- 1. Press the DUAL button to operate you to control the temperature of the wheel.
  • Page 200 Features of your vehicle Adjusting the driver and passenger Temperature conversion WARNING - Reduced side temperature equally You can switch the temperature Visibility 1. Press the DUAL button again to mode between Fahrenheit deactivate DUAL mode. The pas- Centigrade as follows: Continuous use of the climate senger side temperature will be control system in the recirculat-...
  • Page 201 Features of your vehicle Outside thermometer Air intake control Recirculated air position The current outside temperature is With the recirculated air ■ ■ Type A Type B displayed in 1°C (1°F) increments. position selected, air The temperature range is between - from passenger -40°C ~ 60°C (40°F~140°F).
  • Page 202 Features of your vehicle Fan speed control Air conditioning OFF mode ■ ■ Type A Type B OTF044331L OTF044332L OTF044333L The fan speed can be set to the Press the OFF button to turn off the Press the A/C button to turn the air desired speed by pressing the fan air climate control system.

  • Page 203: System Operation

    Features of your vehicle Climate information screen selec- System operation Operation Tips tion (if equipped) • To keep dust or unpleasant fumes Ventilation from entering the vehicle through 1. Set the mode to the position. the ventilation system, temporarily 2. Set the air intake control to the set the air intake control to the outside (fresh) air position.
  • Page 204 Features of your vehicle ✽ ✽ NOTICE Air conditioning Air conditioning system operation tips Kia Air Conditioning Systems are • When using the air conditioning • If the vehicle has been parked in filled with environmentally friendly R- system, monitor the temperature direct sunlight during hot weather, 134a refrigerant.
  • Page 205 Features of your vehicle • When using the air conditioning system, you may notice clear water dripping (or even puddling) on the ground under the passenger side of the vehicle. This is a normal sys- tem operation characteristic. • Operating the air conditioning sys- tem in the recirculated air position provides maximum cooling, how- ever, continual operation in this...

  • Page 206: Windshield Defrosting And Defogging

    Features of your vehicle WINDSHIELD DEFROSTING AND DEFOGGING • For maximum defrosting, set the Manual climate control system WARNING - Windshield temperature control to the extreme To defog inside windshield heating right/hot position and the fan speed control to the highest speed. Do not use the ( ) or ( position during cooling opera-...

  • Page 207: Automatic Climate Control System

    Features of your vehicle To defrost outside windshield Automatic climate control sys- 1. Select desired fan speed. 2. Select desired temperature. 3. Press the defroster button ( To defog inside windshield 4. The outside (fresh) air position will ■ Type A be selected automatically.

  • Page 208: Defogging Logic

    Features of your vehicle To defrost outside windshield Defogging logic 3. Press the defroster button ( To reduce the probability of fogging 4. The outside (fresh) air position will ■ Type A up inside of the windshield, the air be selected automatically. intake or air conditioning are con- trolled automatically according to certain conditions such as...
  • Page 209 Features of your vehicle Manual climate control system If the battery has been discharged or Automatic climate control system disconnected, it resets to the defog ■ Type A logic status. OTF044349 ■ Type B OTF044346 1. Turn the ignition switch to the ON position.
  • Page 210 Features of your vehicle 3. While pressing the air conditioning Auto defogging system (Only for This indicator illuminates button (A/C), press the air intake automatic climate control system, when the auto defogging control button ( ) at least 5 system senses the mois- if equipped) times within 3 seconds.
  • Page 211 Features of your vehicle ✽ ✽ NOTICE If your vehicle is equipped with the auto defogging system, it is automati- If the A/C off or recirculated air cally activated when the conditions position is manually selected while are met. However, if you would like to the auto defogging system is on, the cancel the auto defogging system, auto defogging indicator will blink 3...

  • Page 212: Storage Compartment

    Features of your vehicle STORAGE COMPARTMENT These compartments can be used to Center console storage Glove box store small items. (if equipped) To avoid possible theft, do not leave ■ Type A valuables in the storage compartment. Always keep the storage compart- ment covers closed while driving.

  • Page 213: Cool Box

    Features of your vehicle ✽ ✽ NOTICE Cool box (if equipped) Sunglass holder Do not put perishable food in the cool box because it may not main- tain the necessary consistent tem- perature to keep the food fresh. ✽ ✽ NOTICE If the temperature control knob is in the warm or hot position, warm or hot air will flow into the glove box.
  • Page 214 Features of your vehicle WARNING - Sunglass holder Do not keep objects except sun- glasses inside the sunglass hold- er. Heavier objects can be thrown from the holder in the event of a sudden stop or an accident, pos- sibly injuring the passengers. 4 141...

  • Page 215: Interior Features

    Features of your vehicle INTERIOR FEATURES Cup holder ■ Front Cups or small beverage cans may be • Type A placed in the cup holders. WARNING - Hot liquids Do not place uncovered cups of hot liquid in the cup holder while the vehicle is in motion.

  • Page 216: Sunvisor

    Features of your vehicle Sunvisor Power outlet (if equipped) CAUTION - Vanity mirror lamp * : if equipped Close the vanity mirror cover securely and return the sunvi- sor to its original position after use. If the vanity mirror is not closed securely, the lamp will stay on and could result in bat- tery discharge and possible...

  • Page 217: Digital Clock

    Features of your vehicle Only use 12V electric accessories Digital clock WARNING - Clock Setting which are less than 10A in electric ■ Type A capacity. Distraction Adjust the air-conditioner or heater to Do not adjust the clock while the lowest operating level when driving.

  • Page 218: Clothes Hanger

    Features of your vehicle • HOUR (1) : Clothes hanger (if equipped) CAUTION - Hanging Pressing 'H" button will clothing advance the time display by one Do not hang heavy clothes, hour. since those may damage the hook. • MINUTE (2) : Pressing the "M"...

  • Page 219: Floor Mat Anchor(S)

    This keeps the floor mat from sliding mat anchors that are designed to forward. securely hold the floor mat in place. To avoid any interference with pedal operation, Kia recommends that only the Kia floor mat designed for use in your vehicle be installed.

  • Page 220: Navigation System

    Features of your vehicle Navigation system (if equipped) The navigation system ascertains the present position of your vehicle by using information from satellites and guides you to the place you assign as the destination. Detailed information for the naviga- tion system is described in a sepa- rately supplied manual.

  • Page 221: Audio System

    Features of your vehicle AUDIO SYSTEM ✽ ✽ NOTICE Antenna Shark fin antenna (if equipped) The shark fin antenna will receive the If you install an after market HID transmit data. head lamp, your vehicle’s audio and electronic device may malfunction. CAUTION •...

  • Page 222: Steering Wheel Audio Controls

    Features of your vehicle Steering wheel audio controls MODE (3) VOLUME ( / ) (1) (if equipped) Press the button to change audio • Press the lever upward ( ) to source. increase the volume. ■ Type A FM(1~2) ➟ ➟...

  • Page 223: Aux, Usb And Ipod * Port

    Features of your vehicle ✽ ✽ NOTICE Aux, USB and iPod ® * port WARNING When using a portable audio device Driving while distracted is dan- connected to the power outlet, noise gerous and should be avoided. may occur during playback. If this Drivers should remain attentive happens, use the power source of the to driving and always exercise...
  • Page 224 Features of your vehicle How vehicle audio works AM reception FM radio station FM reception JBM002 JBM003 AM broadcasts can be received at FM broadcasts are transmitted at JBM001 greater distances than FM broad- high frequencies and do not bend to AM and FM radio signals are broad- casts.
  • Page 225 Features of your vehicle Using a cellular phone or a two- way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio system. This does not mean that something is wrong with the audio equipment. In such a case, try to operate mobile devices as far from the audio equipment as possi- ble.
  • Page 226 Features of your vehicle Caring for disc • Depending on the type of CD- R/CD-RW CDs, certain CDs may • If the temperature inside the car is too not operate normally according to high, open the car windows to venti- the manufacturing companies.
  • Page 227 Features of your vehicle WARNING WARNING WARNING - Driver - Antenna - Driver Distraction distraction Do not touch the antenna dur- ing thunder or lightening as • Do not stare at the screen Operating the device while driv- such acts may lead to lightning while driving.
  • Page 228 Features of your vehicle (Continued) CAUTION • Do not place beverages close • Turn on the car ignition before to the audio system. Spilling using the audio system. Do beverages may lead to system not operate the audio system malfunction. for long periods of time with •...
  • Page 229 Features of your vehicle USING THE USB DEVICE (Continued) (Continued) • An encrypted MP3 PLAYER is • You may hear a strange noise • To use an external USB device, not recognizable. when connecting or disconnect- make sure the device is not con- ing a USB device.
  • Page 230 Features of your vehicle (Continued) (Continued) • If you use devices such as a USB • Some USB flash memory read- hub purchased separately, the ers (such as CF, SD, micro SD, vehicle’s audio system may not etc.) external-HDD type recognize the USB device.
  • Page 231 Features of your vehicle ® USING iPod DEVICE (Continued) (Continued) • Some iPod devices, such as the • When connecting iPod with the ® ® ® iPod is a registered trademark of iPhone connected iPod Power Cable, insert the ® ®...
  • Page 232 Bluetooth SIG, lnc. and any use of ogy which uses a 2.4GHz ~ legal operation of a vehicle, and such marks by Kia is under license. 2.48GHz frequency to connect var- use of any handheld devices, ious devices within a certain dis- A compatible Bluetooth ®...
  • Page 233 Features of your vehicle Precautions for Safe Driving When connecting a Bluetooth ® • Park the vehicle when connecting the head unit with the mobile Phone enabled phone. • Bluetooth ® Handsfree is a feature • Bluetooth ® connection • Before connecting the head unit that enables drivers to practice become intermittently disconnect- with the mobile phone, check to...
  • Page 234 Features of your vehicle Voice Recognition (Continued) - When driving on rugged and uneven roads • When using the voice recognition - During severe rain (heavy rains, feature, only commands listed with- windstorms) in the user's manual are supported. • Phone related voice commands •...
  • Page 235 Features of your vehicle ■ ■ CD Player : AM1A0TKAN,8V, AM1A0TKKN,8V...
  • Page 236 Features of your vehicle SYSTEM CONTROLLERS RADIO PHONE AND FUNCTIONS Changes to FM/AM/Sirius mode. Operates Phone Screen ❈ When a phone is not connected, Each time the key is pressed, the ➟ mode is changed in order of FM1 the connection screen is displayed. ❈...
  • Page 237 Features of your vehicle SCAN SETUP Radio Mode Briefly press the key (under 0.8 sec- onds) : Moves to the Display, Sound, - Shortly press the key : Previews Phone, System setting modes each broadcast for 5 seconds each. Press and hold the key (over 0.8 sec- onds) : Move to the Time setting screen - Press and hold the key (over 0.8 seconds): Previews the broadcasts...
  • Page 238 Features of your vehicle (13) (Preset) (12) TUNE knob Radio Mode: Saves frequencies AM/FM Mode : Changes frequency (channels) or receives saved fre- by turning the knob left/right. quencies (channels) CD, USB, iPod , My Music Mode: ® CD, USB, iPod , My Music mode ®...
  • Page 239 Features of your vehicle SETUP Mode Pop up [Mode Pop up] Changes selection mode Display Settings • During On state, press the RADIO key to display the mode MEDIA Press the key Select [Display] change pop up screen. SETUP through TUNE knob or Select menu through TUNE knob...
  • Page 240 Features of your vehicle SOUND SETTINGS Sound Settings Speed Dependent Volume Control This feature will gradually increase This menu allows you to set the the volume as speed increases to ‘Bass, Middle, Treble’ and the Sound Press the key Select [Sound] SETUP offset outside noise.
  • Page 241 Features of your vehicle SYSTEM SETTINGS Memory Information • Off : This mode is for expert users and omits some information during Displays currently used memory and voice command operation. (When total system memory. using Expert mode, guidance Press the Select SETUP Select [Memory Information] OK...
  • Page 242 Features of your vehicle RADIO : FM, AM OR SIRIUS Preset SEEK Selecting through manual search Press the Turn the TUNE knob left/right to • Briefly pressing the key (under 0.8 adjust the frequency. seconds): Plays the frequency saved in the corresponding key. •...
  • Page 243 Features of your vehicle MENU Within key are the A.Store MENU (Auto Store) and Info functions. A.Store Press the key Set [A.Store] MENU through TUNE knob or key. Saves broadcasts with superior reception to keys. If no frequencies are received, then the most recently received frequency will be broadcast.
  • Page 244 Features of your vehicle Sirius Satellite Radio information Satellite Radio channels: • Terrain: Hills, mountains, tall build- For information on extended sub- ings, bridges, tunnels, freeway scription terms, contact Sirius Sirius Satellite Radio has over 130 overpasses, parking garages, 1-800-643-2112. channels, including 69 channels of dense tree foliage and thunder- 100% commercial-free music, plus...
  • Page 245 Using Sirius Satellite Radio • Shortly pressing the key (under 0.8 in order for the radio to receive the Your Kia vehicle is equipped with a 3 seconds): Previews each broad- activation signal. month complimentary period of cast for 5 seconds each...
  • Page 246 Please consult with your Displays the Artist/Song info of the Kia dealership. current song. 2. Acquiring Signal If this message is displayed, it means that the antenna is covered and that the...
  • Page 247 Features of your vehicle BASIC METHOD OF USE : Repeat While song (file) is playing Audio CD / MP3 CD / USB / (RPT) key iPod ® / My Music Audio CD, MP3 CD, USB, iPod , My ® Music mode: RPT on screen Press the key to change the MEDIA...
  • Page 248 Features of your vehicle MP3 CD, USB mode: FLD.RDM on While song (file) playing Folder Search : MP3 CD, USB SEEK screen Mode TRACK • Folder Random (press the key) : • Shortly pressing the key : Plays the While file is playing FOLDER next song.
  • Page 249 Features of your vehicle MENU : Audio CD Information MENU : MP3 CD / USB Press the CD MP3 mode Press the key Set [ Info] Press the CD MP3 mode MENU MENU MENU Repeat, Random, through the TUNE knob or to set the Repeat, Folder Random, Information features.
  • Page 250 Features of your vehicle Folder Random All Random Copy Press the key Set [ A.RDM] Press the key Set [ Copy] MENU MENU Press the key Set [ F.RDM] MENU through the TUNE knob or through the TUNE knob or through the TUNE knob or to randomly play all songs within the...
  • Page 251 Features of your vehicle MENU : iPod Information ® In iPod mode, press the Press the key Set [ Info] MENU MENU ® Repeat, Random, through the TUNE knob or Information and Search features. key. Displays information of the current song.
  • Page 252 Features of your vehicle MENU : My Music Mode Random Delete Press the key Set [ Delete] MENU Press the key Set [ RDM] MENU through the TUNE knob or through the TUNE knob or In My Music mode, press the MENU key.
  • Page 253 Features of your vehicle Delete Selection My Music AUX is used to play external MEDIA • Even if memory is available, a Press the key Set [ MENU currently connected with the AUX maximum of 6,000 songs can be Del.Sel] through the TUNE knob terminal.
  • Page 254 AUDIO owned by Bluetooth SIG, Inc. and [Audio Streaming] of Phone is any use of such marks by Kia is turned What is Bluetooth Wireless under license. Other trademarks ®...
  • Page 255 Features of your vehicle Starting Bluetooth ® Wireless Using the Bluetooth ® Wireless Technology Audio Technology audio features • Press the key to change the • Play / Stop MEDIA mode in order of CD ➟ USB ➟ AUX Press the TUNE knob to play and ➟...
  • Page 256 Features of your vehicle PHONE Making a call using the • Check call history and making call Steering-wheel mounted con- ➀ Briefly press (under 0.8 seconds) trols key on the steering Before using the Bluetooth Wireless ® Technology phone features remote controller.
  • Page 257 Bluetooth SIG, Inc. and any use of such marks by Kia is under license. Other trademarks and trade names are those of their respective owners. A Bluetooth ®...
  • Page 258 Features of your vehicle 2.Select [OK] button to enter the Pair [Non SSP supported device] Pairing Key / PHONE Phone screen. on the Steering Remote (SSP: Secure Simple Pairing) Controller 4. After a few moments, a screen is displayed where the passkey is entered.
  • Page 259 During the pairing process, make sure that all connection requests on the phone are accepted for phone- book download and to allow accept- ance of all future connection requests. and Visit http://www.kia.com/#/blue- tooth for additional information on pairing your Bluetooth-enabled mobile phone, and to view a phone compatibility list.
  • Page 260 Features of your vehicle Pairing through [PHONE] • Bluetooth Wireless Technology • Only Bluetooth ® Wireless Technology ® features supported within the vehi- Handsfree and Bluetooth audio relat- Setup cle are as follows. Some features ed features are supported. may not be supported depending •...
  • Page 261 Features of your vehicle • After pairing is complete, a con- Connecting a Device From the paired phone list, select the tacts download request is sent device you want to connect and once to the mobile phone. Some select [Connect]. Press key Select mobile phones may require confir-...
  • Page 262 Features of your vehicle Changing Priority From the paired phone list, select • Priority icon will be displayed when the phone you want to switch to the the selected phone is set as a pri- highest priority, then select [Change ority phone.
  • Page 263 Features of your vehicle Disconnecting a Device Deleting a Device • When deleting the currently con- nected device, the device will auto- matically be disconnected to pro- Press key Select Press key Select SETUP SETUP ceed with the deleting process. [Phone] Select [Phone List] [Phone] Select [Phone List] •...
  • Page 264 Features of your vehicle • If you select the [Call History] but- Answering Calls USING Bluetooth Wireless ® ton but there is no call history data, Technology a prompt is displayed which asks to Answering a Call download call history data. Phone Menu Screen Answering a call with a Bluetooth ®...
  • Page 265 Features of your vehicle • When an incoming call pop-up is Favorites Call History displayed, most Audio and SETUP mode features are disabled. Only Press the Select Press the Select [Call the call volume will operate. PHONE PHONE [Favorites] History] •...
  • Page 266 Features of your vehicle Contacts • Up to 1,000 contacts saved in your • It is not possible to begin down- Bluetooth Wireless Technology loading a contact list when the con- ® phone can be downloaded into the tact download feature has been Press key Select Bluetooth...
  • Page 267 ® are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Kia is under license. Other trademarks and trade names are those of their respective owners. A Bluetooth enabled cell phone is ®...
  • Page 268 Features of your vehicle 1) Connect/Disconnect Phone Downloading Contacts Auto Download (Contacts) Connect/ disconnects currently Press key Select Press key Select SETUP SETUP selected phone [Phone] Select [Contacts Download] [Phone] Select [Auto Download] 2) Change Priority : Sets currently selected phone to highest connec- tion priority 3) Delete : Deletes the currently selected phone...
  • Page 269 Features of your vehicle Audio Streaming Outgoing Volume Turning Bluetooth System Off Press key Select Press key Select Press the key Select SETUP SETUP SETUP [Phone] Select [Outgoing Volume] [Phone] Select [Bluetooth System [Phone] Select [Audio Streaming] Off] Once Bluetooth Wireless Technology ®...
  • Page 270 Features of your vehicle VOICE RECOGNITION If prompt feedback is in [ON], then Skipping Prompt Messages the system will say “Please say a While prompt message is being stat- command after the beep (BEEP)” ed Shortly press the key on the Using Voice Recognition •...
  • Page 271 RECOGNITION Contact Tips: 1)Do not use acronyms (i.e., use “County Finance Department” The Kia Voice Recognition System instead of “CFD”). While Voice Recognition is operating may have difficulty understanding Press and hold the key on the some accents or uncommon...
  • Page 272 Features of your vehicle Illustration on using voice commands More Help Here are some examples of mode commands. • Starting voice command. You can say a radio type like 'FM', 'AM', or 'Satellite'. Shortly pressing the key (under 0.8 seconds): You can also say a media source like 'USB', 'My Music', or 'iPod'.

  • Page 273: Voice Command List

    Features of your vehicle Voice Command List • Common Commands: These commands can be used in most operations. (However a few commands may not be available during certain operations) Command Function Command Function • More Help Provides guidance on commands that can be When listening to the radio, displays the next ➟...
  • Page 274 Features of your vehicle Command Function Command Function SiriusXM (Satellite) Displays the selected SIRIUS screen. My Music Plays the music saved in My Music. AUX (Auxiliary) Plays the connected external device. Sirius Channel Plays the selected SIRIUS channel. Bluetooth ® Audio Plays the music saved in connected Bluetooth ®...
  • Page 275 Features of your vehicle • FM/AM radio commands: Commands available during • Satellite radio commands: Commands that can be FM, AM radio operation. used while listening to Satellite Radio. Command Function Command Function Preset 1~6 Plays the broadcast station saved in Preset 1~6. Channel 0~223 Plays the selected Satellite Radio channel.
  • Page 276 Features of your vehicle • Audio CD commands: Commands available during • MP3 CD / USB commands: Commands available dur- Audio CD operation. ing USB and MP3 CD operation. Command Function Command Function Random Randomly plays the tracks within the CD. Random Randomly plays the files within the current folder.
  • Page 277 Features of your vehicle • iPod Commands: Commands available during iPod • My Music Commands: Commands available during ® ® operation. My Music operation. Command Function Command Function Random Randomly plays the songs within the current Random Randomly plays all saved files. category.
  • Page 278 Bluetooth ® word mark and logos are registered ation Command Operation trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Kia is under license. A Bluetooth ® enabled cell phone is required to use Command Function Bluetooth ®...

  • Page 279: Driving Your Vehicle

    Driving your vehicle Before driving ......5-4 Cruise control system..... . . 5-34 •...
  • Page 280 • Smooth cornering ......5-52 • Driving at night ......5-52 •...
  • Page 281 1. Close all windows. the exhaust system checked as soon 2. Open side vents. as possible by an authorized Kia 3. Set the air intake control at dealer. "Fresh", the air flow control at "Floor"...

  • Page 282: Before Driving

    Driving your vehicle BEFORE DRIVING Before entering vehicle Before starting WARNING - Distracted • Be sure that all windows, outside • Close and lock all doors. driving mirror(s), and outside lights are • Position the seat so that all con- Driving while distracted can clean.
  • Page 283 Driving your vehicle WARNING WARNING - Check sur- - Loose object rounding Securely store items in your Always check the surrounding vehicle. When you make a sud- areas near your vehicle for peo- den stop or turn the steering ple, especially children, before wheel rapidly, loose objects putting a vehicle into D (Drive) may drop on the floor and it...

  • Page 284: Key Positions

    Driving your vehicle KEY POSITIONS Illuminated ignition switch Ignition switch position Before leaving the driver’s seat, always make sure the shift lever is (if equipped) engaged in P (Park) for the automat- ic transaxle, set the parking brake fully and shut the engine off. ACC (Accessory) The steering wheel is unlocked and electrical accessories are operative.
  • Page 285 Driving your vehicle START WARNING - Steering Turn the ignition switch to the START wheel position to start the engine. The engine will crank until you release Never reach for any controls the key; then it returns to the ON through the steering wheel position.

  • Page 286: Engine Start/Stop Button

    Driving your vehicle ENGINE START/STOP BUTTON (IF EQUIPPED) Illuminated ENGINE ENGINE START/STOP button If the vehicle is still moving, you can restart the engine without depress- START/STOP button position ing the brake pedal by pressing the ENGINE START/STOP button with the shift lever in the N (Neutral) posi- tion.
  • Page 287 Driving your vehicle ACC(Accessory) START/RUN Orange indicator Green indicator Not illuminated Press the ENGINE START/STOP Press the ENGINE START/STOP To start the engine, depress the button while it is in the OFF position button while it is in the ACC position brake pedal and press the ENGINE without depressing the brake pedal.
  • Page 288 Driving your vehicle If you leave the ENGINE START/ STOP button in the ACC or ON posi- tion for a long time, the battery will discharge. WARNING - Starting vehicle Never press ENGINE START/STOP button while the vehicle is in motion except in an emergency.

  • Page 289: Starting The Engine

    Driving your vehicle STARTING THE ENGINE should started without CAUTION WARNING - Starter - Proper depressing the accelerator. footwear Do not engage the starter for 4.Do not wait for the engine to warm more than 10 seconds. If the Always wear appropriate shoes up while the vehicle remains sta- engine stalls or fails to start, when operating your vehicle.

  • Page 290: Starting The Engine With A Smart Key

    Driving your vehicle Starting the engine with a 5.Do not wait for the engine to warm WARNING - Unintended up while the vehicle remains sta- smart key (if equipped) tionary. vehicle movement Start driving at moderate engine Never leave the smart key in the speeds.
  • Page 291 Driving your vehicle • When the stop lamp fuse is blown, you can't start the engine normally. Replace the fuse with a new one. If it is not possible, you can start the engine by pressing the ENGINE START/STOP button for 10 sec- onds while it is in the ACC posi- tion.

  • Page 292: Automatic Transaxle

    Driving your vehicle AUTOMATIC TRANSAXLE Automatic transaxle operation The automatic transaxle has 6 for- ward speeds and one reverse speed. The individual speeds are selected Shift lever automatically, depending on the position of the shift lever. Button ✽ ✽ NOTICE + (UP) The first few shifts on a new vehicle or if the battery has been discon-...
  • Page 293 Driving your vehicle For smooth operation, depress the Transaxle ranges CAUTION - Transaxle brake pedal when shifting from N The indicator light in the instrument (Neutral) to a forward or reverse avoid damage your cluster displays the shift lever posi- gear.
  • Page 294 Driving your vehicle R (Reverse) D (Drive) Use this position to drive the vehicle This is the normal forward driving backward. position. The transaxle will automati- cally shift through 6-gear sequence, providing the best fuel CAUTION - Shifting economy and power. Always come to a complete stop before shifting into or out of R For extra power when passing anoth-...
  • Page 295 Driving your vehicle Up (+) : Push the lever forward • To maintain the required levels of Paddle shifter (if equipped) once to shift up one gear. vehicle performance and safety, the system may not execute cer- Down (-) : Pull the lever backwards tain gearshifts when the shift lever once to shift down one is operated.
  • Page 296 P (Park) position into 3.Move the shift lever. another position to avoid inad- vertent motion of the vehicle. 4.Have your vehicle inspected by an authorized Kia dealer immediately.

  • Page 297: Good Driving Practices

    Driving your vehicle Ignition key interlock system Good driving practices Moving up a steep grade from a (if equipped) standing start • Never move the shift lever from P The ignition key cannot be removed To move up a steep grade from a (Park) or N (Neutral) to any other unless the shift lever is in the P standing start, depress the brake...

  • Page 298: Brake System

    Driving your vehicle BRAKE SYSTEM Wet brakes may impair the vehicle’s CAUTION - Brake pedal ability to safely slow down; the vehi- Power brakes cle may also pull to one side when Do not drive with your foot rest- Your vehicle has power-assisted the brakes are applied.

  • Page 299: Parking Brake

    Driving your vehicle In the event of brake failure Disc brakes wear indicator WARNING - Brake wear If service brakes fail to operate while When your brake pads are worn and the vehicle is in motion, you can new pads are required, you will hear Do not ignore high pitched wear make an emergency stop with the a high-pitched warning sound from...
  • Page 300 Driving your vehicle Parking brake CAUTION - Parking brake Applying the parking brake Driving with the parking brake applied will cause excessive brake pad (or lining) and brake rotor wear. OTF050014 Hand type To engage the parking brake, first OTF050015 apply the foot brake and then without Foot type pressing the release button in, pull...
  • Page 301 Driving your vehicle Releasing the parking brake WARNING - Parking brake All vehicles should always have the parking brake fully engaged when parking to avoid inadver- tent movement of the vehicle which can injure occupants or pedestrians. OTF050016 Hand type OTF050017 To release the parking brake, first Foot type...

  • Page 302: Anti-Lock Brake System (Abs)

    Driving your vehicle If at all possible, stop driving the Anti-lock brake system (ABS) vehicle immediately. If that is not pos- ABS (or ESC) will not prevent acci- sible, use extreme caution while dents due to improper or dangerous operating the vehicle and only con- driving maneuvers.
  • Page 303 ABS but your regular brakes will ping distance than for vehicles work normally. Contact an authorized equipped with a conventional Kia dealer as soon as possible. brake system. 5 25...

  • Page 304: Electronic Stability Control (Esc)

    • Do not pump your brakes! is normal. Otherwise, you may • Have the battery recharged before have a problem with the ABS. driving the vehicle. Contact an authorized Kia dealer as soon as possible. OTF054018 The Electronic Stability control WARNING...
  • Page 305 Driving your vehicle Only a safe and attentive driver can ESC operation WARNING prevent accidents avoiding ESC ON condition maneuvers that cause the vehicle to maximum protection, • When the ignition is turned lose traction. Even with always wear your seat belt. No ON, ESC and ESC OFF installed, always follow all the normal system,...

  • Page 306: Esc Off Button

    Driving your vehicle When operating ESC operation off When the ESC is in opera- ESC OFF state tion, ESC indicator light This car has 2 kinds of ESC blinks. off states. • When Electronic If the engine stops when Stability Control is operat- ESC is off, ESC remains off.
  • Page 307 Driving your vehicle Indicator light Driving with varying tire or wheel sizes may cause the ESC system to ■ ESC indicator light malfunction. When replacing tires, make sure they are the same size as your original tires. WARNING - Electronic ■...

  • Page 308: Hill-Start Assist Control (Hac)

    Driving your vehicle ESC OFF usage Hill-start assist control (HAC) WARNING When driving Hill start Assist Control is a comfort maximum protection, function. The main intent is to pre- • It’s a good idea to keep the ESC always wear your seat belt. No vent the vehicle from rolling back- turned on for daily driving whenev- system,...

  • Page 309: Vehicle Stability Management (Vsm)

    ( ) or EPS warning light and left wheels when braking. instrument cluster remains on, take your vehicle to an authorized Kia dealer and have the VSM operation system checked. VSM operation off • The VSM is designed to function...

  • Page 310: Good Braking Practices

    VSM sys- as it is safe to do so and call an tem. authorized Kia dealer for assis- tance. • Don't coast down hills with the vehicle out of gear. This is extreme- ly hazardous.

  • Page 311: Brake Pedal

    Driving your vehicle • Don't "ride" the brake pedal. If your vehicle is facing uphill, turn Resting your foot on the brake the front wheels away from the pedal while driving can be danger- curb to help keep the vehicle from ous because the brakes might rolling.

  • Page 312: Cruise Control System

    Driving your vehicle CRUISE CONTROL SYSTEM (IF EQUIPPED) ✽ ✽ NOTICE The cruise control system allows you To set cruise control speed: to program the vehicle to maintain a • During normal cruise control constant speed without depressing operation, when the SET switch is the accelerator pedal.

  • Page 313: To Increase Cruise Control Set Speed

    Driving your vehicle To increase cruise control set To decrease the cruising speed: speed: OTFH054021 3.Move the lever (1) down (to SET-), and release it at the desired speed. OTFH054022 OTFH054021 The SET indicator light in the Follow either of these procedures: Follow either of these procedures: instrument cluster will illuminate.

  • Page 314: To Temporarily Accelerate With The Cruise Control On

    Driving your vehicle To temporarily accelerate with To cancel cruise control, do Each of these actions will cancel cruise control operation (the SET the cruise control on: one of the following: indicator light in the instrument clus- If you want to speed up temporarily ter will go off), but it will not turn the when the cruise control is on, system off.

  • Page 315: To Resume Cruising Speed At More Than

    Driving your vehicle To resume cruising speed at To turn cruise control off, do more than approximately 40 one of the following: km/h (25 mph): • Press the CRUISE button (the CRUISE indicator light in the instrument cluster will go off). •...

  • Page 316: Active Eco System

    Driving your vehicle ACTIVE ECO SYSTEM (IF EQUIPPED) Active ECO operation • If Active ECO is turned off, it will Limitation of Active ECO oper- return to the normal mode. ation: If the following conditions occur while When Active ECO is activated: Active ECO is operating, the system operation is limited even though •...

  • Page 317: Drive Mode Integrated Control System

    Driving your vehicle DRIVE MODE INTEGRATED CONTROL SYSTEM (IF EQUIPPED) DRIVE mode ECO mode (Active ECO) When Active ECO is activated: Active ECO helps improve • The acceleration may slightly be fuel efficiency by control- reduced eventhough you depress ling certain engine and the accelerator fully.
  • Page 318 Driving your vehicle Limitation of Active ECO opera- SPORT mode • If the system is activat- tion: SPORT mode focuses on SPORT If the following conditions occur while dynamic driving by auto- - While holding vehicle Active ECO is operating, the system matically controlling the speed, it maintains the operation is limited even though...
  • Page 319 Driving your vehicle BLIND SPOT DETECTION SYSTEM (BSD) (IF EQUIPPED) (1) BSD (Blind Spot Detection) WARNING - BSD The warning range depends on Limitations your vehicle speed. However, if your vehicle is about 6 mph (10 • The Blind Spot Detection km/h) faster than the other vehi- System (BSD) is a supplemen- cle, the system will not warn you.

  • Page 320: Bsd (Blind Spot Detection) / Lca (Lane Change Assist)

    Driving your vehicle BSD (Blind Spot Detection) / When the system is not used turn the Warning type system off by turning off the switch. LCA (Lane Change Assist) The system will activate when: When the system is turned on the 1.The system is on Operating conditions warning light will illuminate for 3 sec-...
  • Page 321 Driving your vehicle Detecting sensor 1st stage 2nd stage OTF054107 OTF054108 If a vehicle is detected within the The second stage alarm will activate OTF054109 boundary of the system, a warning when: The sensors are located inside of the light will illuminate on the outside 1.The first stage alert is on rear bumper.
  • Page 322 Remove the foreign matter on the rear bumper. If the system does not work normally even though the foreign matter is removed, take your vehicle to an authorized Kia dealer and have the system checked. OTF054132N OTF054131 OTF054103L If the system does not work properly,...

  • Page 323: Rcta (Rear Cross Traffic Alert)

    Driving your vehicle RCTA (Rear Cross Traffic Alert) Operating conditions • The system operates when the vehicle speed is below 10 km/h (6.2 mph) with the shift lever in R (Reverse). • The RCTA (Rear Cross Traffic Alert) detecting range is 0.5m ~ 20m based on the side direction.
  • Page 324 Driving your vehicle ❈ If your vehicle's left or right side Warning type CAUTION bumper is blinded by barrier or vehicles, the system sensing abili- • The system may not work ty may be deteriorated. properly if the bumper has been replaced or if a repair work has been done near the WARNING...

  • Page 325: Non-Operating Condition

    Driving your vehicle Non-operating condition - A fixed object is near such as a - When a trailer or carrier is installed. guardrail, etc. - When the temperature of rear Driver's Attention - A lot of amount of metal sub- bumper is high.
  • Page 326 Driving your vehicle Outside rearview mirror may not This device complies with alert the driver when: Industry Canada Standard RSS-210. - The outside rearview mirror hous- ing is severely polluted Operation is subject to the following - The window is severely polluted two conditions: - The windows are severely tinted.

  • Page 327: Economical Operation

    Driving your vehicle ECONOMICAL OPERATION Your vehicle's fuel economy depends • Don't "ride" the brake pedal. This • Keep your vehicle in good condi- mainly on your style of driving, where can increase fuel consumption and tion. For better fuel economy and you drive and when you drive.
  • Page 328 Driving your vehicle • Remember, your vehicle does not • Use your air conditioning sparingly. WARNING - Engine off require extended warm-up. After The air conditioning system is the engine has started, allow the operated by engine power so your during engine to run for 10 to 20 seconds fuel economy is reduced when you...

  • Page 329: Special Driving Conditions

    Driving your vehicle SPECIAL DRIVING CONDITIONS Hazardous driving conditions Do not pump the brake pedal on a Rocking the vehicle vehicle equipped with ABS. When hazardous driving conditions If it is necessary to rock the vehicle • If stalled in snow, mud, or sand, are encountered such as water, to free it from snow, sand, or mud, use second gear.

  • Page 330: Smooth Cornering

    Driving your vehicle Smooth cornering Driving at night CAUTION - Spinning tires Do not spin the wheels, espe- cially at speeds more than 56 km/h (35 mph). Spinning the wheels at high speeds when the vehicle is stationary could cause a tire to overheat which could result in tire damage.

  • Page 331: Driving In The Rain

    Driving your vehicle • Adjust your mirrors to reduce the Driving in the rain • If your tires are not in good condi- glare from other driver's head- tion, making a quick stop on wet lights. pavement can cause a skid and possibly lead to an accident.

  • Page 332: Driving Off-Road

    Driving your vehicle Driving off-road Fuel, engine coolant and engine WARNING - Tire tread Drive carefully off-road because your Always check the tire tread High speed travel consumes more vehicle may be damaged by rocks or before driving your vehicle. fuel than urban motoring.

  • Page 333: Winter Driving

    Driving your vehicle WINTER DRIVING Snowy or Icy conditions Snow tires If you mount snow tires on your vehi- To drive your vehicle in deep snow, it cle, make sure they are radial tires of may be necessary to use snow tires the same size and load range as the on your tires.

  • Page 334: Use High Quality Ethylene Glycol Coolant

    Winter puts additional burdens on er anti-freeze is available from an the battery system. Visually inspect authorized Kia dealer and most auto the battery and cables as described parts outlets. Do not use engine in chapter 7. The level of charge in...

  • Page 335: Don't Let Your Parking Brake Freeze

    Driving your vehicle Don't let your parking brake Carry emergency equipment freeze Depending on the severity of the weather you should carry appropri- Under some conditions your parking ate emergency equipment. Some of brake can freeze in the engaged the items you may want to carry position.

  • Page 336: Vehicle Load Limit

    Driving your vehicle VEHICLE LOAD LIMIT Tire and loading information label The label located on the driver's door sill gives the original tire size, cold tire pressures recommended for your vehicle, the number of people that can be in your vehicle and vehicle capacity weight.
  • Page 337 Driving your vehicle Seating capacity: Steps For Determining Correct 5.Determine the combined weight of Load Limit - luggage and cargo being loaded Total : 5 persons on the vehicle. That weight may not (Front seat : 2 persons, 1.Locate the statement "The com- safely exceed the available cargo Rear seat : 3 persons) bined weight of occupants and...
  • Page 338 Driving your vehicle Example 1 Example 2 Example 3 C190F01JM C190F02JM C190F03JM Item Description Total Item Description Total Item Description Total Vehicle Capacity 385 kg Vehicle Capacity 385 kg Vehicle Capacity 385 kg Weight (849 lbs) Weight (849 lbs) Weight (849 lbs) Subtract Occupant Subtract Occupant...

  • Page 339: Certification Label

    Driving your vehicle Certification label The label will help you decide how WARNING - Over loading much cargo and installed equipment The certification label is located on your vehicle can carry. Never exceed the GVWR for the driver's door sill at the center pil- your vehicle, the GAWR for lar.
  • Page 340 Driving your vehicle WARNING WARNING - Over loading - Loose cargo Do not overload your vehicle. Do not travel with unsecured Overloading your vehicle can blunt objects in the passenger cause heat buildup in your vehi- compartment of your vehicle cle's tires and possible tire fail- (e.g.

  • Page 341: Vehicle Weight

    Driving your vehicle VEHICLE WEIGHT This chapter will guide you in the Cargo weight GVWR (Gross vehicle weight rating) proper loading of your vehicle and/or This figure includes all weight added This is the maximum allowable trailer, to keep your loaded vehicle to the Base Curb Weight, including weight of the fully loaded vehicle weight within its design rating capa-...

  • Page 342: What To Do In An Emergency

    What to do in an emergency Road warning ......6-2 • Producing the tire inflation pressure... . . 6-21 •...

  • Page 343: Road Warning

    What to do in an emergency ROAD WARNING Hazard warning flasher It should be used whenever emer- gency repairs are being made or when the vehicle is stopped near the edge of a roadway. Depress the flasher switch with the ignition switch in any position.

  • Page 344: In Case Of An Emergency While Driving

    Be sure they all get out on vehicle will not start, contact an the side of the vehicle that is away If you have a flat tire while authorized Kia dealer or seek other from traffic. qualified assistance. driving 4.When changing a flat tire, follow...

  • Page 345: If The Engine Will Not Start

    4.If the engine still does not start, call charged. an authorized Kia dealer or seek 4.Check the starter connections to other qualified assistance. be sure they are securely tight- ened.

  • Page 346: Emergency Starting

    What to do in an emergency EMERGENCY STARTING Jump starting Jumper Cables WARNING - Frozen Jump starting can be dangerous if batteries done incorrectly. Therefore, to avoid Do not attempt to jump start the harm to yourself or damage to your vehicle if the discharged battery vehicle or battery, follow these jump is frozen or if the electrolyte...
  • Page 347 AGM batteries. loads. When replacing the AGM battery, 4.Connect the jumper cables in the use only the Kia genuine battery for exact sequence shown in the illus- the ISG system. tration. First connect one end of a jumper cable to the positive termi- ✽...

  • Page 348: Push-Starting

    2,000 rpm, then start the engine of the vehicle with the discharged battery. If the cause of your battery discharg- ing is not apparent, you should have your vehicle checked by an author- ized Kia dealer.

  • Page 349: If The Engine Overheats

    If overheating happens again, stopped. If there is no visible loss 5.If the water pump drive belt is bro- call an authorized Kia dealer for of engine coolant and no steam, ken or engine coolant leaks, stop assistance.

  • Page 350: If You Have A Flat Tire

    What to do in an emergency IF YOU HAVE A FLAT TIRE Jack and tools Jacking instructions Always move the vehicle completely off the road and onto the shoulder The jack is provided for emergency before trying to change a tire. The tire changing only.

  • Page 351: Removing And Storing The Spare Tire

    What to do in an emergency Do not allow anyone to remain in the Removing and storing the Changing tires vehicle while it is on the jack. spare tire Make sure any children present are in a secure place away from the road and from the vehicle to be raised with the jack.
  • Page 352 What to do in an emergency OTF064020 1JBA6504 OTF064004 4.Remove the wheel lug nut wrench, 6.Loosen the wheel lug nuts counter- jack, jack handle, and spare tire clockwise one turn each, but do from the vehicle. not remove any nut until the tire has been raised off the ground.
  • Page 353 What to do in an emergency 9.Loosen the wheel nuts and remove WARNING - Installing a them with your fingers. Slide the wheel off the studs and lay it flat so wheel it cannot roll away. To put the Make sure the wheel makes wheel on the hub, pick up the good contact with the hub when spare tire, line up the holes with...
  • Page 354 If in doubt, consult an they are tight. Then double-check authorized Kia dealer. each nut for tightness. After changing the wheels, have an authorized Kia dealer tighten the wheel nuts to their proper torque as soon as possible. 6 13...
  • Page 355 What to do in an emergency Important - use of compact spare WARNING WARNING - Wheel studs tire (if equipped) Do not drive your vehicle with The compact spare tire is for Your vehicle is equipped with a com- damaged wheel studs. If the emergency use only.
  • Page 356 What to do in an emergency When using a compact spare tire, • Do not take this vehicle through an • The compact spare tire should not observe the following precautions: automatic car wash while the com- be used on any other wheels, nor pact spare tire is installed.
  • Page 357 What to do in an emergency Jack label 1. Model Name 2. Maximum allowable load ■ Example ■ Type A 3. When using the jack, set your parking brake. 4. When using the jack, stop the engine. 5. Do not get under a vehicle that is supported by a jack.

  • Page 358: Introduction

    The Tire Mobility Kit is a temporary fortably seals most punctures in a fix to the tire and the tire should be passenger car tire caused by nails inspected by an authorized Kia deal- or similar objects and reinflates the er as soon as possible. tire.

  • Page 359: Notes On The Safe Use Of The Tire Mobility Kit

    • Use of the Tire Mobility Kit may not be effective for tire damage larger than approximately 6 mm (0.24 in). Please contact the nearest Kia dealership if the tire cannot be made roadworthy with the Tire Mobility Kit.

  • Page 360: Components Of The Tiremobilitykit

    What to do in an emergency 9. Hose to connect compressor and Components of the TireMobilityKit sealant bottle or compressor and wheel Connectors, cable and connection hose are stored in the compressor housing. WARNING - Expired sealant Do not use the Tire sealant after the sealant has expired (i.e.

  • Page 361: Using The Tire Mobility Kit

    What to do in an emergency Using the Tire Mobility Kit WARNING - Tire pressure 1.Detach the speed restriction label Do not attempt to drive your (0) from the sealant bottle (1), and vehicle if the tire pressure is place it in a highly visible place below 200kPa (29 psi).

  • Page 362: Distributing The Sealant

    When you use the Tire Mobility Kit, - To increase the inflation pres- approved by Kia, the tire pres- the tire pressure sensor valve stem sure : Switch on the compressor, sure sensors may be damaged and wheel may be stained by position I.

  • Page 363: Technical Data

    What to do in an emergency Technical Data System voltage: DC 12 V Working voltage: DC 10 - 15 V Amperage rating: max. 15 A Suitable for use at temperatures: -30 ~ +70°C (-22 ~ +158°F) Max. working pressure: 6 bar (87 psi) Size Compressor: 168 x 150 x 68 mm (6.6 x 5.9 x 2.7 in.)

  • Page 364: Towing

    HXD02 OMC045012 If emergency towing is necessary, we recommend having it done by an authorized Kia dealer or a commer- cial tow-truck service. Proper lifting HXD03 and towing procedures are neces- sary to prevent damage to the vehi-...

  • Page 365: Removable Towing Hook (Front)

    • The drivers of both vehicles should If towing is necessary, have it communicate with each other fre- 4.Remove the towing hook and done by an authorized Kia dealer quently. install the cover after use. or a commercial tow truck service.
  • Page 366 • Before emergency towing, check easy visibility. Contact an authorized Kia that the hook is not broken or dam- dealer or a commercial tow aged. • Drive carefully so that the towing truck service for assistance.
  • Page 367 What to do in an emergency Emergency towing precautions When towing your vehicle in an CAUTION - Automatic emergency without wheel dollies : • Place the ignition switch in ACC so transaxle the steering wheel isn’t locked. 1.Set the ignition switch in the ACC •...

  • Page 368: Maintenance

    Maintenance Engine compartment ......7-3 • Filter replacement ......7-39 Wiper blades .
  • Page 369 • License plate light bulb replacement... . . 7-88 • High mounted stop light bulb replacement ..7-88 • Interior light bulb replacement ....7-91 Appearance care .

  • Page 370: Engine Compartment

    Maintenance ENGINE COMPARTMENT ■ ■ 2.4L Engine 1. Engine coolant reservoir 2. Engine oil filler cap 3. Brake fluid reservoir 4. Air cleaner 5. Fuse box ■ ■ 2.0L Engine 6. Positive battery terminal 7. Negative battery terminal 8. Windshield washer fluid reservoir 9.

  • Page 371: Maintenance Services

    Kia dealer perform this work. nical support from Kia in order to pro- dance with the scheduled mainte- vide you with a high level of service An authorized Kia dealer has factory- nance service charts shown on the satisfaction.

  • Page 372: Owner Maintenance Precautions

    As explained earlier in this section, become entangled in moving several procedures can be done only parts, if you must run the by an authorized Kia dealer with spe- engine while working under the cial tools. hood, make certain that you remove all jewelry (especially ✽...

  • Page 373: Owner Maintenance

    • Check the engine oil level. ized Kia dealer at the frequencies exhaust fumes in the vehicle. indicated to help ensure safe, • Check the coolant level in coolant •...
  • Page 374 Maintenance At least monthly: At least twice a year At least once a year : (i.e., every Spring and Fall) : • Check the coolant level in the • Clean the body and door drain engine coolant reservoir. holes. • Check the radiator, heater and air conditioning hoses for leaks or •...

  • Page 375: Scheduled Maintenance Service

    Maintenance SCHEDULED MAINTENANCE SERVICE Follow the Normal Maintenance If your vehicle is operated under the Schedule if the vehicle is usually above conditions, should operated where none of the following inspect, replace or refill more fre- conditions apply. If any of the following quently than the following Normal Maintenance Schedule.
  • Page 376 : If TOP TIER Detergent Gasoline is not available, one bottle of additive is recommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives. : Fuel filter & Fuel tank air filter are considered to be maintenance free but periodic inspection is recommended for this mainte- nance schedule depends on fuel quality.
  • Page 377 Maintenance NORMAL MAINTENANCE SCHEDULE 5,000 km (3,000 miles) or 6 months 24,000 km (15,000 miles) or 12 months ❑ Rotate tire ❑ Replace engine oil and filter (2.0 T-GDI) ❑ Inspect battery condition (At first, replace at 5,000 km (3,000 miles) or 6 months, ❑...
  • Page 378 Maintenance NORMAL MAINTENANCE SCHEDULE 36,000 km (22,500 miles) or 18 months 48,000 km (30,000 miles) or 24 months ❑ Rotate tire ❑ Rotate tire ❑ Inspect battery condition ❑ Inspect battery condition ❑ Inspect vacuum hose ❑ Inspect air cleaner filter ❑...
  • Page 379 Maintenance NORMAL MAINTENANCE SCHEDULE (Continued) 72,000 km (45,000 miles) or 36 months ❑ Add fuel additive * ❑ Rotate tire ❑ Inspect battery condition (12,000 km (7,500 miles) or 12 months) ❑ Inspect cooling system hoses and connections ❑ Inspect air cleaner filter ❑...
  • Page 380 Maintenance NORMAL MAINTENANCE SCHEDULE 84,000 km (52,500 miles) or 42 months 96,000 km (60,000 miles) or 48 months ❑ Rotate tire ❑ Rotate tire ❑ Inspect battery condition ❑ Inspect battery condition ❑ Inspect air cleaner filter ❑ Inspect vacuum hose ❑...
  • Page 381 Maintenance NORMAL MAINTENANCE SCHEDULE (Continued) 108,000 km (67,500 miles) or 54 months ❑ Replace climate control air filter ❑ Rotate tire ❑ Inspect battery condition (for evaporator and blower unit) ❑ Replace air cleaner filter ❑ Inspect air cleaner filter ❑...
  • Page 382 Maintenance NORMAL MAINTENANCE SCHEDULE 120,000 km (75,000 miles) or 60 months (Continued) ❑ Rotate tire ❑ Add fuel additive * ❑ Inspect battery condition (12,000 km (7,500 miles) or 12 months) ❑ Inspect air cleaner filter ❑ Inspect cooling system hoses and connections ❑...
  • Page 383 Maintenance NORMAL MAINTENANCE SCHEDULE 132,000 km (82,500 miles) or 66 months 144,000 km (90,000 miles) or 72 months ❑ Rotate tire ❑ Rotate tire ❑ Inspect battery condition ❑ Inspect battery condition ❑ Inspect air cleaner filter ❑ Inspect vacuum hose ❑...
  • Page 384 Maintenance NORMAL MAINTENANCE SCHEDULE (Continued) 156,000 km (97,500 miles) or 78 months ❑ Replace air cleaner filter ❑ Rotate tire ❑ Replace engine oil and filter (2.4 GDI) ❑ Inspect battery condition ❑ Inspect air cleaner filter (144,000 km (90,000 miles) or 144 months) ❑...
  • Page 385 Maintenance NORMAL MAINTENANCE SCHEDULE 168,000 km (105,000 miles) or 84 months (Continued) ❑ Add fuel additive * ❑ Rotate tire ❑ Inspect battery condition (12,000 km (7,5000 miles) or 12 months) ❑ Inspect air cleaner filter ❑ Inspect cooling system hoses and connections ❑...
  • Page 386 Maintenance NORMAL MAINTENANCE SCHEDULE 192,000 km (120,000 miles) or 96 months 180,000 km (112,500 miles) or 90 months ❑ Rotate tire ❑ Rotate tire ❑ Inspect battery condition ❑ Inspect battery condition ❑ Inspect vacuum hose ❑ Inspect air cleaner filter ❑...
  • Page 387 Maintenance NORMAL MAINTENANCE SCHEDULE (Continued) 204,000 km (127,500 miles) or 102 months ❑ Replace climate control air filter ❑ Rotate tire (for evaporator and blower unit) ❑ Inspect battery condition ❑ Replace air cleaner filter ❑ Inspect air cleaner filter ❑...
  • Page 388 Maintenance NORMAL MAINTENANCE SCHEDULE (Continued) 216,000 km (135,000 miles) or 108 months ❑ Replace spark plugs (iridium coated, 2.0 T-GDI) ❑ Rotate tire ❑ Inspect cooling system hoses and connections ❑ Inspect battery condition ❑ Inspect brake pedal free play ❑...
  • Page 389 Maintenance NORMAL MAINTENANCE SCHEDULE (Continued) 240,000 km (150,000 miles) or 120 months ❑ Replace climate control air filter ❑ Rotate tire ❑ Inspect battery condition (for evaporator and blower unit) ❑ Replace air cleaner filter ❑ Inspect vacuum hose ❑ Replace engine oil and filter (2.4 GDI) ❑...
  • Page 390 Maintenance MAINTENANCE UNDER SEVERE USAGE CONDITIONS The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE DRIVING MAINTENANCE ITEM...
  • Page 391 Maintenance MAINTENANCE DRIVING MAINTENANCE ITEM MAINTENANCE INTERVALS OPERATION CONDITION Steering gear box, linkage & boots/lower More frequently C, D, E, F, G, H, I arm ball joint, upper arm ball joint Every 120,000 km (75,000 miles) or 6 Drive shafts and boots C, D, E, F, G, H, I, J months Climate control air filter...

  • Page 392: Explanation Of Scheduled Maintenance Items

    Have an authorized Kia dealer more frequent oil and filter changes starting. If an excessive amount of replace any damaged or leaking are required.
  • Page 393 Maintenance Vacuum crankcase ventilation Air cleaner filter Cooling system hoses A Genuine Kia air cleaner filter is Check cooling system components, recommended when the filter is such as radiator, coolant reservoir, Inspect the surface of hoses for evi- replaced. hoses and connections for leakage dence of heat and/or mechanical and damage.
  • Page 394 But in severe conditions, the fluid should be changed at an authorized Kia dealer in accordance to the Brake fluid Exhaust pipe and muffler scheduled maintenance at the begin- Check brake fluid level in the brake Visually inspect the exhaust pipes, ning of this chapter.
  • Page 395 Maintenance Steering gear box, linkage & Drive shafts and boots boots/lower arm ball joint Check the drive shafts, boots and clamps for cracks, deterioration, or With the vehicle stopped and engine damage. Replace any damaged off, check for excessive free-play in parts and, if necessary, repack the the steering wheel.

  • Page 396: Engine Oil

    Maintenance ENGINE OIL ■ ■ 2.4 engine Checking the engine oil level 3. Turn the engine off and wait for a few minutes (about 5 minutes) for ■ ■ 2.4 engine the oil to return to the oil pan. 4. Pull the dipstick out, wipe it clean, and reinsert it fully.

  • Page 397: Changing The Engine Oil And Filter

    Changing the engine oil and (Refer to “Recommended lubricants filter and capacities” in chapter 8.) Have engine oil and filter changed by an authorized Kia dealer according to the Maintenance Schedule at the beginning of this chapter. WARNING Used engine oil may cause irri-...

  • Page 398: Engine Coolant

    Bring the level to F (MAX), but do not overfill. If frequent coolant addition is Check the antifreeze protection and required, see an authorized Kia deal- coolant level at least once a year, at er for a cooling system inspection.
  • Page 399 Maintenance Recommended engine coolant For mixture percentage, refer to the following table. • When adding coolant, use only deionized water or soft water for your vehicle and never mix hard Mixture Percentage (volume) water in the coolant filled at the fac- Ambient tory.

  • Page 400: Changing The Coolant

    Use care when remov- Have the coolant changed by an radiator cap ing the radiator cap. Wrap a thick authorized Kia dealer according to towel around it, and turn it counter- Never attempt the Maintenance Schedule at the clockwise slowly to the first stop.

  • Page 401: Checking The Brake Fluid Level

    The fluid level should be tact the vehicle's body paint, as checked by an authorized Kia dealer. between MAX and MIN marks on the paint damage will result. side of the reservoir. Before removing the reservoir cap Use only the specified brake fluid.

  • Page 402: Washer Fluid

    Maintenance WASHER FLUID Checking the washer fluid WARNING - Windshield level fluid Do not drink the windshield washer fluid. The windshield washer fluid is poisonous to humans and animals. WARNING - Flammable fluid Do not allow the washer fluid to come in contact with open OTF074010 flames or sparks.

  • Page 403: Parking Brake

    If the stroke is more or less vehicle on a fairly steep grade. than specified, have the parking brake adjusted by an authorized Kia dealer. Stroke : 6~8 “clicks’’ at a force of 20kg (44 lbs, 196 N).

  • Page 404: Air Cleaner

    Maintenance AIR CLEANER Filter replacement OTF070012 OYF079013 1. Loosen the air cleaner cover 2. Wipe the inside of the air cleaner. OTF070011 attaching clips and open the cover. 3. Replace the air cleaner filter. It must be replaced when necessary, 4.
  • Page 405 • When removing the air cleaner conditions” in this chapter.) filter, be careful that dust or dirt does not enter the air intake, or damage may result. • Use a Kia genuine part. Use of nongenuine part could dam- age the air flow sensor.

  • Page 406: Climate Control Air Filter

    Maintenance CLIMATE CONTROL AIR FILTER (IF EQUIPPED) Filter inspection Filter replacement The climate control air filter should replaced according Maintenance Schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier.
  • Page 407 Maintenance OMG079027 4. Replace the climate control air fil- ter. 5. Reassemble in the reverse order of disassembly. When replacing the climate control air filter install it properly. Otherwise, the system may produce noise and the effectiveness of the filter may be reduced.

  • Page 408: Wiper Blades

    Maintenance WIPER BLADES Blade inspection Contamination of either the wind- Blade replacement shield or the wiper blades with for- When the wipers no longer clean eign matter can reduce the effective- adequately, the blades may be worn ness of the windshield wipers. or cracked, and require replacement.
  • Page 409 Maintenance Front windshield wiper blade OED070113 OED070114 2. Open the cover of the blade. 4. Install the blade assembly until it OED070112 clicks into place 3. Compress the clip behind the Type A wiper arm and lift it off the arm. 5.
  • Page 410 Maintenance OSBL071001 OHM078059 OSBL071002 Type B 4. Push down the wiper arm (3) and install the new blade assembly in 1. Raise the wiper arm. the reverse order of removal. 5. Return the wiper arm on the wind- CAUTION shield. Do not allow the wiper arm to fall against the windshield, since it may chip or crack the...

  • Page 411: Battery

    Maintenance BATTERY For best battery service WARNING WARNING - Risk of - Sulfuric acid explosion in batteries Keep lit cigarettes and Keep batteries out of the other flames reach children sparks away from the because batteries con- battery. tain highly corrosive SULFURIC ACID...
  • Page 412 Dispose the battery according to your local law(s) or regulation. The battery contains lead. Do not dispose of it after use. Please return the battery to an authorized Kia dealer to be recycled. 7 45...

  • Page 413: Battery Recharging

    Maintenance Battery recharging When recharging battery, Reset items observe the following precautions: Your vehicle has a maintenance-free, Items should be reset after the bat- • The battery must be removed from calcium-based battery. tery has been discharged or the bat- the vehicle and placed in an area tery has been disconnected.

  • Page 414: Tires And Wheels

    Maintenance TIRES AND WHEELS Tire care WARNING - Tire underin- For proper maintenance, safety, and flation maximum fuel economy, you must Inflate your tires consistent with always maintain recommended tire the instructions provided in this inflation pressures and stay within manual.

  • Page 415: Checking Tire Inflation Pressure

    (one mile) since startup.) spare tire. refilling, have it checked by an • Check the pressure of your spare authorized Kia dealer. tire each time you check the pres- • Overinflation produces a harsh How to check sure of other tires.

  • Page 416: Tire Rotation

    • Remember to check the pressure Replace the tire if you find either of the valve stems. They help prevent of your spare tire. Kia recommends these conditions. Replace the tire if leaks by keeping out dirt and mois- that you check the spare every fabric or cord is visible.

  • Page 417: Wheel Alignment And Tire Balance

    Maintenance Rotate radial tires that have an Wheel alignment and tire bal- Without a spare tire asymmetric tread pattern only from ance front to rear and not from right to left. The wheels on your vehicle were Do not use the compact spare tire for aligned and balanced carefully at the tire rotation.

  • Page 418: Tire Replacement

    Maintenance Tire replacement The ABS works by comparing the Compact spare tire replacement speed of the wheels. Tire size can A compact spare tire has a shorter affect wheel speed. When replacing tread life than a regular size tire. Tread wear indicator tires, all 4 tires must use the same Replace it when you can see the size originally supplied with the vehi-...

  • Page 419: Wheel Replacement

    - Wheel the tire identification number (TIN) wheel alignment. for safety standard certification. The Wheels that do not meet Kia's When you have new tires installed, TIN can be used to identify the tire in specifications may fit poorly make sure they are balanced. This case of a recall.
  • Page 420 Maintenance 2. Tire size designation 89 - Load Index, a numerical code Tire speed ratings associated with the maximum A tire’s sidewall is marked with a tire The chart below lists many of the dif- load the tire can carry. size designation.
  • Page 421 Maintenance 3. Checking tire life (TIN : Tire 5. Maximum permissible inflation WARNING - Tire age Identification Number) pressure Replace tires within the recom- Any tires that are over 6 years old, This number is the greatest amount mended time frame. Failure to based on the manufacturing date, of air pressure that should be put in replace tires as recommended...
  • Page 422 Maintenance 7. Uniform tire quality grading Tires degrade over time, even when Traction - AA, A, B & C they are not being used. Regardless Quality grades can be found where The traction grades, from highest to of the remaining tread, we recom- applicable on the tire sidewall lowest, are AA, A, B and C.
  • Page 423 Maintenance Temperature -A, B & C Tire terminology and definitions Cold Tire Pressure: The amount of air pressure in a tire, measured in Air Pressure: The amount of air The temperature grades are A (the pounds per square inch (psi) or kilo- inside the tire pressing outward on highest), B and C representing the pascals (kPa) before a tire has built...
  • Page 424 Maintenance Intended Outboard Sidewall: The Occupant Distribution: Designated Speed Rating: An alphanumeric side of an asymmetrical tire, that seating positions. code assigned to a tire indicating the must always face outward when maximum speed at which a tire can Outward Facing Sidewall: The side mounted on a vehicle.
  • Page 425 Vehicle Maximum Load on the All season tires Snow tires Tire: Load on an individual tire due to Kia specifies all season tires on If you equip your car with snow tires, curb and accessory weight plus some models to provide good per-...
  • Page 426 Maintenance Radial-ply tires Longer wearing tires can be more Low aspect ratio tire susceptible to irregular tread wear. It (if equipped) Radial-ply tires provide improved is very important to follow the tire tread life, road hazard resistance and Low aspect ratio tires, whose aspect rotation interval shown in this section smoother high speed ride.

  • Page 427: Wheel And Tire

    - If the tire is impacted, we rec- ommend that you inspect the tire condition or contact an authorized Kia dealer. - To prevent damage to the tire, inspect the tire condition and pressure every 3,000 (1,900 miles).

  • Page 428: Fuses

    Avoid other metal object to remove using the system involved and imme- fuses because it may cause a diately consult an authorized Kia short circuit and damage the dealer. system. Three kinds of fuses are used: blade...
  • Page 429 2. Open the fuse panel cover. fastened incompletely, and it may cause a possible fire. If fuses, relays and terminals fastened with bolts or nuts are blown, we recommend that you consult with an author- ized Kia dealer.
  • Page 430 If it fits loosely, consult an authorized Kia dealer. If you do not have a spare, use a fuse of the same rating from a circuit you may not need for operating the vehi- cle, such as the cigar lighter fuse.
  • Page 431 4. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, consult an authorized Kia dealer.
  • Page 432 Maintenance Main fuse Multi fuse OTF070021 OVG079022 If the main fuse is blown, it must be If the multi fuse is blown, it must be removed as follows: removed as follows: 1. Turn off the engine. 1. Remove the fuse panel in the 2.

  • Page 433: Fuse/Relay Panel Description

    Maintenance Fuse/relay panel description Inside the fuse/relay panel covers, you can find the fuse/relay label describing fuse/relay name and capacity. Instrument fuse panel OTF070023 ✽ ✽ NOTICE Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing.
  • Page 434 Maintenance Inner Fuse panel Description Fuse Rating Protected Component MULTIMEDIA ISG LDC AUDIO,AUDIO_UVO, AUDIO(PA30A,B), NAVI1.5, NAVI_3.0, NAVI_4.0, TMU PDM 1 Smart Key Control Module (With Smart Key) SPARE PDM2 SMK UNIT, BUTTON START SW P/SEAT(PASS) Passenger Seat Manual Switch P/SEAT(DRV) Driver IMS Module, Driver Seat Manual Switch, Driver Lumbar Support Switch (2WAY) MEMORY 2 7.5A...
  • Page 435 Maintenance Description Fuse Rating Protected Component BRAKE SWITCH Smart Key Control Module, Start Stop Button Switch, FOB Holder, Stop Lamp Switch SEAT EXTN (IMS), DR_TRIM_EXTN (FOLD’G), CLUSTER, A/CON, ECM, AUTO FOLDING RLY, MEMORY 1 TPMS, POWER OUTLET, A_L_PHOTO_SNSR, MUT SUNROOF Panorama Sunroof S/HEATER(FRT) SEAT_EXTN (HEAT/VENT)
  • Page 436 Maintenance Description Fuse Rating Protected Component SPARE IG 1 E/R BOX IG1 SPARE POWER OUTLET Front Power Outlet Auto Head Lamp Leveling Device Module (Auto HLLD), Head Lamp Leveling Device Switch (Manual HLLD), Head Lamp Leveling Device Actuator LH/RH, BCM, Front Smart Parking Assist Sensor Module, MODULE 1 Instrument Cluster, Electro Chromic Mirror, A/C Control Module, Driver IMS Module, Rear Parking Assist Buzzer, Lane Keeping Assist Module...
  • Page 437 Maintenance Engine compartment fuse panel (for Theta 2.4 GDI) OVG079025L ✽ ✽ NOTICE Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label.
  • Page 438 Maintenance Engine Compartment fuse panel (for theta 2.4 GDI) Description Fuse Rating Protected Component RR HTD E/R BOX RR HTD RLY COIL HORN HORN (LH, RH) F/PUMP FUEL PUMP MTR ECU 3 PCU (GDI) BATT. DIRECT SENSOR 1 DN O2 SENSOR (GDI), UP O2 SENSOR (GDI) INJECTOR E/R BOX F/PUMP RLY COIL SENSOR 3...
  • Page 439 Maintenance Description Fuse Rating Protected Component TCU 1 STOP LAMP RLY.10 (HAC Relay), STOP LAMP RELAY DEICER RLY.7 (Deicer Relay) IGN SW B+ 1 B+ 2 BLOWER RLY.14 (Blower Relay) IG 2 IGN SW, IG2 RLY ESC 1 ESC UNIT MOTOR B+, DIAGNOSIS ABS A/B VALVE B+ ESC 2 ESC UNIT SOLENOID B+ RR HTD...

  • Page 440: Rear Combination Lamp

    Maintenance Description Fuse Rating Protected Component EPB 1 EPB UNIT BATT1 ECU 2 EMS BOX (B+) ECU 4 ENGINE ECU TCU 2 SPEED SNSR, POSITION SW, O_P_INVERTER ESC 3 ESC UNIT IGN1 B/UP LAMP ELECTRO CHROMIC MIRROR, BCM, REAR COMBINATION LAMP (IN) LH/RH A/CON A/C CONTROL MODULE (Auto A/C) 7 73...
  • Page 441 Maintenance Engine compartment fuse panel (for Theta 2.0 T-GDI) OVG079025L ✽ ✽ NOTICE Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label.
  • Page 442 Maintenance Engine Compartment fuse panel (for theta 2.0 T- GDI) Description Fuse Rating Protected Component RR HTD E/R BOX RR HTD RLY COIL HORN HORN (LH, RH) F/PUMP FUEL PUMP MTR ECU 3 PCU (TGDI) BATT. DIRECT SENSOR 1 DN O2 SENSOR (TGDI), UP O2 SENSOR (TGDI), COOLING FAN RLY COIL (TGDI) INJECTOR E/R BOX F/PUMP RLY COIL SENSOR 3...
  • Page 443 Maintenance Description Fuse Rating Protected Component TCU 1 STOP LAMP RLY.10 (HAC Relay), STOP LAMP RELAY DEICER RLY.7 (Deicer Relay) IGN SW B+ 1 B+ 2 C/ FAN 2 C/FAN RLY IG 2 IGN SW, IG2 RLY ESC 1 ESC UNIT MOTOR B+ , DIAGNOSIS ABS A/B VALVE B+ ESC 2 ESC UNIT SOLENOID B+ RR HTD...
  • Page 444 Maintenance Description Fuse Rating Protected Component EPB 2 EPB UNIT BATT2 EPB 1 EPB UNIT BATT1 ECU 2 EMS BOX (B+) ECU 4 ENGINE ECU TCU 2 SPEED SNSR, POSITION SW, O_P_INVERTER ESC 3 ESC UNIT IGN1 B/UP LAMP ELECTRO CHROMIC MIRROR, BCM, REAR COMBINATION LAMP (IN) LH/RH A/CON A/C CONTROL MODULE (Auto A/C) 7 77...
  • Page 445 Maintenance Engine room (Battery terminal cover) OVG079026 ✽ ✽ NOTICE Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label OTF074089N...

  • Page 446: Light Bulbs

    Headlight, position light, turn WARNING - Lights correct bulbs and the expertise, con- signal light, side marker light, sult an authorized Kia dealer. In and front fog light bulb Prior to working on the light, many cases, it is difficult to replace replacement...
  • Page 447 Maintenance (1) Headlight (High) Headlight bulb Always handle them carefully, and avoid scratches and abrasions. If the (2) Headlight (Low) bulbs are lit, avoid contact with liq- (3) Side marker uids. Never touch the glass with bare (4) Front turn signal light hands.
  • Page 448 Headlight (bulb type) If the headlight aiming adjustment is necessary after headlight assembly is reinstalled, consult an authorized Kia dealer. OEN076051 1. Turn off the engine. 2. Open the hood. 3. Remove the headlight bulb cover by turning it counterclockwise.
  • Page 449 Maintenance Front side marker/Front turn sig- nal light Front side marker 1.Turn off the engine. 2.Open the hood 3.Remove the intake folder and screws. 4.Remove the bumper cover and under pad by rotating the screw. Front side marker 5.Remove the nuts of headlamp assembly.

  • Page 450: Side Repeater Light Bulb Replacement

    If the light bulb does not operate, locks into place. have the vehicle checked by an 6.Install the socket in the assembly authorized Kia dealer. by aligning the tabs on the socket with the slots in the assembly. Push the socket into assembly and turn the socket clockwise.
  • Page 451 If the light bulb does not operate, 1.Turn off the engine. have the vehicle checked by an 2.Remove the under cover by rotat- authorized Kia dealer. ing the screws. 3.Reach your hand into the back of the front bumper. 4.Disconnect the power connector.

  • Page 452: Rear Combination Light Bulb Replacement

    Maintenance 6.Install the new bulb-socket into the Rear combination light bulb (1) Stop and tail light housing by aligning the tabs on the replacement (2) Tail light socket with the slots in the hous- (3) Rear turn signal light ing. (4) Back-up light Push the socket into the housing (5) Rear side marker...
  • Page 453 If the light (LED) does not operate, counterclockwise until the tabs on have the vehicle checked by an the socket align with the slots on authorized Kia dealer. the assembly. 5.Remove the bulb from the socket by pressing it in and rotating it...
  • Page 454 Maintenance Backup light/Tail light 4.Disconnect the cable and then Backup light-1 (if equipped) remove the nuts by turning the nuts counter clockwise. OTF074054 Backup light-2 OTF070033 Backup light OTF074055 5.Take the light assembly out. 6.Insert a new bulb by inserting it into OTF074052 the socket.

  • Page 455: License Plate Light Bulb Replacement

    Maintenance License plate light bulb 3.Loosen the retaining screw of the High mounted stop light trunk lid cover and then remove the replacement replacement (if equipped) cover. 4.Take out the light. 5.Insert a new bulb by inserting it into the socket. 6.Reinstall the trunk lid cover by pushing in the screw.
  • Page 456 Maintenance High mounted bulb ■ 4.Type A Type A Fold the seat back by pulling out the lock release knob (1). Fold the seatback forward and down firmly. (if equipped) Type B Push the seat back up. The seat OTF030020 back is connected to the hook ■...
  • Page 457 Maintenance 11. Reinstall the seat by pushing it down firmly. OTF070059N OTF070061N OTF070060N OTF070062N 5. Take the C-pillar out carefully. If 7. Remove the screws and package you pull the C-pillar strongly, it tray. will be broken. 8. Remove the fabric and nuts. 6.

  • Page 458: Interior Light Bulb Replacement

    Maintenance Interior light bulb replacement Front map lamp Vanity mirror lamp 1. Using a flat-blade screwdriver, gently pry the lens from the interi- or light housing. 2. Remove the bulb by pulling it straight out. WARNING Prior to working on the Interior Room lamp Luggage room lamp Lights, ensure that the “OFF”...

  • Page 459: Appearance Care

    Maintenance APPEARANCE CARE Exterior care Finish maintenance After washing the vehicle, test the brakes while driving slowly to see if Washing Exterior general caution they have been affected by water. If To help protect your vehicle’s finish It is very important to follow the label braking performance is impaired, dry from rust and deterioration, wash it directions when using any chemical...
  • Page 460 Maintenance Waxing CAUTION - Drying vehicle Wax the vehicle when water will no • Wiping dust or dirt off the longer bead on the paint. body with a dry cloth will Always wash and dry the vehicle scratch the finish. before waxing.
  • Page 461 Maintenance Finish damage repair Bright-metal maintenance Underbody maintenance Deep scratches or stone chips in the • To remove road tar and insects, Corrosive materials used for ice and painted surface must be repaired use a tar remover, not a scraper or snow removal and dust control may promptly.
  • Page 462 Maintenance Aluminum or chrome wheel main- Corrosion protection High-corrosion areas tenance If you live in an area where your vehi- Protecting your vehicle from corro- cle is regularly exposed to corrosive The aluminum or chrome wheels are sion materials, corrosion protection is coated with a clear protective finish.
  • Page 463 Maintenance High temperatures can also acceler- Keep your vehicle clean • When cleaning lower door panels, ate corrosion of parts that are not rocker panels and frame mem- The best way to prevent corrosion is properly ventilated so the moisture bers, be sure that drain holes are to keep your vehicle clean and free can be dispersed.

  • Page 464: Interior Care

    Maintenance Keep paint and trim in good con- Interior care CAUTION - Leather dition Interior general precautions When cleaning leather products Scratches or chips in the finish Prevent chemicals such as perfume, (steering wheel, seats etc.), use should be covered with "touch-up" cosmetic oil, sun cream, hand clean- neutral detergents or low alco- paint as soon as possible to reduce...
  • Page 465 Maintenance Cleaning the upholstery and inte- Cleaning the lap/shoulder belt rior trim webbing Clean the belt webbing with any mild Vinyl soap solution recommended for Remove dust and loose dirt from cleaning upholstery or carpet. Follow vinyl with a whisk broom or vacuum the instructions provided with the cleaner.

  • Page 466: Emission Control System

    (The ORVR system is designed to an authorized Kia dealer in accor- allow the vapors from the fuel tank to dance with the maintenance sched- be loaded into a canister while refu- ule in this manual.
  • Page 467 Maintenance Canister 3. Exhaust emission control Engine exhaust gas precautions (carbon monoxide) system Fuel vapors generated inside the fuel tank are absorbed and stored in the • Carbon monoxide can be present Exhaust Emission Control onboard canister. When the engine is with other exhaust...
  • Page 468 All inspections and It may present a fire risk under the emission control system. adjustments must be made by an certain conditions. authorized Kia dealer. WARNING - Catalytic Your vehicle is equipped with a cat- • Avoid driving with a extremely low alytic converter emission control fuel level.

  • Page 469: Specifications & Consumer Information

    Specifications & Consumer information Dimensions ....... . 8-2 Engine ........8-2 Gross vehicle weight.

  • Page 470: Dimensions

    Specifications & Consumer information DIMENSIONS Item mm (in.) Overall length 4,845 (190.7) Overall width 1,830 (72.0) Overall height 1,450 (57.1) Front tread 1,601 (63.0)* /1,595 (62.8)* /1,591 (62.6)* Rear tread 1,601 (63.0)* /1,595 (62.8)* /1,591 (62.6)* Wheelbase 2,795 (110.0) : with R16 tire : with R17 tire : with R18 tire ENGINE...

  • Page 471: Gross Vehicle Weight

    Specifications & Consumer information GROSS VEHICLE WEIGHT ITEM Gasoline 2.4L Gasoline 2.0L 1,950 kg (4,299 lbs) Gross vehicle weight 1,980 kg (4,365 lbs) 2,040 kg (4,497 lbs) LUGGAGE VOLUME ltem Gasoline 2.4L Gasoline 2.0L 437l (15.4 cu ft) AIR CONDITIONING SYSTEM Lubricant Volume Classification...

  • Page 472: High Mounted Stop Lamp

    Specifications & Consumer information BULB WATTAGE Light Bulb Wattage Bulb type Headlamps (Low) H11B Headlamps (Low) - HID type* Headlamps (High) H1L/H7L Front turn signal lamps P28/8W Front Front position lamps 8/LED P28/8W/LED Front fog lamps* 35/LED H8L/LED Side Repeater lamps* 5/LED WY5W/LED Side marker...

  • Page 473: Tires And Wheels

    Specifications & Consumer information TIRES AND WHEELS Inflation pressure Tire kPa (psi) Wheel lug nut torque Wheel size Item size kg•m (lb•ft, N•m) Normal load Maximum load Front Rear Front Rear 205/65R16 95H 6.5J×16 235 (34) 235 (34) 235 (34) 235 (34) Full size tire P215/55R17 93V...

  • Page 474: Recommended Lubricants And Capacities

    ACEA A5 or above 2.0 T-GDI 7.8 l (8.24 US qt.) MICHANG ATF SP-IV, SK ATF SP-IV Automatic transaxle fluid NOCA ATF SP-IV, Kia genuine ATF SP-IV 2.4 GDI 7.1 l (7.50 US qt.) 6.5 ~ 6.6 l 2.0 T-GDI (6.87 ~ 6.97 US qt.)
  • Page 475 Specifications & Consumer information Refer to the recommended SAE viscosity numbers on the next page. Engine oils labeled Energy Conserving Oil are now available. Along with other additional benefits, they contribute to fuel econ- omy by reducing the amount of fuel necessary to overcome engine friction. Often, these improvements are difficult to measure in everyday driving, but in a year’s time, they can offer significant cost and energy savings.

  • Page 476: Recommended Sae Viscosity Number

    Specifications & Consumer information Recommended SAE viscosity Engine oil viscosity (thickness) has Using oils of any viscosity other than an effect on fuel economy and cold those recommended could result in number weather operation (engine start and engine damage. Always be sure to clean the area engine oil flowability).

  • Page 477: Vehicle Identification Number (Vin)

    Specifications & Consumer information VEHICLE IDENTIFICATION NUMBER (VIN) VEHICLE CERTIFICATION LABEL VIN label VIN Label (if equipped) OTF080001 The vehicle identification number OTF080002 OVQ076002N (VIN) is the number used in register- vehicle certification label The VIN is also on a plate attached ing your vehicle and in all legal mat- attatched on the driver’s side center to the top of the dashboard.

  • Page 478: Tire Specification And Pressure Label

    Specifications & Consumer information TIRE SPECIFICATION AND ENGINE NUMBER PRESSURE LABEL ■ ■ 2.4 engine OTF080004 ■ ■ 2.0 engine OMG055004 The tires supplied on your new vehi- cle are chosen to provide the best performance for normal driving. The tire label located on the driver's side center pillar gives the tire pres- sures recommended for your vehicle.
  • Page 479 Index...
  • Page 480 Index Manual heating and air conditioning ... 4-124 System operation ......4-130 Automatic transaxle .
  • Page 481 Index Checking the brake fluid level ....7-34 Brake system....... . . 5-20 Anti-lock brake system (ABS).
  • Page 482 Index Checking the coolant level ....7-31 Engine number ....... 8-10 Engine oil .

  • Page 483: Interior Overview

    Index Technical Data ......6-22 Using the Tire Mobility Kit ....6-20 In case of an emergency while driving.
  • Page 484 Index Front fog light ......4-104 Headlight escort function ..... 4-99 Headlight leveling device.

  • Page 485: Seat Warmer (Front)

    Index Seat warmer (rear) ......3-15 Storage compartment ......4-139 Seat warmer (front) .
  • Page 486 Index Tire traction ....... 7-52 Wheel alignment and tire balance ....7-50 Wheel replacement.
  • Page 487 Index Use high quality ethylene glycol coolant..5-56 Wiper blades ....... . . 7-41 Blade inspection .

This manual is also suitable for:

2015 optima2014 optima

Table of Contents

Save PDF
